X7RKRC118102-AF14CDMA 1900 RF Repeater

Rev PA1 CDMA1900 Dual Band Selective Repeater 0.5W User Manual Rev PA1 CDMA1900 Dual Band Selective Repeater 0.5W User Manual © Ericsson AB 2009 All rights reserved. The information in this document is the property of Ericsson. Except as specifically authorized in writing by Ericsson, the receiver of this document shall keep the information contained herein confidential and shall protect the same in whole or in part from disclosure and dissemination to third parties. Disclosure and disseminations to the receiver's employees shall only be made on a strict need to know basis. The information in this document is subject to change without notice and Ericsson assumes no responsibility for factual inaccuracies or typographical errors. Contents 1 Preface...................................................................................................... 1 2 System Summary .................................................................................... 2 2.1 Overview.................................................................................................... 2 2.2 Brief Introduction ....................................................................................... 2 2.3 Basic Working Principle............................................................................. 2 2.4 Product Features ....................................................................................... 3 2.5 Case Variants ............................................................................................ 3 2.6 Interface..................................................................................................... 4 3 System Structure..................................................................................... 5 3.1 System Constitution................................................................................... 5 3.2 DL/UL LNA ................................................................................................ 5 3.3 DL/UL Band Selective Unit ........................................................................ 5 3.4 DL/UL PA................................................................................................... 5 3.5 Coupler for Modem.................................................................................... 5 3.6 Modem....................................................................................................... 5 3.7 Control Unit................................................................................................ 6 3.8 Duplexer .................................................................................................... 6 3.9 Power Supply ............................................................................................ 6 4 Instruction for antenna selection ........................................................... 7 4.1 Applicable MPE Limits............................................................................... 8 4.2 FCC Formulas and Calculations................................................................ 8 4.3 Selection for Service Antennas ................................................................. 9 5 System Commissioning........................................................................ 11 5.1 Testing Tools and Instruments ................................................................ 11 5.2 VSWR Test of Antenna and Feeder System ........................................... 11 5.3 Voltage Test of Power Supply System .................................................... 11 5.4 Parameter Test........................................................................................ 11 5.5 Remote Control Test ............................................................................... 12 CDMA1900 Dual Band Selective Repeater 0.5W Rev PA1 2010-1-12 © Ericsson AB 20089 Public 1 (10) 1 Preface Manual Instruction CDMA1900 Dual Band Selective Repeater 0.5W is an important part of the CDMA network system. It mainly receives processes and amplifies RF signal to extend the BTS coverage area. This manual introduces the working principle, function, structure and commissioning of the Dual Band Selective Repeater. Content Introduction This user manual mainly introduces four chapters including working principle, function, structure, commission. Chapter 2: System brief introduction mainly introduces the basic working principle, product characteristics and interfaces etc... Chapter 3: System structure introduces the use of every unit in the Band selective repeater such as main modules, monitoring units and PA units... which will make the user have a good knowledge of the Band selective repeater structure. Chapter 4: System instruction for antenna selection, The equipment does meet the exemption requirements in respect of RF Exposure... Applicable MPE Limits, FCC Formulas and Calculations, Selection for Service Antennas. Chapter 5: System commissioning mainly introduces the general testing procedures of the system, testing tool, apparatus, system testing content, testing methods that will help user to run the Band selective repeater in the optimal condition. Annex A is Outlet Configuration. NOTE： This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense. CDMA1900 Dual Band Selective Repeater 0.5W Rev PA1 2010-1-12 © Ericsson AB 20089 Public 2 (10) 2 System Summary 2.1 Overview This chapter gives a b…

Text truncated - open the document above for the full version.

Shenzhen Winhap Communications INC. Unit 3A, F6.13 Building, Tian’an Cyberpark, Futian District, Shenzhen city, GuangDong Province, P.R.China Tel: 086-755-83309999 Fax: 086-755-83892643 Authorization Letter Date: March 22, 2010 BABT Forsyth House Churchfield Road Walton-on-Thames Surrey KT12 2TD Dear Sir or Madam: We, the undersigned, hereby authorize Ms. Li Qun from TUV Product Service Limited, Beijing Branch, Unit 918, Landmark Tower 2, 8 North Dongsanhuan Road, 100004 Beijing, act on our behalf, as our agent, in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. I further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. This authorization shall expire 3 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Sincerely Title: Quality Division Director

Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: CDMA RF Repeater Product Model: KRC 118 102/AF14 FCC ID: X7RKRC118102-AF14 The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Title: Quality Division Director Shenzhen Winhap Communications INC. Unit 3A, F6.13 Building, Tian’an Cyberpark, Futian District, Shenzhen city, GuangDong Province, P.R.China 518126 Tel: 086-755-83309999 Fax: 086-755-83892643

X7RKRC118102-AF14 External Photo

X7RKRC118102-AF14 Label and Label location

X7RKRC118102-AF14 Internal Photo All the active units and passive units in the RF case V RF circuit for UL PA and DL PA UL Channel and DL channel RF circuit for UL LNA RF circuit for DL LNA RF circuit for DL CH and UL CH RF circuit for CH PCB RF circuit for main control unit

DAT-P-174/04-00 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRMC2010-H024-E0007 Product Name: CDMA RF Repeater Product Model: KRC 118 102/AF14 Applicant: Shenzhen Winhap Communications INC. Manufacture: Shenzhen Winhap Communications INC. Specification: FCC Part 24E, Part 2 (October 1, 2008 edition) FCC ID: X7RKRC118102-AF14 The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center No.: SRMC2010-H024-E0007 State Radio Spectrum Monitoring and Testing Center FCC ID: X7RKRC118102-AF14 Tel: 86-10-68009202 68009203 fax: 86-10-68009195 68009205 Page 2 of 32 CONTENTS 1．General information ................................................................................ 3 1.1 Notes of the test report...................................................................................................3 1.2 Information about the testing laboratory.......................................................................3 1.3 Applicant’s details............................................................................................................3 1.4 Manufacturer’s details.....................................................................................................3 1.5 Application details............................................................................................................4 1.6 Reference specification...................................................................................................4 1.7 Information of EUT..........................................................................................................4 1.7.1 General information..............................................................................................4 1.7.2 EUT details............................................................................................................4 2. Test information ........................................................................................ 5 2.1 Summary of the test results............................................................................................5 2.2 Test result..........................................................................................................................6 2.2.1 RF Power Output-FCC Part2.1046/24.232(c)..................................................6 2.2.2 Occupied Bandwidth-FCC Part2.1049..............................................................7 2.2.3 Spurious Emissions at antenna terminal-FCC Part2.1051/24.238(a)......... 11 2.2.4 Band Edges Compliance-FCC Part2.1051/24.238(a)...................................21 2.2.5 Frequency Stability-FCC Part2.1055/Part24.135/Part24.235......................24 2.2.6 Radiated Spurious Emissions-FCC Part2.1053/24.238(a)...........................25 2.3. List of test equipments.................................................................................................31 Appendix................................................................................................................................32 The State Radio Monitoring Center No.: SRMC2010-H024-E0007 State Radio Spectrum Monitoring and Testing Center FCC ID: X7RKRC118102-AF14 Tel: 86-10-68009202 68009203 fax: 86-10-68009195 68009205 Page 3 of 32 1．General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio Monitoring Center. The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] 1.3 Applicant’s details Company: Shenzhen Winhap Communications INC. Address: Unit 3A, F6.13 Building, Tian’an Cyberpark, Futian District City: Shenzhen Country or Region: P.R.China Grantee Code: X7R Contacted person: Li Bin Tel: +86-755-83309999 Fax: +86-755-83892643 Email: [email protected] 1.4 Manufacturer’s details Company: Shenzhen Winhap Communications INC. Address: Unit 3A, F6.13 Building, Tian’an Cyberpark, Futian District City: Shenzhen Country or Region: P.R.China Grantee Code: X7R Contacted person: Li Bin Tel: +86-755-83309999 Fax: +86-755-83892643 Email: [email protected] The State Radio Monitoring Center No.: SRMC2010-H024-E0007 State Radio Spectrum Monitoring and Testing Center FCC ID: X7RKRC118102-AF14 Tel: 86-10-68009202 68009203 fax: 86-10-68009195 68009205 Page 4 of 32 1.5 Application details Date of reception of test sample: 1 st Feb 2010 Date of test: 1 st Feb 2010 to 24 th Feb 2010 1.6 Reference specification FCC Part 24E, Part 2 (October 1, 2008 edition) 1.7 Information of EUT 1.7.1 General information Name of EUT CDMA RF Repeater FCC ID X7RKRC118102-AF14 Frequency range Uplink:1850~1915MHz Downlink:1930~1995MHz Rated output power Uplink:23.0dBm Downlink:27.0dBm Modulation type OQPSK Emission Designator 1M25F9W Duplex mode FDD Duplex spacing 80MHz Maximum Gain Uplink:80dB Downlink:85dB Gain Control Range ≥30dB (1dB/Step) Antenna type External Antenna connector 50Ω N-Type (Female) Power Supply 90 ~ 270Va.c., 45~65Hz Extreme Temperature Lowest: -10°C Highest: +50°C Extreme Voltage Minimum: 102Va.c. Maximum: 138Va.c. (Note: The Reference input voltage is 120 Va.c.) HW Version V0.1 SW Version GM_V1.0.2_*.HEX 1.7.2 EUT details Name Model IMEI CDMA RF Repeater KRC 118 102/AF14 2010010701 The State Radio Monitoring Center No.: SRMC2010-H024-E0007 State Radio Spectrum Monitoring and Testing Center FCC ID: X7RKRC118102-AF14 Tel: 86-10-68009202 68009203 fax: 86-10-6800919…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRMC2010-H024-E0007 Product Name: CDMA RF Repeater Product Model: KRC 118 102/AF14 Applicant: Shenzhen Winhap Communications INC. Manufacture: Shenzhen Winhap Communications INC. Specification: FCC Part 24E, Part 2 (October 1, 2008 edition) FCC ID: X7RKRC118102-AF14 The State Radio Monitoring Center State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center No.: SRMC2010-H024-E0007 State Radio Spectrum Monitoring and Testing Center FCC ID: X7RKRC118102-AF14 Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 2 of 2 Appendix1 Test Setup Radiated Spurious Emissions Test setup
