Y98RP-44873RFID transceiver working at 125 kHz

Vers.1.2 RFID 2000 (Radio Frequency Identification) Architect’s User’s Owner’s Guide Note: Company Sumetzberger reserves the right to do modifications on their products, which serve the technical development of the products. These modifications are not necessarily recorded in each particular case. This documentation and the contained information are recorded and arranged with the necessary diligence, but company Sumetzberger takes no guarantee for printing errors or other faults or resulting damages. The brand and products named in this documentation are trademarks or regis- tered trademarks of the particular title holder. © Copyright 2011 Ing Sumetzberger GmbH Ing Sumetzberger GmbH Leberstraße 108 A-1110 Vienna Te l e p h o n e +43.(0)1.74035 0  Fax+43.(0)1.74035 300 E-mail (Technical support)[email protected] E-mail (Sales)[email protected] Þ Homepagewww.sumetzberger.com CONTENTS RFID 2000 (Radio Frequency Identification) 1 Data sheets RFID 2000 ................................................................................................ 1 Code Tag.................................................................................................. 2 Antenna 110 ............................................................................................. 3 Antenna 160 ............................................................................................. 4 2 Installation RFID2000 ................................................................................................. 5 Antenna ................................................................................................... 6 Carrier 160 ............................................................................................... 7 Flip top carrier 110 .................................................................................... 8 Application examples of RFID2000 units ..................................................... 9 3 Cabling General-System cable ................................................................................ 10 Power supply with filter modul ................................................................... 11 SCB2000 with RFID and 1 Antenna............................................................. 12 SCB2000 with RFID and 3 Antenna............................................................. 13 4 EU-Conformity Declaration 5 FCC-Registration FCC Statement.......................................................................................... 15 FCC Confidentiality Request ....................................................................... 16 6 User Instruction Manual General Safety Instructions ........................................................................ 17 Label for devices ....................................................................................... 18 General .................................................................................................... 19 Keyboard.................................................................................................. 20 User numbers ........................................................................................... 20 Making a transit ........................................................................................ 21 Arrival Signal ............................................................................................ 22 Special Codes ........................................................................................... 23 Security.................................................................................................... 24 DCU Instruction Special Codes ................................................................... 25 Data sheets 1 - 1 8.3.11 RFID 2000 Vers.1.2 Data sheets RFID 2000 Model RFID 2000 Manufacturer Sumetzberger GmbH Leberstraße 108; 1110 Vienna Use Extension card: Code Tag Function By equipping the carrier with passive transponder (no battery), called code tags on both ends, all carries can receive there own identification number and so they can be assigned to a determinate station. The return to this "homestation" is possible without entering the address. Therefor only carriers can be used which are registered to the system and not registered carriers can’t be infiltrated in the system. Follow stations can be equipped: DRT110, DRT Front 110, E3S110 MSS110/160 DST160, DST-END160. Technical description The RFID 2000 board is a four antenna reader for Philips HITAG2 Chips. The main controller is a PIC16F873A running with 16 MHz, which multi- plexes four tuning devices (Philips HTRC-110) and is connected with an I²C bus to the main board. Each antenna has an own tuning device (Philips HTRC-110), which produces the 125 kHz antenna signal and reads the chips. Technical data Sending frequency: 125kHz Exciting frequency: 125kHz Picture: Data sheets 1 - 2 8.3.11 RFID 2000 Vers.1.2 Code Tag Model "Code Tag" (passive Transponder) Item Identification Transponder for the use in contactless applications Frequency 125kHz operating frequency Power supply Data transmission and supply energy via RF link, no internal battery The code tag is dedicated for the use in secure access systems (transpon- der and reader have to identify each other). The transponder requires no internal power supply; it derives its power from magnetic component of the RF carrier frequency generated by the reader antenna. Data storage EEPROM; guaranteed ten years of non-volatile data retention Programming Programming via carrier programming unit. More than 100.000 erase/ write cycles possible. Mechanical dimensions 12x6x3mm (refer to pic) Temperature Operating temperature:- 40°C bis 85°C Storage temperature:- 55°C bis 125°C Protection class IP67 Casting material epoxy resin Picture Data sheets 1 - 3 8.3.11 RFID 2000 Vers.1.2 Antenna 110 Model Antenna 110 Manufacturer Sumetzberger GmbH Leberstraße 108; 1110 Vienna Use To identify the coded carrier Technical data φ110mm Accessori…

Text truncated - open the document above for the full version.

Coverletter: Ing. Sumetzberger GmbH wants to get FCC-Certification as limited modular approval for the solely use in their end-products for the following model: RFID module device named RFID 2000. The unit will get the following FCC-ID: Y98RP-44873 List of documents: Exhibit Thema File Exhibit 01 Label and placement labelandplacement.jpg Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern 11-126.pdf * Exhibit 04 Block Diagrams Block Diagram.pdf * Exhibit 05 Schematic Diagrams 3 - Schaltbild.pdf Exhibit 06 Testreport 11-126.pdf Exhibit 07 Test Set-up Photos setup 11-126.pdf Exhibit 08 User Manual Architect's User's Owner's Guide.pdf Exhibit 09 Internal Photos intern 11-126.pdf Exhibit 10 Not needed -------------------- Exhibit 11 RF exposure -------------------- * Exhibit 12 Operational Description technical_description.pdf Exhibit 13 Cover letter Request for confidentiality This file 6 - Request for Confidentiality.pdf For the Exhibits marked with ‘*’ Ing. Sumetzberger GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos is not the actual status. The correct labelling you can see on the label and placement photo in Exhibit 1.
