Y4O-HC03Bluetooth Speaker(MINI CAB W / RECHARGEABLE BATTERY AND BT)

C D E F GH I J C D E F GH I J GETTING STARTED SETUP A B 1. Press and hold the BLUETOOTH button for 3 seconds, then release it. FRFR-GO will enter pairing mode and the BLUETOOTH LED will flash. 2. Select “FRFR-GO” from your Bluetooth device’s setup screen. 3. When paired successfully, the Pair LED will be lit solid. To control the input level, make sure your Bluetooth device volume is turned up and then adjust the MAIN VOLUME knob. To unpair, press and hold the BLUETOOTH button for 3 seconds. Input Voltage: 100-240 VAC, 50/60 Hz Consumption: 45W A B Model: HC03 BLUETOOTH GUÍA DE INICIO RÁPIDO (ESPAÑOL) • REGISTRE SU PRODUCTO • DESCARGUE LA GUÍA DEL USUARIO • REGISTER YOUR PRODUCT • DOWNLOAD THE USER GUIDE Package Contents: FRFR-GO, Power Cable, Quickstart Guide, Safety & Warranty Manual Contenido del paquete: FRFR-GO, Cable de alimentación, Guía de inicio rápido, Manual sobre la seguridad y garantía PARA COMENZAR C.Charge LED: This LED will be lit green when fully charged and lit red when charging. D.Input: Use a 1/4” (6.35 mm) cable (not included) to connect your amp modeler to this line-level input. E.Input Volume: Turn this knob to adjust the gain of the input. F.Bass: Turn this knob to adjust the low-end frequency sound. G. Treble: Turn this knob to adjust the high-end frequency sound. H.Main Volume: Turn this knob to adjust the overall volume of the speaker and the PHONES output. I. Aux: Connect an optional stereo audio source (e.g., smartphone, tablet, etc.) to this input using an 1/8” (3.5 mm) stereo cable (not included). J.Phones: Connect standard 1/8” (3.5 mm) stereo headphones to this output. Note: This will mute the internal speaker. Notes: Consult the full User Guide for additional safety precautions. For best results, do not connect a guitar directly to FRFR-GO’s input as the circuitry is designed to only be connected to an amp modeler’s line output. To avoid unwanted distortion, set the output of your amp modeler’s line-level output as close to unity gain (0 dB) without going over. For HeadRush modelers, set their main volume knob around “7”, depending on your rig’s setup. If you are unsure of where the unity gain position of your amp modeler is, check your amp modeler’s User Guide. QUICKSTART GUIDE (English) GUÍA DE INICIO RÁPIDO (Español) GUIDE D’UTILISATION RAPIDE (Français) GUIDA RAPIDA (Italiano) SCHNELLSTART-ANLEITUNG (Deutsch) v1.1 Para artículos, videos y soporte web. Pour des articles, des vidéos et de l’assistance technique par web. Per articoli, video, e supporto di web. Für Artikel, Videos und Web-Support. HEADRUSHFX.COM/SUPPORT HEADRUSHFX.COM HEADRUSHFX.COM HEADRUSHFX.COM For articles, videos, and web support. CONFIGURACIÓN GUIDE D’UTILISATION RAPIDE (FRANÇAIS) MISE EN ROUTE DÉMARRAGE CARACTERISTICAS • ENREGISTREZ VOTRE PRODUIT • TÉLÉCHARGEZ LE GUIDE DE L'UTILISATION Contenu de l'emballage : FRFR-GO, Câble d’alimentation, Guide d’utilisation rapide, Consignes de sécurité et informations concernant la garantie Notas: Consulte las precauciones de seguridad adicionales en la Guía de usuario completa. Para obtener mejores resultados, no conecte una guitarra directamente a la entrada del FRFR-GO ya que los circuitos están diseñados para conectarse solamente a la salida de línea de un modelador de amplificador. Para evitar distorsiones no deseadas, ajuste la salida de nivel en línea de su modelador de amplificador lo más cerca posible a la ganancia unitaria (0 dB) sin sobrepasarse. Para modeladores HeadRush, ajuste perillas de volumen principal de los mismos alrededor de "7" dependiendo de los ajustes de su configuración. Si no está seguro de dónde se encuentra la posición de ganancia unitaria en su modelador de amplificador, consulte la guía de usuario del mismo. Power Teléfono inteligente Corriente C.LED de carga: Este LED se enciende de color verde cuando la carga se completa y de color rojo durante la carga. D.Entradas: Utilice un cable de 6,35 mm (1/4 pulg.) (no incluido) para conectar su modelador de amplificador a esta entrada de nivel de línea. E. Volumen de entrada: Gire esta perilla para ajustar la ganancia de la entrada. F.Bass: Tire esta perilla para ajustar el sonido de las frecuencias bajas. G. Treble: Gire esta perilla para ajustar el sonido de las frecuencias altas. H. Volumen principal: Gire esta perilla para ajustar el volumen general del parlante y la salida PHONES. I. Auxiliar: Conecte una fuente de audio estéreo opcional (por ej., un teléfono inteligente smartphone, tableta, etc.) a esta entrada mediante un cable estéreo de 3,5 mm (1/8 pulg.) (no incluido). J. Auriculares: Conecte auriculares estéreo estándar de 3,5 mm (1/8 pulg.) a esta salida. Nota: Esto silenciará el altavoz interno. Remarques : Consultez le guide d'utilisation complet pour les précautions de sécurité supplémentaires. Pour de meilleurs résultats, ne pas brancher une guitare directement à l'entrée de la FRFR-GO car le circuit est conçu pour être branché uniquement à la sortie ligne d'un modélisateur d'amplificateur. Pour éviter toute distorsion indésirable, réglez la sortie à niveau ligne de votre modélisateur d'amplificateur aussi près que possible de l'unité de gain (0 dB) sans la dépasser. Pour les modélisateurs HeadRush, réglez leur bouton du volume principal autour de « 7 », en fonction de la configuration de votre appareil. Si vous ne savez pas où se trouve la position du gain unitaire de votre modélisateur d'amplificateur, consultez le guide d'utilisation de votre modélisateur d'amplificateur. Modelado de amplificadores FEATURES BLUETOOTH Guitarra Corriente 1. Mantenga pulsado el botón PAIR durante 3 segundos y luego suéltelo. El FRFR-GO ingresará al modo de apareamiento y comenzará a parpadear el LED BLUETOOTH. 2. Seleccione “FRFR-GO” en la pantalla de configuración Bluetooth de su dispositivo. 3. Una vez apareado exitosamente, el LED de apareamiento quedará encendido permanentemente. Para controlar el nivel de entrada, asegúrese de que el volumen de su dispositivo Bluet…

Text truncated - open the document above for the full version.

Important Safety Instructions ( English ) 1. Read and keep these instructions. Heed all warnings and follow all Instructions. 2. Warning (if applicable): Please refer to any important info rmation (e.g., electrical, safety, etc.) printed on the exterior bottom enclosure or rear panel before installing or operating the product. 3. Clean only with dry cloth. 4. Water and Moisture (if applicable): Do not use this apparatus near water. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Electrical equipment should NEVER be kept or stored in damp environments. 5. (If applicable) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install this equipment in a confin ed or “boxed-in” space such as a bookcase or similar unit, and maintain good ventilation conditions. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, tablecloths, curtains, etc. 6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not place expose d flame sources such as lighted candles on the apparatus. 7. (If applicable) This product should be connected to a power supply only of the type described in these operating instructions, or as marked on the unit. 8. (If applicable) Be careful not to damage the power cord. When moving or not using the appliance, secure the power cord (e.g., wrap it with a cable tie). Before using it again, make sure the power cord has not been damaged. If the power cord has been damaged at all, bring the unit and cord to a qualified service technician for repair or replacement as specified by the manufacturer. 9. Unplug this apparatus during lightning storms or when unused for long periods of time. 10. Only use attachment/accessories specified by the manufacturer. 11. (If applicable) Use only the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 12. Internal/External Voltage Selectors (if applicable): Internal or external voltage selector switches, if any, should only be reset and re-equipped with a proper plug for alternative voltage by a qualified service technician. Do not attempt to alter this yourself. 13. Caution (if applicable): Danger of explosion if battery is incorr ectly replaced. Replace only with the same or equivalent type. Batteries (a battery pack or an in stalled battery) shall not be exposed to excessive heat such as sunshine, fire, etc. 14. (If applicable) Do not defeat the safety purpose of the polarized or grounding-type plug. 15. Protective earthing terminal (if applicable): The ap paratus should be connected to a mains socket outlet with a protective earthing connection. • Denmark ( Danmark ): Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver forbindelse til stikproppens jord. • Finland ( Suomi ): Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan. • Norway ( Norge ): Apparatet må tilkoples jordet stikkontakt. • Sweden ( Sverige ): Apparaten skall anslutas till jordat uttag. 16. For Class II apparatus only : This symbol means the equipment is a Class II or double-insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. When servicing use only identi cal replacement parts installed by an instructed person or with the use of ready-made leads or cords. 17. Warning (if applicable): Provide an earthing connection be fore the mains plug is connected to the mains. When disconnecting the earthing connection, be sure to disconnect it after pulling the mains plug out from the mains. 18. (If applicable) Where the mains plug or an applian ce coupler is used as the disconnect device, the disconnect device shall remain readily operable . 19. Warning (if applicable): To prevent possible hearing damage, do not listen at high volume levels for long periods. 20. This apparatus is for professional use only . Intended operational climate: moderate. Safety Notices CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE ANY COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIE D SERVICE PERSONNEL ONLY. DANGEROUS VOLTAGE : The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. INSTRUCTIONS : The exclamation point within the equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instru ctions in the literature acco mpanying this appliance. CAUTION ( for U.S.A. & CANADIAN models only ): TO PREVENT ELECTRIC SH OCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. NOTICE CONCERNING LASER PRODUCTS : DANGER : INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. AVOID DIRECT EXPOS URE TO BEAM. USE OF CONTROLS OR ADJUSTMENTS OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. NOTICE CONCERNING FCC REGULATIONS : You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio freque ncy energy and, if not installed and used in acc…

Text truncated - open the document above for the full version.

INMUSIC BRANDS INC 2024-08-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: Y4O-HC03) [INMUSIC BRANDS INC ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Hill Lien Director of Compliance INMUSIC BRANDS INC 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864 INMUSIC BRANDS INC 2024-08-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: Y4O-HC03 ) [INMUSIC BRANDS INC ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Hill Lien Director of Compliance INMUSIC BRANDS INC 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864

Attestation Statements (2024-08-13) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: Y4O-HC03) (INMUSIC BRANDS INC), the undersigned, hereby authorize (INMUSIC BRANDS INC) to act as our designated U.S. agent for service of process, (INMUSIC BRANDS INC) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (INMUSIC BRANDS INC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: INMUSIC BRANDS INC Contact Name: Hill Lien Address: 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864 FRN: 0022102461 Telephone No: +866-2-2717-2389 Email: [email protected] Signature [Hill Lien] U.S. Agent Information: Company Name: INMUSIC BRANDS INC Address: 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864 FRN: 0022102461 Contact Name: Hill Lien Telephone No: +866-2-2717-2389 Ext:77 Email: [email protected] Signature [Hill Lien]

SPEAKER 4/15W PRE POWER POWER SUPPLY AMP POWER BT POWER 1 2 3 4 2402-2480MHz

INMUSIC BRANDS INC Declaration on model difference We the undersigned hereby confirm that these models are identical, and all models have the same RF module and antenna, PCB layout, schematics and component. Only the models name are different. Production name Trademark FCC ID Model no. Bluetooth Speaker(MINI CAB W / RECHARGEABLE BATTERY AND BT) Y4O-HC03 HC03, HC03XXXXXX, FRFR- GO, FRFR-GOXXXXXXXX (X can be "0-9", "a-z", "A-Z", blank, "-", "+" or any character, symbol, alphanumeric) Sincerely, Hill Lien Director of Compliance Telephone No: +866-2-2717-2389 ext77 Email: [email protected] INMUSIC BRANDS INC 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864

INMUSIC BRANDS INC 2024-08-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Hill Lien Director of Compliance Telephone No: +866-2-2717-2389 ext77 Email: [email protected] INMUSIC BRANDS INC 200 SCENIC VIEW DRIVE, SUITE 201, CUMBERLAND, Rhode Island, United States, 02864

External Photographs View of EUT-1 View of EUT-2 Page 2 of 4 View of EUT-3 View of EUT-4 Page 3 of 4 View of EUT-5 View of EUT-6 Page 4 of 4 View of EUT-7

Headrush FRFR-GO Dan Singer 06/06/2024 RevA: NewArtwork RevB: Updated Compliance Info RevC: Updated Compliance Info RevD: Updated Compliance Info RevE: Updated Compliance Info RevF: Added S/N box on rear panel, adjusted compliance icon locations. Moved BT symbol below button on top panel silkscreen. RevF Layer 1 -- Background/info/dielines [DO NOT PRINT] Layer 2 -- White HC03Silkscreen

Internal Photographs Internal View of EUT-1 Internal View of EUT-2 Page 2 of 7 Internal View of EUT-3 Internal View of EUT-4 Page 3 of 7 Internal View of EUT-5 Internal View of EUT-6 Page 4 of 7 Internal View of EUT-7 Internal View of EUT-8 Page 5 of 7 Internal View of EUT-9 Internal View of EUT-10 Page 6 of 7 Internal View of EUT-11 Internal View of EUT-12 Page 7 of 7 Internal View of EUT-13 Antenna

Operation description Product name is Bluetooth Speaker(MINI CAB W / RECHARGEABLE BATTERY AND BT). It supports BT dual mode. The Bluetooth function of the product is controlled by chip AC6925A with 24MHz crystal oscillator. EUT Name Bluetooth Speaker(MINI CAB W / RECHARGEABLE BATTERY AND BT) Model FRFR-GO Series Model HC03, HC03XXXXXX, FRFR-GOXXXXXXXX (X can be "0-9", "a-z", "A-Z", blank, "-", "+" or any character, symbol, alphanumeric) Hardware Version V1.0 Software Version V1.0 Ratings 100-240V~ 60/50Hz 45W Battery Ratings XKD 18650 2000mAh 11.1V 22.2Wh Power Supply AC 120V/60Hz Battery 11.1V BT: Frequency Band: 2400 MHz to 2483.5 MHz Frequency Range: 2402 MHz to 2480 MHz Bluetooth Version: 5.3 Modulation Technique: Frequency Hopping Spread Spectrum(FHSS) Type of Modulation: GFSK, π/4-DQPSK Number of Channels: 79 Channel Separation: 1 MHz Maximum Peak Power: -0.64 dBm Antenna Type: Internal antenna Antenna Gain: 3.2 dBi EUT Test software: FCC_assist Note: The Antenna Gain was provided by customer, and this information may affect the validity of the results, customer should be responsible for this. BLE: Frequency Band: 2400 MHz to 2483.5 MHz Frequency Range: 2402 MHz to 2480 MHz Bluetooth Version: 5.3 Type of Modulation: GFSK Number of Channels: 40 Channel Separation: 2 MHz Maximum Peak Power: 2.73 dBm Antenna Type: Internal antenna Antenna Gain: 3.2 dBi EUT Test software: FCC_assist Note: The Antenna Gain was provided by customer, and this information may affect the validity of the results, customer should be responsible for this.

RF EXPOSURE EVALUATION EUT Specification EUT Bluetooth Speaker(MINI CAB W / RECHARGEABLE BATTERY AND BT) Model Number FRFR-GO Series Model HC03, HC03XXXXXX, FRFR-GOXXXXXXXX (X can be "0-9", "a-z", "A-Z", blank, "-", "+" or any character, symbol, alphanumeric) FCC ID Y4O-HC03 Antenna gain (Max) 3.2dBi Operation Frequency 2402-2480MHz Input Rating AC 120V/60Hz or Battery 11.1V Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation BT: GFSK, π/4-DQPSK BLE: GFSK Max. output power BT: -0.64dBm(0.0009W) BLE: 2.73dBm(0.0019W) Test Requirement: According to ß15.247(i) and ß1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by ß2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BT BLE According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Shawn Wen Date: 2024-8-7 Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2480 2-DH5 -0.64 0±1 1 0.40 3 Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2480 BLE 1M 2.73 2±1 3 0.63 3
