XRZKD07011 to 10 RC CAR(Shadow Striker)

TIP: PULL THE THROTTLE TRIGGER SLOWLY TO EXPERIENCE SPEED. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

DATE : May 19, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XRZKD0701 Product Name: 1 to 10 RC CAR(Shadow Striker) Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Agency agreement expiration date: May 19, 2015 to May 18, 2016 By: Sunny Sun Signature Printed Title: Sales Mana ger On behalf of : KidsRock Limited Telephone: +852-6944 6418

Label information: F FCC ID: XRZKD0701

Report No. : EED32H000542-1 Page 1 of 17 FCC TEST REPORT Product : 1:10 RC CAR(Shadow Striker) Trade mark : N/A Model/Type reference : KD0701(5F62DB5) FCC ID : XRZKD0701 Report Number : EED32H000542-1 Date : May 19, 2015 Regulations : See below Prepared for KidsRock Limited Unit 08A, 25/F Gammon House, 12 Harcourt Road, Admiralty, Hong Kong Prepared by Centre Testing International Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by:Reviewed by: Approved by: Date:May 19, 2015 Jimmy Li Lab manager Check No.: 1727851003 Test Standards Results 47 CFR FCC Part 15 Subpart C 15.249: 2014 PASS Report No. : EED32H000542-1 Page 2 of 17 TABLE OF CONTENTS 1. GENERAL INFORMATION ......................................................................................... 3 2. TEST SUMMARY ........................................................................................................ 3 3. MEASUREMENT UNCERTAINTY .............................................................................. 4 4. TEST EQUIPMENT LIST ............................................................................................. 4 5. SUPPORT EQUIPMENT LIST .................................................................................... 4 6. PRODUCT INFORMATION ......................................................................................... 4 7. 20DB/ 99% BANDWIDTH MEASUREMENT .............................................................. 5 7.1 LIMITS ............................................................................................................ 5 7.2 BLOCK DIAGRAM OF TEST SETUP ............................................................ 5 7.3 TEST PROCEDURE ....................................................................................... 5 7.4 TEST RESULT................................................................................................ 5 8. RADIATED EMISSIONS MEASUREMENT ................................................................ 9 8.1 LIMITS ............................................................................................................ 9 8.2 BLOCK DIAGRAM OF TEST SETUP ............................................................ 9 8.3 TEST PROCEDURE ..................................................................................... 10 8.4 TEST RESULT.............................................................................................. 11 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................... 14 APPENDIX 2 PHOTOGRAPHS OF EUT ...................................................................... 15 (Note: N/A means not applicable) Report No. : EED32H000542-1 Page 3 of 17 1. GENERAL INFORMATION The above equipment was tested by Centre Testing International (Shenzhen) Corporation for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart C and the measurement procedure according to ANSI C63.4:2009 and ANSI C63.10:2009. 2. TEST SUMMARY The complete list of measurements is given below: No.Test Item RuleResult 1 20dB/ 99% Bandwidth FCC 15.215(c) 7& RSS-Gen 4.6.1 PASS 2 Radiated Emission FCC 15.249 & A2.9 PASS 3 AC Conducted Emission FCC PART15.207 & RSS-Gen 7.2.4 N/A 4 Antenna Requirements *FCC 15.203 & RSS-Gen 7.1.2 PASS 1. According to Section 15.203 and RSS-Gen 7.1.2, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The EUT has a built in antenna which is a short wire solder on the PCB, this is permanently attached antenna and meets the requirements of this section. 2. New battery is used during all the test. Applicant: KidsRock Limited Unit 08A, 25/F Gammon House, 12 Harcourt Road, Admiralty, Hong Kong Manufacturer: KidsRock Limited Unit 08A, 25/F Gammon House, 12 Harcourt Road, Admiralty, Hong Kong FCC ID: XRZKD0701 Product: 1:10 RC CAR(Shadow Striker) Trade mark: N/A Model/Type reference: KD0701(5F62DB5) Serial Number: N/A Report Number: EED32H000542-1 Sample Received Date: Apr. 11, 2015 Sample tested Date: Apr. 11, 2015 to May 19, 2015 Report No. : EED32H000542-1 Page 4 of 17 3. MEASUREMENT UNCERTAINTY This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement itemsUncertainty Radiated Emissions 4.5 dB 4. TEST EQUIPMENT LIST EquipmentManufacturerModelSerial No. Due Date 3M Chamber & Accessory Equipment TDK SAC-3 --- 06/01/2016 Receiver R&S ESCI 100435 07/08/2015 Receiver R&S ESCI 100435 07/08/2015 TRILOG Broadband Antenna schwarzbeck VULB 9163 617 07/13/2015 Multi device Controller maturo NCD/070/10711 112 --- N/A Horn Antenna ETS-LINGREN 3117 00057407 07/07/2015 Microwave Preamplifier Agilent 8449B 3008A02425 01/28/2016 Spectrum Analyzer R&S FSP40 100416 07/06/2015 5. SUPPORT EQUIPMENT LIST No.Device Type Brand Model Series No. Data Cable Power Cord ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- 6. PRODUCT INFORMATION ItemsDescription Rating DC 3V Intentional Transceiver Intentional Transmitter Modulation GFSK Frequency Range 2.406̚2.480GHz Channel Number 16 Type Integrate Antenna Antenna Gain 2.54dBi Connector fixed on board Report No. : EED32H000542-1 Page 5 of 17 7. 20DB/ 99% BANDWIDTH MEASUREMENT 7.1 LIMITS None 7.2 BLOCK DIAGRAM OF TEST SETUP 7.3 TEST PROCEDURE 1. The transmitter output (antenna port) was connected to the spectrum analyzer. 2. Set spectrum analyzer’s RBW and VBW to applicable value with Peak in Max Hold. 3. A PEAK output reading and 20dB/99% BW function in spectrum analyzer were taken. 7.4 TEST RESULT 20dB Bandwidth: ChannelFrequency (GHz) 20 dB BW (MHz) 99% BW (MHz) Low2.406 1.91 2.64 Middle2.443 1.52 1.69 High2.480 1.88 2.12 2.46 Report No. : EED32H000542-1 Page 6 of 17 Please see the following plots: 20dB BW: Ref 20 dBmAtt 30 dB * * * 1 PK MAXH A 3DB RBW 100 kH…
