XJ6-MJ2MATRIX JOYSTICK II

PS2 Wireless Joystick Operation and Function Description Transmitter: 1. Power on: Press and hold the START key for more than 2 seconds. 2. Power off: Press and hold the START key for more than 3 seconds. 3. Bind Mode: Press and hold the L3 key for more than 2 seconds during normal operation. 4. Neutral point correction: Press and hold the L1&R1 keys and then Power on for more than 2 seconds. After the execution is completed, the LED flashes twice before returning to normal working mode, and the LED remains on. 5. LED indication: a Normal emission&Analog Mode (Default) - LED constant brightness b. Normal emission&Digital Mode - LED flashing for 0.5 seconds ON OFF Continuous. c. Low battery voltage warning - LED flashes for 0.25 seconds, ON and OFF continuously. d. Bind Mode - The LED flashes 0.1 seconds ON and OFF for 3 consecutive seconds before returning to normal operating mode. e. Neutral point correction - LED flashes 0.15 seconds ON, 0.15 seconds OFF, 0.15 seconds ON, and 0.15 seconds OFF before returning to normal working mode. e. Sleep mode - After each function has not been operated for more than 15 minutes, the LED flashes for 1 second and remains ON and OFF continuously. After the function is activated, it returns to normal working mode. FCC Statement Th e equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help T his device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. •This device must accept any interference received, including interference that may cause undesired operation. T his equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC exposure compliance requirement, please follow operation instruction as documented in this manual. Y ou are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment

U.S. AGENT LETTER OF ATTESTATION Date: 2023-05- 15 FEDERAL COMMUNICATIONS COMMISSION Aut hor ization and Eva lua tion Divi sion 7435Oakl and Mills Roa d Col um bi a, MD 21046 Ref: Attestation Statement s CFR 47 §2.911(d) (7) Filing FCC ID: XJ6- MJ2 SHANGHAI MERIT TECHNOLOGY CORP. (“the Appl icant ”) certifies tha t, as of the da te of the filing of the appl ication, Icons igh Inc. is our de signa ted U.S . age nt for servi ce of pr oc ess for the abovereferenc ed FCC ID. SHANGHAI MERIT TEC HNOLOGY CORP. (“the Appl icant ”) accept s to maint ain an age nt for no less tha n one year after the grant ee ha s termina ted all marke ting and impor tation or the conc lus ion of any Com mission- related pr oc eedi ng invol vi ng the equi pm ent . Icons igh Inc. accept s, as of the da te of the filing of the appl ication, the obl igation of the de signa ted U.S . age nt for servi ce of pr oc ess for the abovereferenc ed FCC ID. Designa ted U.S . Age nt Infor mation: Com pa ny Name: Icons igh Inc. Addr ess : 2310Hom estead Roa d, Sui te C1, Los Altos , CA, 94024,USA FRN: 0033398652 Tel.: +1 (408)320- 9867 Email: be nj amin.ka ur @icons igh.c om Signe d by (pr int ed na me): Benj amin Kaur Signa tur e: Appl icant : SHANGHAI MERIT TECHNOLOGY CORP. Addr ess: 1058TAOGAN RD., SHESHAN TOWN SONGJIANAG DISTRICT, SHANGHAI, Chi na FRN: 0018901918 Tel: (86) 21- 57793858Ext ens ion: 218 Email: xy zhu@ seahi gh.c om Signe d by (pr int ed na me): Dongc he ng Zhe ng Signa tur e:

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 1 of 3 External Photographs Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 2 of 3 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 3 of 3 ***** END *****

JOYSTIC K II ATRIXM

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 1 of 5 Internal Photographs Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 2 of 5 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 3 of 5 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 4 of 5 Antenna Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 5 of 5 RF Chip ***** END *****

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ230324061RF01 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 13 of 40 5 FCC §1.1307(b)(3)(i) – RF EXPOSURE 5.1 Applicable Standard According to subpart 15.247(i)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of this section. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using Table 1 and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half- wave dipole (1.64 linear value). Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ230324061RF01 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 14 of 40 5.2 RF Exposure Evaluation Result Project info § 1.1307(b)(3)(i)(A) and (C) methid is not applicable. § 1.1307(b)(3)(i)(B) The available maximum time-averaged power or effective radiated power (ERP), whichever is greater. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Result: The EUT meets exemption requirement. Band Freq (MHz) Tune-up Average Power (dBm) Ant Gain (dBi) Tune-up Average Power (mW) ERP (dBm) ERP (mW) SRD 2465 3 1.6 2.00 2.45 1.76 Band Freq (MHz) Pth (mW) X ERP 20cm (mW) Result Option B SRD 2465 2.73 1.903 3060 exempt

name:PCB Antenna model:PS Ant v1.2 Brand:MERITRC

Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 1 of 40 FCC Part 15.247 TEST REPORT For SHANGHAI MERIT TECHNOLOGY CORP. 1058 TAOGAN RD., SHESHAN TOWN SONGJIANAG DISTRICT, SHANGHAI,China FCC ID: XJ6-MJ2 Report Type: Original Report Product Type: MATRIX JOYSTICK II Report Producer : Coco Lin Report Number : RXZ230324061RF01 Report Date : 2023-06-08 Reviewed By: Andy Shih Prepared By: Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) 70, Lane 169, Sec. 2, Datong Road, Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C. Tel: +886 (2) 2647 6898 Fax: +886 (2) 2647 6895 www.bacl.com.tw Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ230324061RF01 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 2 of 40 Revision History Revision No. Report Number Issue Date Description Author/ Revised by 0.0 RXZ230324061 RXZ230324061RF01 2023-06-08 Original Report Coco Lin Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ230324061RF01 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 3 of 40 TABLE OF CONTENTS 1 General Information ....................................................................................................... 5 1.1 Product Description for Equipment under Test (EUT) ......................................................... 5 1.2 Objective ............................................................................................................................... 6 1.3 Related Submittal(s)/Grant(s) ................................................................................................ 6 1.4 Test Methodology.................................................................................................................. 6 1.5 Statement ............................................................................................................................... 6 1.6 Measurement Uncertainty ..................................................................................................... 7 1.7 Environmental Conditions ..................................................................................................... 7 1.8 Test Facility ........................................................................................................................... 7 2 System Test Configuration ............................................................................................. 8 2.1 Description of Test Configuration ......................................................................................... 8 2.2 Equipment Modifications ...................................................................................................... 8 2.3 EUT Exercise Software ......................................................................................................... 8 2.4 Support Equipment List and Details...................................................................................... 8 2.5 External Cable List and Details ............................................................................................. 8 2.6 Test Mode .............................................................................................................................. 9 2.7 Block Diagram of Test Setup ................................................................................................ 9 2.8 Duty Cycle ........................................................................................................................... 10 3 Summary of Test Results .............................................................................................. 11 4 Test Equipment List and Details ................................................................................. 12 5 FCC §1.1307(b)(3)(i) – RF EXPOSURE ..................................................................... 13 5.1 Applicable Standard ............................................................................................................ 13 5.2 RF Exposure Evaluation Result........................................................................................... 14 6 FCC §15.203 – Antenna Requirements ....................................................................... 15 6.1 Applicable Standard ............................................................................................................ 15 6.2 Antenna Information ........................................................................................................... 15 7 FCC §15.209, §15.205 , §15.247(d) – Spurious Emissions ......................................... 16 7.1 Applicable Standard.......................................................................................................... 16 7.2 EUT Setup .......................................................................................................................... 17 7.3 EMI Test Receiver & Spectrum Analyzer Setup ............................................................ 18 7.4 Test Procedure ..................................................................................................................... 18 7.5 Corrected Factor & Margin Calculation ........................................................................ 18 7.6 Test Results ........................................................................................................................ 19 8 FCC §15.247(a)(1) – 20 dB Emission Bandwidth ....................................................... 26 8.1 Applicable Standard.......................................................................................................... 26 8.2 Test Procedure ..........................................................................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 1 of 2 EUT Setup Photographs Radiated Emission (Below 1GHz)： Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ230324061 Page 2 of 2 Radiated Emission (Above 1GHz)： ***** END *****
