X6W-3N16MWIFI LOGGER CARD

Quick installation guide VSN300 WIFI LOGGER CARD ABB Solar inverters 1. Product Identification - Labels ans Symbols 3. Operating diagram 5. Assembly Instructions Main components 2. List of supplied components 4. EN Preliminary operation The inside of the inverter may only be accessed after the equipment has been disconnected from the grid and from the photovoltaic generator. -Turn off the inverter by physically disconnecting the AC and DC voltages, as well as any voltage connected to the multi-function relay. 10 Wait the time need to discharge stored energy on the inverter and use safety clothing and/or personal safety devices -Open the inverter front cover. Antenna installation The antenna must be installed outside the inverter in place of a service cable gland (size M20) -Remove one of the M20 service cable gland of the inverter (using a 25mm wrench) and preserve the plastic lock nut. -Pass the antenna connection cable into the inverter by passing it through the M20 cable gland opening, the gasket, the plastic lock nut and the adaptor (If used). -Affix the antenna bulk head connector to the inverter using the plastic lock nut previosly removed (tightening torque 5Nm). In some inverter models it is necessary to use the adaptor kit (see annex A) due to the greater thickness of the inverter enclosure. In this case, proceed as follows: -Install the gasket on the adaptor -Affix the adaptor to the inverter using the plastic lock nut of the adaptor kit (tightening torque 5Nm). -Pass the antenna connection cable into the inverter by passing it through the M20 cable gland opening, the adaptor, the gasket and the nut. -Affix the antenna bulk head connector to the adaptor (tightening torque 5Nm). -Screw the antenna on the support Use only antenna type RF Technology Corp. Model EA-79 F RP SMA, or a similar type having equal or lesser gain WIFI card installation -Take the antenna cable and connect this to the coaxial counterpart present on the WIFI card. During this step, pay special attention that the terminal of the antenna cable is correctly aligned with the counterpart. Do not make pressure on the terminal if it is crooked. J1 U8 U3 U11 U7 J2 1 2 23 24 J1 U8 U3 U11 U7 J2 1 2 23 24 -Install the card by fitting the connection terminals in the dedicated connector located on the inverter board. The connection on the inverter board can be compo- sed by one or two different connectors (see the table on the “Annex A” paragraph) depending of the inverter model. During this step, check that all the terminals are correctly aligned. Any terminal misalignment may result in damage to the WIFI board and/or to the inverter. J1 U8 U3 U11 U7 J2 1 2 23 24 J1 U8 U3 U11 U7 J2 1 2 23 24 J1 U8 U3 U11 U7 J2 1 2 23 24 J1 U8 U3 U11 U7 J2 1 2 23 24 Installation with double connectorInstallation with single connector The main components of the VSN 300 WIFI LOGGER CARD are shown in the figure and described in the following table: Main components A Antenna connection cable B Antenna (RF Technology Corp. Model EA-79 F RP SMA) C Connection terminals D Power LED E Status LED 2 F Status LED 1 G Coaxial connector H Mechanical mounting bracket The printed wiring board of the VSN300 WIFI LOGGER CARD will be marked with the following information, identifying the product: -Manufacturer Mark/Trade Mark -CE (European Union) Marking -RCM (Australia) Marking -FCC ID The FCC ID is FCC ID: X6W-3N16E when the WIFI LOGGER CARD is assembled with WiFi radio module supplied by Epcos The FCC ID is FCC ID: X6W-3N16M when the WIFI LOGGER CARD is assembled with WiFi radio module supplied by Murata A dedicated label including the FCC ID must be placed in a visible position on the exterior of the Inverter host equipment ContainsFCC ID: X6W -3N16E ContainsFCC ID: X6W -3N16M FCC (Federal Communications Commission) WARNING 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation 2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are desig- ned to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. 3. RF Exposure. This device complies with Part 2.1091 of the FCC Rules for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the antenna and the user. Refer to the specific section describing procedures how to integrate and use this device into the host fixed mount inverter. Changes or modifications made to this equipment not expressly approved by the Manufacturer may void the FCC authorization to operate this equipment. The identification label contained on the WIFI LOGGER CARD box have the information of the device and manufacturer. In the manual and/or in some cases on the equipment, the danger or hazard zones are indicated with signs, labels, symbols or icons. Symbols and icons Always refer to instruction manual General warning - Importan…

Text truncated - open the document above for the full version.

__________________________________________ Power–One Italy, S.p.A. ____________________________________________ 52028 Terranuova Bracciolini (AR) – Via S.Giorgio, 642 – Tel. +39 055.9195.1 – Fax +39 055.9195.248 – Fax +39 055.9195.263 purch.dept.) Capitale Sociale € 22.000.000 int. vers. – C.C.I.A.A. Arezzo n. 101220 – Reg. Imp. E Cod. Fisc. 09286180154 – Partita I.V.A. 01574720510 Società soggetta alla direzione e controllo della Power-One Inc. ref. Installation Ownership - WIFI LOGGER CARD (Murata) DECLARATION We, Power-One Italy S.p.A., hereby declare that the module named WIFI LOGGER CARD with FCC ID: X6W-3N16M is only to be fitted into host devices manufactured by Power-One Italy S.p.A. We also declare that a Power-One approved engineer will be installing the module within the host device and that Power-One Italy S.p.A. will maintain overall responsibility for the host product’s FCC compliance once the module is installed within the host. Terranuova B.ni, 28 April 2014 Power-One Italy S.p.A. Via San Giorgio, 642 52028 Terranuova Bracciolini (AR) Italy Mr. Gianfranco Iannuzzi Test houses liaison Engineer

_________________________________________________ Power–One Italy, S.p.A. __________________________________________________ 52028 Terranuova Bracciolini (AR) – Via S.Giorgio, 642 – Tel. +39 055.9195.1 – Fax +39 055.9195.248 – Fax +39 055.9195.263 (purch. dept.) Capitale Sociale € 22.000.000 int. vers. – C.C.I.A.A. Arezzo n. 101220 – Reg. Imp. E Cod. Fisc. 09286180154 – Partita I.V.A. 01574720510 Società soggetta alla direzione e controllo della Power-One Inc. ref. WIFI LOGGER CARD - Agency Letter Telecommunication Certification Body UL VS Ltd Pavilion A AshwoodPark Ashwood Way Basingstoke Hampshire RG23 8BG United Kingdom Terranuova Bracciolini, 2014 April 03 Subject: Agency Letter To whom it may concern This is to certify that Power-One Italy S.p.A. authorises UL VS Ltd.to act on our behalf for the application of the model WIFI LOGGER CARD identified with FCC ID: X6W-3N16M to UL VS Ltd. Telecommunication Certification Body. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours faithfully, _______________________________ Gianfranco Iannuzzi Test Houses Liaison Engineer Power-One Italy S.p.A.

_________________________________________________ Power–One Italy, S.p.A. __________________________________________________ 52028 Terranuova Bracciolini (AR) – Via S.Giorgio, 642 – Tel. +39 055.9195.1 – Fax +39 055.9195.248 – Fax +39 055.9195.263 (purch. dept.) Capitale Sociale € 22.000.000 int. vers. – C.C.I.A.A. Arezzo n. 101220 – Reg. Imp. E Cod. Fisc. 09286180154 – Partita I.V.A. 01574720510 Società soggetta alla direzione e controllo della Power-One Inc. ref. WIFI LOGGER CARD - Confidentiality Request Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Terranuova Bracciolini, 2013 December 09 Gentlemen, This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Power-One Italy S.p.A. would like the following documents regarding this submission for FCC ID: X6W-3N16M to be kept confidential. Documents: Block diagram Operational description Schematic diagrams Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, for Power-One Italy S.p.A. ________________________________ Gianfranco Iannuzzi Test Houses Liaison Engineer

__________________________________________ Power–One Italy, S.p.A. ____________________________________________ 52028 Terranuova Bracciolini (AR) – Via S.Giorgio, 642 – Tel. +39 055.9195.1 – Fax +39 055.9195.248 – Fax +39 055.9195.263 purch.dept.) Capitale Sociale € 22.000.000 int. vers. – C.C.I.A.A. Arezzo n. 101220 – Reg. Imp. E Cod. Fisc. 09286180154 – Partita I.V.A. 01574720510 Società soggetta alla direzione e controllo della Power-One Inc. ref. Limited Modular Approval Request Letter - WIFI LOGGER CARD (Murata) Limited Modular Approval Request Letter Subject: Limited Modular Approval Date: 2014-04-17 FCC ID: X6W-3N16M We, Power-One Italy S.p.A hereby authorize UL Verification Services Ltd to have our model: WIFI LOGGER CARD, identified with FCC ID: X6W-3N16M, approved under limited modular approval. The application of this module is specified to host equipment. As required by FCC rule part §15.212, limited modular compliance is detailed below: Requirement Compliance: Yes or No with justification (i). The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly. No The RF section of the module does not have any RF shielding. RF shielding is provided by the host product (Note 1) . (ii). The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal. Yes Buffered data input stage has been integrated in the microprocessor of the main board. (iii). The module must contain power supply regulation on the module. Yes The data logger has on-board power supply regulation and is therefore not reliant on any PSU regulation from the host equipment. (iv). The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). Yes The test report details the antenna that meets the requirements for a unique antenna connector. (v). The module must demonstrate compliance in a stand-alone configuration. Yes Refer to the test set-up photos exhibit. . / . __________________________________________ Power–One Italy, S.p.A. ____________________________________________ 52028 Terranuova Bracciolini (AR) – Via S.Giorgio, 642 – Tel. +39 055.9195.1 – Fax +39 055.9195.248 – Fax +39 055.9195.263 purch.dept.) Capitale Sociale € 22.000.000 int. vers. – C.C.I.A.A. Arezzo n. 101220 – Reg. Imp. E Cod. Fisc. 09286180154 – Partita I.V.A. 01574720510 Società soggetta alla direzione e controllo della Power-One Inc. - 2 – (vi). The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements). Yes Refer to the label exhibit and the installation instructions exhibit. (vii). The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee. Yes Refer to the installation instructions exhibit. The module must comply with RF exposure requirements. Yes Refer to the RF exposure exhibit. Note 1: The module will only ever be installed in Power-One host devices by Power-One approved engineers or by trained professional installers. Power-One shall maintain compliance with the FCC rules parts once installed in the host device. This will be demonstrated via separate test reports based upon FCC verification procedure. Company name: Power-One Italy S.p.A. Company Address: Via San Giorgio 642 – 52028 Terranuova Bracciolini (AR) – Italy Signature: Name: Mr. Gianfranco Iannuzzi Job Title: Test Houses Liaison Engineer

21 May 2014 FCC ID: X6W-3N16M Exhibit Update This is to confirm the Modular Approval Request Letter and DTS test report FCCTR_131691-3 were superseded on 21 May 2014. The Modular Approval Request Letter update added a comment for installation by trained professional installers. The updated FCCTR_131691-4 report was to correct a duplication of test data. The recorded test results and product compliance are unchanged. TCB UL VS Ltd

FCC ID: X6W-3N16M WIFI DATA LOGGER Top View Antenna Connector Port FCC ID: X6W-3N16M WIFI DATA LOGGER Bottom View

MP1 Pb ‐ free 3N16 FCC ID:X6W ‐ 3N16M 1 2

FCC ID: X6W-3N16M WIFI DATA LOGGER Top View Antenna Connector Port FCC ID: X6W-3N16M WIFI DATA LOGGER Bottom View

PRIMARICERCA & SVILUPPO S.r.l. Sede operativa e Laboratori di prova / Headquarter and Testing lab: Via Campagna, 92 – I-22020 FALOPPIO (CO) Tel. +39 031 3500011 – Fax +39 031 991309 – [email protected] – www.primaricerca.it RAPPORTO DI PROVA / TEST REPORT Rif./Ref.No. MPETR_131691-5 Data / Date:08/04/2014 Pagine / Pages : 8 Scopo delle prove /Test object : Prove di tipo in accordo a / Type test acccording to FCC Cfr 47 part 2 - §2.1091, part 1 - §1.1310 Richiedente / Applicant : POWER-ONE ITALY SPA Via San Giorgio 642 – 52028 Terranuova Bracciolini – AR – Italy Tel. +39 055 9195 Persona di riferimento / Applicant’s referee : Sig. Gianfranco Iannuzzi ([email protected]) Marchio commerciale / Trade mark : Fabbricante / Manufacturer : POWER-ONE ITALY SPA Prodotto / Product : WIFI LOGGER CARD for inverter Modello / Model : WIFI LOGGER CARD identified by the FCC id: X6W-3N16M Data ricevimento campioni / Date of test samples receipt: 25/11/2013 Campioni verificati / No. of tested samples 1 Data verifiche / Testing date : 28-29/11/2013 Sito di prova / Testing site : Prima Ricerca & Sviluppo Via Campagna - 92 I-22020 FALOPPIO (CO) Esito delle valutazioni / Assessment results : CONFORME / COMPLIANT Verifiche effettuate da / Verifications carried out by : Andrea Bortolotti Tecnico di laboratorio / Test Engineer Approvato / Approved by : Giacomo ARMELLINI Responsabile Laboratorio EMC e RADIO/ EMC and RADIO Laboratory Manager Rapporto di prova / Test report n.MPETR_131691-5. Data / Date 08/04/2014 Pagina / Page2 of 8 CONTENUTO / TABLE OF CONTENTS 0 RELEASE CONTROL RECORD .............................................................................................................. 2 1 TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) .................................................... 3 EUT Identification ............................................................................................................ 3 Technical data ................................................................................................................. 3 1.1 Technical information .............................................................................................. 4 1.2 EUT ports identification ........................................................................................... 5 1.3 EUT modification ..................................................................................................... 5 1.4 Auxiliary equipment ................................................................................................. 5 2 REFERENCE STANDARDS .................................................................................................................... 6 3 MEASUREMENTS AND CALCULATION RESULTS ............................................................................... 6 3.1 Calculation Method ................................................................................................. 6 3.2 Limits ....................................................................................................................... 7 3.3 Measurements and Calculation Results .................................................................. 8 0 RELEASE CONTROL RECORD TEST REPORT NUMBER REASON OF CHANGE DATE OF ISSUE MPETR_131691-0 Original Release 27/01/2014 MPETR_131691-1 Added FCC ID 29/01/2014 MPETR_131691-2 Typing error correction 20/02/2014 MPETR_131691-3 Added comments and new calculation results 19/03/2014 MPETR_131691-4 Typographical error correction 28/03/2014 MPETR_131691-5 Editorial change and deleting photographic documentation 08/04/2014 Rapporto di prova / Test report n.MPETR_131691-5. Data / Date 08/04/2014 Pagina / Page3 of 8 1 TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) EUT Identification Brand name: Manufacturer: Power-One Italy S.p.A. Type of Equipment : WIFI LOGGER CARD for inverter Model name or number : WIFI LOGGER CARD identified by the FCC id: X6W-3N16M Serial number : 200034 VCA.V1E02.0 002 FCC ID : X6W-3N16M Country of manufacturer: Italy Technical data FCC class: 47 CFR FCC Part 15 Subpart C § 15.247 Product type: Radio Equipment Radio type: Intentional radiators Product description / application The application is radio module for photovoltaic inverter Power supply requirements : 12Vdc powered by inverter board Frequency range : 2400-2483,5MHz Std 802.11: IEEE Std 802.11b, 802.11g and 802.11n Modulation Type: CCK DQPSK DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM Modulation Technology DSSS for 802.11b OFDM for 802.11g/n Transfer Rate 802.11b: 11 / 5.5 / 2 / 1 Mbps 802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6 Mbps 802.11n: 65 / 58.5 / 52 / 39 / 26 / 19.5 / 13 / 6.5 Mbps RF Output Impedance : 50 Ohms Channel bandwidth: 20MHz Channel spacing: 5MHz Antenna Connector /Types : RSMA connector Rapporto di prova / Test report n.MPETR_131691-5. Data / Date 08/04/2014 Pagina / Page4 of 8 1.1 Technical information MODULE MANUFACTURER: MURATA MODULE TYPE: Series/Type R078 (WL1801) / D7021 TYPE OF ANTENNA: Integral ; External ; Dedicated ANTENNA GAIN: Max. 3.32dBi (worst case) Rapporto di prova / Test report n.MPETR_131691-5. Data / Date 08/04/2014 Pagina / Page5 of 8 1.2 EUT ports identification This section contains descriptions of all ports, the length and the type of the cable provided by manufacturer needed for the tests. Moreover it is specified if the ports are ever or optionally connected. Port Description Connection 1 Enclosure Not present (electronic PCB board only) Plug-in electronic board 2 AC Power Supply Not present (electronic PCB board only) ----- 3 DC power supply 12Vdc Plug-in electronic board 4 Signal lines Signal line Plug-in electronic board 5 Telecomm. Lines Not present (electronic PCB board only) ----- 6 Antenna RSMA connector Connector Note: During the tests all cables must be what provided the manufacturer or the same that used in the real employment of the EUT. 1.3 EUT modification  None 1.4 Auxiliary equipment  None Rapport…
