XDTSW206Wireless Door/Window Sensor

Note: Magnet assembly must be located within 3/4” (2 cm) of the sensor when the door/ SW206 Wireless Door/Window Sensor Installation Guide WARNING • READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE OR SERVICE THIS DEVICE. • Failure to observe safety information and comply with instructions could result in PERSONAL INJURY, DEATH AND/OR PROPERTY DAMAGE. • To avoid electrical shock or damage to equipment, disconnect power to all devices before installing or servicing. • To avoid potential fi re and/ or explosion do not use in potentially fl ammable or explosive atmospheres. • Retain these instructions for future reference. This product, when installed, will be part of an engineered system whose specifi cations and performance characteristics are not designed or controlled by PECO, Inc. You must review your application and national and local codes to assure that your installation will be functional and safe. ▲ ! SPECIFICATIONS Power supply 2 x AAA alkaline battery / 1.5 V Nominal (1200MAH) Magnet operation Maximum 3/4“ inch (2 cm) from sensor for closed switch Radio frequency 902-928 MHz Radio range 100 feet (30.5 m) line of sight at open fi eld Radio modulation Frequency Hopping Spread Spectrum (FHSS) Temperature limit -10°C~50°C (-14°F ~ 122°F) Humidity 95% RH maximum Dimensions 4.8” x 1.1” x .78” (123.5 x 29 x 20 mm) INTRODUCTION Thank you for choosing the PECO ® SW206 Wireless Door/Window Sensor, an accessory intended for use with the RW205 Receiver as part of the PECO Wave Wireless ® System. The SW206 Sensor (in association with magnet assembly) is desig ned to report the open/ closed status change of the monitored door/window to the paired PECO RW205 Receiver (HVAC operation controller) via a built-in radio communication module. The SW206 Sensor is powered by two AAA alkaline batteries. DESCRIPTION The SW206 Wireless Door/Window Sensor operates in association w ith a required magnet. When the sensor moves away (min. 10”) from the magnet, the switch opens; when the sensor moves close to the magnet, the switch closes. A radio signal is transmitted from the sensor to the associated RW205 Receiver when it detects any door/window open/closed status change. The sensor is comprised of: • Front cover: Plastic part must be assembled with unit base for proper sensor operation. • Printed Circuit Board Assembly (PCBA): Main board for sensor operation and settings. • Unit base: Plastic base part where the PCBA is located. • Magnet assembly: Associated magnet must be located within 3/4” (2 cm) of sensor for proper “closed” signal. INSTALLATION Required Components (included unless noted): • SW206 Wireless Door/Window Sensor • Magnet assembly (required) • Package of screws (4) • Two AAA alkaline batteries • Small Phillips screwdriver (not included) Wireless Pairing • PECO recommends completing the pairing process before mounting the sensor. • • • • • • To ensure successful pairing, refer to pairing instructions for the RW205 Receiver. The SW206 Sensor must be paired with the RW205 Receiver. Wireless pairing enables the associated RW205 Receiver to receive a radio signal from the SW206 Sensor. 1. To begin pairing, remove the front cover of the SW206 Sensor (see Fig. 1). 2. Place two AAA batteries in the SW206 Sensor battery compartment. 3. On the SW206 Sensor, press and hold the pairing switch (see Fig. 1) for about fi ve seconds. The corresponding LED indicator on the RW205 Receiver will begin fl ashing. After the sensor has been successfully paired with the RW205 Receiver, .til niamer lliw revieceR 502WR eht no DEL gnidnopserroc eht Mounting 1. Open the front cover of the SW206 Sensor. 2. Insert two AAA batteries (if not already inserted) in the SW206 battery compartment. 3. Insert screws through the mounting holes of the unit base on the frame of the door/window (see Fig. 2/3) that will be monitored, and mount the SW206 Sensor. 4. Mount the magnet assembly on the door/window, directly adjacent to the SW206 Sensor. window is in the closed position (see Fig.2/3) for sensor to function properly. Sensor installation is complete after both wireless pairing and mounting. STATUS HEARTBEAT A heartbeat signal will be transmitted from the SW206 Sensor once every 10 minutes to report the current open/closed status to the associated RW205 Receiver. The sensor will also transmit an update when the status changes. LOW BATTERY The SW206 Sensor LED will blink once every four (4) seconds to alert the occupant when battery power is getting low. If this occurs, replace old batteries with new batteries immediately. The LED will stop blinking after new batteries are inserted. PECO Wave Wireless and PECO are registered trademarks of PECO, Inc. The PECO logo is a trademark or servicemark of PECO, Inc. © COPYRIGHT 2010 PECO, INC. ALL RIGHTS RESERVED. P/N 70514 3220-2280 REV 00 1 Figure 1. SW206 Door/Window Sensor. Front Cover Magnet assembly Unit baseSensor PCBA Battery compartment Pairing switch mounting hole mounting hole LED Radio module Figure 2. SW206 Sensor Door Mount. SW206 Sensor Figure 3. SW206 Sensor Window Mount. SW206 Sensor NOTE: In the event of battery depletion, the sensor’s corresponding LED on RW205 will shut off; the RW205 will assume that the room is occupied. ▲ ! FCC COMPLIANCE This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment under FCC rules. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can r…
