X27-NGWCP-1Remote Station

Ondas Networks Inc.
Remote Station - FCC ID X27-NGWCP-1 - Ondas Networks Inc.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Apr 21, 2021
Application Purpose
Original Equipment
Date of Application
Apr 21, 2021
Equipment Note
Remote Station
Frequency Range
896.88750000 - 897.98750000
Company
Ondas Networks Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Ondas Networks Inc. | 165 Gibraltar Court, Sunnyvale, CA 94089 | (888) 350-9994 | ondas.com Airlink WCP User and Installation Guide Document Version 1.2 April 2021 Warning: Never power on a Airlink WCP without a load on the RF connector. Page 2 of 10 April 2021 Table of Contents 1 FCC Compliance .................................................................................................................................... 3 2 FCC Exposure Statement ....................................................................................................................... 3 3 System Overview................................................................................................................................... 4 4 Physical Installation ............................................................................................................................... 5 4.1 Introduction .................................................................................................................................. 5 4.2 Airlink WCP Enclosure ................................................................................................................... 5 4.2.1 Specifications ........................................................................................................................ 5 4.2.2 Product Overview.................................................................................................................. 6 4.2.3 Connection Descriptions ....................................................................................................... 8 4.2.4 Mounting Guidelines ............................................................................................................. 9 5 System Operation ............................................................................................................................... 10 Page 3 of 10 April 2021 1 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Ondas Networks could void the user’s authority to operate the equipment. 2 FCC Exposure Statement This equipment complies with the FCC RF radiation exposure limits set forth for a controlled environment. This transmitter must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must be at least 20 centimeters from the user and must not be co-located or operating in conjunction with any other antenna or transmitter. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Ondas Networks may void the user’s authority to operate the equipment. Page 4 of 10 April 2021 3 System Overview The Airlink WCP platform employs Ondas Networks’ FullMAX technology. The Airlink WCP makes up a wayside communications package, including the radio and associated software/hardware that enables the transmission of ATCS datagrams from the WIU to the BCPs and vice- versa. It will function as per the standards that are defined in S-9553.V1.0 & S-9553A.V1.0 Airlink WCPs will interoperate with the existing Siemens BCP infrastructure. It provides a standard interface to the data network for a wide variety of user devices. Airlink WCP shall be used to perform the following general functions, • Provide the interface between Base Communication Package (BCP) and Wayside device Interface Unit (WIU) • Deliver ATCS messages to and receive messages from BCP via an RF link • Deliver ATCS messages to and receive messages from WIU via the serial ports and a local network interface • Deliver ATCS messages to and receive messages from a Network Management System in the office. Figure 1 System Overview Page 5 of 10 April 2021 4 Physical Installation 4.1 Introduction A Airlink WCP radio is comprised of software and hardware which is packaged in an indoor enclosure intended for mounting in a 19” rack or directly attached to a wall board. 4.2 Airlink WCP Enclosure 4.2.1 Specifications Enclosure Material Aluminum Alloy Dimensions (W x D x H) 9” x 9” x 9” (230mm x 230mm x 255mm) Operating Temperature -40° F to 158° F (-40° C to 70° C) DC Input Power Range 10 to 36 VDC Power Consumption No load : 100 watts @ 24 VDC Peak load : 150 watts @ 24 VDC Page 6 of 10 April 2021 4.2.2 Product Overview Figure 2 ; Airlink WCP Overview Page 7 of 10 April 2021 Figure 3 : Airlink WCP Front Panel Figure 4 : Airlink WCP Top Panel Page 8 of 10 April 2021 4.2.3 Connection Descriptions Connector Application GPS Antenna SMA female connector for optional GPS antenna. RF Out 50Ω N-Type female connector for RF input from antenna DC Input DC power input 10 to 36 volts. Warning: E…

Text truncated - open the document above for the full version.

Cover Letter(s)

QA-FR-170-B 7/29/2014 Ondas Networks Inc. | 165 Gibraltar Court, Sunnyvale, CA 94089 | (888) 350‐9994 | ondas.com Letter of Authorization June 25 th , 2020 Subject: Agent Authorization To whom it may concern: I, Stewart Kantor, the undersigned, hereby authorizes Guy Simpson, Chief Operating Officer in Ondas Networks Inc.to act on my behalf in all matters relating to submission application for Equipment authorization, including the signing of all documents relating to these matters. Please contact in with me if you have any concern. Sincerely Yours, Stewart Kantor Ondas Networks Inc. 165 Gibraltar Court Sunnyvale, CA 94089

Cover Letter(s)

QA-FR-172-A FCC Confidential Authorization 2021-02-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: X27- NGWCP-1 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Ondas Networks Inc. hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • Part List/BOM • Tune up Procedure As well as short-term confidential treatment of information accompanying this application as outlined below: • Internal Photos • User’s Manual • External Photos • Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Guy Simpson - COO (669) 350-0440 [email protected] 165 Gibraltar Court, Sunnyvale, CA, 94089

External Photos

Ondas Networks Inc. FCC ID: X27-NGWCP-1 EUT External Photographs 1.1 EUT – Side View 1.2 EUT – Top View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.3 EUT External Photograph – Main Unit Front View 1.4 EUT External Photograph – Main Unit Rear View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.5 EUT External Photograph – Main Unit Top View 1.6 EUT External Photograph – Main Unit Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.7 EUT External Photograph – Main Unit Left View 1.8 EUT External Photograph – Main Unit Right View

ID Label/Location Info

FCC Label Location (Rear Panel) FCC Label Detail

Internal Photos

Ondas Networks Inc. FCC ID: X27-NGWCP-1 EUT Internal Photographs 1.1 Open EUT Internal- Front View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.2 Open EUT Internal- Rear View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.3 NG-WCP Communications Base Board (CBB)- Top View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.4 NG-WCP Communications Base Board (CBB)- Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.5 NG-WCP Complimentary Radio Module (CRM)- Top View 1.6 NG-WCP Complimentary Radio Module (CRM)- Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.7 NG-WCP Power Amplifier Board (PA900)- Top View 1.8 NG-WCP Power Amplifier Board (PA900)- Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.9 NG-WCP Power Supply Unit(PSU)- Top View 1.10 NG-WCP Power Supply Unit(PSU)- Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.11 NG-WCP Radio Frequency Module(RFM)-Top View 1.12 NG-WCP Radio Frequency Module (RFM)-Bottom View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.13 NG-WCP Display Module(VFD)- Top View 1.14 NG-WCP Display Module(VFD)- Bottom View

RF Exposure Info

Ondas Networks Inc. FCC ID: X27-NGWCP-1 Report Number: R2008317-90 Page 12 of 82 FCC Part 90 Test Report 4 FCC §1.1307(b) (1), §2.1091 &§90.223 - RF Exposure 4.1 Applicable Standards FCC §2.1091, (a) Requirements of this section are a consequence of Commission responsibilities under the National Environmental Policy Act to evaluate the environmental significance of its actions. See subpart I of part 1 of this chapter, in particular §1.1307(b). According to §1.1310 and §2.1091 RF exposure is calculated. Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *(100) ≤6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1,500 f/300 <6 1,500-100,000 5 <6 Note: f = frequency in MHz * = Plane-wave equivalent power density 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ondas Networks Inc. FCC ID: X27-NGWCP-1 Report Number: R2008317-90 Page 13 of 82 FCC Part 90 Test Report 4.3 Test Results Maximum average output power at antenna input terminal (dBm): 42.31 Maximum average output power at antenna input terminal (mW): 17021.585 Prediction frequency (MHz): 897.9875 Antenna Gain, maximum (dBi): -0.56 Maximum Antenna Gain (numeric): 0.88 Prediction distance (cm): 20 Power density of prediction frequency at 20 cm (mW/cm 2 ): 2.99 FCC MPE limit for controlled exposure at prediction frequency (mW/cm 2 ): 2.99 The average output power was derived from the maximum tune up power (45.32 dBm) and duty cycle (50%). The average output power = peak output power – 10*log(1/duty cycle)=45.32-3.01=42.31 dBm.. Note: Duty Cycle declared by customer Results In order to pass the controlled exposure limit of 2.99 mW/cm 2 with the Output Power being 45.10 dBm, 50% duty cycle, and prediction distance of 20cm, the EUT can have a maximum antenna gain of -0.56 dBi.

Test Report

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.3) FCC PART 90 TEST REPORT For Ondas Networks Inc. 165 Gibraltar Court, Sunnyvale, CA 94089, USA FCC ID: X27-NGWCP-1 R e p o r t T y p e : O r i gi n a l R e p o r t P r o d u c t T y p e: R e mo t e S t a t i o n Prepared By: Christian McCaig Test Engineer Report Number: R2008317-90 Report Date: 2021-03-29 Reviewed By: Simon Ma RF Supervisor Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: +1 (408) 732-9162, Fax: +1 (408) 732-9164 Ondas Networks Inc. FCC ID: X27-NGWCP-1 Report Number: R2008317-90 Page 2 of 83 FCC Part 90 Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION ............................................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................... 5 1.2 MECHANICAL DESCRIPTION............................................................................................................................... 5 1.3 OBJECTIVE ......................................................................................................................................................... 5 1.4 RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 5 1.5 TEST METHODOLOGY ........................................................................................................................................ 5 1.6 MEASUREMENT UNCERTAINTY .......................................................................................................................... 6 1.7 TEST FACILITY REGISTRATIONS ........................................................................................................................ 6 1.8 TEST FACILITY ACCREDITATIONS ...................................................................................................................... 7 2 SYSTEM TEST CONFIGURATION .................................................................................................................. 9 2.1 JUSTIFICATION ................................................................................................................................................... 9 2.2 EUT EXERCISE SOFTWARE ................................................................................................................................ 9 2.3 EQUIPMENT MODIFICATIONS ............................................................................................................................. 9 2.4 REMOTE SUPPORT EQUIPMENT LIST AND DETAILS ............................................................................................ 9 2.5 POWER SUPPLY AND LINE FILTERS .................................................................................................................... 9 2.6 INTERFACE PORTS AND CABLING .................................................................................................................... 10 3 SUMMARY OF TEST RESULTS ...................................................................................................................... 11 4 FCC §1.1307(B) (1), §2.1091 &§90.223 - RF EXPOSURE ............................................................................... 12 4.1 APPLICABLE STANDARDS ................................................................................................................................ 12 4.2 MPE PREDICTION ............................................................................................................................................ 12 4.3 TEST RESULTS ................................................................................................................................................. 13 5 FCC §2.1046, §90.205(K) & §90.635(B) - RF OUTPUT POWER ................................................................... 14 5.1 APPLICABLE STANDARDS ................................................................................................................................ 14 5.2 TEST PROCEDURE ............................................................................................................................................ 14 5.3 TEST EQUIPMENT LIST AND DETAILS .............................................................................................................. 14 5.4 TEST ENVIRONMENTAL CONDITIONS ............................................................................................................... 14 5.5 TEST RESULTS ................................................................................................................................................. 15 6 FCC §2.1049 & §90.209 - OCCUPIED BANDWIDTH .................................................................................... 27 6.1 APPLICABLE STANDARDS ................................................................................................................................ 27 6.2 TEST PROCEDURE ............................................................................................................................................ 27 6.3 TEST EQUIPMENT LIST AND DETAILS .............................................................................................................. 27 6.4 TEST ENVIRONMENTAL CONDITIONS ............................................................................................................... 27 6.5 TEST RESULTS ...…

Text truncated - open the document above for the full version.

Test Setup Photos

Ondas Networks Inc. FCC ID: X27-NGWCP-1 Test Setup Photographs 1.1 Radiated Spurious Emissions Test: Below 1 GHz – Front View 1.2 Radiated Spurious Emissions Test: Below 1 GHz – Rear View Ondas Networks Inc. FCC ID: X27-NGWCP-1 1.3 Radiated Spurious Emissions Test: Above 1 GHz – Front View 1.4 Radiated Spurious Emissions Test: Above 1 GHz – Rear View

Contact Information

Applicant

Stewart Kantor(President)
[email protected]650-743-8945Fax: 650-743-8945

Test Firm

Bay Area Compliance Laboratories Corp.Lisa Tang
[email protected]408-732-9162Fax: 408 732 9164

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
49896.8875 MHz - 897.9875 MHz24 W9K95D7E1.5 ppm
Confidentiality
Long Term
Grant Notes
Power is listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
