GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 28 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 9. PHOTOGRAPHS FOR PRODUCT 1. Front View of RFID HF Reader.(EUT) 2. Back View of RFID HF Reader.(EUT) GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 29 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 3. Front View of RFID HF Reader.(EUT) 4. Back View of RFID HF Reader.(EUT)

GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 28 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 9. PHOTOGRAPHS FOR PRODUCT 1. Front View of RFID HF Reader.(EUT) 2. Back View of RFID HF Reader.(EUT) GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 29 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 3. Front View of RFID HF Reader.(EUT) 4. Back View of RFID HF Reader.(EUT)

GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 5 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 2.2 OPERATIONAL DESCRIPTION This device is transceiver of 13.56MHz RF Module included transmit and receive function. Another information please refer to users manual. 2.3 TEST MODES & EUT COMPONENTS DESCRIPTION 2.4 SUMMARY OF TEST PROCEDURE AND TEST RESULTS Test Item Applied Standard Section Test Resut Conducted Emission 15.207, ANSI C63.4 Section 7 Pass (refer to section 3.7) Radiated Emission 15.209, ANSI C63.4 Section 8 Pass (refer to section 4.7) The field strength of fundamental 15.225(a), ANSI C63.4 Section 13 Pass (refer to section 5.6) The field strength of any emissions appearing outside 15.225(d) , ANSI C63.4 Section 13 Pass (refer to section 6.6) Frequency Stability 15.225(e) , ANSI C63.4 Section 13 Pass (refer to section 7.6) 2.5 CONFIGURATION OF THE TESTED SYSTEM The FCC IDs/Types for all equipment, plus descriptions of all cables used in the tested system (including inserted cards, which have grants) are: Item Device No. Configuration 1 NOTEBOOK DELL NB 1 Model Number: Latitude D600 PPO5L BSMI ID FCC ID :R33002 E2K24CLNS Serial Number:10826163280 C.P.U:Intel Pentium M 1.4G HZ DDR:PC2100 256MB WIRELESS LAN CARD Manufacturer :INTEL M/N:WM3A2100 FCC ID: E2K24CLNS F.D.D:N/A H.D.D.:Manufacturer : FUJITSU 30G M/N: MHT2030AT S/N:NN15T421E09C BSMI ID:D33073 DVD-ROM:Manufacturer :DELL M/N:5W299-A01 BATTERY MODULE :Manufacturer :DELL Li-ion M/N:6Y270 RATING:14.8V 220mAh AC ADAPTOR :Manufacturer :DELL M/N: PA-1650-05D S/N:CN-05U092-48010-39N-227C INPUT:AC 100-240 V~1.5A 50-60HZ Shielded, Undetachable, 2.5m EUT: RFID HF Reader, M/N: WM150 Test Mode Mode 1-Transmit

Certificate Gestek GESTEK Gestek Gestek GESTEK Gestek estek GESTEK Gestek GEST stek GESTEK Gestek GESTE tek GESTEK Gestek GESTEK ek GESTEK Gestek GESTEK k GESTEK Gestek GESTEK GESTEK Gestek GESTEK GESTEK Gestek GESTEK Certificate of Test January 2011 GesTek EMC Lab N0. 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. TEL:886-2-2603-5321 FAX:886-2-2603-5325 WAVE TEK TECHNOLOGY Co., Ltd. Product Type : RFID HF Reader Model Number : WM150 Brand Name : WAVE-TEK Test Report Number : 1012009R-01 Date of Test : December 13, 2010 – December 16, 2010 This Product was tested to the following standards at the laboratory of Global EMC Standard Tech. Corp., and found Compliance. Standards: FCC Part 15 Subpart C Paragraph 15.225 ANSI C63.4: 2009 Sharon Chang, President Issue Date: January 05, 2011 http : //www.gestek.com.tw NVLAP LAB CODE 200085-0 GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 1 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 Test Report Application for Certification On Behalf Of WAVE TEK TECHNOLOGY Co., Ltd. EUT: RFID HF Reader Model Number: WM150 FCC ID: Y4V-WM150 Prepared for: WAVE TEK TECHNOLOGY Co., Ltd. 12F., No.953, Jhongjheng Rd., Jhonghe City., Taipei County 235, Taiwan (R.O.C.) Report By :Global EMC Standard Tech. Corp. No.3 Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel : 886-2-2603-5321 Fax : 886-2-2603-5325 1.Test results given in this report only relate to the specimen(s) tested, measured. 2.This report is the property of GesTek, and shall not be reproduced, other than in full, without the written consent of GesTek. 3.The report must not be used by the client to claim product certification, approval, or endorsement by any agency of the federal government. 4.All data in this report are traceable to national standard or international standard. GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 2 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 T A B L E OF C O N T E N T S DESCRIPTION PAGE 1. CERTIFICATION ..................................................................................................... 3 2. GENERAL INFORMATION ..................................................................................... 4 2.1 PRODUCTION DESCRIPTION ............................................................................... 4 2.2 OPERATIONAL DESCRIPTION ............................................................................. 5 2.3 TEST MODES & EUT COMPONENTS DESCRIPTION ......................................... 5 2.4 SUMMARY OF TEST PROCEDURE AND TEST RESULTS .................................. 5 2.5 CONFIGURATION OF THE TESTED SYSTEM ..................................................... 5 2.6 LAB AMBIENT ......................................................................................................... 6 2.7 TEST FACILITY ACCREDITATION ........................................................................ 6 2.8 TEST SETUP .......................................................................................................... 7 2.9 EUT OPERATING CONDITIONS ............................................................................ 7 3. CONDUCTED EMISSION MEASUREMENT .......................................................... 8 3.1 TEST EQUIPMENTS ............................................................................................... 8 3.2 TEST METHOD ....................................................................................................... 8 3.3 BLOCK DIAGRAM OF TEST SETUP ..................................................................... 8 3.4 CONDUCTED EMISSION LIMITS .......................................................................... 9 3.5 EUT CONFIGURATION ON MEASUREMENT ....................................................... 9 3.6 CONDUCTED EMISSION MEASURED PROCEDURE AND DATA ....................... 9 3.7 CONDUCTED EMISSION MEASUREMENT RESULTS ....................................... 10 4. RADIATION EMISSION DATA ............................................................................. 12 4.1 TEST EQUIPMENT ............................................................................................... 12 4.2 TEST METHOD ..................................................................................................... 12 4.3 TEST SITE SETUP DIAGRAM .............................................................................. 12 4.4 RADIATED EMISSION LIMIT ................................................................................ 13 4.5 EUT CONFIGURATION ........................................................................................ 13 4.6 RADIATED EMISSION DATA ............................................................................... 13 4.7 RADIATED EMISSIONS MEASUREMENT RESULTS ......................................... 14 5. RADIATION EMISSION DATA ............................................................................. 16 5.1 TEST EQUIPMENT ............................................................................................... 16 5.2 TEST METHOD ..................................................................................................... 16 5.3 TEST SITE SETUP DIAGRAM .............................................................................. 16 5.4 LIMITS ................................................................................................................... 17 5.5 EUT CONFIGURATION ........................................................................................ 17 5.6 TEST RESULTS .....................................................…

Text truncated - open the document above for the full version.

GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 25 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 8. PHOTOGRAPHS FOR TEST 8.1 TEST PHOTOGRAPHS FOR CONDUCTION Mode 1 GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 26 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 8.2 TEST PHOTOGRAPHS FOR RADIATION Mode 1-(30 MHz to 1 GHz) GESTEK Lab Report No: 1012009R-01 N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:886-2-2603-5321 Fax:886-2-2603-5325 Accredited Lab. Of BSMI, NEMKO, NVLAP. Page 27 of 33 Listed Lab. of Commerce, FCC, VCCI. NVLAP Lab Code:200085-0 Mode 1-(BELOW 30 MHz)
