XX6SER8050DMR Repeater

Installation and Operation Guide DMR Repeater For SBR8000 / SCR8000 / SER8000 Installation and Operation Guide 1 General This guide contains the installation and basic oper ating instructions for the DMR Repeater models SBR8000, S CR8000 and SER8000. This guide does not contain informatio n relating to the installation of accessories such as the ante nna and duplexer. Refer to the installation instructions su pplied with these accessories for further safety and installati on instructions. Disclaimer notice Sepura’s policy is to continually improve its produ cts. The features and facilities described in this document were correct at publication, but are subject to change without noti ce. Contact Us Sepura plc. Radio House, St Andrew’s Road, Cambridge CB4 1GR United Kingdom Tel: +44 (0)1223 876000 Fax: +44 (0)1223 879000 © Sepura plc. 2014 SPR-DOC-03800/2a Original Instructions: ENGLISH All rights reserved. This document is intended for the use of Sepura plc’s customers and/or other parties only for the purposes of the a greement or arrangement under which this document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written perm ission of Sepura plc. Contents Safety ............................................ ................................................... .. 2 Regulatory ........................................ ................................................ 3 Repeater technical specifications ................. ................................. 4 Duplexer technical specifications ................. ................................ 5 Controls, connectors and components ............... .......................... 7 Status indicators ................................. ............................................. 7 Unpacking ......................................... ............................................... 8 Accessory information ............................. ....................................... 8 Installation ...................................... ................................................. 8 Connections ....................................... ............................................. 10 Basic operation ................................... ............................................ 11 Configuring the Repeater .......................... .................................. 12 Caring for your product ........................... ..................................... 12 2 DMR Repeater SBR8000, SCR8000, SER8000 Safety Read these safety instructions carefully. Attention! Sepura products are intended for use in occupationa l/controlled conditions. It is the responsibility of the person operating th e product to ensure that it is operated safely at all times, and that local laws and regulations governing the usage of Radio Freque ncy (RF) products are observed. Obey all signs and instructi ons relating to the usage to RF wireless devices. It is recommended that you obtain training on how t o safely operate this product. Your personal safety could be affected if you do not understand how to operate this product c orrectly. This product must not be operated in environments t hat exceed those listed in the product technical datasheet and in the Regulatory section of the product user guide. Unauthorised modifications to the product could cau se the product to become non-operational. Always use Sepur a approved antenna, battery and accessories with this product. Exposure to RF energy Sepura designs and manufactures products to meet st rict guidelines and international standards relating to Radio Frequency (RF) energy and the potential health risk s associated with using such products. If you have any concerns about potential health risks associated with long term ex posure to RF energy, you should obtain advice from your employer . RF energy interference with electronic equipment Some personal medical devices, such as hearing aids and pacemakers, can be affected by RF energy. Always co nsult your service provider or the manufacturer of the medical device before using RF wireless devices. Important safety notes about the Antenna NEVER touch the antenna when the repeater is transm itting, this may cause a minor burn to the skin and may aff ect the operational range of the antenna. NEVER use your repeater without an antenna attached . Transmitting without an antenna may damage the prod uct. Only use a Sepura approved antenna with your repeat er. The antenna must be installed and operated with a m inimum distance of 1.2m to any person. This distance has b een calculated based on a 2dB cable loss between radio and antenna , 0dBi antenna gain and maximum target output power of all radio models. Accessories Sepura products have been tested to meet strict gui delines for personal safety and operational conditions. Only ac cessories approved by Sepura are recommended for use with thi s product. Always read the instructions supplied with the accessory for additional safety instructions. The use of non-approved accessories may invalidate any product warranty. If a non-approved accessory is fi tted, it may compromise the product safety ratings. Safe installation CAUTION! This product has double pole/neutral fusing. Installation and Operation Guide 3 Servicing Do not attempt to dismantle this product. Servicing and repairs to this product must be performed by trained servic e technicians at Sepura approved service centres Regulatory Sepura declares that this product is complaint with the essential requirements and other relevant provisions of the European R&TTE directive 1999/5/EC relating to radio and telecommunications terminal equipment and the mutua l recognition of their conformity. This product is al so compliant with directive 2011/65/EU having been designed and manufactured to the RoHS requirements. Waste Electrical and Electronic Equipment recycling This symbol on the product or its packaging indicat es that this product must not…

Text truncated - open the document above for the full version.

Statement of Voice Channel Support To whom it may concern We, Sepura plc, hereby declare that the following products covered by their relevant certifications are capable of supporting a voice channel and a minimum data rate of 4800 bits per second per 6.25kHz of channel bandwidth. Product FCC ID DMR Repeater XX6SER8010 DMR Repeater XX6SER8040 DMR Repeater XX6SER8050 DMR Mobile Radio XX6SEM8010 DMR Mobile Radio XX6SEM8040 DMR Mobile Radio XX6SEM8050 DMR Mobile Radio XX6SEM8010H DMR Mobile Radio XX6SEM8040H DMR Mobile Radio XX6SEM8050H DMR Two Way Radio XX6SEP8010 DMR Two Way Radio XX6SEP8040 DMR Two Way Radio XX6SEP8050 Yours faithfully, Steve Wood Verification Engineering Team Leader 10 November 2015

BACL Reference: QA-FR-170-B FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 21 August 2015 FCC Authorization To whom it may concern We, Sepura plc, the undersigned, hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from Sepura plc. Yours faithfully, Steve Wood Verification Engineering Team Leader

BACL Reference: QA-FR-171-A FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 21 August 2015 FCC Confidential Authorization Dear Sir or Madam RE: Confidentiality Request regarding application for certification of FCC ID: XX6SER8050 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Sepura plc, hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram --- (Long term)  Circuit Description --- (Long term)  Schematic --- (Long term)  Parts list --- (Long term)  Tune up procedure --- (Long term) The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Yours faithfully, Steve Wood Verification Engineering Team Leader

FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 10 November 2015 FCC Part 90 Section 203 (e) (g) Declaration To whom it may concern We, Sepura plc, hereby declare that the following products covered by their relevant certifications meet the requirements of the FCC Rules, Parts 90.203(e) and (g), as applicable. Programming of these products’ transmit frequencies can be performed only by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment’s external operation controls. Product FCC ID DMR Repeater XX6SER8010 DMR Repeater XX6SER8040 DMR Repeater XX6SER8050 DMR Mobile Radio XX6SEM8010 DMR Mobile Radio XX6SEM8040 DMR Mobile Radio XX6SEM8050 DMR Mobile Radio XX6SEM8010H DMR Mobile Radio XX6SEM8040H DMR Mobile Radio XX6SEM8050H DMR Two Way Radio XX6SEP8010 DMR Two Way Radio XX6SEP8040 DMR Two Way Radio XX6SEP8050 Yours faithfully, Steve Wood Verification Engineering Team Leader

FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 21 August 2015 Dear Sir or Madam RE: Extended Frequencies Justification The radio with FCC ID: XX6SER8050 was designed to operate in the frequency bands 450-520MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Sepura plc. is requesting that the FCC lists the above frequencies 450-520 MHZ, under FCC Rule Part 90 and 22 on the FCC Grant. Sepura plc attests that the radio will not be marketed to USA users with the frequency band which is not allowed by the rules Part 90 and 22. As per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range(MHz) FCC rule part 450-454MHz Part 90 454-455MHz Part 22 456-460MHz Part 90/Part 22 460-462.5375MHz Part 90 462.7375-467.5375MHz Part 90 467.7375-470 MHz Part 90 470-512 MHz Part 90/Part 22 Please contact me if you require any additional information. Yours faithfully, Steve Wood Verification Engineering Team Leader

Page 1 of 4 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT-All View EUT-Front View Page 2 of 4 EUT-Rear View EUT-Top View Page 3 of 4 EUT-Bottom View EUT-Left Side View Page 4 of 4 EUT-Right Side View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG150812003-00 FCC Part 22 and 90 Page 8 of 47 FCC §1.1310 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to 1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E|, |H| or S (minutes) 0.3- 3.0 614 1.63 (100)* 6 3.0 - 30 1842/f 4.89/f (900/f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 / / f/300 6 1500-100,000 / / 5 6 f = frequency in MHz * = Plane-wave equivalent power density MPE Calculation Predication of MPE limit at a given distance S = PG/4πR 2 Where: S = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Frequency Max. Target Conducted Output Power Typical Antenna GainDistancePower Density Limit MHz mW dBi numeric cm mW/cm 2 mW/cm 2 450.0125 40300 0 1.0 49 1.34 1.50 Radio Exposure Statement: Using the parameters given in the above calculation, a minimum antenna to person distance of 49 cm is required to meet the limits for occupational/controlled exposure. Result: Compliant.

Page 1 of 2 EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission Front View (Below 1GHz) Radiated Emission Rear View (Below 1GHz) Radiated Emission Front View (Above 1GHz) Radiated Emission View (Above 1GHz)
