XKVV120Assets GPS Tracker

V120 Assets GPS Tracker User Manual V0.93 ADVANCE VISION ELECTRONICS CO., LTD. 6F., No.,199, Lide St., Zhonghe Dist., New Taipei City 23556, Taiwan, R.O.C TEL: +886 2 8228-2088 FAX: +886 2 8228-1200 www.avecl.com [email protected] 2 TABLE OF CONTENTS 1. Warning..............................................................3 2. Features..............................................................4 3. Specification.......................................................5 4. Introduction........................................................6 5. Battery Charging.................................................7 6. SIM Card Installation............................................8 7. Operating..........................................................10 3 1. Warning: USE RESPONSIBLY. READ ALL INSTRUCTIONS AND SAFETY INFORMATION BEFORE USE TO AVOID INJURY. Advance Vision Electronics Co., Ltd. will not accept any responsibility whatsoever for accidents resulting from failure to observe common sense precautions. Your personal judgment, traffic regulations, and common sense must always take precedence over any directions produced by GPS tracker or the mapping software of backend. WARNING: Be certain GPS tracker is secure for position of installation and does not interfere driving safety. It is your responsibility as the vehicle operator to securely place the GPS unit and antenna so that they will not interfere with driving and prevent operations of any safety device, i.e. vehicle’s airbag. Do not mount the devices in a place where the driver or passengers may receive injury during vehicle operation or collision. For your safety, take care to route all cables away from shifters, pedals, accessory controls and mechanisms. 4 2. Features:  GSM/SMS/GPRS Communication.  Quad-Band GSM (850/900/1800/1900MHz) / GPRS Class10.  Support Quick GPS Fix (AGPS).  Real-Time tracking.  Buffer Storage for recording 5,000 data positions.  Geofence Function.  Impact Detection / Movement / Low Battery / Over Speed Alert.  Firmware Upgrade over the Air (OTA).  Configuration via SMS or TCP/IP (GPRS).  Long Battery Life.  Quick Installation (Strong Magnet).  IP67 Water-Resistance. Goods Investigate Assets 5 3. Specification: GSM Frequency GSM 850/900/1800/1900 system GPS Channels 50-channel acquisition 14-channel tracking GPS Start Time Hot Start: 1 sec, Warm Start: 32 sec, Cold Start: 32 sec Position Accuracy Position 2.5m CEP Default Datum WGS84 Operating Temperature -20°C~ 55°C Humidity 5%~ 95% Non-condensing Dimension 131mm x 71.5 mm x 36.5mm Weight 420g Battery Rechargeable 12000 mAh Li-ion battery (3.7V) External Power Source 12V、24V DC Power Consumption Operating(GPS ON, GSM ON) : 110mAh Power Save (GPS OFF, GSM ON): 10mAh Sleep (GPS OFF, GSM OFF): 2mAh LED Power / GSM (Orange/Green) GPS (Blue) Water-Resistance IP67 Certification CE, FCC, PTCRB, NCC, BSMI AC Adaptor Accessories Option: Power Cable (Support 12V / 24V DC Input) 6 4. Introduction:  Power Key  LED  Screw  DC Connector  Magnet Front Back      7 5. Battery Charging: First time to use: Please make sure that rechargeable battery is completely charged. (to charge over 12 hours) Charging: The orange LED will start flashing when the device is low battery, at this time please put the charger into the device and then the orange LED lights will become constant light, to be fully charged after orange LED will extinguish and return to the green LED flashing. 8 6. SIM Card Installation: Open the screw Open the top cover 9 Install the SIM card Close the top cover and tighten the screws 10 7. Operating Turn on: Hold the power key until the LED is lit up Turn off: Hold the power key until the LED is light off LED status: LED Constant Light Blink Quickly (Once per second) Blink Slowly (Once every 3 seconds) Green x 1. No SIM card inserted 2. Device is searching GSM network 3. SIM card is registering to GSM network SIM card is registered to GSM network Orange Device is being charged 1. Low battery and no SIM card inserted 2. Low battery and device is searching GSM network 3. Low battery and SIM card is registering to GSM network Low battery and SIM card is registered to GSM network Blue x Device does not get GPS fix GPS fixed 11 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: 1) this device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation of the device. FCC RF Radiation Exposure Statement: 1) This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2)This equipment com…

Text truncated - open the document above for the full version.

FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group All View of EUT Front View of EUT FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Back View of EUT Side View of EUT – 1 FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Side View of EUT – 2 Side View of EUT – 3 FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Side View of EUT – 4 Adapter FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is i…

Text truncated - open the document above for the full version.

FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Open View of EUT – 1 Internal View of EUT – 1 FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Internal View of EUT – 2 Internal View of EUT – 3 FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Internal View of EUT – 4 Internal View of EUT – 5 WWAN Antenna GPS Antenna FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Internal View of EUT – 6 Internal View of EUT – 7 FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) t…

Text truncated - open the document above for the full version.

Maximum Permissible Exposure (MPE) Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended to comply with Section Part 22, subpart H and Part 24, subpart E of the FCC CFR 47 Rules. And RSS-102 issue 4 For 47 CFR 1.1310 Radio frequency Radiation Exposure requirement. Special Accessories Not available for this EUT intended for grant. Equipment Modifications Not available for this EUT intended for grant. Limitation Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-15000 / / 1.0 30 F = frequency in MHz * = Plane-wave equipment power density Maximum Permissible Exposure (MPE) Evaluation In this application we seek approval to the V120. Based on the FCC OET Bulletin 65 Supplement C and 47 CFR §2.1091, we have concluded that the MC55i module will comply with the FCC rules on RF exposure for mobile devices in cellular band and PCS band. The following analysis will demonstrate such compliance. The analysis will be done in two US bands. Operation in cellular band (824 – 849 MHz) The ERP of V120 in cellular band is 23.04dBm max at GPRS mode. The resulted power density at a distance of 20 cm can be deducted as follows: EUT Measurement Operation Band Pol. Fundamental Frequency CH Antenna Pol. S.G. Output Antenna Gain Cable Loss ERP Limit MHz V/H dBm dBd dB dBm dBm V 13.22 3.96 -4.22 12.9638.40 824.20 128 H 23.30 3.96 -4.22 23.04 38.40 V 13.54 4.00 -4.24 13.3038.40 836.60 190 H 22.98 4.00 -4.24 22.7438.40 V 12.87 4.03 -4.33 12.5738.40 GPRS 850 E2 848.80 251 H 22.56 4.03 -4.33 22.2638.40 ERP = 23.04 dBm = 201.37 mW Power Density = ERP*Duty Cycle/(R 2 ) = 201.37*0.25/(4**20 2 ) = 0.010015 mW/cm 2 where Duty Cycle is 0.25 for GPRS operation (class 10) and R is 20 cm. The MPE limit for General Population/Uncontrolled Exposure is shown in the FCC OET Bulletin 65 Supplement C and can be calculated as follows: MPE limit = 824/1500 = 0.55 mW/cm 2 As we can see the resulted power density is below the MPE limit, therefore V120 in cellular band is compliant with the FCC rules on RF exposure. Operation in PCS band (1850 – 1910 MHz) The EIRP of V120 in PCS band is 18.71 dBm. max. The resulted EIRP can be expressed as follows: EUT Measurement Operation Band Pol. Fundamental Frequency CH Antenna Pol. S.G. Output Antenna Gain Cable Loss EIRPLimit MHz V/H dBm dBi dB dBm dBm V 16.38 4.17 -5.49 15.0733.00 1850.20 512 H 10.89 4.51 -5.49 9.92 33.00 V 18.04 4.13 -5.56 16.6133.00 1880.00 661 H 10.75 4.44 -5.56 9.62 33.00 V 20.17 4.09 -5.56 18.71 33.00 GPRS 1900 E2 1909.80 810 H 12.92 4.36 -5.56 11.7333.00 EIRP = 18.71 dBm = 74.30 mW Power Density = EIRP*Duty Cycle/(R 2 ) = 74.30*0.25/(4**20 2 ) = 0.003695 mW/cm 2 where Duty Cycle is 0.25 for GPRS operation (class 10) and R is 20 cm. The MPE limit for General Population/Uncontrolled Exposure is shown in the FCC OET Bulletin 65 Supplement C and can be calculated as follows: MPE limit = 1.0 mW/cm 2 As we can see the resulted power density is below the MPE limit, therefore V120 in PCS band is compliant with the FCC rules on RF exposure.

Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Report No.: EH/2011/A0034 FCC ID: XKVV120 Issue Date: Jan. 11, 2012 Page 1 of 57 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 22 SUBPART H, PART 24 SUBPART E OF Product Name: Assets GPS Tracker Brand Name: SAPLING Model No.: V120 Model Differences: N/A FCC ID: XKVV120 Report No.: EH/2011/A0034 Issue Date: Jan. 11, 2012 FCC Rule Part: 2 , 22H & 24E Prepared for: ADVANCE VISION ELECTRONICS CO., LTD. 6F., No. 199, Lide St., Jhonghe City, Taipei County, Taiwan, R.O.C. Prepared by: SGS Taiwan Ltd. Electronics & Communication Laboratory No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. per- sonnel only, and shall be noted in the revision section of the document. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Report No.: EH/2011/A0034 FCC ID: XKVV120 Issue Date: Jan. 11, 2012 Page 2 of 57 VERIFICATION OF COMPLIANCE Applicant: ADVANCE VISION ELECTRONICS CO., LTD. 6F., No. 199, Lide St., Jhonghe City, Taipei County, Taiwan, R.O.C. Product Name: Assets GPS Tracker Brand Name: SAPLING Model No.: V120 Model Different: N/A FCC ID: XKVV120 File Number: EH/2011/A0034 Date of test: Oct. 28, 2011 ~ Jan. 10, 2012 Date of EUT Received: Oct. 28, 2011 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. Electronics & Communication Laboratory The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA-603-C-2004 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rule FCC PART 22 subpart H, PART 24 subpart E. The test results of this report relate only to the tested sample identified in this report. Test By: Date: Jan. 11, 2012 Lion Wang / Engineer Prepared By: Date: Jan. 11, 2012 Celine Chou / Clerk Approved By: Date: Jan. 11, 2012 Jim Chang / Supervisor Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the trans…

Text truncated - open the document above for the full version.

FCC ID: XKVV120 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its inter- vention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unau- thorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Radiated Emission Setup Photos
