XD6T510GMOBILE PHONE

1 Contents 1. For your Safety..............................5 2. Mobile Phone Profile......................8 3. Preparation before Use.................10 Install SIM Card .......................................... 10 Install Memory Card ................................... 11 Install Battery .............................................. 12 Charge Battery............................................ 13 Notices on using the battery ....................... 14 4. General Instructions.....................16 SIM1 Dial Key ............................................. 16 Switch-on/off Key ........................................ 16 Keypad lock ................................................ 16 Icons in Standby State ................................ 17 Language and Input Mode ......................... 18 Call hint ....................................................... 18 Services ....... ............................................... 19 Callers’ group .............................................. 19 Te r m D e s c r i p t i o n ......................................... 19 5. Basic Operation...........................22 Switch on .................................................... 22 Switch off .................................................... 23 Standby Shortcut Function ......................... 24 2 Dial a Call ................................................... 24 Answer a Call .............................................. 25 Read Calls .................................................. 25 Keypad Lock ............................................... 26 Power Economical Mode ............................ 26 Speedy Dialing............................................ 27 Send DTMF Signal ..................................... 27 Dial Hold ............... ...................................... 28 Connect to Voice mail ................................. 29 Save and Back to Previous Menu .............. 30 6. Use Menu Functions.....................30 Games ........................................................ 30 Messages ..................... 错误！未定义书签。 Messages ......................................... 31 Email ................................................. 35 Broadcast Message ......................... 36 Settings ....................................................... 37 User Profiles ..................................... 37 Phone settings .................................. 39 Call settings ...................................... 43 Network Settings .............................. 47 Security Settings .............................. 48 Restore factory settings ................... 49 Camera .................. ..................................... 49 Services ................ ...................................... 51 Phonebook .................................................. 53 3 Multimedia .................................................. 56 Image viewer .................................... 56 Video recorder .................................. 57 Video player ...................................... 58 Photo editor ...................................... 59 Sound recorder ................................. 61 Audio player...................................... 62 FM ..................................................... 63 Schedule FM record ......................... 65 File Manager ............................................... 66 Organizer .................................................... 67 Bluetooth .......................................... 67 Calendar ...... ..................................... 73 Tasks ................................................. 75 Alarm ........... ..................................... 75 World Clock ...................................... 76 Calculator ......................................... 76 Currency Converter .......................... 77 E-book .............................................. 77 Call history .................................................. 78 7. English Editor Operation...............80 Basic Letter Input ... ..................................... 82 Number Input .............................................. 82 Symbol Input ............................................... 83 8. Use Accessories..........................83 Notices for USB cable: ............................... 83 4 Notices for Battery ...................................... 84 Charger ....................................................... 84 9. Appendix I...................................85 10. Appendix II................................89 5 1. For your Safety For your safety and proper use of the mobile phone, please read the following guidelines carefully: 1. Do not switch the mobile phone on when close to chemical factory, gas station or other explosive objects. 2. Always keep the mobile phone out of children’s reach. 3. During driving, please use headset for safety purpose; unless otherwise in emergency, always stop the car on roadside to have a call conversation. 4. Because the use of the mobile phone can cause interference in the aircraft, never use the mobile phone in aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone before boarding. 5. Pay special attention to the use of the mobile phone near heart pacemaker, deaf-aid and some other medical devices, because the mobile phone can cause interference with them. 6 6. None-original factory’s accessories and parts will lose guarantee. 7. Do not dismantle the mobile phone without permission. In case of failure, please contract the supplier as soon as possible. 8. Do not plug the charger into the mobile phone and charge without battery. Always power off the mobile phone when taking out the battery; otherwise the memory of the phone may be damaged. 9. When charging the mobile phone, always keep it in the place with good ventilation, heat sink and away from flammable and explosive objects. 10. In order to avoid demagnetization, always keep the mobile phone away from magnetic objects…

Text truncated - open the document above for the full version.

SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. Date: 01 Sep, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. , the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. solely in matters relating to the application for an FCC equipment authorization for FCC ID:XD6T510G including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. in connection with the Application shall have the same effect as acts of the SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD.. The SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Jinwen Guo Quality Director

SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. Date: 01 Sep, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. FCC ID: XD6T510G FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. requests that the following documents regarding this submission for FCC ID: XD6T510G be kept confidential: Exhibit Type File Name Block Diagram CONF APPENDIX XD6T510G_Block Diagram.pdf Schematics CONF APPENDIX XD6T510G_Schematics.pdf Operational Description CONF APPENDIX XD6T510G_Circuit description.pdf Part list CONF APPENDIX XD6T510G_BOM.pdf Tune-Up-Procedure CONF APPENDIX XD6T510G_Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Yours Sincerely, Jinwen Guo Quality Director

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Label Label Location

SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. Date: 1 Sep, 2010 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: XD6T510G Dear Sirs: SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier XD6T510G. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls, camera and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD will add the FCC identifier " XD6T510G" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely, Jinwen Guo Quality Director

Internal Photos

Report No.: SZ10080009E02 Page 2 of 14 TABLE OF CONTENTS 1. TEST CERTIFICATION ........................................................................................................... 3 2. GENERAL INFORMATION .................................................................................................... 4 2.1 EUT Description ......................................................................................................................... 4 2.2 Test Standards and Results ........................................................................................................ 5 2.3 Facilities and Accreditations ...................................................................................................... 6 2.3.1 Facilities .................................................................................................................................... 6 2.3.2 Test Environment Conditions .................................................................................................... 6 2.3.3 Measurement Uncertainty ......................................................................................................... 6 3. TEST CONDITIONS SETTING .............................................................................................. 7 3.1 Test Mode .................................................................................................................................... 7 3.2 Test Setup and Equipments List ................................................................................................ 9 3.2.1 Conducted Emission.................................................................................................................. 9 3.2.2 Radiated Emission ................................................................................................................... 10 4. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 4.1 Conducted Emission ................................................................................................................. 11 4.1.1 Requirement ............................................................................................................................ 11 4.1.2 Test Description ...................................................................................................................... 11 4.1.3 Test Result ............................................................................................................................... 11 4.1.3.1 GSM Test Mode ........................................................................................................................ 11 4.2 Radiated Emission .................................................................................................................... 13 4.2.1 Requirement ............................................................................................................................ 13 4.2.2 Test Description ...................................................................................................................... 13 4.2.3 Test Result ............................................................................................................................... 13 Change History Issue Date Reason for change 1.0 September 6, 2010 First edition Report No.: SZ10080009E02 Page 4 of 14 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ............................. : GSM phone Model Name ......................... : T510G Serial No............................... : (n.a, marked #1 by test site) Hardware Version ................. : V1.0 Software Version .................. : V0.21 Modulation Type .................. : GMSK Power Supply ....................... : Battery Model Name: E500 Brand name: TINNO Capacitance: 1000mAh Rated voltage: 3.7V Ancillary Equipment 1 ......... : AC Adapter (Charger for Battery) Model Name: BMT30UA Brand Name: TINNO Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 50- 60Hz, 120mA Rated Output: 5.0V, 500mA Note 1: The EUT is a GSM phone; it supports GSM 850MHz, 1900MHz, GPRS and ISM 2.4GHz Bluetooth module. GSM 850MHz and 1900MHz are tested in this report. Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ10080009E02 Page 5 of 14 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ10080009E02 Page 6 of 14 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 2.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 2.3.3 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. Uncertainty of Conducted Emission: ±1.8dB Uncertainty…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2. RE
