XX6SER8010DMR Repeater

Installation and Operation Guide DMR Repeater For SBR8000 / SCR8000 / SER8000 Installation and Operation Guide 1 General This guide contains the installation and basic operating instructions for the DMR Repeater models SBR8000, SCR8000 and SER8000. This guide does not contain information relating to the installation of accessories such as the antenna and duplexer. Refer to the installation instructions supplied with these accessories for further safety and installation instructions. Disclaimer notice Sepura’s policy is to continually improve its products. The features and facilities described in this document were correct at publication, but are subject to change without notice. Contact Us Sepura plc. Radio House, St Andrew’s Road, Cambridge CB4 1GR United Kingdom Tel: +44 (0)1223 876000 Fax: +44 (0)1223 879000 © Sepura plc. 2014 SPR-DOC-03800/2 Original Instructions: ENGLISH All rights reserved. This document is intended for the use of Sepura plc’s customers and/or other parties only for the purposes of the agreement or arrangement under which this document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written permission of Sepura plc. Contents Safety ................................................................................................. 2 Regulatory ........................................................................................ 3 Repeater technical specifications .................................................. 4 Duplexer technical specifications ................................................. 5 Controls, connectors and components ......................................... 7 Status indicators .............................................................................. 7 Unpacking ........................................................................................ 8 Accessory information .................................................................... 8 Installation ....................................................................................... 8 Connections .................................................................................... 10 Basic operation ............................................................................... 11 Configuring the Repeater ............................................................ 12 Caring for your product ................................................................ 12 2 DMR Repeater SBR8000, SCR8000, SER8000 Safety Read these safety instructions carefully. Attention! Sepura products are intended for use in occupational/controlled conditions. It is the responsibility of the person operating the product to ensure that it is operated safely at all times, and that local laws and regulations governing the usage of Radio Frequency (RF) products are observed. Obey all signs and instructions relating to the usage to RF wireless devices. It is recommended that you obtain training on how to safely operate this product. Your personal safety could be affected if you do not understand how to operate this product correctly. This product must not be operated in environments that exceed those listed in the product technical datasheet and in the Regulatory section of the product user guide. Unauthorised modifications to the product could cause the product to become non-operational. Always use Sepura approved antenna, battery and accessories with this product. Exposure to RF energy Sepura designs and manufactures products to meet strict guidelines and international standards relating to Radio Frequency (RF) energy and the potential health risks associated with using such products. If you have any concerns about potential health risks associated with long term exposure to RF energy, you should obtain advice from your employer. RF energy interference with electronic equipment Some personal medical devices, such as hearing aids and pacemakers, can be affected by RF energy. Always consult your service provider or the manufacturer of the medical device before using RF wireless devices. Important safety notes about the Antenna NEVER touch the antenna when the repeater is transmitting, this may cause a minor burn to the skin and may affect the operational range of the antenna. NEVER use your repeater without an antenna attached. Transmitting without an antenna may damage the product. Only use a Sepura approved antenna with your repeater. The antenna must be installed and operated with a minimum distance of 1.2m to any person. This distance has been calculated based on a 2dB cable loss between radio and antenna. Accessories Sepura products have been tested to meet strict guidelines for personal safety and operational conditions. Only accessories approved by Sepura are recommended for use with this product. Always read the instructions supplied with the accessory for additional safety instructions. The use of non-approved accessories may invalidate any product warranty. If a non-approved accessory is fitted, it may compromise the product safety ratings. Safe installation CAUTION! This product has double pole/neutral fusing. Installation and Operation Guide 3 Servicing Do not attempt to dismantle this product. Servicing and repairs to this product must be performed by trained service technicians at Sepura approved service centres Regulatory Sepura declares that this product is complaint with the essential requirements and other relevant provisions of the European R&TTE directive 1999/5/EC relating to radio and telecommunications terminal equipment and the mutual recognition of their conformity. This product is also compliant with directive 2011/65/EU having been designed and manufactured to the RoHS requirements. Waste Electrical and Electronic Equipment recycling This symbol on the product or its packaging indicates that this product must not be disposed of as household or commercial waste. Some countries have set up collection and recycling systems for waste electr…

Text truncated - open the document above for the full version.

Statement of Voice Channel for FCC ID: XX6SER8010 Dear Sir or Madam We, Sepura plc, hereby declare that our product: DMR Repeater (FCC ID: XX6SER8010), covered by this certification is capable of supporting a voice channel and a minimum data rate of 4800 bits per second per 6.25kHz of channel bandwidth. Yours faithfully, Steve Wood Verification Engineering Team Leader 04 March 2015

FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 19 November 2014 FCC Agent Authorization To whom it may concern We, Sepura plc, the undersigned, hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from Sepura plc. Yours faithfully, Steve Wood Verification Engineering Team Leader

FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 08 January 2015 FCC Confidential Authorization Dear Sir or Madam Confidentiality Request regarding application for certification of FCC ID: XX6SER8010 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below:  Detailed Circuit Schematics of EUT --- (Long term)  Block Diagram --- (Long term)  Circuit Description --- (Long term)  Part List --- (Long term)  Tune up --- (Long term) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Yours faithfully, Steve Wood Verification Engineering Team Leader

Date: 2015-01-08 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 Subject: Extended Frequency Justification. Dear Sir/Madam, The DMR Repeater with FCC ID: XX6SER8010 was designed to operate in the frequency bands 136~174MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for certification, Sepura plc is requesting that the FCC lists the frequencies 136~174MHz, under FCC Rules Parts 22 and 90 on the FCC Grant. Sepura plc attests that the repeater will not be marketed to USA users with the frequency band which is not allowed by the rule part 22 and 90. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Also, equipment programming is the responsibility of Authorized Service Personnel, the DMR repeater complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Sincerely, Company Officer: Steve Wood Telephone Number: +44 (01223) 877354 Email: [email protected] Position: Verification Engineering Team leader Frequency Range (MHz） FCC Rule Part 136-150.8 MHz For Federal 150.8-152.855MHz FCC Part 22/90 152.855-154MHz FCC Part 90 154-156.2475MHz FCC Part 90 157.1875-157.45MHz FCC Part 90 157.45-161.575MHz FCC Part 22/90 161.575-161.625MHz FCC Part 22 161.625-161.775MHz FCC Part 22 161.755-161.9625MHz FCC Part 90 162.0375-173.2MHz FCC Part 90 173.2-173.4MHz FCC Part 90 173.4-174MHz For Federal

Page 1 of 4 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT-All View EUT-Top View Page 2 of 4 EUT-Bottom View EUT-Front View Page 3 of 4 EUT-Rear View EUT-Left Side View Page 4 of 4 EUT-Right Side View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

Page 1 of 12 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT-Uncover View 1 EUT-Uncover View 2 Page 2 of 12 EUT-Uncover View 3 EUT-Uncover View 4 Page 3 of 12 EUT- Main Board Top View EUT- Main Board Top Shielding off View Page 4 of 12 EUT- Main Chip View EUT- Main Board Bottom View Page 5 of 12 EUT- Main Board Bottom Shielding off View EUT-TX Module Uncover View Page 6 of 12 EUT-TX Module Board Top View EUT-TX Module Board Bottom View Page 7 of 12 EUT-RX Module Uncover View EUT-RX Module Board Top View Page 8 of 12 EUT-RX Module Board Bottom View EUT- Amplifier Module Uncover View 1 Page 9 of 12 EUT- Amplifier Module Uncover View 2 EUT- Amplifier Module Board Top View Page 10 of 12 EUT- Amplifier Module Board Bottom View EUT- AC Power Box Label View Page 11 of 12 EUT- Power Controller Board Top View EUT- Power Controller Bottom View Page 12 of 12 EUT-LED Board Top View EUT- LED Board Bottom View

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG140724008-00 FCC Part 22 and 90 Page 8 of 41 FCC §1.1310 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to 1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E|, |H| or S (minutes) 0.3- 3.0 614 1.63 (100)* 6 3.0 - 30 1842/f 4.89/f (900/f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 / / f/300 6 1500-100,000 / / 5 6 f = frequency in MHz * = Plane-wave equivalent power density MPE Calculation Predication of MPE limit at a given distance S = PG/4πR 2 Where: S = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Frequency Conducted Output Power Typical Antenna GainDistancePower Density Limit MHz mW dBi numeric cm mW/cm 2 mW/cm 2 155 45000 0 1.0 120 0.249 1.0 Radio Exposure Statement: To comply with FCC RF exposure requirements, a minimum separation distance of 1.2m is required between antenna and people. Result: Compliant.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 22 AND 90 TEST REPORT For Sepura plc Radio House, St. Andrews Road, Cambridge CB4 1GR, UK FCC ID: XX6SER8010 Report Type: Original Report Product Type: DMR Repeater Test Engineer: Dean Liu Report Number: RDG1 40724008-00 Report Date: 2014 -08-18 Reviewed By: Sula Huang RF Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG140724008-00 FCC Part 22 and 90 Page 2 of 41 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 4 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 FCC §1.1310 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ............................................................................... 8 APPLICABLE STANDARD .............................................................................................................................................. 8 FCC §2.1046 &§ 22.727 & §90.205- RF OUTPUT POWER .................................................................................... 9 APPLICABLE STANDARD .............................................................................................................................................. 9 TEST PROCEDURE ........................................................................................................................................................ 9 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 9 TEST DATA .................................................................................................................................................................. 9 FCC §2.1047 & §90.207 - MODULATION CHARACTERISTIC .......................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 TEST PROCEDURE ...................................................................................................................................................... 11 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 11 TEST DATA ................................................................................................................................................................ 11 FCC §2.1049& §22.357 & § 22.731 &§90.209 & §90.210 – OCCUPIED BANDWIDTH & EMISSION MASK 17 APPLICABLE STANDARD ............................................................................................................................................ 17 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 18 TEST DATA ................................................................................................................................................................ 18 FCC §2.1051 & §22.861 & §90.210 - SPURIOUS EMISSIONS AT ANTENNA TERMINALS .......................... 26 APPLICABLE STANDARD ............................................................................................................................................ 26 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 26 TEST PROCEDURE ...................................................................................................................................................... 27 TEST DATA ................................................................................................................................................................ 27 F…

Text truncated - open the document above for the full version.

Page 1 of 1 EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission View (Below 1 GHz) Radiated Emissions View (Above 1 GHz)
