XZRBRD01288Mifare/NFC reader

This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS. MAN10408_00 1 of 8 MAN10408 Rev.00 Description User Manual - NFC 3V3 board GDS Part No. BRD01288 - 0WR00975AA Issue Date 27.11.2012 Issue Level 00 Pages 7 Author(s): Signature: Date: F.Ceccato F.Ceccato 27/11/2012 Approved: P. Giardini P.Giardini 27/11/2012 Final Release This technical literature is subject to change without notice. Please contact GDS or its representative before designing your product based on this specification This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS. MAN10408_00 2 of 8 TABLE OF CONTENTS 1. FCC Notice (U.S. Only) ............................................................................................................................ 3 2. Safety Instructions .................................................................................................................................... 4 3. NFC compatibility ..................................................................................................................................... 4 4. Mechanical dimensions ............................................................................................................................ 5 5. Connections ............................................................................................................................................. 6 6. Operating mode........................................................................................................................................ 6 7. Labelling................................................................................................................................................... 8 This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS. MAN10408_00 3 of 8 1. FCC Notice (U.S. Only) FCC Class B – Applicable only to Limited Feature connections This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual, may cause interference with radio and television reception. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 This device may not cause harmful interference. 2 This device must accept any interference received, including interference that may cause undesired operation. NOTICE: The FCC regulations provide that changes or modifications not expressly approved by Global Display Solutions SpA could void your authority to operate this equipment. These limits are designed to provide reasonable protection against harmful interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference with radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more of the following measures:  Reorient the receiving antenna.  Relocate the system with respect to the receiver.  Move the system away from the receiver.  Plug the system into a different outlet so that the system and the receiver are on different branch circuits. If necessary, consult a representative of Technogym SpA or an experienced radio/television technician for additional suggestions. The following information is provided on the device or devices covered in this document in compliance with the FCC regulations:  Product name: NFC 3V3 board  Model number: BRD01288 - 0WR00975AA  Company name: Global Display Solutions SpA This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS. MAN10408_00 4 of 8 2. Safety Instructions The NFC 3V3 board is a Mifare/NFC reader module of the display NIC-SP (G0700004 - 0WR00874AA). It must be used for no other purpose. Read the Safety Instruction carefully and keep it for use later. Beware of all warning and instruction signs marked on the NFC 3V3 board. Ensure that the ambient temperature around the module is between +5°C and +50 °C (with relative humidity between 5% and 85%). 3. NFC compatibility The NFC module will be compatible with the following handsets with respect to the development phases: Phase 1:  Samsung GALAXY NEXUS GT-i9250  Samsung MINI 2 S6500 NFC Phase 2:  Google NEXUS S  Blackberry CURVE 9360  Blackberry BOLD 9900  Samsung GALAXY SII I9100 NFC  Nokia 700 This list may be subject to future changes according to new devices released on the market in the coming months. For a complete list of devices which integrate NFC please refer to: http://www.nfcworld.com/nfc-phones-list/ http://www.paywithisis.com/ http://www.nfc.cc/nfc-phones/ This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS. MAN10408_00 5 of 8 4. Mechanical dimensions The NFC 3V3 board shows the following mechanical dimensions: Quota Dimensione MAX PBC_W 83mm PCB_L 45mm PCB_H 1.6mm An…

Text truncated - open the document above for the full version.

Photographs of BRD01288 - Top view BRD01288 - Top view (without emi shield) - Bottom view

FCC Label specification Date: 20.11.2012 Code product: BRD01288 Description: NFC board Author: Pizzol S. Approved: Bertoia C. FCC LABEL BRD01288 Pagina 1 di 1 FCC Compliance Label - Label code: X4000023 ( 35 x 20 mm) - FCC label position FCC ID : XZRBRD01288 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Device may only be used as an integrated component of an end product. R2-3mm TYP

Photographs of BRD01288 - Top view BRD01288 - Top view (without emi shield) - Bottom view

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Test report R12177301_rev20 Rev. 2.0 Order M121773 page 1 of 22 TEST REPORT nr. R12177301_rev20 Federal Communication Commission (FCC) This test report cancel and replace document nr. R12177301 date 27.11.12 Test item Description .................... : Mifare / NFC Reader Trademark ..................... : GLOBAL DISPLAY SOLUTIONS Model/Type ................... : BRD01288 Test Specification Standard ........................ : FCC Rules & Regulations, Title 47 (2012) Part 15 paragraph(s) : 203, 204, 209 and 225 Client’s name ............... : GLOBAL DISPLAY SOLUTIONS S.p.A. Address ......................... : Via Tezze, 20/A – 36073 Cornedo Vicentino (VI) - Italy Manufacturer’s name . : Same as client Address ......................... : -- Report Tested by ....................... : G. Gandini - Technician Approved by .................. : R. Beghetto - Laboratory Manager Date of issue .................. : 27.02.12 Contents ........................ : 22 pages This test report shall not be reproduced except in full without the written approval of CMC. The test results presented in this report relate only to the item tested. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R12177301_rev20 Rev. 2.0 Order M121773 page 2 of 22 Index 1. SUMMARY ............................................................................................................................................................. 3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................. 4 2.1 TEST SITE .............................................................................................................................................................. 4 3. TESTING AND SAMPLING ................................................................................................................................. 4 4. OPERATIVE CONDITIONS................................................................................................................................. 4 5. PHOTOGRAPH(S) OF EUT ................................................................................................................................. 5 6. EQUIPMENT LIST ................................................................................................................................................ 7 7. MEASUREMENT UNCERTAINTY .................................................................................................................... 8 8. EFERENCE DOCUMENTS .................................................................................................................................. 9 9. DEVIATION FROM TEST SPECIFICATION ................................................................................................. 10 10. TEST CASE VERDICTS...................................................................................................................................... 10 11. RESULTS............................................................................................................................................................... 10 11.1 RADIATED EMISSION ...................................................................................................................................... 11 11.2 FIELD STRENGTH WITHIN THE ASSIGNED BAND ............................................................................................... 13 11.3 FREQUENCY TOLERANCE ................................................................................................................................ 14 12. GRAPHS AND TABLES ...................................................................................................................................... 15 CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R12177301_rev20 Rev. 2.0 Order M121773 page 3 of 22 1. Summary Emission: FCC Rules & Regulations, Title 47 (2011) Test specifications Environmental Phenomena Tests sequence Result Part 15.203 and 15.204 Antenna Requirement 4 Complies (The antenna is embedded) Part 15.209 Radiated Emission 1 Complies Part 15.225 Field strength within the assigned band 2 Complies Part 15.225 (e) Frequency tollerance 3 Complies The Test Report was given to the Client representatives for necessary documentation of ratification of the tested equipment and it is valid for the FCC certification. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R12177301_rev20 Rev. 2.0 Order M121773 page 4 of 22 2. Description of Equipment under test (EUT) Power supply .......................................................................... : 3,3Vdc from battery Serial number ......................................................................... : Sample Pre-D Type of equipment ............................................................... :  Transmitter Unit  Receiver Unit  Fixed station  Portable station  Mobile station Working Frequency ............................................................... : 13,56 MHz Information on antenna ......................................................... : Embedded Auxiliary equipment ............................................................. : Monitor 7” by Global Display Solution Spa Filtering and construction devices ......................................... : None 2.1 Test Site Company ................................................................................ : CMC Centro Misure Compatibilità S.r.l. Address .................................................................................. : Via dell’Elettronica, 12/C – 36016 Thiene (VI) – …

Text truncated - open the document above for the full version.

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 1 SETUP PHOTO
