sepura TETRA Terminals Product Guide MOD-10-1164 Issue 1 © SEPURA PLC 2010 MOD-10-1164 sepura TETRA Terminals Product Guide March 26 th 2010 Page 2 of 35 Issue 1 © Sepura plc 2010 Contents CONVENTIONS _______________________________________________ 4 REGULATORY STATEMENTS ___________________________________ 5 SRG3900 terminals _________________________________________________________ 5 STP8040/STP8140 terminals _________________________________________________ 6 OPERATIONAL REQUIREMENTS ________________________________ 7 Operating Conditions _______________________________________________________ 7 HANDHELD TERMINAL RANGE _________________________________ 8 STP8000, STP8100 _________________________________________________________ 9 SRH3500, SRH3800, SRH3900 _______________________________________________ 19 MOBILE / GATEWAY TERMINAL RANGE _________________________ 24 SRM3000, SRG3000 Mobile / Gateway Transceiver _____________________________ 25 Standard Console _________________________________________________________ 26 Handset Based Console ___________________________________________________ 26 Applications Interface Unit _________________________________________________ 27 Mobile / Gateway Terminal Accessories ______________________________________ 28 Mobile / Gateway Terminal Audio Control _____________________________________ 28 RADIO OPERATION __________________________________________ 30 HEALTH AND SAFETY ________________________________________ 31 User Information __________________________________________________________ 31 Compliance with Standards ________________________________________________ 32 GLOSSARY _________________________________________________ 33 ACKNOWLEDGEMENTS ______________________________________ 34 MOD-10-1164 sepura TETRA Terminals Product Guide March 26 th 2010 Page 3 of 35 Issue 1 © Sepura plc 2010 NOTICE ____________________________________________________ 35 Contact Details ___________________________________________________________ 35 MOD-10-1164 sepura TETRA Terminals Product Guide March 26 th 2010 Page 4 of 35 Issue 1 © Sepura plc 2010 CONVENTIONS This guide uses the following formatting and graphical conventions. Convention Description Note icon. Emphasises related, reinforcing, or important information. Tip icon. Suggests alternative methods for accomplishing tasks or procedures. Caution icon. Indicates actions or processes that require caution from the user. MOD-10-1164 sepura TETRA Terminals Product Guide March 26 th 2010 Page 5 of 35 Issue 1 © Sepura plc 2010 REGULATORY STATEMENTS The following regulatory statements apply to users in the North American and/or Canadian markets. SRG3900 TERMINALS Changes or modifications not expressly approved by the party responsible for compliance could void the user‟s authority to operate the equipment (FCC rule part 15.21). This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (FCC Rule Part 15.19(a)(3)). NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense (FCC Rule Part 15.105). When used with the High Gain Tetra Modular Whip antenna (maximum antenna gain 7dBi), the antenna must be installed to provide a separation distance of at least 31 cm from all persons during normal operation to ensure compliance for RF Exposure. When used with the rigid Tetra Modular Whip antenna (maximum antenna gain 2dBi), the antenna must be installed to provide a separation distance of at least 25 cm from all persons during normal operation to ensure compliance for RF Exposure. This Class A digital apparatus complies with Canadian ICES-003. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication This radio is intended for use in occupational/controlled applications where users have been made aware of the potential for exposure and can exercise control over their exposure. This radio device is NOT authorized for general population, consumer or similar use. MOD-10-1164 sepura TETRA Terminals Product Guide March 26 th 2010 Page 6 of 35 Issue 1 © Sepura plc 2010 STP8040/STP8140 TERMINALS Changes or modifications not expressly approved by the party responsible for compliance could void the user‟s authority to operate the equipment (FCC rule part 15.21). This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (FCC Rule Part 15.19(a)(3)). NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of th…

Text truncated - open the document above for the full version.

Quick Reference Guide STP8000/8100 sepura Sepura plc Radio House, St Andrew‟s Road, Cambridge, CB4 1GR England www.sepura.com SPR-DOC-01189 Issue 2 © Sepura plc 2009 STP8000 STP8100 Navi-knob™ Tri-colour LED Mode key On/Off Soft Key (Call Clear Key) Emergency Key PTT Left Context Key Antenna Navigation Keys Green Telephone Key Alpha-Numeric Keypad (Half-Duplex speaker behind) Facility Connector Blue LED Duplex Earpiece and Half Duplex Microphone Soft Key (Missed Event) Rugged Accessory Connector Right Context Key Red Telephone Key Duplex Microphone Half-Duplex Speaker Switch On Press the Mode Key. Switch Off Press & Hold the Mode Key. Volume Adjust Rotate the Navi Knob™. Emergency Call Press and hold the Emergency Key. Change Talkgroup Press the Mode Key once, and then rotate the Navi Knob™ to choose from the list of talkgroups in the current folder, or dial the number of the talkgroup using the keypad. W ait or press the PTT to activate the new talkgroup. Change Folder Press the Mode Key once, and then use the Up and Down Navigation Keys to select a talkgroup folder. Then change the talkgroup as explained above. Talkgroup Call Press the PTT. Call one Radio Dial the radio number and select (using Up/Down Navigation Keys), then press PTT to start the call. Telephone Call Dial the required number and select (using Up/Down Navigation Keys), and then press the appropriate Context Key to start the call. To end the call press the other Context key. Send Status Press the Mode Button twice and then rotate the Navi Knob™ to select a status value. Press PTT twice to send to the currently active talkgroup. These messages can also be accessed from the menu structure. Menu Access From the default screen: Press the Down Navigation Key once to see the menus available; Press the Left or Right Navigation Key to move across and select the menus; Press the Down Navigation Key to enter menu; Press the Left or Right Navigation Key to move across the cards within the menu. Press and hold the Up Navigation Key to exit the menus and return to the default screen. Alternatively, do nothing and the default screen will reappear after a timeout. Activating Menu Options Some menu cards allow you to alter settings within the radio by checking or unchecking a checkbox. Press the appropriate Context key to activate a function and „check‟ its checkbox or to deactivate a function and „uncheck‟ its checkbox. In the Network Selection Menu only one Network can be activated, so the previous network is deactivated automatically. Entering Text Within menu cards that allow text entry, e.g. to send message; Press and hold the Down Navigation Key to start editing; Enter or edit your text as required from the keypad; Press the appropriate Context key to action your changes or to exit. Activating Soft key Functions Press and hold the required soft key. (A list of soft key functions may be displayed on the Help key if programmed.) Some soft keys are a “toggle” function, requiring no further action. Some are navigation keys requiring a second action. Icons Description Icon Description Icon Half duplex call DMO Gateway Broadcast call Signal strength Telephone type call dialling mode DMO Repeater found Transmit Inhibit Battery Emergency call Keypad Locked New message Volume level meter Description Icon Description Icon Missed Call Packet Data session Low battery Scanning Lone Worker Radio Settings Covert Operation WAP Calls not encrypted Calls are E2E encrypted Power from charger Telephone style call Paging Alert Status Messages Turn Navi-knob™ clockwise to move cursor Turn Navi-knob™ anticlockwise to move cursor Communication mismatch Messages DMO Repeater Directory Privacy Mode Call History Group Focus Message Store GPS GPS disabled TETRA type dialling mode Device connected using Bluetooth ® Incoming Call Outgoing Call Folders Network Selection External Alerts Short Data Applications Function is activated Function not activated Radio Information Bluetooth ® On DMO Outgoing Call DMO Incoming Call Man Down Motion and Tilt Sensors On Man Down Motion Only Sensor Active Man Down Tilt Only Sensor Active

Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. Date 26 th January 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Sepura plc hereby requests permanent confidential treatment of information accompanying this application as outlined below: BOM’s Circuit Diagrams Circuit Descriptions Operating Descriptions Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Bob Allen Telephone Number: +44 (0) 1223 876000 Email: [email protected]

Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. REF: FCC Approvals Date 26 th January 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK hereby authorize Natalie Bennett TÜV Product Service Ltd Octagon House Concorde Way Segensworth North Fareham Hampshire PO15 5RL Tel: +44 (0)1489 558254 Fax: +44 (0)1489 558101 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 31 st January 2011 Sincerely, Company Officer: Bob Allen Telephone Number: +44 (0) 1223 877291 Email: [email protected]

Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. BABT FCB Forsyth House Churchfield Road Walton-on-Thames Surrey KT12 2TD Declaration regarding Sepura SP8040 and STP8140 FCC certification number: STP8040: FCC ID: XX6STP8040 STP8140: FCC ID: XX6STP8140 Company: SEPURA plc Product: STP8040; STP8140 We, Sepura do declare that the only difference between our Tetra portables type numbers STP8040 and STP8140 is the fitment of a different key-mat and key-mat bezel, apart from this change the products are identical in all over mechanical respects and are identical in all electrical and RF aspects. We further declare that both products are manufactured from the same basic Bill of Materials, contain the same software and firmware and follow identical Quality and Manufacturing Processes. Yours sincerely, Company Officer: Bob Allen Telephone Number: 01223 877291 Email: [email protected]

FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP8140 Front View FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 Back View FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 Top View FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 Antennas 300-00662 300-00449 300-00663 FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 RAC Side FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 PTT Side FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 Basic RSM 300-00389 FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 Advanced RSM 300-00388 FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 GSM Hands free 300-00428 FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 EH6 300-00562 500mm lead EH6 300-00563 900mm lead EH6 300-00564 RSM lead FCC ID: XX6STP8140 IC ID: 8739A-STP8000 STP8140 Portable Tetra Radio Job Number 75908190 Sepura plc Radio House, St Andrew’s Road, Cambridge CB4 1GR, UK Tel: +44 (0) 1223 876000 Fax: +44 (0) 1223 879000 www.sepura.com Sepura plc Registered in England No: 4353801 Registered office: Radio House, St Andrew’s Road, Cambridge CB4 1GR, England. STP 8040 & STP8140 EM2 300-00579 500mm lead EM2 300-00580 900mm lead EM2 300-00581 RSM lead

Document 75908190 Report 01 Issue 2 March 2010 Report On FCC Testing of the Sepura plc STP8040 Portable Tetra Radio In accordance with FCC CFR 47 Part 90 COMMERCIAL-IN-CONFIDENCE FCC ID: XX6STP8040 TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75908190 Report 01 Issue 2 Page 1 of 51 APPROVED BY M Jenkins Authorised Signatory C Gould Authorised Signatory ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 90. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineers; R A Blagg G Lawler This report has been up-issued to remove references to Issue 2 to Industry Canada. REPORT ON FCC Testing of the Sepura plc STP8040 Portable Tetra Radio In accordance with FCC CFR 47 Part 90 Document 75908190 Report 01 Issue 2 March 2010 PREPARED FOR Sepura plc Radio House St Andrew’s Road Cambridge CB4 1GR PREPARED BY N Bennett Senior Administrator DATED 02 March 2010 Document 75908190 Report 01 Issue 2 Page 2 of 51 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Declaration of Build Status ........................................................................................................... 6 1.4 Product Information ...................................................................................................................... 7 1.5 Test Conditions ............................................................................................................................. 9 1.6 Deviations from the Standard ....................................................................................................... 9 1.7 Modification Record ...................................................................................................................... 9 2 TEST DETAILS .......................................................................................................................... 10 2.1 Emission Limitations for Cellular Equipment .............................................................................. 11 2.2 Effective Radiated Power ........................................................................................................... 21 2.3 Power and Antenna Height Limits / Transmitter Output Power .................................................. 25 2.4 Types of Emission / Types of Modulation ................................................................................... 27 2.5 Bandwidth Limitations ................................................................................................................. 29 2.6 Emission Mask ............................................................................................................................ 32 2.7 Frequency Stability ..................................................................................................................... 38 2.8 Transient Frequency Behaviour ................................................................................................. 40 3 TEST EQUIPMENT USED ......................................................................................................... 45 3.1 Test Equipment Used ................................................................................................................. 46 3.2 Measurement Uncertainty .......................................................................................................... 49 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ........................................................... 50 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 51 Document 75908190 Report 01 Issue 2 Page 3 of 51 SECTION 1 REPORT SUMMARY FCC Testing of the Sepura plc STP8040 Portable Tetra Radio In accordance with FCC CFR 47 Part 90 Document 75908190 Report 01 Issue 2 Page 4 of 51 1.1 INTRODUCTION The information contained in this report is intended to show verification of the FCC Testing of the Sepura plc, STP8040 Portable Tetra Radio to the requirements of FCC CFR 47 Part 90. Objective To perform FCC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Sepura plc Model Number(s) STP8040 Portable Tetra Radio Serial Number(s) 2PN40092294Y10S Number of Samples Tested One Test Specification/Issue/Date FCC CFR 47 Part 90: 2008 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date 315350/T0201 19 November 2009 Start of Test 08 December 2009 Finish of Test 12 January 2010 Name of Engineer(s) R A Blagg G Lawler Related Document(s) ANSI 63.4 : 2003 Document 75908190 Report 01 Issue 2 Page 5 of 51 1.2 BRIEF SUMMARY OF RESULTS A brief summary of the tests carried out in acco rdance with FCC CFR 47 Part 90 is shown below. Section Spec Clause Test Description Mode Result Comments 2.1 90.210(c)(3) Emission Limita tions for Cellular Equipment Transmit Bottom Pass Transmit Middle Pass Transmit Top Pass 2.2 90.205 (h) Effective Radiated Power Transmit Bottom Pass Transmit Middle Pass Transmit Top Pass 2.3 90.205, 2.1046 Power and Antenna Height Limits / Transmitter Output Power Transmit Bottom Pass Transmit Middle Pass Transmit Top Pass 2.4 90.207, 2.1047 Typ…
