M7 System Proprietary and Confidential 1 28235591 NAD LT Box User Manual (Version 1.0) December 4, 2009 M7 SYstem Confidential M7 System Proprietary and Confidential 2 1. LT Box Block Diagram M7 SYstem Confidential M7 System Proprietary and Confidential 3 2. LT Box Picture <TOP VIEW> <BOTTOM VIEW> M7 SYstem Confidential M7 System Proprietary and Confidential 4 3. LT Box Interface ⓐ Main Power DC Jack:  DC 9V input. Plug in AC/DC Adaptor or Power Supply instruments (8V – 12V). Indicator turns red. ⓑ Sub Power DC Jack:  DC 4V input. Only for current drain measurement. ⓒ JTAG Interface :  ARM7 JTAG Interface. Connect Trace32 JTAG. Not used. ⓓ Main Power On/off Switch:  Power up NAD and Power On main power switch to turn-on LT. ⓔ Sub Power On/Off Switch:  Sub power switch is only for current drain measurement, otherwise turn off sub power switch. ⓕ 5V_PWR, MIC/SPK Select Switch:  To use 5V power, move “5V_PWR - MIC/SPK” switch to 5V_PWR. Then 5V_PWR indicator turns red. 5V power is for 28235591 NAD only.  For 28235591 NAD to be used in 28235591 LT BOX, move “5V_PWR - MIC/SPK” switch to MIC/SPK. And confirm that 5V_PWR indicator is off. If 5V power is on, 28235591 NAD can’t work normally or damaged.  To use analog audio of 28235591 NAD, move “5V_PWR - MIC/SPK” and “PCM - MIC/SPK” switch to MIC/SPK. ⓖ UART_DTR/ Switch:  Data input, Default High, Active Low. Toggle switch from high to low, it provides TCU processor active. Indicator turns green. ⓗ IG_IND/ Switch:  Data input, Default High, Active Low. Toggle switch from high to low, it provides ignition on. Indicator turns green. ⓘ PHONE_RST/ Switch:  Data input, Default High, Active Low. Press tact switch, It provides NAD reset. Indicator turns green. ⓙ PHONE_WU/ Switch:  While using the JTAG, press tact switch and NAD wake-up. Or press tact switch to turn-on NAD. Indicator turns green. M7 SYstem Confidential M7 System Proprietary and Confidential 5 ⓚ HW_SD/ Switch:  Data input, Default High, Active Low. Press tack switch, It provides NAD shut down. Indicator turns green. ⓛ 5V_PWR Indicator:  Move “5V_PWR - MIC/SPK” switch to 5V_PWR. Then 5V_PWR indicator turns red. ⓜ AUDIO_IN Jack: MIC  Audio input. Analog audio input from codec in LT. ⓝ Ear Jack 2.5mm:  2.5mm headset used. Analog audio input/output from codec in LT. ⓞ AUDIO_OUT Jack: Speaker  Audio Output. Analog audio output from codec in LT. ⓟ PCM, MIC/SPK Select Switch:  To use analog audio and PCM interface of 28235591 NAD. ⓠ SD_REQ/ Indicator:  Data output, Default High, Active Low. NAD requests hardware shutdown to TCU. Indicator turns yellow. ⓡ RI/ Indicator:  Data output, Default High, Active Low. Incoming call by NAD. Indicator turns yellow. ⓢ UART_TX Indicator:  Data output, Default Low, Active High. NAD sends signal to TCU. Indicator turns yellow. ⓣ UART_RX Indicator:  Data output, Default Low, Active High. NAD is received control signal from TCU. Indicator turns yellow. ⓤ CAIT_TX Indicator:  Data output, NA. NAD sends data to TCU. Indicator turns yellow. ⓥ CAIT_RX Indicator:  Data output, Default Low, Active High. NAD is received data from TCU. Indicator turns yellow. ⓦ UART1 (Interface to TCU):  NAD UART 1 port for TCU Interface. You can connect programs that use AT Commands. ⓧ UART2 (CAIT, QXDM):  NAD UART 2 port for CAIT, QXDM. You can connect programs.(CAIT,QXDM) M7 SYstem Confidential M7 System Proprietary and Confidential 6 ⓨ USB Socket:  USB port, USB to RS232 convertor in LT. When you want to use USB cable, plug in USB port, download USB Driver (VCP Driver: Virtual COM Port Driver “CDM2.00.00.zip”) at www.ftdichip.com and install. ⓩ RS-232 On/Off switch:  If you want to use serial cable for connecting UART1 and UART2, RS-232 switch On and USB switch Off. ① USB On/Off switch:  If you want to use USB cable for connecting UART1 and UART2, RS-232 switch Off and USB switch On. ② 30 Pin I/O Interface:  30 pin connector (bottom side) for NAD interface. M7 SYstem Confidential M7 System Proprietary and Confidential 7 4. LT Box Functions. 1) NAD Booting ① Plug in DC 9V power supply or AC/DC Adaptor(9V) in the DC power jack (ⓐ). ② Toggle main power switch from Off to On (ⓓ). ③ Press the PHONE_WU/ switch (ⓙ). ④ NAD booting. Notice: 1. Don’t plug in DC9V power supply at the Sub Power DC Jack (ⓑ). 2. Sub Power On/Off switch is usually Off (ⓔ). M7 SYstem Confidential M7 System Proprietary and Confidential 8 2) Audio test. Connect MIC at AUDIO_IN Port and SPK AUDIO_OUT Port. You can test Audio. 3) Using Tools. ① Hyper Terminal A. Click Hyper Terminal Program B. Insert the New Connection Name, Click OK Button M7 SYstem Confidential M7 System Proprietary and Confidential 9 C. Set up the Com port. D. Set up Bits per second(9600), Data bits(8), Pantry(Odd), Stop bits(1), Flow control (None). E. Click Apply and OK Button. M7 SYstem Confidential M7 System Proprietary and Confidential 10 F. You can use AT command. M7 SYstem Confidential M7 System Proprietary and Confidential 11 ② CAIT A. Click CAIT Program. B. In the Option, Click the Configure CAIT. C. Click the Phone and Set up the Com port, Baud rates. D. Click OK Button E. You can use CAIT. ③ UTPST - Refer to the “28235591_M7PST_User_Manual.pdf” M7 SYstem Confidential M7PST User’s Guide 1 M Seven System Proprietary M Seven System Product Support Tool Nov. 17, 2009 Restricted Distribution: T his document contains critical information about M Seven System products and may not be distributed to anyone that is not an employee of without the approval of R&D Management. M Seven System Ltd. 275-7, Trust Tower Bldg. YangJae 2-Dong, Seocho-Gu, Seoul, Korea. M7 System Confidential M7PST User’s Guide M Seven System Incorporated 275-7,Trust Tower Bldg . YangJae 2-Dong, Seocho Gu, Seoul, Korea. Copyright © 2009 M Seven System Incorporate d. All rights re served. All data and information contained in or disclosed by this document is confidential and proprietary information of M Seven System Incorporated, and all rights there…
