Y4O-TBT2Bluetooth Receiver with XLR outputs

Manual Version 1.2 9 10 1 23 4 5 6 7 8 Bluetooth ® Ultimate Español Contenido de la caja: Bluetooth ® Ultimate, cable de carga micro-USB, guía del usuario. Carga del Bluetooth Ultimate: Utilice el cable micro-USB incluido para conectar el Bluetooth Ultimate a un adaptador de alimentación USB (que se vende por separado) conectado a una toma de corriente o a su ordenador (encendido). Nota: Bluetooth Ultimate podría no estar totalmente cargado al momento de su compra. Si bien es seguro utilizarlo inmediatamente después de su compra, se recomienda cargarlo durante 3-4 horas antes de su primer uso para garantizar una carga completa y el mejor rendimiento. Controles 1. Salida XLR Principal 2. Enlace estéreo 3. LED de enlace estéreo 4. Apareamiento 5. LED de apareamiento 6. Mono / estéreo 7. Encendido/apagado 8. LED de encendido y de estado de la batería 9. Segunda salida XLR 10. Puerto de carga micro-USB Actividad del LED Cuando este ENCENDIDO y la batería no se está cargando: 20–100% = LED verde encendido permanentemente. 10–20% = LED verde y ámbar encendidos permanentemente. 0–10% = LED verde y rojo encendidos permanentemente. Modo de espera de encendido = LED verde apagado. El LED rojo parpadea una vez cada 10 segundos. Cuando este ENCENDIDO y la batería se está cargando: Modo de espera de encendido = LED verde apagado. El LED rojo parpadea una vez cada 10 segundos. Cargado al 5–80% = LED verde apagado. El LED ámbar parpadea lentamente. Cargado al 80–99% = El LED verde parpadea lentamente y el LED ámbar está apagado. Cargado al 100% = LED verde encendido permanentemente. El LED ámbar está apagado. Cuando está APAGADO y cargando: Cargado al 5%–80% = LED verde apagado. El LED ámbar parpadea lentamente. Cargado al 80%–99% = El LED verde parpadea lentamente. El LED ámbar está apagado. Cargado al 100% = LED verde encendido permanentemente. El LED ámbar está apagado. Apareamiento mediante Bluetooth de un solo Bluetooth Ultimate 1. Encienda sus dispositivos Bluetooth. 2. Encienda el Bluetooth Ultimate. 3. Mantenga presionado el botón Pair durante 3 segundos en Bluetooth Ultimate. Sonará un tono de emparejamiento mientras Bluetooth Ultimate está en modo de emparejamiento. Nota: Pulse Pair nuevamente antes de que se aparee su dispositivo para cancelar el proceso de apareamiento. Nota: Antes de aparearlo, apague el Wi-Fi de su dispositivo y detenga toda reproducción de audio. 4. Acceda a la pantalla de configuración Bluetooth de su dispositivo, busque “ALTO BTU” y establezca la conexión. 5. Una vez apareado exitosamente, se escuchará un tono de confirmación y el LED azul Pair se encenderá permanentemente. Nota: Si su dispositivo Bluetooth solicita un código de apareamiento, ingrese "0000". 6. Ajuste el volumen de su dispositivo Bluetooth. Para borrar todos los ajustes previos de apareamiento mantenga pulsado el botón Pair durante 10 segundos. Se escuchará un tono de confirmación que indica que los ajustes de apareamiento han sido eliminados. Ahora puede aparearlo a un nuevo dispositivo. Enlace estéreo de 2 unidades Bluetooth Ultimate 1. Siga los pasos 1-6 en la sección Apareamiento mediante Bluetooth de un solo Bluetooth Ultimate. 2. Mantenga presionado el botón Stereo-Link durante 3 segundos en el Bluetooth Ultimate principal (canal izquierdo). Luego, mantenga presionado el botón Stereo-Link durante 3 segundos en el Bluetooth Ultimate secundario (canal derecho). 3. Ambos LED de Stereo-Link parpadearán y sonará un tono de enlace mientras cada Bluetooth Ultimate "busca" al otro. 4. Una vez enlazados exitosamente, cada Bluetooth Ultimate emitirá un tono de confirmación y los LED de enlace estéreo en ambas unidades se encenderán permanentemente. Para borrar todos los ajustes de enlace en la unidad enlazada, mantenga pulsado el botón Stereo-Link durante 10 segundos. Se escuchará un tono de confirmación que indica que los ajustes de enlace han sido eliminados. Para borrar todos los ajustes de enlace en ambas unidades, mantenga pulsado el botón Stereo-Link de la unidad maestra durante 10 segundos. Se escuchará un tono de confirmación que indica que los ajustes de enlace han sido eliminados. Interruptor mono / estéreo Cuando una unidad está conectada a Bluetooth y el interruptor Mono / Estéreo está en la posición Estéreo, la Salida XLR Principal (1) enviará el canal de audio izquierdo y la Segunda Salida XLR (9) enviará el canal de audio derecho. Cuando una unidad está conectada a Bluetooth y el interruptor Mono / Estéreo está en la posición Mono, tanto la Salida XLR Principal (1) como la Segunda Salida XLR (9) enviarán los canales izquierdo y derecho sumados en mono. Cuando dos unidades están en Stereo-Link y conectadas a Bluetooth, el interruptor Mono / Stereo no tiene función. Tanto la Salida XLR Principal (1) como la Segunda Salida XLR (9) de la unidad principal enviarán el canal de audio izquierdo, y tanto la Salida XLR principal (1) como la Segunda Salida XLR (9) de la unidad secundaria enviarán el canal de audio derecho canal de audio. altoprofessional.com/support For technical support. Para soporte técnico. Pour obtenir de l’assistance technique. Per assistenza tecnica. Für technischen Support. User Guide Guía del usuario Guide d'utilisation Guida per l'uso Benutzerhandbuch Français Contenu de la boîte : Bluetooth ® Ultimate, câble de rechargement micro-USB, guide d'utilisation. Rechargement du Bluetooth Ultimate : Utilisez le câble micro-USB inclus afin de brancher le Bluetooth Ultimate à un adaptateur d’alimentation USB (vendu séparément) branché à une prise secteur ou à un ordinateur (sous tension). Remarque : Il se peut que la batterie du Bluetooth Ultimate ne soit pas entièrement chargée lors de l’achat. Bien qu’il est sûr de l’utiliser dès que vous le sortez de la boîte, la recharger pendant 3 à 4 heures avant la première utilisation assurera une charge complète et une performance optimale. Commandes 1. Sortie XLR Principale 2. Touche Stereo-Link 3. DEL Stereo-Link 4. Touche Pair 5. DEL Pair 6…

Text truncated - open the document above for the full version.

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 17.04.2009 Datum: 0 Seite 1 von 1 Request for Confidentiality Industry Canada Date: 2020.11.24 C ertification & Engineering Bureau P.O. Box 11490, Station H 3701 Carling Avenue, (Building 94) Ottawa, Ontario K2H 8S2 RE: Certification Application IC: 11215A-TBT2 Con fidentiality Request To whom it may concern: Pur suant to the provisions of the Access to Information Act of the Industry Canda rules, the applicant hereby requests the Bureau to withhold the following attachments as confidential documents from public disclosure indefinitely. Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Thank you for your attention in this matter. Applicant’s Company address : 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. Si gnature : ____________________________ Job Title and Dept. : Senior Compliance Manager

Updated on 2005/1/5 by Elis Ng To : The Hong Kong Standards and Testing Centre Ltd. DECLARATION OF IDENTITY Hereby we: inMusic Brands, Inc. (Name of Manufacturer) Basic Model Number: BLUETOOTH ® ULTIMATE Basic Brand Name: ALTO PROFESSIONAL Basic Product Name: Bluetooth Receiver with XLR outputs Basic Test Report Application Number: Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): BLUETOOTH ® TOTAL MK2 New / Additional Brand Name(s): New / Additional Product Name(s): Except the following(s) : Please see attached Remarks: Signature with Company Chop : Printed Name : inMusic Brands, Inc. DATE: 2020/9/2 Updated on 2005/1/5 by Elis Ng

PAGE 3 OF 5 Date : 2020/11/20 Equipment Authorization Division Office id Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dear Sirs, Re. : Letter of Appointment Product name : Bluetooth Receiver with XLR outputs Model : This authorization will expire one year from the date of this letter. Senior Compliance Manager ________________________ Signature with title Jacky Liao - This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for inMusic Brands, Inc., 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of inMusic Brands, Inc.

FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 1 of 4 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 2 of 4 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 3 of 4 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 4 of 4

Product DevelopmentArtwork Release product name / description revision print date descriptioncode Bluetooth Ultimate 2020.08.13 REV G Silkscreen created changes from last revision Nick Pennington [TBT2] Reference/Info -- DO NOT PRINT PART COLOR: Mechanical Dieline/Drawing - DO NOT PRINT Pure White checked Artwork 1:1 scale Design Development ArtworkApproval RevA: New Artwork RevE: updated compliance locations and updated PAIR/LINK instructions RevF: updated USB input power text RevG: removed the RCM logo Nathan Landes

FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 1 of 5 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 2 of 5 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 3 of 5 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 4 of 5 FCC ID: Y4O-TBT2 PHOTOGRAPH OF THE PRODUCT Page 5 of 5

Annex C - Declaration of RF Exposure Compliance for Exemption from Routine Evaluation Limits 1.PRODUCT MARKETING NAME (PMN): BLUETOOTH ® ULTIMATE, 2.HARDWARE VERSION IDENTIFICATION NO. (HVIN): BLUETOOTH ® ULTIMATE, 3.FIRMWARE VERSION IDENTIFICATION NO. (FVIN): HY_AC6925A_ALTO BTU_V2.6.3_WDQ_20201009_V1.7_E259.fw 4.HOST MARKETING NAME (HMN): N/A 5. CERTIFICATION NUMBER: 11215A-TBT2 ATTESTATION: I attest that the radiocommunication apparatus meets the exemption from the routine evaluation limits in Section 2.5 of this standard; that the Technical Brief was prepared and the information contained therein is correct; that the device evaluation was performed or supervised by me; that applicable measurement methods and evaluation methodologies have been followed; and that the device meets the SAR and/or RF field strength limits of RSS-102. Signature: ____________________________________ Date: 2020/11/24 NAME (Please print or type): Jacky Liao TITLE (Please print or type): Senior Compliance Manager COMPANY (Please print or type): inMusic Brands, Inc

Test Report Date : 2020-09-28 Page 1 of 85 No. : HM20080050 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant: inMusic Brands Inc 200 Scenic View Drive Cumberland, RI 02864 USA Manufacturer: inMusic Brands Inc 200 Scenic View Drive Cumberland, RI 02864 USA Description of Sample(s): Submitted sample(s) said to be Product: Bluetooth Receiver with XLR outputs Brand Name: ALTO PROFESSIONAL Model No.: BLUETOOTH ® ULTIMATE FCC ID: Y4O-TBT2 Date Samples Received: 2020-08-24 Date Tested: 2020-09-02 to 2020-09-12 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2018 and ANSI C63.10:2013 for FCC Certification. Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: Bluetooth BR + EDR only Dr. LEE Kam Chuen, Authorized Signatory Test Report Date : 2020-09-28 Page 2 of 85 No. : HM20080050 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. CONTENT: Cover Page 1 of 85 Content Page 2 of 85 1.0 General Details 1.1 Test Laboratory Page 3 of 85 1.2 Equipment Under Test [EUT] Page 3 of 85 Description of EUT operation 1.3 Date of Order Page 3 of 85 1.4 Submitted Sample(s) Page 3 of 85 1.5 Test Duration Page 4 of 85 1.6 Country of Origin Page 4 of 85 1.7 RF Module Details Page 4 of 85 1.8 Channel List Page 4 of 85 2.0 Technical Details 2.1 Investigations Requested Page 5 of 85 2.2 Test Standards and Results Summary Page 5 of 85 2.3 Table for Test Modes Page 6 of 85 3.0 Test Results 3.1 Emission Page 7-63 of 85 Appendix A List of Measurement Equipment Page 64 of 85 Appendix B Photograph(s) of Product Page 65-85 of 85 Test Report Date : 2020-09-28 Page 3 of 85 No. : HM20080050 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory Head Office: 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 FCC Test Firm Registration Number 723883 Designation Number HK0001 1.2 Equipment Under Test [EUT] Description of Sample(s) Product Name: Bluetooth Receiver with XLR outputs Manufacturer: inMusic Brands Inc 200 Scenic View Drive Cumberland, RI 02864 USA Brand Name: ALTO PROFESSIONAL Model Number: BLUETOOTH ® ULTIMATE Internal Product Code: TBT2 Rating: 3.7Vd.c Li-ion Battery (500mAh) 5Vd.c of USB port of EUT 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a 2.4GHz Bluetooth Audio Receiver. The tests were conducted under RF Test mode to maintain continuous transmission during test. The transmission signal is digital modulated with channel frequency range 2402-2480MHz. The R.F. signal was modulated by IC. The test mode was controlled by test software – “FCC_assist.exe “used during tests, which was provided by manufacturer. 1.3 Date of Order 2020-08-24 1.4 Submitted Sample(s): 2 Samples 1.5 Test Duration 2020-09-02 to 2020-09-12 1.6 Country of Origin Not Provided Test Report Date : 2020-09-28 Page 4 of 85 No. : HM20080050 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.7 RF Module Details Module Model Number: AC6925A Module FCC ID: N/A Module Transmission Type: Bluetooth BR +EDR Modulation: GFSK, /4-DQPSK Data Rates: 2Mbps (Max) Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Channel List Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 42 2444 1 2403 43 2445 2 2404 44 2446 3 2405 45 2447 4 2406 46 2448 5 2407 47 2449 6 2408 48 2450 7 2409 ... ... 8 2410 67 2469 9 2411 68 2470 ... ... 69 2471 33 2435 70 2472 34 2436 71 2473 35 2437 72 2474 36 2438 73 2475 37 2439 74 2476 38 2440 75 2477 39 2441 76 2478 40 2442 77 2479 41 2443 78 2480 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2018 Regulations. ANSI C63.10:2013 for FCC Certification. The device was realized by test software. Test Report Date : 2020-09-28 Page 5 of 85 No. : HM20080050 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industri…

Text truncated - open the document above for the full version.

FCC ID: Y4O-TBT2 TEST SETUP PHOTOGRAPH OF THE PRODUCT Page 1 of 2 Radiated emission FCC ID: Y4O-TBT2 TEST SETUP PHOTOGRAPH OF THE PRODUCT Page 2 of 2 Conducted Emission
