Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
www.tuv.com Test Report No.: 14030236 001 Appendix 3 page 2 of 6 External View External View www.tuv.com Test Report No.: 14030236 001 Appendix 3 page 3 of 6 External View External View
www.tuv.com Test Report No.: 14030236 001 Appendix 4 page 2 of 14 1.1 FCCID Label Artwork The yellow oval shows the location of the Rating Label
www.tuv.com Test Report No.: 14030236 001 Appendix 3 page 4 of 6 Internal View Internal View www.tuv.com Test Report No.: 14030236 001 Appendix 3 page 5 of 6 Internal View Internal View www.tuv.com Test Report No.: 14030236 001 Appendix 3 page 6 of 6 Internal View
www.tuv.com Test Report No.: 14030236 001 Date: 31.07.2012 page 2 of 15 Table of Content Page Cover Page .................................................................................1 Table of Content ..........................................................................2 Product information ......................................................................................................3 Manufacturers declarations........................................................................................................................3 Product function and intended use ...........................................................................................................4 Submitted documents .................................................................................................................................4 Remark..........................................................................................................................................................4 Special accessories and auxiliary equipment ..........................................................................................4 List of Test and Measurement Instruments.................................................................5 Results FCC Part 15 β Subpart C .................................................................................6 Subclause 15.203 β Antenna Information........................................................................Pass .................6 Subclause 15.204 β Antenna Information........................................................................Pass .................6 Subclause 15.207 β Disturbance Voltage on AC Mains .................................................Pass .................6 Subclause 15.247 (a)(1) β Carrier Frequency Separation ..............................................Pass .................7 Subclause 15.247 (a)(1)(iii) β Number of hopping channels..........................................Pass .................7 Subclause 15.247 (a)(1)(iii) β Time of Occupancy (Dwell Time) ....................................Pass .................8 Subclause 15.247 (a) β 20 dB Bandwidth ........................................................................Pass .................8 Subclause 15.247 (a) β Hopping Sequence.....................................................................Pass .................9 Subclause 15.247 (a) β Equal Hopping Frequency Use .................................................Pass ...............10 Subclause 15.247 (a) β Receiver Input Bandwidth .........................................................Pass ...............11 Subclause 15.247 (a) β Receiver Hopping Capability ....................................................Pass ...............11 Subclause 15.247 (b)(1) β Peak Output Power................................................................Pass ...............11 Subclause 15.247 (d) β Band edge compliance of conducted emissions ...................Pass ...............12 Subclause 15.205 β Band edge compliance of radiated emissions ............................Pass ...............12 Subclause 15.247 (d) β Spurious Conducted Emissions...............................................Pass...............13 Subclause 15.247 (c) β Spurious Radiated Emissions ..................................................Pass ...............14 Appendix 1 β Test protocols 26 pages Appendix 2 β Test setup 2 pages Appendix 3 β Photo documentation 6 pages Appendix 4 β Product documentation 14 pages www.tuv.com Test Report No.: 14030236 001 Date: 31.07.2012 page 3 of 15 Product information Manufacturers declarations Transceiver Operating frequency range 2402 - 2480 MHz Type of modulation GFSK; Pi/4 DQPSK; 8 DPSK Number of channels 79 Channel separation 1 MHz Type of antenna Chip antenna Antenna gain (dBi) 0 Power level fix Type of equipment stand alone radio device Connection to public utility power line No Nominal voltage V nor : 5.0V Independent Operation Modes Page scan Inquiry scan Connection state - ACL Link Connection state - SCO Link www.tuv.com Test Report No.: 14030236 001 Date: 31.07.2012 page 4 of 15 Product function and intended use The test item is a Bluetooth audio receiver based on the Bluetooth technology. Bluetooth is a short-range radio link intended to be a cable replacement between portable and/or fixed electronic devices. Bluetooth operates in the unlicensed ISM Band at 2.4GHz. With the introduction of the enhanced data rate (EDR) feature, the data rates can be up to 3 Mb/s. An increase in the peak data rate beyond the basic rate of 1 Mb/s is achieved by modulating the RF carrier using phase shift keying (PSK) techniques, resulting in an increase of two to three times the number of bits per symbol. The 2 Mb/s EDR packets use a Pi/4-DQPSK modulation and the 3 Mb/s EDR packets use 8DPSK modulation. The USB connector is for charging only, no data exchange supported. Submitted documents Circuit Diagram Block Diagram Bill of material User Manual Label Artwork Remark Preliminary tests were performed in different data rate to find the worst radiated emission. The data rate shown in the table below is the worst-case rate with respect to the specific test item. Investigation has been done on all the possible configurations for searching the worst cases. Special accessories and auxiliary equipment Test Setup Since an audio gateway is required to setup a Bluetooth SCO link, Apple iPod Touch, which provided by client, was used in the immunity test to act as an audio gateway. Additional accessory used for testing The product has been tested together with the following additional accessory: AC/DC Power adaptor Model number: KSD10-050-1000 Input: 100-240VAC, 50/60Hz, 300mA Output: 5VDC 1000mA www.tuv.com Test Report No.: 14030236 001 Date: 31.07.2012 page 5 of 15 List of Test and Measurement Instruments Hong Kong Productivity Council (Registration number: 90656) Equipment used Manufacturer Model No. S/N Due Date Semi-anechβ¦
Text truncated - open the document above for the full version.
www.tuv.com Test Report No.: 14030236 001 Appendix 2 page 2 of 2 Setup for Radiated Emission Setup for Radiated Emission
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 90.00 Β΅W |
