User Guide // Manuel Utilisateur Power on/off // Bouton d’alimentation Press the power (play, pause, stop) button for 3 seconds or untill you hear a beep sound. A blue LED is indicate for power on, and a red LED is indicated for power off. Appuyez sur le bouton (play/pause/stop) pendant 3 secondes ou jusqu'à ce que vous entendiez un bip sonore un voyant bleu indique la mise sous tension, et un voyant rouge indique la mise hors tension. Pairing // Connexion/Jumelage When power is off. Press the power and hold until you hear two separate beeps. The LED indicator will blink blue and red. Pause // Pause Press the power button once to pause and once to play again. Appuyez sur le bouton marche/arrêt une fois pour mettre en pause et une fois de plus pour continuer. Volume up // Volume Haut Press the volume up/next track button once and let go. Permet d’augmenter le volume. Lorsque l’alimentation est coupée. Appuyez sur le bouton marche/arrêt et maintenez le jusqu’a que vous entendiez 2 bips distincts. Le voyant clignotera en bleue et rouge. Note: Button function is on bottom of Speaker. When placed on hard surface buttons can be used on top of speaker. NB: Les boutons de fonction sont au-dessous des haut-parleurs. Si l’appareil est placé sur une surface dure, les boutons peuvent-être utilisés sur le dessus. Volume down // Volume Bas Press the volume down/previous track button once and let go. Next track // Piste Suivante Press and hold the volume up/next track button for 3 seconds. Appuyez sur le volume haut et maintenez- le enfonce pendant 3 secondes, pour passer à la chanson suivante. Permet de diminuer le volume. Previous track // Piste Précédente Press and hold the volume down/previous track button for 3 seconds. Appuyez le volume bas et maintenez-le enfonce pendant 3 secondes, pour revenir à la chanson précédente. Charging // Chargement Simply plug in the micro USB into the charging port. The indicator turns red when charging, it's turn blue if fully charged. (Note: Music cannot be played while charging.) Simplement, branche un câble micro-USB dans le port de chargement. Le voyant deviendra rouge pendant le chargement, et deviendra bleue quand il est totalement charge, (NB: Aucune musique ne peut être jouée pendant le chargement). Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. FCC ID: Y22-SK20130011 IC:10486A-SK20130011
DATE : Mar. 11, 2015 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint _ Christy Chen of Centre Testing International (Shenzhen) Corporation / Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China , to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with _ Skullcandy / 1441 W. Ute Blvd Suite 250 Park City, UT 84098 United States. Dated this Agency agreement expiration date: Mar. 11, 2015 to Mar. 10, 2016 By: Thomas Bishop Signature Printed Title: Vice President of Product and Manufacturing On behalf of : Skullcandy Telephone: (435) 940-1545
DATE : Mar. 11, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: Y22-SK20130011 Product Name: Portable Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Agency agreement expiration date: Mar. 11, 2015 to Mar. 10, 2016 By: Thomas Bishop Signature Printed Title: Vice President of Product and Manufacturing On behalf of : Skullcandy Telephone: (435) 940-1545
Label information: label Print to PDF without this message by purchasing novaPDF (http://www.novapdf.com/)
RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2441 MHz 4.47 dBm(2.8 mW) output power] (2.8 mW /5mm) ·[√2.441 (GHz)]= 0.875 <3.0 for 1-g SAR Then SAR evaluation is not required
Report No. : EESZG12250005-1 Page 1 of 57 TEST REPORT Product : Portable Bluetooth Speaker Trade mark : Skullcandy Model/Type reference : Soundmine Serial number : N/A Ratings : Charging input: 5V , 500mA lithium Battery: 3,7V 500mAh, IPX0, Class III FCC ID : Y22-SK20130011 Report number : EESZG12250005-1 Date : Mar. 11, 2015 Regulations : See below Test Standards Results 47 CFR FCC Part 15 Subpart C 15.247: 2014 PASS Prepared for: Skullcandy 1441 W. Ute Blvd Suite 250 Park City, UT 84098 United States Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: Mar. 11, 2015 Jimmy Li Lab manager Check No.: 1702066245 Report No. : EESZG12250005-1 Page 2 of 57 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................ 4 2. TEST SUMMARY ........................................................................................................... 4 3. PRODUCT INFORMATION ............................................................................................ 5 4. MEASUREMENT UNCERTAINTY ................................................................................. 5 5. TEST EQUIPMENT LIST ............................................................................................... 5 6. SUPPORT EQUIPMENT LIST ....................................................................................... 5 7. 20DB / 99% BANDWIDTH MEASUREMENT ................................................................ 5 7.1. LIMITS ..................................................................................................................... 6 7.2. BLOCK DIAGRAM OF TEST SETUP ..................................................................... 6 7.3. TEST PROCEDURE ............................................................................................... 6 7.4. TEST RESULT ........................................................................................................ 6 8. CARRIER FREQUENCY SEPARATION ..................................................................... 16 8.1. LIMITS ................................................................................................................... 16 8.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 16 8.3. TEST PROCEDURE ............................................................................................. 16 8.4. TEST RESULT ...................................................................................................... 16 9. NUMBER OF HOPPING FREQUENCY ....................................................................... 22 9.1. LIMITS ................................................................................................................... 22 9.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 22 9.3. TEST PROCEDURE ............................................................................................. 22 9.4. TEST RESULT ...................................................................................................... 22 10. TIME OF OCCUPANCY (DWELL TIME) .................................................................. 25 10.1. LIMITS ................................................................................................................... 25 10.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 25 10.3. TEST PROCEDURE ............................................................................................. 25 10.4. TEST RESULT ...................................................................................................... 25 11. MAXIMUM PEAK CONDUCTED OUTPUT POWER MEASUREMENT ................... 31 11.1. LIMITS ................................................................................................................... 31 11.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 31 11.3. TEST PROCEDURE ............................................................................................. 31 11.4. TEST RESULT ...................................................................................................... 31 Report No. : EESZG12250005-1 Page 3 of 57 12. CONDUCTED BANDEDGE EMISSION MEASUREMENT ...................................... 34 12.1. LIMITS ................................................................................................................... 34 12.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 34 12.3. TEST PROCEDURE ............................................................................................. 34 12.4. TEST RESULT ...................................................................................................... 34 Π/4-DQPSK: .................................................................................................................... 37 13. CONDUCTED SPURIOUS EMISSION MEASUREMENT ........................................ 41 13.1. LIMITS ................................................................................................................... 41 13.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 41 13.3. TEST PROCEDURE ............................................................................................. 41 13.4. TEST RESULT ...................................................................................................... 41 14. RADIATED BANDEDGE EMISSION / RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................................................. 44 14.1. LIMITS .............................................…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.80 mW |
