Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 37 of 52 Appendix J: Manual Please refer to the following pages. BAT TM (Blackbird Asset Tracker) User Guide Prepared By: Blackbird Technologies, Inc. 13900 Lincoln Park Drive Suite 400 Herndon, VA 20171 June 2010 1 Firmware Version 6 This product uses satellite and terrestrial technologies that are inherently subject to transmission and reception limitations, and will operate intermittently under certain environmental conditions. Extreme weather or objects that prevent an unobstructed view of the sky may restrict reception or transmission of messages as well as acquisition of your global positioning system (GPS) coordinates. In addition, service may become limited or temporarily unavailable due to equipment failures or outages by the service providers. Accordingly, Blackbird cannot guarantee that the product will operate without interruption. The BAT device integrates with Blackbird Technologies’ Gotham system. The Gotham system is a comprehensive back-end solution for monitoring, operating, and managing tagging, tracking, and locating (TTL) devices and viewing associated geospatial data. For information about Blackbird’s other TTL products and services, and for technical support, contact the Blackbird Help Desk through the following email address: [email protected] Copyright 2010, Blackbird Technologies, Inc. All Rights Reserved Rev B 2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help This device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1999 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2003, OET Bulletin 65 Supp. C and Safety Code 6. Changes or modifications not expressly approved by Blackbird could void the user's authority to operate the equipment. Copyright 2010, Blackbird Technologies, Inc. All Rights Reserved 3 BAT DIAGRAM BASIC USAGE Device Description—BAT is a small, global positioning system (GPS)-enabled, satellite transmitter capable of sending its position as well as emergency beacons and brevity messages. Batteries —BAT requires two AA lithium batteries (1.5V only). To replace the batteries, follow the steps below. 1. Rotate the ¼-turn screw counterclockwise. 2. Remove the battery door. 3. Insert batteries in direction of diagram located in battery casing. 4. Replace door. 5. Rotate the ¼-turn screw clockwise until it clicks. Power On —To power on BAT, press and hold Power until a short vibration occurs. Power Off —To power off BAT, press and hold Power until the GPS LED extinguishes and two short vibrations occur. NOTE: When Emergency Mode is activated, the BAT must be unlocked before Power Off is functional. 4 LED Indicators —BAT is equipped with two LED indicators. The left LED indicates GPS status (RED or GREEN), and the right LED indicates transmission (TX) status (BLUE). LED Action LED Status GPS Acquiring GPS Rapid triple RED flash every 2 seconds GPS GPS acquired with Error ≥ 50M Double GREEN flash every 2 seconds GPS GPS acquired with Error < 50M Single GREEN flash every 2 seconds TX Preparing to transmit Flashing BLUE TX Transmission in progress Solid BLUE TX Satellite transmit failure detected Constant rapid BLUE flashing BOTH Emergency Mode started via A&D or Emergency button Flash in unison for 4 seconds BOTH Emergency beacon in progress Solid on BOTH Hardware failure Continuously flash in unison immediately following power on Transmission Status Vibration Indicators —BAT is equipped with a vibration motor, which indicates power on, power off, and transmission sent. A single vibration indicates power on and transmission sent, while a double vibration indicates power off. LED Settings —BAT is equipped with three LED settings: Visible, Infrared, and Off. The default mode is Visible. The user can toggle through the modes by pressing the LED button located above the GPS and TX LEDs. When BAT is in Infrared LED setting, the LED flashes are displayed in white and can only be viewed using infrared goggles or through some digital camera lenses. NOTE: The Infrared and Off LED settings are only available in Normal Mode. NOTE: The selected LED setting persists through power cycles. 5 Brevity Messages —A brevity message is activated by pressing and releasing buttons A through D or any 2-, 3-, or 4-button combinations. Each brevity message can be assigned a spec…
Text truncated - open the document above for the full version.
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 29 of 52 Appendix B: Agency Authorization Please refer to the following page.
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 30 of 52 Appendix C: FCC Confidentiality Request Letter Please refer to the following page.
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 40 of 52 Appendix L: External Photographs Photograph 5: Front Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 41 of 52 Photograph 6: Back, with Battery Cover Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 42 of 52 Photograph 7: Back, without Battery Cover Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 43 of 52 Photograph 8: Bottom, Showing Lanyard Holder Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 44 of 52 Photograph 9: Top, with LED Color Select Button Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 45 of 52 Photograph 10: Right Side, Showing 911 Button Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 46 of 52 Photograph 11: Left Side, Showing A-D Brevity Buttons and Power Button
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 31 of 52 Appendix D: ID Label Photograph 1: ID Label Sample Photograph 2: ID Label Location FCC ID: X6K-BAT-001
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 47 of 52 Appendix M: Internal Photographs Photograph 12: PCB Side 1 Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 48 of 52 Photograph 13: PCB Side 1 with GPS Antenna and Connector for WS-9161 Globalstar Antenna Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 49 of 52 Photograph 14: PCB Side 2 Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 50 of 52 Photograph 15: PCB Side 2 with GPS Antenna and Connector for WS-9161 Globalstar Antenna Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 51 of 52 Photograph 16: PCB Seated in Front Half of Clamshell Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 52 of 52 Photograph 17: PCB Seated in Back Half of Clamshell
© 2010 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 2867 Progress Place, Suite 4D • Escondido, CA 92029 • U.S.A. TEL (760) 737-3131 • FAX (760) 737-9131 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Blackbird Technologies, Inc. Dates of Test: March 22, 2010 13900 Lincoln Park Drive, Suite 400 Test Report Number: SAR.20100313 Herndon, VA 20171 Revision A This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1999 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, OET Bulletin 65 Supp. C, RSS-102 and Safety Code 6 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 FCC ID: X6K-BAT-001 Model(s): BAT Rev H Test Sample: Engineering Unit Same as Production Serial No.: 359446 Equipment Type: Location Transceiver Classification: Portable Transmitter Next to Body TX Frequency Range: 1611.25 MHz; 1616.25 MHz Frequency Tolerance: ± 25 ppm Maximum RF Output: 1611 MHz – 19.23 dBm; 1616 MHz – 18.93 dBm Conducted Signal Modulation: BPSK Antenna Type: Internal; PCTEL P/N WS-9161 Battery: Standard AA Lithium Battery Application Type: Certification FCC Rule Parts: Part 25 FCC ID: X6K-BAT-001 © 2010 RF Exposure Lab, LLC Page 2 of 78 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ...........................................................................................................................3 SAR Definition [5]......................................................................................................................3 2. SAR Measurement Setup .....................................................................................................4 Robotic System .........................................................................................................................4 System Hardware .....................................................................................................................4 System Description ...................................................................................................................4 E-Field Probe ............................................................................................................................5 3. Robot Specifications .............................................................................................................7 4. Probe and Dipole Calibration ................................................................................................8 5. Phantom & Simulating Tissue Specifications........................................................................9 SAM Phantom ...........................................................................................................................9 Brain & Muscle Simulating Mixture Characterization ................................................................9 Device Holder ...........................................................................................................................9 6. Definition of Reference Points.............................................................................................10 Ear Reference Point................................................................................................................10 Device Reference Points ........................................................................................................10 7. Test Configuration Positions ...............................................................................................11 Positioning for Cheek/Touch [5] ..............................................................................................11 Positioning for Ear / 15 ̊ Tilt [5] ................................................................................................12 Body Worn Configurations ......................................................................................................13 8. ANSI/IEEE C95.1 – 1999 RF Exposure Limits [2]...............................................................14 Uncontrolled Environment.......................................................................................................14 Controlled Environment .......................................................................................................... 14 9. Measurement Uncertainty ...................................................................................................15 10. System Validation ........................................................................................................... 16 Tissue Verification...................................................................................................................16 Test System Verification .........................................................................................................16 11. SAR Test Data Summary ................................................................................................17 Procedures Used To Establish Test Signal.............................................................................17 Device Test Condition .............................................................................................................17 SAR Data S…
Text truncated - open the document above for the full version.
Engineering and Testing for EMC and Safety Compliance Accredited under A2LA Testing Certificate # 2653.01 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Tel: 703-689-0368 Fax: 703-689-2056 FCC Part 25 Certification Report Blackbird Technologies, Inc. 13900 Lincoln Park Drive, Suite 400 Herndon, VA 20171 Contact: Bob Nelson MODEL: Blackbird Asset Tracker (BAT) Revision H FCC ID: X6K-BAT-001 March 12, 2010 Standards Referenced for this Report Part 2: 2009 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations Part 25: 2009 Satellite Communications TIA-EIA-603-C August 2004 Land Mobile FM or PM Communications Equipment – Measurement and Performance Standards Digital Interface Information: Digital Interface was found to be compliant Frequency Range (MHz) Rated Transmit Power (W) (Conducted) Frequency Tolerance (ppm) Emission Designator 1611.25 - 1618.75 0.100 0.7 2M50G1D Report Prepared By: Daniel Baltzell Document Number: 2010008 This report may not be reproduced, except in full, without the full written approval of Rhein Tech Laboratories, Inc. and Blackbird Technologies, Inc.. Test results relate only to the item tested. Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 2 of 52 Table of Contents 1 General Information ...................................................................................................................................... 5 1.1 Scope ...................................................................................................................................................... 5 1.2 Description of EUT .................................................................................................................................. 5 1.3 Test Facility ............................................................................................................................................. 5 1.4 Related Submittal(s)/Grant(s) ................................................................................................................. 5 1.5 Modifications ........................................................................................................................................... 5 2 Test Result Summary ................................................................................................................................... 6 3 Tested System Details .................................................................................................................................. 7 4 FCC Rules and Regulations §2.1046(a): RF Power Output: Conducted; §25.204: Transmitter Power ... 9 4.1 Test Procedure ........................................................................................................................................ 9 4.2 Test Data ................................................................................................................................................. 9 5 FCC Rules and Regulations §2.1051: Spurious Emissions at Antenna Terminals; §25.202(f) Emission Limitations .......................................................................................................................................................... 10 5.1 Test Procedure ...................................................................................................................................... 10 5.2 Test Data ............................................................................................................................................... 10 6 FCC Rules and Regulations §2.1053(a): Field Strength of Spurious Radiation; §25.202(f) Emission Limitations .......................................................................................................................................................... 14 6.1 Test Procedure ...................................................................................................................................... 14 6.2 Test Data ............................................................................................................................................... 14 7 FCC Rules and Regulations §2.1049(c)(1): Occupied Bandwidth; §25.202(f) Emission Limitations ........ 16 7.1 Test Procedure ...................................................................................................................................... 16 7.2 Test Data ............................................................................................................................................... 16 8 FCC Rules and Regulation §2.1055: Frequency Stability; §25.202(d)): Frequency Stability................... 20 8.1 Test Procedure ...................................................................................................................................... 20 8.2 Test Data ............................................................................................................................................... 20 8.2.1 Frequency Stability/Voltage Variation .......................................................................................... 21 9 FCC Part 2.1047: Modulation Characteristics ........................................................................................... 21 10 FCC Rules and Regulation §25.216 - Emissions from Mobile Earth Stations for Protection of Aeronautical Radionavigation-Satellite Service ................................................................................................. 22 10.1 Test Data ............................................................................................................................................... 22 11 Conclusion .................................................................................................................................................. 27 Rhein Tech Laborator…
Text truncated - open the document above for the full version.
Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 38 of 52 Appendix K: Test Configuration Photographs Photograph 3: Radiated Emissions – Front View MOUSE MOUSE Rhein Tech Laboratories, Inc. Client: Blackbird Technologies, Inc. 360 Herndon Parkway Model: Blackbird Asset Tracker Suite 1400 FCC ID: X6K-BAT-001 Herndon, VA 20170 Standards: FCC Part 25 http://www.rheintech.com Report #: 2010008 39 of 52 Photograph 4: Radiated Emissions – Back View
360 Herndon Parkway Suit 1400 · Herndon · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 25 | 1.61 GHz - 1.62 GHz | 83.00 mW | 2M50G1D | 0.7000000000 ppm |

GPS tracker that uses satellite communications and GSM transmitters
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
