Y22-SK20130012Bluetooth Headphones

Wireless Barrel User Guide Power On – Press and hold the MFB unil the LED ashes blue and the ascending tone plays through the headphones. Power O – Press and hold the MFB until the LED turns RED and the descending tone plays through the headphones. Pairing – While power is o, hold the MFB until the LED alternates ashing BLUE and RED. Un-pairing – Press and hold the volume up and volume down buttons until you hear two short tones. Pause – Press the MFB once to pause and once again to play. Volume Up – Press the volume up button. A tone will sound at maximum volume. Volume Down – Press the volume down button. A tone will sound at minimum volume. Next Track – Press and hold the volume up button. Previous Track – Press and hold the volume down button. Answer Call – While paired, push the MFB once. Hang Up Call – Push the MFB once. Charging –The LED will be Red while charging and turn Blue once fully charged. Low Battery – The LED will ash Red and a tone will sound 4 times. EN ® Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

FCC IDY22-SK20130012 IC: 10486A-SK20130012 Model NoUproar Wireless

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Worse case is as below: [2480 MHz -1.96dBm（0.64 mW） output power] (0.64 mW /5mm) ·[√2.480 (GHz)]= 0.2 <3.0 for 1-g SAR Then SAR evaluation is not required

Report No. : EED32H000449 Page 1 of 50 1 COVER PAGE TEST REPORT Product Name : Bluetooth Headphone Trade mark : N/A Mode No. : Uproar Wireless Serial Number : N/A Report Number : EED32H000449 FCC ID : Y22-SK20130012 Date of Issue: : May 29, 2015 Test Standards : 47 CFR FCC Part 15.247 (2014) Test result : PASS Prepared for: Skullcandy 1441 W. Ute Blvd Suite 250 Park City, UT 84098 United States Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date:May 29, 2015 Sheek Luo Lab supervisor Check No.: 2135171939 Report No. : EED32H000449 Page 2 of 50 2 Version Version No.Date Description 00 2015-04-01 Original Report No. : EED32H000449 Page 3 of 50 3 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10-2009 PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10-2009 PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10-2009 PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10-2009 PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10-2009 PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10-2009 PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10-2009 PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10-2009 PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10-2009 PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10-2009 PASS Test according to ANSI C63.4-2009 & ANSI C63.10-2009. Report No. : EED32H000449 Page 4 of 50 4 Content 1COVER PAGE ............................................................................................................................................................. 1  2VERSION ...................................................................................................................................................................... 2  3TEST SUMMARY ........................................................................................................................................................ 3  4CONTENT ..................................................................................................................................................................... 4  5TEST REQUIREMENT ............................................................................................................................................... 5  5.1TEST SETUP .......................................................................................................................................................... 5 5.1.1For Conducted test setup ............................................................................................................................. 5 5.1.2For Radiated Emissions test setup ............................................................................................................. 5 5.1.3For Conducted Emissions test setup .......................................................................................................... 6 5.2TESTENVIRONMENT ............................................................................................................................................. 6 5.3TESTCONDITION ................................................................................................................................................... 6 6GENERAL INFORMATION ....................................................................................................................................... 7 6.1CLIENTINFORMATION ........................................................................................................................................... 7 6.2GENERAL DESCRIPTION OF EUT ......................................................................................................................... 7 6.3PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ............................................................................... 7 6.4DESCRIPTION OF SUPPORT UNITS ....................................................................................................................... 8 6.5TESTLOCATION .................................................................................................................................................... 8 6.6TESTFACILITY ...................................................................................................................................................... 8 6.7DEVIATION FROM STANDARDS ............................................................................................................................. 9 6.8ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................................. 9 6.9OTHERINFORMATION REQUESTED BY THE CUSTOMER ...................................................................................... 9 7EQUIPMENT LIST ..................................................................................................................................................... 10 8RADIO TECHNICAL REQUIREMENTS SPECIFICATION ................................................................................ 11 Appendix A): 20dB Occupied Bandwidth ............................................................................................................... 12 Appendix B): Carrier Frequency Separation .......................................................................................................... 16 Appendix …

Text truncated - open the document above for the full version.
