XRF-NETNODEP41W

Domo Tactical Communications

IP Mesh radio with amplifier

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Feb 10, 2020
Application Purpose: Original Equipment
Date of Application: Feb 10, 2020
Equipment Note: IP Mesh radio with amplifier
Frequency Range: 2454.00000000 - 2479.00000000
Company: Domo Tactical Communications
Country: United Kingdom

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Test Report

Contact Information

Applicant

Greg M Harris(Mr)

[email protected]1489884551Fax: +44 1489880538

Technical Contact

Sulis Consultants LtdCharlie J Blackham

[email protected]07946624317

Mead House · Eversley · United Kingdom

Test Firm

RN Electronics LtdClint Hilling

[email protected]+44 1277 352219

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	90	2.45 GHz - 2.48 GHz	860.00 mW	5M56D2D	2.3800000000 ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. This device must operate with the specific antennas shown in this filing. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance requirements.
