Bluetooth Speaker Instruction Guide MODEL NO.: FH-17 PDF created with pdfFactory trial version www.pdffactory.com PDF created with pdfFactory trial version www.pdffactory.com Know your speaker ---- Speaker Adaptor On / Pause / Play Volume- Volume+ On/Off button Charging indicator light (Red) Bluetooth indicator Light AUX IN Micro 5p DC 5V IN PDF created with pdfFactory trial version www.pdffactory.com Using Bluetooth Speaker - To turn ON, slide the [POWER ON/OFF] switch to the ON position, the LED flashes BLUE 5 times quickly then once every few seconds. - To turn OFF, slide the [POWER ON/OFF] switch to the OFF position, the LED illuminates and the speaker will power OFF. The Reasons why you love it - Compatible with the Iphone, Ipad or any cell phone has Bluetooth, enjoy your loved song anytime, anywhere. - Can control the play mode through the speaker, makes everything convenient. - Wireless Bluetooth connection, effective range can reach to 10M, enjoys music boundless. - Automatically snooze mode, smart energy conversation. - USB charge support, easy for operation. Product Specifications - Wireless Bluetooth range: 33 feet 3 watt sound output Version: 3.0+ EDR - Standard Battery: Built in rechargeable 400mAh Lithium battery - Charge condition: Charge time: 2-3 hours Power input: DC 5V/200mA. Speaker Specifications - Diameter: φ40 mm - Impedance: 4Ω - Power output: 3W - Dbspl: 80±3dB 1W/M Wireless function - Frequency: 2.402-2.480 GHz - Receiving sensitivity: -82dBm - Transmission distance: within 10 meters - Data transmission rate: 3 Mbps PDF created with pdfFactory trial version www.pdffactory.com Package & accessories - Bluetooth Speaker - USB cable - Instruction manual FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body PDF created with pdfFactory trial version www.pdffactory.com
