User Manual Urja remote control egg vibe rechargeable waterproof 7100028-TX 7100028-RX Transmitter and Receiver Hahdu Inc New Industrial Zone, QiuFu Road, Dalang Town,Dongguan City,Guangdong Province,China. Tel: +86-769-83132750 Fax: +86-769-83132749 Note: The information contained in this document is proprietary and confidential Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited. INTRODUCTION The product of Egg Vibe is used personal health care, it is small and individuation so that it is accpted by market of all over the world. The product compose with two parts: 7100028-TX (Transmitter) and 7100028-RX (Receiver) The product operate by wireless system, worked as belowing description: Speed I: Press the key one time and hold approximately 2 seconds, the receiver will vibrate with low speed I. Speed II: Press the key second time and hold approximately 2 seconds, the receiver will vibrate with low speed II. Speed III: Press the key third time and hold approximately 2 seconds, the receiver will vibrate with high speed I. Speed VI: Press the key fourth time and hold approximately 2 seconds, the receiver will vibrate with high speed II. Power Off: Press the key fifth time and hold approximately 2 seconds, the receiver will be powered off. control key Product parameters Value ParaMeter Min Typical Max Unit Operating(Receiver) Voltage 33.6 4.2 V Quiescent current 1030 50 Ua Current 150180 220 Ma Temperature ﹣2030 60 C° Battery(Receiver) Voltage 2.753.6 4.2 V Capaity 250 mah Size 30*20*05mm Temperature range ﹣20°C 65°C C° Storage max.temp ﹣20°C 45°C C° Weight(approx) 5.6 g Battery(Transmitter) Voltage 11.912 12.2 V Capaity 52 mah Cutoff＠+20C° Pulse current Size 23A 3LR50 Temperature range ﹣20°C 60°C C° Storage max.temp ﹣20°C 45°C C° Weight(approx) 7.8 g Frequency characteristics Frequency 315 MHz Bandwidth 50 KHz Modulation ASK *** Caution *** This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes of modifications not expressly approved by the party responsible for compliance could void the user ’s authority to operate the equipment.

External Photos Top Bottom Side Side Side Side

Mark Location: FCC ID: X8S7100028 Model: 7100028-TX 15mm 7mm

Internal Photos Internal Photo PCB of EUT PCB of EUT Photo of Battery Antenna

Operation Specification Urja remote control egg vibe rechargeable waterproof 7100028-TX 7100028-RX Transmitter and Receiver Hahdu Inc New Industrial Zone, QiuFu Road, Dalang Town,Dongguan City,Guangdong Province,China. Tel: +86-769-83132750 Fax: +86-769-83132749 Note: The information contained in this document is proprietary and confidential Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited. Function Diagram: Function Decription: The product compose with two parts: 7100028-TX (Transmitter) and 7100028-RX (Receiver) The product operate by wireless system, worked as belowing description: Press the control key and you will switch on the power of singal, Low frequency digtal singal is moulated by frequency moulatating (32.678KHz), FM singal is also mixing by mixer of 315MHz, High frequency that was mixed, was amplifed by HF amplifier and emitted by antenna in transmitter.(please refer above chart) Receiver are all time ready to receive any singal including 315MHz, High frequency singal was filtered by 315MHz filter in receiver, then was demodulated by 32.678KHz FM demodulator, low frequency digital signal that was demodulated, if it is strong and from TX(programming in advance), and the driver will power on the motor. (please refer above chart) Product Photos: control key Product technology parameters Value ParaMeter Min Typical Max Unit Operating(Receiver) Voltage 33.64.2 V Quiescent current 103050 Ua Current 150180220 Ma Temperature ﹣203060 C° Battery(Receiver) Voltage 2.753.64.2 V Capaity 250 mah Size 30*20*05mm Temperature range ﹣20°C65°C C° Storage max.temp ﹣20°C45°C C° Weight(approx) 5.6 g Battery(Transmitter) Voltage 11.91212.2 V Capaity 52 mah Cutoff＠+20C° Pulse current Size 23A 3LR50 Temperature range ﹣20°C60°C C° Storage max.temp ﹣20°C45°C C° Weight(approx) 7.8 g Frequency characteristics Frequency 315 MHz Bandwidth 50 KHz Modulation ASK

Report No.: TR-1003-003-01 Page 1 of 23 TDK South China EMC Center SAE Technologies Development (Dongguan) Co., Ltd. Changan Branch FCC Test Report (TR-1003-003-01) Applicant : Hahdu Inc Address : New Industrial Zone, QiuFu Road, Dalang Town,Dongguan City,Guangdong Province,China Manufacturer : Hahdu Inc Address : New Industrial Zone, QiuFu Road, Dalang Town,Dongguan City,Guangdong Province,China Product Name : Urja remote control egg vibe rechargeable waterproof Trademark : None Model(s) : 7100028-TX Standard(s) : FCC Part 15 Subpart C Test Result : Pass Date of Test : Mar 10, 2010 to Mar 15, 2010 Report issued Dated : Mar 15, 2010 The report shall not be reproduced except in full, without the written approval of the TDK EMC Center. The results in this report apply only to the sample(s) tested. The production units are required to conform to the initial sample as received when the units are placed in the market. Responsible Engineer : Approved by : Phenix Zhang Technical manager CHAN king-chui Date : 2010.03.15 Date : 2010.03.15 Report No.: TR-1003-003-01 Page 2 of 23 TDK South China EMC Center SAE Technologies Development (Dongguan) Co., Ltd. Changan Branch Table of Contents Description Page 1. Description of the Test Site ...................................................................................................................... 3 1.1 Test Site Location: ..................................................................................................................................... 3 1.2 Site Registration ....................................................................................................................................... 3 1.3 Test Scope................................................................................................................................................... 3 2. Description of the Tested Samples .......................................................................................................... 4 2.1 Customer Information .............................................................................................................................. 4 2.2 Identification of EUT ............................................................................................................................... 4 2.3 Spec of EUT .............................................................................................................................................. 4 2.4 Test Standards List.................................................................................................................................... 4 3. Test Specifications ....................................................................................................................................... 5 3.1 Standard(s) Used ....................................................................................................................................... 5 3.2 Deviations from the Test Specification .................................................................................................... 5 4. Test Result.................................................................................................................................................... 6 4.1 Antenna Requirement ............................................................................................................................... 6 4.2 Conducted Emission (mains).................................................................................................................... 7 4.3 Radiated Emission Test............................................................................................................................. 8 4.4 20dB Occupied Bandwidth..................................................................................................................... 13 4.5 Release Time Measurement.................................................................................................................... 15 5. FCC ID Label ............................................................................................................................................ 17 6. Test Setup ................................................................................................................................................... 18 6.1 Photographs of the Test Configuration ................................................................................................ 18 6.2 Photographs of the EUT ........................................................................................................................ 19 7. Equipment List.......................................................................................................................................... 22 8. Test Uncertainty ........................................................................................................................................ 23 9. Appendix .................................................................................................................................................... 23 9.1 Confirmation of Compliance within the Limits ................................................................................... 23 Report No.: TR-1003-003-01 Page 3 of 23 TDK South China EMC Center SAE Technologies Development (Dongguan) Co., Ltd. Changan Branch 1. Description of the Test Site 1.1 Test Site Location: Laboratory : TDK South China EMC Center SAE Technologies Development (Dongguan) Co., Ltd. Changan Branch Address : Zhenan Hi-tech Industrial Park, Dongguang City, Guangdong Province, China Phone no. : (86)-769-8564-4678 Fax no. : (86)-769-8564-4499 Email : [email protected] 1.2 Site Registration VCCI (September, 2008) : Reg. No. R-2205, C-2392 FCC site registration (July, 2008) : Reg. No. 732901 IC registration : Reg. No. 7993 EMCC (September, 2008) : Reg. No. NAR/tl-060330 1.3 Test Scope EMC and RF testing according to national / international standards Report N…
