EXPLORER BLUETOOTH® QUICKSTART GUIDE ENGLISH ( 3 - 5 ) Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: †Reorient or relocate the receiving antenna. †Increase the separation between the equipment and receiver. †Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. †Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons 3 QUICKSTART GUIDE (ENGLISH) 1. Make sure all items listed on the front of this guide are included in the box. 2. READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE PRODUCT. 3. MAKE SURE THAT YOU HAVE COMPLETELY CHARGED THE BATTERY PRIOR TO FIRST USE FOR MAXIMUM BATTERY LIFE. 4. Study this setup diagram. 5. Make sure all input devices such as microphones, CD players, or mp3 players are turned off and volume settings are set at "zero." 6. Connect all devices as shown. 7. Switch everything on in the following order: • audio input sources (i.e. microphones, instruments, CD/MP3 Players) • EXPLORER BLUETOOTH® 8. When turning off, always reverse this operation: • EXPLORER BLUETOOTH • last, any input devices Go to http://www.ionaudio.com for product registration. RECHARGEABLE BATTERIES Rechargeable lead-acid batteries are the same type used in automobiles. As with your car battery, how you use this battery has a significant impact on its lifespan. With proper use and treatment, a lead-acid battery can last for years. Here are some recommendations for getting the longest life from the internal battery. GENERAL USAGE • FULLY CHARGE THE BATTERY BEFORE USING IT. • CHARGE THE BATTERY COMPLETELY AFTER EACH USE. • AVOID COMPLETELY DRAINING THE BATTERY. • You may leave the unit plugged in for up to two weeks. • For maximum life, drain the battery 80% once a month. STORAGE • Avoid storing in high temperatures and moist places. • For long-term storage, periodically recharge the battery. • If you do not charge the battery for six months, it may not charge. REPAIR • As the battery nears the end of its life, it may lose its ability to recharge. If this occurs, contact ION Audio technical support at www.ionaudio.com/supporthome. DISPOSAL • Bring the unit to a recycling center or dispose of in accordance with local ordinances. BOX CONTENTS ƒ EXPLORER BLUETOOTH ƒ Microphone with mic cable ƒ 1/8" to 1/8" cable ƒ Power Cable (standard IEC) ƒ Quickstart Guide ƒ Safety Instructions & Warranty Information Bookle t REAR PANEL POWER TOP PANEL MICROPHONE (not included) iPhone® (not included) iPhone is a trademark of Apple Inc., registered in the U.S. and other countries. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by ION Audio is under license. Other trademarks and trade names are those of their respective owners. MP3 PLAYER (not included) 4 DIAGRAM AND PARTS DESCRIPTION 1. Microphone Input with Volume Control (1/4"): This mono input accepts a 1/4" input such as a microphone, guitar, or other musical instrument. 2. Auxiliary input: This stereo 1/8” input can be used to connect a CD player, MP3 player, or other audio source. 3. Bluetooth: The Paired LED will be lit when a device is paired to EXPLORER BLUETOOTH. This LED will not be lit when EXPLORER BLUETOOTH is first powered on (unless it was previously paired with a device). Press the Disconnect button to disconnect a paired Bluetooth device. 4. Master Volume Control: This adjusts the speaker’s main mix volume, which includes the Microphone Input, Auxiliary Input, Tuner, and the audio of a paired Bluetooth device. 5. AM/FM Presets: Store a favorite radio station and quickly tune to a preset radio station. There are 6 numeric positions for AM stations and 6 numeric positions for FM stations. To add a preset: A. Select either the AM or FM band and then use the Tuner buttons to select the desired radio station. B. Press and hold a numeric preset button to assign the current station to that preset number. To use an added preset, tap a preset number once lightly to go to the stored radio station. 6. Radio Selector: This switch sets the tuner to AM or FM or turns the tuner off. (Note: This switch does not turn the unit's power off – just the tuner.) 7. LCD: Displays the current radio station. 8. Tuner: Use these buttons to search for a radio station. To "scan" (jump to the next available station), hold this down for a few seconds until it starts to seek a station. Unit will remember the last station you were on and start at that station when you power off and power on again. 9. Power LED: Indicates whether EXPLORER BLUETOOTH is on or off. 10. Dock Charge: Connect your device’s charge cable here to charge it. USB charging only functions when the unit’s power is turned on. Note: Users with iPad (3 rd generation) may experience slower charging. We recommend charging with the screen locked when using iPad (3 rd generation). 11. Device Cradle: Place your iPad/iPod touch®/iPhone®, Android® …

Text truncated - open the document above for the full version.

Letter of Agency 2013/4/19 To whom it may concern, Letter of Agency I, an officer of inMusic Brands, Inc. do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 74 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Signature David Gill Engineering Director

inMusic Brands, Inc. inMusic is the exclusive distributor of Sonivox. www.inmusicbrands.com To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: Y4O-IPA23B Request is hereby submitted by inMusic Brands, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and inMusic Brands, Inc. reserves the right to discern which parties can obtain access to these information: Schematics Detailed Block diagrams Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of inMusic Brands, Inc. and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Signature David Gill Engineering Director

external photos

Internal photos

INTERTEK TESTING SERVICES RF Exposure report The equipment under test (EUT) is a Portable Sound System with AM/FM Radio for iPod. The EUT was powered by AC 100-120V, 60 Hz, 50 W. For more detail information pls. refer to the user manual. Modulation Type: Modulation Type: GFSK, /4 –DQPSK and 8-DPSK Bluetooth Version: 3.0 with EDR function and without AFH mode Antenna Type: Integral antenna Antenna Gain: 2dBi The nominal radiated output power (e.i.r.p) specified: 0dBm (Tolerance: +/- 3dB) The worst-case radiated emission for the EUT is 95.7dBμV/m at 3m in the frequency 2.480GHz = [(FS*D) ^2 / 30] mW = 0.5 dBm which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting devices is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, According to the KDB 447498 and OET 65, the simple calculation as below: For Maximum Permissible Exposure (MPE) evaluation of the product, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65. The maximum radiated output power(e.i.r.p) = 3 dBm =2.0mW The source-based time averaged maximum radiated power (including the tune-up tolerance) = 2.0 * Duty Cycle = 1.7 mW From above data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: = 1.7 mW / 4πR^2 = 0.0003 mW/cm^2 The MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure in the Bluetooth frequency range according to FCC Part 1.1310. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. Transmitter Duty Cycle Calculation 1 2 Based on the Bluetooth Specification (BT version: 3.0 ), transmitter duty cycle is dependent of packet type (DH1, DH3 and DH5). For one period for a pseudo-random hopping through all 79 RF channels, for DH5: One hopset consists of 5 TX slot and 1 RX slot. Duty cycle = 5 / 6 = 0.833 The following RF exposure statement is proposed to be included in the user manual: “FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons.”
