Y961415100Wheelchair Scale System - Pad

26352 Ruether Avenue  Santa Clarita CA 91350-2990  (661) 250-0554  Fax (661) 250-7992 innoVision Devices, LLC 3/17/2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Innovision Devices LLC, would like to declare that the application being submitted for the device with FCC ID: Y961415100 has not been submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at 661-250-0554. Sincerely, Dave Lyznick COO

Correspondence by Project Project Number: Correspondence NumberMemo Y961415100-1 1. Please provide an alternate location for the FCC label. The FCC label is not permitted to go on the battery cover. Response: Per KDB Response: 667231 - this is OK. 2. Please provide a corrected block diagram. The block diagram shows Y1 as 12 MHz, but the schematics and photos show Y1 as 4 MHz. Response: The block diagram has been revised 3. Please provide information describing how the EUT meets the operational limitations of section 15.231 Response: The Theory of Operation has been revised. 4. Please provide a signed TCB contract Response: The signed contract has been uploaded.

26352 Ruether Avenue  Santa Clarita CA 91350-2990  (661) 250-0554  Fax (661) 250-7992 3/17/2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Wheelchair Scale Pad Battery Cover Gentlemen: The FCC label is to be affixed to the battery cover on the pad assembly PN: 1415-100. The battery cover is a hinged assembly that cannot be removed by the user. If you have any questions, please do not hesitate to contact us at 661-250-0554. Sincerely, Dave Lyznick COO innoVision Devices, LLC

Inquiry: Would the labeling requirements still be met if the FCC ID and FCC statement are on a battery cover that is a hinged assembly that cannot be removed? In other words, the battery cover cannot be removed from the EUT and will always be attached to the EUT. Response: This is permissible if the battery cover is permanently attached and cannot be removed. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. Message Status: Forwarded Message From: [email protected] To:[email protected] Date:03/23/2011 02:58 PM Subject:Response to Inquiry to FCC (Tracking Number 667231) FCC Home | Search | RSS | Updates | E-Filing | Initiatives | Consumers | Fi Office of Engineering and Technology Page 1 of 1WorldClient 3/31/2011https://www.celectronics.com:3001/WorldClient.dll?Session=UMZXFMS&View=Messag ...

Report Number: B10217D2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wheelchair Scale System – Pad Model: 1415-100 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 18 FCC PART 15 SUBPART B and C TEST REPORT for WHEELCHAIR SCALE SYSTEM – PAD MODEL: 1415-100 Prepared for INNOVISION DEVICES, LLC 26352 RUETHER AVENUE SANTA CLARITA, CALIFORNIA 91350 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: FEBRUARY 18, 2010 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 2 11 7 42 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B10217D2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wheelchair Scale System – Pad Model: 1415-100 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Facility Environmental Characteristics 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.1.3 RF Emissions Test Results 16 7.2 Bandwidth of the Fundamental 17 8. CONCLUSIONS 18 Report Number: B10217D2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wheelchair Scale System – Pad Model: 1415-100 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos • Test Setup Diagram • Antenna and Amplifier Factors • Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B10217D2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wheelchair Scale System – Pad Model: 1415-100 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 18 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Wheelchair Scale System – Pad Model: 1415-100 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Innovision Devices, LLC 26352 Ruether Avenue Santa Clarita, California 91350 Test Date(s): Feburary 15 and 16, 2011 Test Specifications: EMI requirements CFR Title 47, Part 15, Subpart B Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz The EUT does not directly or indirectly connect to the AC mains, thus this test was not performed. 2 Radiated RF Emissions 10 kHz – 4180 MHz (Transmitter Portion) Complies with the limits of CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231. Highest reading in relation to spec limit: 70.24 (Avg) dBuV/m @ 418 MHz (*U = 3.59 dB) 3 Radiated RF Emissions 10 kHz – 4180 MHz (Receiver and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B. *U = Expanded Uncertainty with a coverage factor of k=2 Report Number: B10217D2 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wheelchair Scale System – Pad Model: 1415-100 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 18 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Wheelchair Scale System – Pad, Model: 1415-100. The…
