Y9MRA-450DMR REPEATER-UHF BASE STATION

R R a a d d i i o o A A c c t t i i v v i i t t y y S S . . r r . . l l . . Headquarter: Via Ponte Nuovo, 8- 20128 Milano- Italy– email:[email protected] Phone 02.36514205- FAX/Voicebox 1782242408- Registrazion CCIAA Milano N° 1728248- P.I./C.F.04135130963 D D M M R R _ _ M M a a n n a a g g e e r r O O p p e e r r a a t t i i n n g g M M a a n n u u a a l l V V e e r r s s i i o o n n 1 1 v v 2 2 DMR_Manager Operating Manual2011/07/04Version1v2 Reserved Document– Don’t forward without authorization Page2 of51 Index 1INTRODUCTION........................................................................................................................4 2CONCEPTS OVERVIEW..............................................................................................................5 2.1TRX ARCHITECTURE.......................................................................................................................5 2.2RADIO ACTIVITY DMR REPEATER AND UPGRADEABILITY TO SIMULCAST NETWORK........................6 2.3NETWORK.....................................................................................................................................7 2.3.1MASTER BASE STATION IN “RF LINKED” NETWORKS.......................................................................7 2.3.2SATELLITE BASE STATION IN “RF LINKED” NETWORKS.....................................................................7 2.4SIMULCAST NETWORKS.................................................................................................................7 2.4.1SYNCHRONIZATION, VOTING AND EQUALIZATION..........................................................................8 2.5DMR (DIGITAL MOBILE RADIO).......................................................................................................9 2.5.1ALARM MESSAGES..........................................................................................................................10 3INSTALLATION........................................................................................................................11 3.1SYSTEM REQUIREMENTS..............................................................................................................11 3.2INSTALLATION ON THE PC............................................................................................................11 3.2.1INSTALLATION ON WINDOWS XP  OPERATING SYSTEMS.............................................................11 3.2.2INSTALLATION ON WINDOWS VISTA or Windows 7 OPERATING SYSTEM..................................11 3.3CREATING LINK TO DESKTOP........................................................................................................12 3.4UNINSTALLATION FROM WINDOWS 2000 OR WINDOWS XP.........................................................12 3.5UNINSTALLATION ON WINDOWS VISTA OPERATING SYSTEM........................................................12 4PROGRAM STARTUP..............................................................................................................13 4.1CONNECTION SETUP....................................................................................................................13 4.2REMOTE CONTROL CONNECTION LOST.........................................................................................15 5MAIN MENU WINDOW..........................................................................................................16 5.1DMR MANAGER...........................................................................................................................17 5.2SOFTWARE..................................................................................................................................17 5.3RA DMR.......................................................................................................................................18 6MENU DETAILS.......................................................................................................................19 6.1SOFTWARE MENU........................................................................................................................19 6.1.1VERSIONS........................................................................................................................................19 DMR_Manager Operating Manual2011/07/04Version1v2 Reserved Document– Don’t forward without authorization Page3 of51 6.1.2DOWNLOAD....................................................................................................................................19 6.2RA-DMR MENU............................................................................................................................21 6.2.1SETUP..............................................................................................................................................21 6.2.1.1DATE AND TIME.......................................................................................................................22 6.2.1.2E-DSP CONFIGURATION...........................................................................................................22 6.2.1.3GPS/GPRS CONFIGURATION....................................................................................................23 6.2.1.4STARTUP STATUS.....................................................................................................................24 6.2.2RADIO CONFIGURATION.................................................................................................................24 6.2.2.1TRX OPERATING MODES..........................................................................................................26 6.2.2.2CHANNELS TABLE.....................................................................................................................27 6.2.2.3TX CONTROL...........................................................................................................................…

Text truncated - open the document above for the full version.

DMR DIGITAL MOBILE RADIO ASSOCIATION Radio Activity S.r.l. Sede: Via Ponte Nuovo, 8 - 20128 Milano – email: [email protected] - www.radioactivity-tlc.com Tel. 02.36514205 - FAX/Voicebox 1782242408 - Registrazione CCIAA Milano N° 1728248 - P.I./C.F. 04135130963 D D M M R R R R e e p p e e a a t t e e r r u u s s e e r r m m a a n n u u a a l l V V e e r r s s i i o o n n 1 1 v v 3 3 DMR repeater 18/02/2011 Versione 1.3 Documento Riservato - non divulgabile senza autorizzazione Pag. 2 / 32 Index 1 RADIO ACTIVITY DMR REPEATER AND EXPANDIBILITY TO SIMULCAST NETWORK......................4 2 PARAMETERS CONFIGURATION AND REMOTE CONTROL ..........................................................5 3 HARDWARE COMPOSITION OF A BASE STATION.......................................................................6 3.1 PSU: POWER SUPPLY UNIT MODULE.............................................................................................. 6 3.2 DSP: DIGITAL SIGNAL PROCESSOR ................................................................................................. 7 3.3 RECEIVER...................................................................................................................................... 8 3.4 TRANSMITTER............................................................................................................................... 9 3.5 I/O AND SERVICES MODULE ........................................................................................................ 10 4 TECHNICAL DATA....................................................................................................................11 4.1 REGULATIONS COMPLIANCE........................................................................................................ 11 4.2 GENERAL CHARACTERISTICS ........................................................................................................ 11 4.3 IP interfacing .............................................................................................................................. 12 4.3.1 LAN protocol ...................................................................................................................................12 4.3.2 LAN requirements...........................................................................................................................12 4.3.3 Ports and connectors......................................................................................................................13 4.3.4 Codec VoIP......................................................................................................................................13 4.4 Radio frequency.......................................................................................................................... 14 4.4.1 Transmitter......................................................................................................................................14 4.4.2 Receiver...........................................................................................................................................15 4.4.3 Frequency bands.............................................................................................................................17 4.4.4 Commutation band (without duplexer)..........................................................................................17 4.4.5 Branching requirements .................................................................................................................17 4.4.5.1 TX to antenna duplex isolation requirements @10W TX RF power........................................17 4.4.5.2 Suggested RX max input limits on unwanted signals...............................................................18 4.5 Other specifications .................................................................................................................... 18 4.5.1 Environmental parameters.............................................................................................................19 4.5.2 Power supply...................................................................................................................................19 4.5.3 Mechanical characteristics..............................................................................................................19 4.5.4 Audio balanced interfaces...............................................................................................................19 5 EQUIPMENT INSTALLATION AND MAINTENANCE....................................................................20 5.1 CONNECTIONS AND PINOUTS...................................................................................................... 20 5.2 EQUIPMENT START UP, RUNNING AND ALARMS: INDICATOR LAMPS ........................................... 27 5.2.1 PSU..................................................................................................................................................27 5.2.2 DSP..................................................................................................................................................27 DMR repeater 18/02/2011 Versione 1.3 Documento Riservato - non divulgabile senza autorizzazione Pag. 3 / 32 5.2.3 RX....................................................................................................................................................28 5.2.4 TX.....................................................................................................................................................28 5.2.5 I/O ...................................................................................................................................................28 5.3 GENERAL RECOMMENDATIONS AND NOTES................................................................................ 29 5.3.1 Improper use...........................................................................................…

Text truncated - open the document above for the full version.

29/09/2011 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Spa– via del Carroccio n. 4, Biassono (MB) Italy to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with(applicant name and address). Dated this 29 Day ofSeptember 2011 Agency agreement expiration date:September29, 2012 By:Mauro Campidoglio SignaturePrinted Title:Mr. On behalf of :Radio Activity s.r.l. Telephone:00390236514205

29/09/2011 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: Y9MRA-450 Product Name: RA-450 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics and parts lists Block diagrams Operational description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 29 Day ofSeptember 2011 By: Mauro Campidoglio SignaturePrinted Title:Mr. On behalf of :Radio Activity s.r.l. Telephone:00390236514205

Radio Activity S.r.l. Via Ponte Nuovo, 8- 20128 Milano- Italy email:[email protected] Tel. +39.02.36514205- FAX/Voicebox +39.1782.242408 CCIAA Milano N° 1728248- VAT Id. 04135130963 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: Y9MRA-450 Product Name: RA-450 FCC ID justification letter for expanded frequency range 407-470 MHz The RA-450 radio was designed to operate in the frequency band 407-470 MHz Radio Activity s.r.l. requests to have FCC authorized frequency band 407-470 MHz under FCC rule part 90 on the FCC Grant Local, State and Federal organizations,Government bodies and their various departments, user organizations and military may use this device in the extended frequency range. This device will also be sold in non-US markets where use of the extended frequenciesmay be authorized. The applicant will notify the end users in the US that: 1.The device is to be programmed only for frequencies allowed by the user’s radio station authorization. 2.It is a violation of FCC rules if the device operates on the unauthorized frequencies. 3.This device uses extended frequencies and may contain functions that are not operational in US territories, except as noted in the filing. List of authorized frequencies allowed by the rule part applied for 406.1 to42090Private Land Mobile* 420 to45090Private Land Mobile* 97Amateur 450 to454 74DRemote Pickup 74HLow Power Auxiliary 90Private Land Mobile* 45445522Public Mobile 80Maritime 45545674DRemote Pickup 74HLow Power Auxiliary 456 to460 22Public Mobile 80Maritime 90Private Land Mobile* Radio Activity S.r.l. Via Ponte Nuovo, 8- 20128 Milano- Italy email:[email protected] Tel. +39.02.36514205- FAX/Voicebox +39.1782.242408 CCIAA Milano N° 1728248- VAT Id. 04135130963 460 to462.537590Private Land Mobile* 462.5375462.737595Personal Radio 462.7375 to467.537590Private Land Mobile* 467.5375467.737595Personal Radio 467.7375 to47090Private Land Mobile* *authorized frequencies highlighted in blue Equipment programming is responsibility of Authorized Service Personnel. The device complies with CFR Title 47, section 90.203. The operator can’t directly program and transmit on frequencies, other than those programmed by the manufacturer, service or maintenance personnel, using only the normally accessible external controls of the unit. According FCC KDB634817 guidance, we acknowledge that it is a violation of FCC rules if the device operated on unauthorized frequencies. Dated this 22 Day ofOctober2011 By:Mauro Campidoglio SignaturePrinted Title:Mr. On behalf of : Radio Activity s.r.l. Telephone: 00390236514205

DMR DIGITAL MOBILE RADIO ASSOCIATION Radio Activity S.r.l. Sede operativa: Via Ponte Nuovo, 8- 20128 Milano– email:[email protected] Tel. 02.36514205-FAX/Voicebox 1782242408- Registrazione CCIAA Milano N° 1728248- P.I./C.F. 04135130963 E E x x t t e e r r n n a a l l p p h h o o t t o o s s R R A A - - 4 4 5 5 0 0 V V e e r r s s i i o o n n e e 1 1 v v 0 0 DMR repeater03/10/2011Versione1.3 Pag.2 /5 Index 1FRONT.....................................................................................................................................3 2TOP..........................................................................................................................................3 3REAR........................................................................................................................................4 4BOT.........................................................................................................................................4 5RIGHT......................................................................................................................................5 6LEFT.........................................................................................................................................5 DMR repeater03/10/2011Versione1.3 Pag.3 /5 1FRONT 2TOP DMR repeater03/10/2011Versione1.3 Pag.4 /5 3REAR 4BOT DMR repeater03/10/2011Versione1.3 Pag.5 /5 5RIGHT 6LEFT

R R a a d d i i o o A A c c t t i i v v i i t t y y S S . . r r . . l l . . Registration CCIAA Milano No. 1728248– P.I./C.F.: 04135130963 Operational headquarter: Via Ponte Nuovo 8– 20128 Milano MI- Italy Phone: +39 0236 514 205–Fax/Voicebox: +39 1782 242 408–Email:[email protected] www.radioactivity-tlc.it I I n n t t e e r r n n a a l l p p h h o o t t o o s s RA-450 V V e e r r s s i i o o n n 1 1 v v 0 0 Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page2of8 Summary Internal photos..............................................................................................................................3 PSM........................................................................................................................................................3 DPS.........................................................................................................................................................4 RX UHF....................................................................................................................................................5 TX UHF....................................................................................................................................................6 I/O..........................................................................................................................................................7 BACK PLANE............................................................................................................................................8 Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page3of8 INTERNAL PHOTOS P P S S M M Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page4of8 D D P P S S Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page5of8 R R X X U U H H F F Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page6of8 T T X X U U H H F F Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page7of8 I I / / O O Internal photos2011/09/29Version1v0 Confidential-Notpublishablewithout authorization Page8of8 B B A A C C K K P P L L A A N N E E

DMR DIGITAL MOBILE RADIO ASSOCIATION Radio Activity S.r.l. Sede operativa: Via Ponte Nuovo, 8 - 20128 Milano – email: [email protected] - www.radioactivity-tlc.com Tel. 02.36514205 - FAX/Voicebox 1782242408 - Registrazione CCIAA Milano N° 1728248 - P.I./C.F. 04135130963 R R A A - - x x x x x x t t u u n n e e u u p p i i n n f f o o r r m m a a t t i i o o n n V V e e r r s s i i o o n n e e 1 1 v v 0 0 DMR repeater 25/01/2011 Versione 1.3 Pag. 2 / 8 Index 1 CARATTERISTICHE GENERALI ..................................................Errore. Il segnalibro non è definito. 1.1 Standard.....................................................................................Errore. Il segnalibro non è definito. 1.1.1 PORTE E CONNETTORI...............................................................Errore. Il segnalibro non è definito. DMR repeater 25/01/2011 Versione 1.3 Pag. 3 / 8 1 TUNE UP INFORMATION Tune up process of RA-xxx equipments is very simple and can be made through a PC with installed DMR_manager application. Every setting of the transceiver can be changed by SW application only. 1 1 . . 1 1 Q Q U U I I C C K K I I N N S S T T A A L L L L A A T T I I O O N N A A N N D D P P O O W W E E R R O O N N The base station is equipped with a discrete set of HW connectors on the rear side, but only few of them are essential for working; the following connections are needed: ∞ Power supply: by 12V battery with negative to ground; nominal power supply voltage is 13,8Vdc, minimum is 10.8V and maximum is 15.4V, with electronic protection from overvoltage and undervoltage. Current absorption is 1A@1W, 5A@25W, max 7A. ∞ Main RX / TX antenna; for laboratory test, it is better to connect a 20dB RF attenuator between radio equipment and the antenna; ∞ Ethernet: TCP/IP connection to the same LAN as for the PC for remote control. The following picture shows the basic connections in red colour and optional ones in blu. When the equipment is powered on, it automatically performs the following actions: DMR repeater 25/01/2011 Versione 1.3 Pag. 4 / 8 ∞ Linux booting, during which LEDs of DSP module are yellow; ∞ download of software applications to DSP, clock generator and eventually to microcontrollers of peripheral modules which LEDs are flashing yellow and green; ∞ self calibration test, with the aim to tune the parameters of modulator and of demodulator and to test the overall performances. It taks about 1 minute, during which LEDs are flashing green and red. At the end of this process, only the following LEDs will remain on (see User Manual for further information): ∞ on PSM module, both leds will be green, monitoring the correct supply; ∞ on DSP module “LINK” led is green if equipment is connected to ethernet LAN, “ACT” led is flashing yellow if LAN communication is present; Now the equipment is ready to be tuned through a PC connected to the same LAN. The Ethernet interface of RA-xxx transceiver is auto-sensing: both straight and crossed cables are allowed. On a PC the application “DMR_Manager.exe” shall be installed (see User Manual for further information) and launched. The equipment can be accessed at a specific IP address, as indicated on a side of the equipment itself. 1 1 . . 2 2 T T U U N N E E U U P P P P A A R R A A M M E E T T E E R R S S RA-xxx equipments can work in dual mode, that is, they can recognize if the incoming signal from a terminal equipment is analog or digital and configure itself as analog or DMR. The remote control SW is very powerful and complex, but few mask are enough to set and to monitor the basic analog and DMR parameters. DMR repeater 25/01/2011 Versione 1.3 Pag. 5 / 8 From the main mask of DMR_Manager, open RA-DMR
Controls
Radio control. This mask allows the following actions: ∞ to change power of RF transmitter from 1W to 25W; ∞ to change frequency of RX and TX, or to change the current channel; ∞ to change TCS/DPL ; ∞ to check the main analog measures which are automatically performed. Eventual modifications of parameters will not be saved into internal flash: in order to permanently change parameters, channel table must be edited (by the mask RA-DMR
Radio Configuration
Channel table). If frequencies are significantly changed (some MHz), it is suggested to make the transceiver perform a new self-calibration process. In order to do this, the last channel (the 201 st ) of the channel table contains self-calibration frequencies parameters: you should change the frequencies of both working and self-calibration channel. Specifically in detail, the TX and RX frequency of calibration channel must be the same, they must be multiple of 100KHz and must be as nearest as possible to the TX frequency of working channel. In order to make the modification active and to perform a new self-calibration, the application on the equipment can be restarted by the command RA-DMR
Restart...
Main. DMR repeater 25/01/2011 Versione 1.3 Pag. 6 / 8 The main parameters of DMR mode can be set by the mask RA-DMR
Radio Configuration
DMR Layer configuration. In the lower part of this mask main, DMR measures which are automatically performed, can be seen. DMR repeater 25/01/2011 Versione 1.3 Pag. 7 / 8 The transmission can be enabled by different commands to get different effects: ∞ if the “repeater mode is enabled” the equipment will transmit the same received signal. This function can be enabled in DMR mode by the mask RA-DMR
Radio Configuration
DMR Layer configuration by checking the box “Enabling DMR repeater” and in analog mode by the mask RA-DMR
Radio Configuration
TRX operating modes by checking the box “Enabling repeater mode”; ∞ if an external analog signal is applied to the input of the “audio line interface” connector and its input contact is closed, the TX will go “on air” with the modulated carrier by the external signal in FM mode; ∞ the TX can also transmit a modulated carrier by an internally generated analog signal: by the mask RA-DMR
Controls
Radio control an audio frequen…

Text truncated - open the document above for the full version.

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 43.77 (dBm) Maximum peak output power at antenna input terminal: 23823.19469 (mW) Antenna gain(typical): 8 (dBi) Maximum antenna gain: 6.309573445 (numeric) Prediction distance: 210 (cm) Prediction frequency: 407 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 0.271333333 (mW/cm^2) Power density at prediction frequency: 0.271239 (mW/cm^2) Maximum allowable antenna gain: 8.001516037 (dBi) Margin of Compliance: 0.001516037 2 4 R PG S π =

www.nemko.com Nemko Italy S.p.A., Via del Carroccio 4, 20853, Biassono, Italy. Report number: 165681TRFWL Apparatus: RA*450 Applicant: Radio Activity S.r.l. FCC ID: Y9MRA*450 Test specification: Title 47*Telecommunication Chapter I * Federal Communications Commission Subchapter D – Safety and special radio services Part 90 – Private land mobile services − Subpart I – General technical standards Reviewed by: 2011*10*19 Signature Date G. Curioni, Wireless/EMC Specialist Tested by: 2011*10*19 Signature Date D. Guarnone, Wireless/EMC Specialist Nemko S.p.A. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko S.p.A. accepts no responsibility for damages, if any suffered by any third party as a result of decisions made or actions based on this report. This report shall not be reproduced except in full without the written approval of the testing laboratory. Nemko Italy S.p.A. Via del Carroccio 4, 20853, Biassono, Italy. Report Number: 165681TRFWL Specification: FCC 90 Page 2 of 57 Table of contents Section 1: Report summary ................................................................................................................... 3 Section 2: Equipment under test .......................................................................................................... 4 2.1 Identification of equipment under test (EUT) ............................................................................ 4 2.2 Accessories and support equipment ......................................................................................... 4 2.3 EUT description ........................................................................................................................ 5 2.4 Technical specifications of the EUT .......................................................................................... 5 2.5 EUT setup diagram................................................................................................................... 6 2.6 Operation of the EUT during testing ......................................................................................... 6 2.7 Modifications incorporated in the EUT ...................................................................................... 6 Section 3: Test conditions .................................................................................................................... 7 3.1 Deviations from laboratory tests procedures ............................................................................. 7 3.2 Test conditions, power source and ambient temperatures .......…

Text truncated - open the document above for the full version.
