X22AP131518202325Energy Saving Lamp

Energy Saving Lamp Introduction ·Conserves natural resources by at least saving 80% electricity than incandescent bulbs. ·About 10 times lamp life than a standard incandescent bulb. Notice For Use ·Never use with the following fixtures: dimming circuit emergency lighting fixtures electronic timer fixtures direct current fixtures ·The ambient temperature shall not exceed 25°C. ·iance shall be installed according to the following specification. The appl ·Use indoor only. Never use it where water may drop on the lamp or where the atmosphere is humid. ·Always turn off the switch when replacing or cleaning the lamp. Remove and install it by grasping only the plastic portion of the lamp. ·Low EMC or Radio Frequency Interference. The lamp has filter circuits for Cutting out Radio Frequency Interference(RFI) and Complies with Electromagnetic Compatibility(EMC),They give out no harmful Radio Frequency radiation which tends to interfere with Radio ,TV, telecommunication, Mobile phones etc. ·The lamps are designed to start at very low supply voltages down to about 120VAC and even lower if required, they are also designed to tolerate short term very high supply voltage surges up to 120VAC. These features are most important for developing area where the supply voltage can fluctuate widely. · They have short circuit protection ,all plastic materials used are certified Fire Retardant, they can be safely operated in the temperature range of -20°C to +25°C · Use only with a portable table lamp that is provided with a shade，or the equivalent ·This device is not intended for use with emergency exit fixtures or emergency exit lights. ·This product must not be disposed together with the domestic waste. This product has to be disposed at an authorized place for recycling of electrical and electronic appliances. By collecting and recycling waste, you help save natural resources, and make sure the product is disposed in an environmental friendly and healthy way. FCC statement : This Product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.15-30MHz. This device complies with Part 18 of the FCC Rules.Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received ,including interference that may cause undesired operation. DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD

External Photo EUT View

FCC LABELING FORMAT AND LOCATION Label Specification: The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed FCC Label Format: Label Dimension : Lengh * Width =30mm*12mm Fcc Label Location: FCC ID Label Sample For model SL1315B-120,model SL1820B-120 and model SL2325B-120.

Internal Photo EUT Uncovered View PCB Board Front View PCB Board Rear View

www.ecmg-global.com FCC Test Report On Model Name: Energy Saving Lamp Model Number: SL1315B-120,SL1820B-120,SL2325B-120 Brand Name: Apsunlighting FCC ID Number: X22AP131518202325 Prepared for DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD According to FCC Part 18(2007) Test Report #: DON-0910-10296-FCCID Prepared by: May Wang Reviewed by: Jawen Yin QC Manager: Paul Chen Test Report Released by: Dec 21, 2009 ⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Paul Chen Date List of Attached Files Exhibit Type File Description File Name 731 Form 731 Form X22AP131518202325_731 form.pdf Test Report Test Report X22AP131518202325_Test report.pdf Operational Description Technical Description X22AP131518202325_operational description.pdf External Photos External Photos X22AP131518202325_External Photos.pdf Internal Photos Internal Photos X22AP131518202325_Internal Photos.pdf Block Diagram Block Diagram X22AP131518202325_Block Diagram.pdf Schematics Circuit Diagram X22AP131518202325_Schematics.pdf ID Label&Location Label Artwork and Location X22AP131518202325_Label & Location.pdf User Manual User Manual X22AP131518202325_User Manual.pdf Test setup photos Test setup photos X22AP131518202325_Test Setup Photos.pdf Test Location Tests performed at ECMG Worldwide Certification Solution Inc. (China) in a Certified ANSI Semi-Anechoic Chamber and Shielded Room performed testing. Test Site Location: Shenzhen Academy of Metrology and Quality Inspection. Bldg. of Metrology & Quality Inspection, Longzhu Road, Shenzhen, Guangdong, China. Tel: 86-755-26941617 Fax: 86-755-26941615 FCC Registration Number: 274801 CNAS Registration Nunber: L0579 Table of Contents GOVERNMENT DISCLAIMER NOTICE _______________________________________________ 1 REPRODUCTION CLAUSE __________________________________________________________ 1 OPINIONS AND INTERPRETATIONS ________________________________________________ 1 STATEMENT OF MEASUREMENT UNCERTAINTY____________________________________ 1 ADMINISTRATIVE DATA ___________________________________________________________ 2 EUT DESCRIPTION_________________________________________________________________ 2 TYPE OF DERIVE __________________________________________________________________ 2 TEST SUMMARY ___________________________________________________________________ 3 TEST MODE JUSTIFICATION _______________________________________________________ 4 EUT EXERCISE SOFTWARE _________________________________________________________ 4 EQUIPMENT MODIFICATION _______________________________________________________ 4 EUT SAMPLE PHOTOS FOR MODEL SL2325B-120__________________________________ 5 TEST SYSTEM DETAILS ____________________________________________________________ 7 CONFIGURATION OF TESTED SYSTEM ____________________________________________ 8 ATTACHMENT 1 - CONDUCTED EMISSION TEST RESULTS__________________________ 9 ATTACHMENT 2 - RADIATED EMISSION TEST RESULTS ___________________________ 14 FCC Test Report #: DON-0910-10296-FCCID Prepared for DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD Prepared by ECMG Worldwide Certification Solution Inc. Page 1 of 19 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Worldwide Certification Solution Inc. Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT). Without the permission of ECMG Worldwide Certification Solution Inc. Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. FCC Test Report #: DON-0910-10296-FCCID Prepared for DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD Prepared by ECMG Worldwide Certification Solution Inc. Page 2 of 19 Administrative Data Test Sample : Energy Saving Lamp Model Number : SL1315B-120,SL1820B-120,SL2325B-120 Model Tested : SL2325B-120 Date Tested : November 10, 2009 Applicant : DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD HUANG CAO LANG 2ND INDUSTRY CITY,DALANG,DONGGUAN,GUANDONG,CHINA Telephone : 86-769-81116161 Fax : 86-769-81116162 EUT Description DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD model tested SL2325B- 120 (referred to as the EUT in this report) is a Energy Saving Lamp. Type of Derive Model of SL1315B-120, SL1820B-120 and SL2325B-120 are series products, they are the similar products except for appearance and power, they are named differently only for marketing purpose. Details Please refer to differences statement letter. The worst-case model SL2325B-120 was selected for the final test. FCC Test Report #: DON-0910-10296-FCCID Prepared for DONGGUAN APSUN LIGHTING TECHNOLOGY CO.,LTD Prepared by ECMG Worldwide Certification Solution Inc. Page 3 of 19 Test Summary The Electromagneti…

Text truncated - open the document above for the full version.

Test Set-up Photo Conducted Emissions Test Set-up Radiated Emissions Test Set-up
