X9DWP0C700BOOK SHAPE PC

Caution : Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Compliance statement: 1: This device is verified to comply with Part 15 of the FCC Rules. Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

Attestation for FCC Declaration of Conformity FCC ID: X9DWP0C700 Data: May. 25, 2010 Please be notified that we,the undersigned, Zhejiang Mapor Electronic Technology Co.,lTd declares that the product which bears the above FCC ID is also compliant with the FCC requirements for Doc,The test report number supporting the DoC is 1002353,Testing in regards to this report was done by SIEMIC Inc, located at 2206 Ringwood Avenue,San Jose,CA 95131 USA which has been accredited in accordance to all of the requirements of 47CFR2.948(d)and(e)of the FCC rules and KDB349827 Sincerely, Xuhui shen / Manufacture Manager Zhejiang Mapor Electronic Technology Co.,lTd Tel: +86-574-65151118 Fax: +86-574-65159703 Email: [email protected]

Label Location

33mm 9mm 25mm 19mm L=40mm 30mm*10mm 2.5mm 15mm

Antenna location

RF Exposure Statement 1. Standard Applicable According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a portable device. 2. Measurement Result: This is a portable device and the max average output power is 10.06 dBm (10.0641mW). The antenna gain of the device is 0.5dBi The EIRP of the devi ce is 12.46+0.5=12.96dBm=19.7697mW Lower than the low threshold 60/f GHz = (24.37 mW),. The SAR/MPE measurement is not necessary.

FCC ID: X9DWP0C700 NS Technology Co., Ltd. Report No. NSE- F10054868 Page 1 of 66 FCC TEST REPORT for Zhenjiang Mapor Electronic Technology Co.,Ltd BOOK SHAPE PC Model Number: WP-C700 Prepared for : Zhenjiang Mapor Electronic Technology Co.,Ltd Address : Dajiahe Village,Dajiahe Town,Ninghai,Ningbo, Zhejiang,China Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE- F10054868 Date of Test : May 20~May 28, 2010 Date of Report : May 29, 2010 Test Lab Cert 2951.01 FCC ID: X9DWP0C700 NS Technology Co., Ltd. Report No. NSE- F10054868 Page 2 of 66 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ......................................................................... 4 1.1. Product Function ........................................................................................................................ 4 1.2. Description of Device (EUT) .....................................................................................................4 1.3. Independent Operation Modes ................................................................................................... 4 1.4. Test Supporting System ............................................................................................................. 4 2. TEST SITES.......................................................................................................................... 5 2.1. Test Facilities ............................................................................................................................. 5 2.2. List of Test and Measurement Instruments ................................................................................ 6 3. TEST SET-UP AND OPERATION MODES .................................................................... 7 3.1. Principle of Configuration Selection.......................................................................................... 7 3.2. Block Diagram of Test Set-up....................................................................................................7 3.3. Test Operation Mode and Test Software.................................................................................... 7 3.4. Special Accessories and Auxiliary Equipment .......................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance........................................................................ 7 4. TEST SUMMARY................................................................................................................ 8 5. DATA RATE VS POWER................................................................................................... 9 6. EMISSION TEST RESULTS............................................................................................ 10 6.1. Conducted Emission at The Mains Terminals Test.................................................................. 10 6.2. Radiated Emission.................................................................................................................... 13 6.3. 6dB Bandwidth ........................................................................................................................ 43 6.4. Power Spectral Density Test ....................................................................................................45 6.5. Output Power Test.................................................................................................................... 48 6.6. Band Edge ................................................................................................................................ 49 6.7. ANTENNA REQUIREMENT ................................................................................................. 66 FCC ID: X9DWP0C700 NS Technology Co., Ltd. Report No. NSE- F10054868 Page 3 of 66 NS Technology Co., Ltd. Applicant: Address: Zhenjiang Mapor Electronic Technology Co.,Ltd Dajiahe Village,Dajiahe Town,Ninghai,Ningbo, Zhejiang,China Manufacturer: Address: Zhenjiang Mapor Electronic Technology Co.,Ltd Dajiahe Village,Dajiahe Town,Ninghai,Ningbo, Zhejiang,China E.U.T: BOOK SHAPE PC Model Number: WP-C700 Trade Name: I-ZOON Operating Frequency: IEEE802.11b 2412~2462MHz IEEE802.11g 2412~2462MHz Date of Receipt: Mar.16, 2010 Date of Test: May 20~May 28, 2010 Test Specification: FCC Part 15 Subpart C: Oct.1,2009 ANSI C63.4:2003 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: May 29, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. FCC ID: X9DWP0C700 NS Technology Co., Ltd. Report No. NSE- F10054868 Page 4 of 66 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Details please refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) E.U.T. : BOOK SHAPE PC Model No. : WP-C700 Operating Frequency : 2412~2462MHz Number of Channels : 11 Channels Channel frequency F = 2412 + 5(K-1) K=1,2,.......11 Type of Modulation : DSSS for IEEE 802.11b/g IEEE 802.11b:11/5.5/2/1M bps Data Rate : IEEE 802.11g:54/48/36/24/18/12/9/6Mbps Antenna Type : Integral Antenna Gain : 0.5dBi System Input Voltage : DC 9V from adapter input AC 120V/60Hz Temperature Range(Operating) : 0 ~+ 40°C Adapter : M/N:GFP151C-090160B-1 I/P:100-240V~50/60Hz 0.5A O/P:9V_1.6A DC Line:Unshielded,Undetachable ,1.5m 1.3. Independent Operation Modes The basic operation modes are: 1.4.1. IEEE 802.11b; TX CH1 (2412MHz) 1.4.2. IEEE 802.11b; TX CH 6 (2437MHz) 1.4.3. IEEE 802.11b; TX CH11…

Text truncated - open the document above for the full version.

Set-up for radiated emission test (30MHz~1GHz) Set-up for Conduction test Set-up for output power test Set-up for radiated emission test (Above 1GHz)
