XUJCRPHDAAutomotive diagnosis computer

Launch Tech Co., Ltd.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Oct 07, 2014
Application Purpose: Original Equipment
Date of Application: Oct 07, 2014
Equipment Note: Automotive diagnosis computer
Company: Launch Tech Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Version: V1.00.000 Revised date: 08-29-2014 II LAUNCH CRP-HD User's Manual Copyright Information Copyright © 2013 by LAUNCH TECH. CO., LTD. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of LAUNCH. The information contained herein is designed only for the use of this unit. LAUNCH is not responsible for any use of this information as applied to other units. Neither LAUNCH nor its affiliates shall be liable to the purchaser of this unit or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: Accident, misuse, or abuse of this unit, or unauthorized modifications, repairs, or alterations to this unit, or failure to strictly comply with LAUNCH operating and maintenance instructions. LAUNCH shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original LAUNCH Products or LAUNCH Approved Products by LAUNCH. Trademark Information LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (also called LAUNCH for short) in China and other countries. All other LAUNCH trademarks, service marks, domain names, logos, and company names referred to in this manual are either trademarks, registered trademarks, service marks, domain names, logos, company names of or are otherwise the property of LAUNCH or its affiliates. In countries where any of the LAUNCH trademarks, service marks, domain names, logos and company names are not registered, LAUNCH claims other rights associated with unregistered trademarks, service marks, domain names, logos, and company names. Other products or company names referred to in this manual may be trademarks of their respective owners. You may not use any trademark, service mark, domain name, logo, or company name of LAUNCH or any third party without permission from the owner of the applicable trademark, service mark, domain name, logo, or company name. You may contact LAUNCH by visiting the website at www.cnlaunch. com, or writing to LAUNCH TECH. CO., LTD., Launch Industrial Park, North of Wuhe Avenue, Banxuegang, Bantian, Longgang, Shenzhen, Guangdong, P.R.China, to request written permission to use Materials on this manual for purposes or for all other questions relating to this manual. Safety Precautions Before using CRP-HD, please read the following safety information carefully. Never collide, throw, or punch CRP-HD, and avoid falling, extruding and • blending it. Do not use CRP-HD in exceptionally cold or hot, dusty, damp or dry • environments. To ensure a safe driving, please do not use CRP-HD while driving.• Turn off CRP-HD before boarding any airplane. • Do not dismantle CRP-HD by yourself. If there is any inquiry, please • contact the dealer. Never place CRP-HD into apparatus with strong electromagnetic field.• Keep CRP-HD far away from magnetic devices because its radiations • may erase the data stored on CRP-HD. Store CRP-HD out of reach of children and do not allow children to use • LAUNCH CRP-HD User's Manual III it unsupervised. Please use the included battery and charger. Otherwise, explosion may • happen. Do not disconnect power abruptly when CRP-HD is being formatted or • in process of uploading or downloading. Or else it may result in program error. Precautions on Operating Vehicle’s ECU Do not disconnect battery or any wiring cables in the vehicle when the • ignition switch is on, as could avoid damage to the sensors or the ECU. Do not place any magnetic objects near the ECU. Cut off the power • supply to the ECU system before performing any welding operations on the vehicle. Use caution when performing any operations near the ECU or sensors.• Ground yourself when you disassemble PROM, otherwise ECU and sensors can be damaged by static electricity. When reconnecting the ECU harness connector, be sure it is attached • firmly, otherwise electronic elements, such as ICs inside the ECU, can be damaged. Table of Contents 1 Introduction ...........................................................................................1 1.1 Product Profile .....................................................................................1 1.2 Features ..............................................................................................1 1.3 Technical Specifications ......................................................................1 2 Knowledge of CRP-HD .........................................................................2 2.1 CRP-HD Display Tablet .......................................................................2 2.2 CRP-HD Accessory Checklist..............................................................3 3 Preparations..........................................................................................4 3.1 Charging CRP-HD ...............................................................................4 3.2 On Using Your Battery .........................................................................4 3.3 Power On / Power Off CRP-HD ..........................................................4 3.3.1 Power on .....................................................................................4 3.3.2 Power off .....................................................................................4 3.4 Tips On Finger Operations ..................................................................4 3.5 Lock & unlock the screen ....................................................................4 3.5.1 Lock the screen ...........................................................................5 3.5.2 Unlock the screen ........................................................................5 3.6 Screen Layout .....................................................................................5 3.7 Status Bar .............…

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Launch Tech Co., Ltd. 2014/9/28 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ Launch Tech Co., Ltd. _____hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): (Product description: Automotive diagnosis computer, model name: Creader professional HD, CRP HD,CRP-HD ) FCC ID : XUJCRPHDA We affirm that between SIEMIC, Inc. and ____ Launch Tech Co., Ltd. ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Yibing Xue/ Manager Contact information / address : Launch Industrial Park, North of Wuhe Rd., Banxuegang, Longgang, Shenzhen, China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Launch Tech Co., Ltd. 2014/9/28 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: XUJCRPHDA We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Yibing Xue/ Manager Contact information / address : Launch Industrial Park, North of Wuhe Rd., Banxuegang, Longgang, Shenzhen, China

Cover Letter(s)

Launch Tech Co., Ltd. To：SIEMIC , 775 Montague Expressway, Milpitas, CA 95035,USA Declaration Letter Dear Sir， For our business issue and marketing requirement, we would like to list the following model numbers on The FCC certificates and reports, as following: Model No.: Creader professional HD, CRP HD，CRP-HD We declare that the difference of these is listed as below Main Model No Serial Model No Difference Creader professional HD CRP HD CRP-HD Abbreviation Thank you! Client’s signature： Client’s name / title： Contact information / address：Launch Industrial Park, North of Wuhe Rd., Banxuegang, Longgang, Shenzhen, China Yibing Xue /Manager/Manager

External Photos

ID Label/Location Info

Label location

Internal Photos

Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 23 of 36 www.siemic.com www.siemic.com.cn Annex B.i. Photograph 2: EUT Internal Photo Cover Off - Top View 1 Cover Off - Top View 2 Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 24 of 36 www.siemic.com www.siemic.com.cn Cover Off - Top View 3 Mainboard - Top View Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 25 of 36 www.siemic.com www.siemic.com.cn Mainboard - Rear View RF PCB with Shielding- Top View Antenna View Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 26 of 36 www.siemic.com www.siemic.com.cn RF PCB without Shielding- Top View RF PCB - Rear View Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 27 of 36 www.siemic.com www.siemic.com.cn LCD Board – Front View LCD Board – Reart View Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 28 of 36 www.siemic.com www.siemic.com.cn Battery - Front View Battery - Rear View

Test Report

Launch Tech Co., Ltd. Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD September 28, 2014 Report No.: 14070314-FCC-E1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Kahn Yang Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 2 of 36 www.siemic.com www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 3 of 36 www.siemic.com www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 4 of 36 www.siemic.com www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS.......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS................................................................... 9 ANNEX A. TEST INSTRUMENTATION & GENERAL PROCEDURES ............................................................. 14 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 19 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 31 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................. 35 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 36 Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 5 of 36 www.siemic.com www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Launch Tech Co., Ltd., Automotive Diagnosis Computer and Model: Creader professional HD against the current Stipulated Standards. The Automotive Diagnosis Computer has demonstrated compliance with the FCC Part 15 Subpart B Class B: 2013, ANSI C63.4: 2009. EUT Information EUT Description : Automotive Diagnosis Computer Main Model : Creader professional HD Serial Model CRP HD, CRP-HD (The difference between Main Model and Serial Model is only model number) Antenna Gain : WIFI: 2.5 dBi Input Power : Adapter: Model: HKC0055010-2A Input: 100-240V; 50/60Hz 0.15A Output: 5V; 1.0A Battery: Model: Creader professional 229 Spec: 3.8V 3000mAh Limited charger voltage: 4.35V Classification Per Stipulated Test Standard : Class B Emission Product Per FCC Part 15 Subpart B Class B: 2013, ANSI C63.4: 2009 Title: EMC Test Report for Automotive Diagnosis Computer Main Model: Creader professional HD Serial Model: CRP HD, CRP-HD To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 14070314-FCC-E1 Issue Date: September 28, 2014 Page: 6 of 36 www.siemic.com www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Automotive Diagnosis Computer with stipulated standards Applicant / Client Launch Tech Co., Ltd. Launch Industrial Park, North of Wuhe Rd., Banxuegang, Longgang, Shenzhen, China Manufacturer Launch Tech Co., Ltd. Launch Industrial Park, North of Wuhe Rd., Banxuegang, Longgang, Shenzhen, China Laboratory performing the tests SIEMIC (Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 14070314-FCC-E1 Date EUT received September 1…

Text truncated - open the document above for the full version.

Test Setup Photos
