XKR-RE300B1WiFi Repeater

11n Repeater User’s Manual 1 802.11n WLAN Portable Repeater User’s Manual 11n Repeater User’s Manual 2 Table of Contents 1 Introduction ........................................................... 6 Features ................................................................................. 6 Device Requirements ............................................................ 6 Using this Document .............................................................. 7 Notational conventions .................................................. 7 Typographical conventions ............................................ 7 Special messages .......................................................... 7 Getting Support ...................................................................... 7 2 Getting to know the device ................................... 8 Computer / System requirements ......................................... 8 Package Contents .................................................................. 8 LED meanings & activations .................................................. 8 Top Side ......................................................................... 8 Rear and Left Panel and bottom Side ........................... 9 3 Computer configurations under different OS, to obtain IP address automatically ...................................................... 10 For Windows 98SE / ME / 2000 / XP .................................. 10 For Windows Vista-32/64 .................................................... 14 For Windows 7-32/64 ........................................................... 19 For Windows 8-32/64 ........................................................... 24 4 Connecting your device ..................................... 29 Connecting the Hardware .................................................... 29 WPS Pairing between 11n Repeater and Wireless xDSL/Cable Modem ........................................... 30 5 Advanced Configuration ..................................... 31 Advanced Configuration ...................................................... 31 Wireless Connection ............................................................ 33 6 What the Internet/WAN access of your own Network now is ........................................... 35 Internet/WAN access is the DHCP client ............................ 37 Internet/WAN access is the Static IP ................................... 38 Internet/WAN access is the PPPoE client ........................... 40 7 Getting Started with the Web pages .................. 41 Accessing the Web pages ................................................... 41 Testing your Setup ............................................................... 43 Default device settings ......................................................... 43 11n Repeater User’s Manual 3 8 Quick Setup ........................................................ 45 9 LAN Interface ..................................................... 48 LAN Interface Setup ............................................................. 48 Changing the LAN IP address and subnet mask .................................................................................. 50 DHCP Static IP Configuration .............................................. 53 10 Wireless Network ............................................... 55 Wireless Basics .................................................................... 55 Wireless Advanced Settings ................................................ 57 Wireless Access Control Mode ........................................... 58 Allow Listed .................................................................. 59 11 Reboot/Reset ..................................................... 61 Reboot/Reset ....................................................................... 61 12 Firmware Upgrade ............................................. 62 About firmware versions ...................................................... 62 Manually updating firmware ................................................. 62 13 Backup/Restore Settings ................................... 64 Save Settings to File ............................................................ 64 Load Settings from File ........................................................ 65 14 Password ........................................................... 67 Setting your username and password ................................ 67 15 Time and Date .................................................... 69 Time and Date Configuration settings ................................. 69 16 Status ................................................................. 71 17 Active Client Table ............................................. 72 18 Statistics ............................................................. 73 A Configuring your Computers .............................. 74 Configuring Ethernet PCs .................................................... 74 Before you begin .......................................................... 74 Windows® XP PCs ...................................................... 74 Windows 2000 PCs ..................................................... 74 Windows Me PCs ........................................................ 76 Windows 95, 98 PCs ................................................... 76 Windows NT 4.0 workstations ..................................... 77 Assigning static Internet information to your PCs ................................................................... 78 B IP Addresses, Network Masks, and Subnets .............................................................. 79 IP Addresses ........................................................................ 79 11n Repeater User’s Manual 4 Structure of an IP address ........................................... 79 Network classes ........................................................... 79 Subnet masks .....................................................................…

Text truncated - open the document above for the full version.

1 of 4 External Photos Model Number: RE300B1-2T2R, WRE-6001 FCC ID: XKR-RE300B1 2 of 4 EUT Photo 1 ) EUT Photo 2 ) 3 of 4 EUT Photo 3 ) EUT Photo 4 ) 4 of 4 EUT Photo 5 )

ID Label info & Label Location FCC ID : XKR-RE300B1

1 of 4 Internal Photos Model Number: RE300B1-2T2R, WRE-6001 FCC ID: XKR-RE300B1 2 of 4 EUT Photo 1 ) EUT Photo 2 ) 3 of 4 EUT Photo 3 ) EUT Photo 4 ) 4 of 4 EUT Photo 5 ) EUT Photo 6 ) Wi-Fi ANT.

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 MPE Report Test Report No. ： 1409FS19-02 Applicant ： BaudTec Corporation Manufacturer ： BaudTec Corporation Product Type ： WiFi Repeater Trade Name ： Baudtec Model Number ： RE300B1-2T2R, WRE-6001 Date of Received ： Sep. 05, 2014 Test Period ： Sep. 19, 2014 Date of Issued ： Oct. 30, 2014 Test Specification ： 47 CFR § 2.1091 47 CFR §1.1310 ANSI / IEEE Std.C95.1-1992 Location of Test Lab. ： Chang-an Lab. 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. 4. This document may be altered or revised by A Test Lab Techno. Corp. personnel only, and shall be noted in the revision section of the document. Approved By ： Tested By ： (Bill Hu) (Sky Chou) ©2014 A Test Lab Techno Corp. Report Number: 1409FS19-02Page 1 of 7 Contents 1. Description of Equipment under Test (EUT)............................................................... 3 2. Human Exposure Assessment .................................................................................... 4 3. RF Output Power........................................................................................................... 5 4. Test Result.....................................................................................................................7 ©2014 A Test Lab Techno Corp. Report Number: 1409FS19-02Page 2 of 7 1. Description of Equipment under Test (EUT) Applicant BaudTec Corporation Applicant Address 12F,NO,181,Sec.1.TatungRd.,His-chih City ,Taipei county,Taiwan, 221 Manufacturer BaudTec Corporation Manufacturer Address 12F,NO,181,Sec.1.TatungRd.,His-chih City ,Taipei county,Taiwan, 221 Product Type WiFi Repeater Trade Name Baudtec Model Number RE300B1-2T2R, WRE-6001 * There model numbers differ from each other in selling region. FCC ID XKR-RE300B1 Frequency Range IEEE 802.11b / 802.11g / 802.11n 2.4GHz (20MHz): 2412 ~ 2462 MHz IEEE 802.11n 2.4GHz (40MHz): 2422 ~ 2452 MHz Transmit Power IEEE 802.11b: 0.033 W / 15.20 dBm (conducted power) IEEE 802.11g: 0.029 W / 14.58 dBm IEEE 802.11n 2.4GHz (20MHz): 0.032 W / 15.04 dBm IEEE 802.11n 2.4GHz (40MHz): 0.029 W / 14.65 dBm Antenna Used Antenna Port Type Max. Gain ANT 1 PCB Antenna -2.73 dBi ANT 2 PCB Antenna -3.67 dBi RF Evaluation 0.04 W/m 2 The above equipment was tested by A Test Lab Techno Corp. For compliance with the requirements set forth in 47 CFR § 2.1091 & 47 CFR § 1.1310. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties ©2014 A Test Lab Techno Corp. Report Number: 1409FS19-02Page 3 of 7 2. Human Exposure Assessment Due to the design and installation of this product, it is not possible to conduct SAR evaluation. This is because client either manufactures or supplies the antenna(s) that will be used in the installation of this product. Therefore, this product will be evaluated as a mobile device per 47 CFR §1.1310 titled “Radiofrequency radiation exposure limits”, generally referred to as MPE limits. In 47 CFR § 2.1091, paragraph (b) defines a mobile device as “a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. ” This product is intended to be installed into a vehicle such that the unit is physically secured at one location. In the installation guide supplied with the product, Client has made the following statement: “IMPORTANT: To meet the FCC’s RF Exposure Guidelines, the antenna should be installed so there is at least 20 cm of separation between the body of the user and nearby persons and the antenna”. Based on the installation of the transceiver and the antenna, the transmitters radiating structure is more than 20 cm from the user. Thus, this product is a “mobile device” as defined in section § 2.1091 paragraph (b). Exposure evaluation 2 4R PG S π = Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna. ©2014 A Test Lab Techno Corp. Report Number: 1409FS19-02Page 4 of 7 3. RF Output Power Average Conducted power (dBm) Band Date Rate CH Frequency (MHz) ANT 1 ANT 2 1 2412.0 15.20 15.19 6 2437.0 15.15 15.11 1M 11 2462.0 15.19 15.08 2M 6 2437.0 15.12 15.00 5.5M 6 2437.0 15.09 15.01 IEEE 802.11b 11M 6 2437.0 15.10 15.08 1 2412.0 14.14 14.51 6 2437.0 14.39 14.32 6M 11 2462.0 14.58 14.22 9M 6 2437.0 14.36 14.27 12M 6 2437.0 14.30 14.26 18M 6 2437.0 14.29 14.28 24M 6 2437.0 14.28 14.25 36M 6 2437.0 14.35 14.24 48M 6 2437.0 14.33 14.30 IEEE 802.11g 54M 6 2437.0 14.31 14.31 ©2014 A Test Lab Techno Corp. Report Number: 1409FS19-02Page 5 of 7 Average Conducted power (dBm) Band Date Rate CH Frequency (MHz) ANT 1 ANT 2 ANT 1+2 1 2412.0 12.02 11.98 15.01 6 2437.0 12.06 11.90 14.99 13M 11 2462.0 12.20 11.85 15.04 26M 6 2437.0 12.01 11.88 14.96 39M 6 2437.0 11.97 11.87 14.93 52M 6 2437.0 11.99 11.81 14.91 78M 6 2437.0 12.00 11.83 14.93 104M 6 2437.0 12.03 11.85 14.95 117M 6 2437.0 12.02 11.89 14.97 IEEE 802.11n 2.4GHz (20MHz) 130M 6 2437.0 11.99 11.81 14.91 3 2422.0 11.01 11.43 14.24 6 2437.0 11.51 11.41 1…

Text truncated - open the document above for the full version.

FCC 47 CFR PART 15 SUBPART C Product Type ： WiFi Repeater Applicant ： BaudTec Corporation Address ： 12F,NO,181,Sec.1.TatungRd.,His-chih City,Taipei county,Taiwan, 221 Trade Name ： Baudtec Model Number ： RE300B1-2T2R, WRE-6001 FCC ID ： XKR-RE300B1 Test Specification ： FCC 47 CFR PART 15 SUBPART C: Oct., 2013 ANSI C63.4:2009 Receive Date ： Sep. 05, 2014 Test Period ： Sep. 11~Sep.18, 2014 Issue Date ： Oct. 30, 2014 Issue by A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 Note: This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. This document may be altered or revised by A Test Lab Techno Corp. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, or any government agencies. The test results in the report only apply to the tested sample. A Test Lab Techno Corp. Report Number: 1409FR24-04 1 of 78 Revision History Rev. Issue Date Revisions Revised By 00 Sep. 19, 2014 Initial Issue 01 Oct. 22, 2014 Update report information Nico Peng 02 Oct. 27, 2014 Revised report information Nico Peng 03 Oct. 28, 2014 Revised report information Nico Peng 04 Oct. 30, 2014 Revised report information Nico Peng A Test Lab Techno Corp. Report Number: 1409FR24-04 2 of 78 Verification of Compliance Issued Date: 10/30/2014 Product Type : WiFi Repeater Applicant : BaudTec Corporation Address : 12F,NO,181,Sec.1.TatungRd.,His-chih City,Taipei county,Taiwan, 221 Trade Name : Baudtec Model Number : RE300B1-2T2R, WRE-6001 FCC ID : XKR-RE300B1 EUT Rated Voltage : AC100V~240V Test Voltage : 120 Vac / 60 Hz Applicable Standard : FCC 47 CFR PART 15 SUBPART C: Oct., 2013 ANSI C63.4:2009 Test Result : Complied Performing Lab. : A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 http://www.atl-lab.com.tw/e-index.htm The above equipment was tested by A Test Lab Techno Corp. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247 . The test results of this report relate only to the tested sample identified in this report. Approved By ： Reviewed By ： (Manager) (Fly Lu) (Testing Engineer) (Eric Ou Yang) A Test Lab Techno Corp. Report Number: 1409FR24-04 3 of 78 TABLE OF CONTENTS 1 General Information ....................................................................................................................................... 6 2 EUT Description ............................................................................................................................................. 7 3 Test Methodology .......................................................................................................................................... 8 3.1. Mode of Operation.................................................................................................................................. 8 3.2. EUT Exercise Software.......................................................................................................................... 8 3.3. Configuration of Test System Details ..................................................................................................... 9 3.4. Test Site Environment .......................................................................................................................... 10 4 Conducted Emission Measurement ........................................................................................................... 10 4.1. Limit ...................................................................................................................................................... 10 4.2. Test Instruments ................................................................................................................................... 10 4.3. Test Setup..............................................................................................................................................11 4.4. Test Procedure ......................................................................................................................................11 4.5. Test Result............................................................................................................................................ 12 5 Radiated Emission Measurement............................................................................................................... 14 5.1. Limit ...................................................................................................................................................... 14 5.2. Test Instruments ................................................................................................................................... 14 5.3. Setup .................................................................................................................................................... 15 5.4. Test Procedure ..................................................................................................................................... 16 5.5. Test Result............................................................................................................................................ 18 6 Maximum Conducted Output Power Measurement.................................................................................. 25 6.1. Limit ............................................................................................................…

Text truncated - open the document above for the full version.

Part 15C Test Setup Photographs Conducted Emissions Test Configuration: Front View Rear View A Test Lab Techno Corp. Report Number: 1409FR24-04 1 of 3 Radiated Emissions Test Configuration: Below 1GHz _ Front View Below 1GHz _ Rear View A Test Lab Techno Corp. Report Number: 1409FR24-04 2 of 3 Above 1GHz _ Front View Above 1GHz _ Rear View A Test Lab Techno Corp. Report Number: 1409FR24-04 3 of 3
