YAW529027-ZSunPower Monitoring System with PVS6

Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2. Installation location The product shall be installed at a location where the radiating antenna can be kept 25cm from nearby person in normal operation condition to meet regulatory RF exposure requirement. 3. External antenna Use only the antennas which have been approved by the applicant. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC limit and is prohibited. 4. Installation procedure Please refer to user’s manual for the detail. Mount the PVS6 (1). Select an installation location that is not in direct sunlight. (2). Mount the PVS6 bracket to the wall (+0 degree) using appropriate hardware for the mounting surface and that can support at least 6.8 kg (15 lbs). (3). Fit the PVS6 onto the bracket until the mounting holes at the bottom are aligned. (4). Use a screwdriver to secure the PVS6 to the bracket using the provided screws. Do not overtighten. 5. Warning Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to serious federal penalty.

Installation and field service is to be performed only by qualified, trained personnel with the necessary skills and knowledge to work on this type of electrical device. Field service is limited to the components contained in the lower compartment of the PVS6. • Perform all electrical installations in accordance with any national and local codes, such as the National Electrical Code (NEC) ANSI/NFPA 70. • This enclosure is suitable for use indoors or outdoors (NEMA Type 3R). Operating ambient from −30°C to 60°C. • Before connecting power, the PVS6 must be securely mounted to an inside or outside wall following the instructions in this document. • For electrical wiring code compliance, connect the PVS6 to a de dicated UL Listed 15 A rated breaker using 14 AWG wiring, or a UL Listed 20 A rated breaker using 12 AWG wiring. The input operating current is less than 0.1 amp with AC nominal voltages of 240 VAC (L1–L2). • The PVS6 contains internal transient surge protection for conne ction to the load side of the service entrance AC service panel (overvoltage category III). For installations in areas at risk of surges generated by high-voltage utilities, industry, or by lightning, it is recommended that a UL Listed external surge protective device also be installed. • Do not attempt to repair the PVS6. Tampering with or opening th e upper compartment voids the product warranty. • Use only UL Listed, double-insulated, XOBA CTs with the PVS6. Safety Instructions Safety & Certifications This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. IMPORTANT NOTES: Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 25 cm (9.84 in) between the device and your body. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. FCC Compliance • UL Listed to UL 61010 and UL 50 for outdoor use. • The PVS6 is not a utility meter, disconnect device, or power distribution device. Safety Certification 1.Mount the PVS6 1.Select an installation location that is not in direct sunlight. 2. Mount the PVS6 bracket to the wall using appropriate hardware for the mounting surface and that can support at least 6.8 kg (15 lbs). 3.Fit the PVS6 onto the bracket until the mounting holes at the b ottom are aligned. 4. Use a screwdriver to secure the PVS6 to the bracket using the provided screws. Do not overtighten. 2.Wire the PVS6 power Danger! Hazardous voltages! Do not power up the system until after you complete Sections 1 through 3. Accessing the system involves possible contact with potentially lethal voltages and currents. No attempt to access, install, adjust, repair, or test the system should be made by anyone who is not qualified to work on such equipment. Use copper conductors only, with min. 75°C temp. rating. 1. Use a screwdriver—do not use power tools—to prepare the PVS6 for AC wiring: • Using a flat-blade screwdriver, carefully bend the PVS6 cover retention tab back to release and then remove the outer cover •Remove the lower AC wiring cover •Remove the upper AC wiring cover 2.Run power conduit from the service panel to the PVS6. If you use the rear conduit entrances, seal the holes on the bottom of the enclosure with the included hole plugs. Use step drill if you are using rear or center bottom entrances . 3.Connect the PVS6 to either a 15 A (with 14 AWG) or a 20 A (with 12 AWG) UL Listed dedicated dual-pole breaker. Note: For AC modules, this breaker should be in the same service panel containing the AC module output circuits. 4.Strip wires to 12 mm and land according to the color-coded labels (black wire to L1 , red wire to L2, the white wire to N, and green wire to GND) in the J2 terminals on the bottom left of the PVS6 board, and then close each locking lever completely. 3.Install and wire the consumption CTs Danger! Hazardous voltages! Do not power up the system until after you complete Sections 1 through 3. Accessing the system involves possible contact with potentially lethal voltages and currents. No attempt to access, install, adjust, repair, or test the system should be made by anyone who is not qualified to work on such equipment. Max. 120/240 VAC split phase, three wire system, Measurement Category III, 0.333 VAC from a current sensor rated to measure max. 50 A. The SunPower-provided CTs are suitable for use on 200 A conduct ors. CTs may be labeled “100 A” but this is a calibration reference rati…

Text truncated - open the document above for the full version.

Date: June 15, 2022 FCC ID: YAW529027-Z AUTHORIZATION LETTER To whom it may concern: I, the undersigned Ramakrishna Jupalli of SunPower Corporation hereby authorize Kevin Fischer of SunPower Corporation to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by Kevin Fischer on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------------------------------------------------- Ramakrishna Jupalli/Senior Electronics Engineer [email protected] Tel: 510-260-8219 Fax: 510-540-0552

香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 1 Referencing Test Data Table of Contents 1. Original General Descriptions of EUT ............................................................................................. 2 2. Form Factor and Photos .................................................................................................................. 2 3. Main board PCB Photos ................................................................................................................... 3 4. PSU PCB Photos .............................................................................................................................. 4 5. Referencing test items ..................................................................................................................... 5 6. Spot- Check Test Plan ...................................................................................................................... 6 7. Acceptance criteria for spot check .................................................................................................. 7 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 2 1. Original General Descriptions of EUT Equipment Referenced Device Model Variant Device FCC ID YAW529027 YAW529027-Z FCC Granted Date Original: 01/25/2019, C2PC: 01/19/2022 NA Test Model PVS6 PVS6 RF characteristics 2TX WLAN 2.4GHz 2412 - 2462 MHz 2TX WLAN 2.4GHz 2412 – 2462 MHz 2TX WLAN 5GHz 5180 - 5240 MHz 5745 - 5825 MHz 2TX WLAN 5GHz 5180 - 5240 MHz 5745 - 5825 MHz 1Tx BT-EDR 2402 - 2480MHz 1Tx BT-LE 2402 - 2480MHz 1Tx Zigbee 2405 – 2480MHz 1Tx BT-EDR 2402 - 2480MHz 1Tx BT-LE 2402 - 2480MHz Hardware Difference 1. With Zigbee component 1. W/O Zigbee component Identical Identical internal printed circuit board layouts Have a common design and components except Zigbee component WLAN 2.4GHz & 5GHz & BT CHIP : AP6398S Variant spot-check test results are within the tune-up tolerance range specified and are compliant with applicable rule part(s). 2. Form Factor and Photos base on FCC KDB guidance 484596 Rules , The printed circuit board layouts the same ; RF technologies the same (WiFi 2.4G & WiFi 5G & BT) Difference : Remove Zigbee component 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 3 3. Main board PCB Photos Referenced Device Model variant FCC ID: YAW529027 FCC ID: YAW529027-Z 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 4 4. PSU PCB Photos Referenced Device Model variant FCC ID: YAW529027 FCC ID: YAW529027-Z all is the same with original. 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 5 5. Referencing test items Part 15C FCC Clause Test Items Referenced Test Data Note 15.247 (a)(1) / (b) Conducted Output Power Y 15.207 AC Power Line Conducted Emission N 15.247(a)(1) (iii) Number of Hopping Frequency Used and Dwell Time on Each Channel Y 15.247(a)(1) 1. Hopping Channel Separation 2. Spectrum Bandwidth of a Frequency Hopping Sequence Spread Spectrum System Y 15.205/ 15.209/ 15.247(d) Radiated Emissions and Band Edge Measurement Y 15.247(d) Antenna Port Emission Y 15.247(a)(2) 6dB bandwidth Y 15.247(e) Power Density Y Part 15E FCC Clause Test Items Referenced Test Data Note 15.407(a)(1/2/3) Conducted Output Power Y 15.207 AC Power Line Conducted Emission N 15.407(b) (1/2/3/4 (i/ii) Radiated Emissions and Band Edge Measurement Y 15.407(a)(1/2/3) 26dBc bandwidth Y - 99% Occupied bandwidth Y 15.407(e) 6dB bandwidth Y 15.407(a)(1/2/3) Power Density Y 15.407(g) Frequency Stability Y Variant spot-check test results are within the tune-up tolerance range specified and are compliant with applicable rule part(s). 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 6 6. Spot- Check Test Plan Amount of test samples: 1 sample Equipment Class Rule Part Test Items Frequency Band Test Modes Test Channel DTS Part 15C Conducted output power 2412-2462 MHz 802.11 b/g/n Low/ Mid/ High Radiated emission – Band edge and Harmonics (Above 1GHz) One channel with maximum power among 802.11 b/g/n One channel with maximum power Radiated emission (Below 1GHz) AC Power Line Conducted Emission DTS Part 15C Conducted output power 2402-2480 MHz BT-LE Low/ Mid/ High Radiated emission – Band edge and Harmonics (Above 1GHz) One channel with maximum power among BT-LE GFSK One channel with maximum power Radiated emission (Below 1GHz) AC Power Line Conducted Emission DSS Part 15C Conducted output power 2402-2480 MHz BT-EDR Low/ Mid/ High Radiated emission – Band edge and Harmonics (Above 1GHz) All Channel retest (See Note 2) Low/ Mid/ High Radiated emission (Below 1GHz) One channel with maximum power among BT-EDR One channel with maximum power AC Power Line Conducted Emission NII Part 15E Conducted output power 5180-5240MHz, 5745-5825MHz 802.11 a/n/ac Low/ Mid/ High for each sub band Radiated emission – Band edge and Harmonics (Above 1GHz) One channel with maximum power among 802.11 a/n/ac One channel with maximum power Radiated emission (Below 1GHz) AC Power Line Conducted Emission 香港商立德國際商品試驗有限公司桃園分公司 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 7 Note: RF Conducted output power were confirmed and the same as Referenced Device (FCC ID: YAW529027) Note2 : The standard has changed the test above 1G, so the data above BT-EDR is updated Variant spot-check test results are within the tune-up tolerance range specified and are compliant with applicable rule part(s). Original Report Test Data: Please find attached the PDF File: YAW529027 (Referenced Device) original Data.PDF 7. Acceptance criteria for spot check Test Items Frequency Deviation Tolerance Acceptance criteria Conducted Output power All operating band -0.5 dB The test result compare to the test result of Referenced device must be within Deviation Tolerance and must be lo…

Text truncated - open the document above for the full version.

Reference No.: BFBE-WTW-P22040507_EXT Page 1/5 CONSTRUCTION PHOTOS OF EUT Reference No.: BFBE-WTW-P22040507_EXT Page 2/5 Reference No.: BFBE-WTW-P22040507_EXT Page 3/5 Reference No.: BFBE-WTW-P22040507_EXT Page 4/5 Reference No.: BFBE-WTW-P22040507_EXT Page 5/5

FCC ID: YAW529027-Z Label (Contains FCC ID : XMR2020BG95M1) Unit：mm Label Location: Label will be put under the enclosure cover

Reference No.: BFBE-WTW-P22040507_INT Page 1/24 CONSTRUCTION PHOTOS OF EUT Reference No.: BFBE-WTW-P22040507_INT Page 2/24 Reference No.: BFBE-WTW-P22040507_INT Page 3/24 Reference No.: BFBE-WTW-P22040507_INT Page 4/24 Reference No.: BFBE-WTW-P22040507_INT Page 5/24 Reference No.: BFBE-WTW-P22040507_INT Page 6/24 Reference No.: BFBE-WTW-P22040507_INT Page 7/24 Reference No.: BFBE-WTW-P22040507_INT Page 8/24 Reference No.: BFBE-WTW-P22040507_INT Page 9/24 Reference No.: BFBE-WTW-P22040507_INT Page 10/24 Reference No.: BFBE-WTW-P22040507_INT Page 11/24 Reference No.: BFBE-WTW-P22040507_INT Page 12/24 Reference No.: BFBE-WTW-P22040507_INT Page 13/24 Reference No.: BFBE-WTW-P22040507_INT Page 14/24 Reference No.: BFBE-WTW-P22040507_INT Page 15/24 Reference No.: BFBE-WTW-P22040507_INT Page 16/24 Reference No.: BFBE-WTW-P22040507_INT Page 17/24 Reference No.: BFBE-WTW-P22040507_INT Page 18/24 Reference No.: BFBE-WTW-P22040507_INT Page 19/24 Reference No.: BFBE-WTW-P22040507_INT Page 20/24 Antenna 1 Reference No.: BFBE-WTW-P22040507_INT Page 21/24 Antenna 2 Reference No.: BFBE-WTW-P22040507_INT Page 22/24 Reference No.: BFBE-WTW-P22040507_INT Page 23/24 Antenna 4 Reference No.: BFBE-WTW-P22040507_INT Page 24/24

Report No.: MFBFBE-WTW-P21070951A Page No. 1 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 RF Exposure Report Report No.: MFBFBE-WTW-P21070951A FCC ID: YAW529027-Z Test Model: PVS6 Received Date: 2022/4/14 Test Date: 2022/5/19 Issued Date: 2022/6/22 Applicant: SunPower Corporation Address: 1414 Harbour Way South Suite 1901, Richmond, CA 94804, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: MFBFBE-WTW-P21070951A Page No. 2 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result ............................................................................................................................... 7 Appendix .......................................................................................................................................................... 8 Report No.: MFBFBE-WTW-P21070951A Page No. 3 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 Release Control Record Issue No. Description Date Issued MFBFBE-WTW-P21070951A Original release. 2022/6/22 Report No.: MFBFBE-WTW-P21070951A Page No. 4 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 1 Certificate of Conformity Product: SunPower Monitoring System with PVS6 Brand: SUNPOWER Test Model: PVS6 Sample Status: Engineering sample Applicant: SunPower Corporation Test Date: 2022/5/19 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: 2022/6/22 Vivian Huang / Specialist Approved by : , Date: 2022/6/22 May Chen / Manager Report No.: MFBFBE-WTW-P21070951A Page No. 5 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 25 cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: MFBFBE-WTW-P21070951A Page No. 6 / 8 Report Format Version: 6.1.1 Reference No.: BFBE-WTW-P22040507 2.4 Antenna Gain WLAN Ant No. Chain No. Brand Model Antenna Net Gain (dBi) Frequency rang (GHz) Antenna type Connector type 1 Chain 0 (Including BT) airgain 65-031-212002B 2.2 2.4~2.4835 PCB I-PEX 3.8 5.15~5.25 4.2 5.725~5.85 2 Chain 1 (WLAN use only) airgain 65-031-212003B 4.2 2.4~2.4835 PCB I-PEX 4.1…

Text truncated - open the document above for the full version.

PVS6 PVS6PVS6 PVS6 Installation Notes Installation NotesInstallation Notes Installation Notes Frequency=5150(MHz)MAX GAIN1.489371069 PhiTheta Angle degrees from the vertical Angle above 30 degrees from the horizon E Total. dBE(Phi) . Amp dBE(Theta) . Amp dB E(Phi) . Phase E(Theta) . Phase -3.141592650.523598776-180301.255175522-1.257831621-2.3168133590.7226285880.12112652 -3.089232780.523598776-17730-0.321987322-3.18055417-3.4895141340.009602321-0.579204671 -3.03687290.523598776-17430-3.460799664-7.263174134-5.801444554-1.102116685-1.54669094 -2.984513020.523598776-17130-2.357963507-5.242548139-5.497726631-2.265821568-2.425977301 -2.932153140.523598776-16830-3.01426297-4.852685962-7.634485287-2.817673289-2.983241551 -2.879793270.523598776-16530-7.329875792-8.379585417-14.011315422.9204581512.337508346 -2.827433390.523598776-16230-10.51982651-14.33236842-12.853224232.1168191061.008291651 -2.775073510.523598776-15930-12.53560147-24.53267168-12.81884669-0.0491874110.39263638 -2.722713630.523598776-15630-8.270569883-9.672809764-13.86246149-1.329243692-0.613916193 -2.670353760.523598776-15330-3.381903525-4.51623483-9.767175318-1.538335293-1.409474312 -2.617993880.523598776-15030-2.134105482-3.567254703-7.645921446-1.708080164-1.8835071 -2.5656340.523598776-14730-3.458714985-5.862499994-7.174198736-2.04801693-2.506094468 -2.513274120.523598776-14430-4.512310443-9.480277467-6.178090571-2.8965497243.104694412 -2.460914250.523598776-14130-4.567344877-8.759694236-6.6494544112.3467204962.585526403 -2.408554370.523598776-13830-6.08044397-7.585901788-11.41260771.6221297481.922885881 -2.356194490.523598776-13530-6.346850403-7.118172468-14.232290611.0240464460.249129841 -2.303834610.523598776-13230-5.680336431-7.406948706-10.520973170.645692412-0.664064809 -2.251474740.523598776-12930-6.962724468-8.784240347-11.615209970.528714397-1.306995106 -2.199114860.523598776-12630-8.433024791-9.292460507-15.89136760.543470901-2.139380376 -2.146754980.523598776-12330-7.594872393-7.701417984-23.750524560.3794419232.559715923 -2.09439510.523598776-12030-5.327127413-5.745451654-15.697323540.0501862750.747028004 -2.042035220.523598776-11730-4.132635221-5.016293432-11.48197527-0.3305638740.255535206 -1.989675350.523598776-11430-5.001525301-6.009277697-11.83996715-0.785763648-0.02141805 -1.937315470.523598776-11130-7.505222062-8.295503399-15.29439829-1.389688751-0.078205991 -1.884955590.523598776-10830-9.761842875-10.45975685-18.04595191-2.1975191510.449962402 -1.832595710.523598776-10530-8.934206409-10.21395014-14.86498994-3.0329634120.932465785 -1.780235840.523598776-10230-7.082613355-8.598382659-12.389989382.7428287711.101564977 -1.727875960.523598776-9930-6.260640188-7.952446348-11.173454682.5088088241.241943944 -1.675516080.523598776-9630-6.46195199-8.898430822-10.133602012.3760178351.315618898 -1.62315620.523598776-9330-7.386113348-11.72639143-9.3796669282.2404821331.281297584 -1.570796330.523598776-9030-9.093471747-17.48175524-9.7734776942.1599568021.249894375 -1.518436450.523598776-8730-12.05590347-24.95850815-12.28441025-2.7641690661.426415701 -1.466076570.523598776-8430-11.44987783-14.10954839-14.84162139-2.1222911182.173477122 -1.413716690.523598776-8130-7.438596456-9.341223529-11.9395412-2.1468863962.854108585 -1.361356820.523598776-7830-5.309161652-7.314337626-9.629560815-2.2443663783.066100908 -1.308996940.523598776-7530-4.362676617-6.37977705-8.662829176-2.439703614-3.13361647 -1.256637060.523598776-7230-3.365884478-5.126898225-8.136894721-2.718921456-3.059787015 -1.204277180.523598776-6930-2.115089293-3.342061976-8.203635845-2.95084696-2.959385504 -1.151917310.523598776-6630-1.338305342-2.007064493-9.793540645-3.071632935-2.792961815 -1.099557430.523598776-6330-1.409931499-1.684274316-13.54128801-3.094873171-2.431142858 -1.047197550.523598776-6030-2.212502288-2.348656253-17.31794161-3.016448396-1.717586246 -0.994837670.523598776-5730-3.584310222-3.685790764-19.94896701-2.794015804-1.182544767 -0.94247780.523598776-5430-5.030485376-5.034642269-35.22271821-2.362842283-1.024260121 -0.890117920.523598776-5130-4.897257907-5.022076052-20.37458339-1.7392935752.15926115 -0.837758040.523598776-4830-2.949392116-3.277582171-14.32904276-1.1518353992.186663599 -0.785398160.523598776-4530-1.222881747-1.621391364-11.79406807-0.7034644572.334881299 -0.733038290.523598776-4230-0.681751033-1.195712631-10.20473419-0.2868852122.622292676 -0.680678410.523598776-3930-1.206564265-1.953666032-9.2188068920.2415084942.935668614 -0.628318530.523598776-3630-1.848646719-2.574986269-9.9732023080.972298368-3.05757751 -0.575958650.523598776-3330-1.421928092-1.674687785-13.898459941.750369205-2.705868977 -0.523598780.523598776-3030-0.299117399-0.313732894-25.036130882.403712247-1.889131905 -0.47123890.523598776-27300.3120065080.267004437-19.55599322.9595191330.869097017 -0.418879020.523598776-2430-0.318926879-0.628628854-11.94126105-2.7884478061.481329107 -0.366519140.523598776-2130-2.349989412-3.421415307-8.952916084-2.1167535561.879919261 -0.314159270.523598776-1830-4.4019755-6.030527511-9.450662731-1.0475928212.318532412 -0.261799390.523598776-1530-4.097426574-4.900031-11.82537788-0.012507009-3.116369749 -0.209439510.523598776-1230-3.311429848-4.342825912-10.060515090.721783835-2.106659935 ANT 1 -0.157079630.523598776-930-3.882252455-5.611613306-8.7172645961.435674122-1.520836458 -0.104719760.523598776-630-6.323774502-8.324184706-10.652307592.278174874-0.935998123 -0.052359880.523598776-330-9.574776229-11.22007754-14.58687516-2.7841348550.005227825 -4.4409E-160.523598776030-8.308118013-8.956428663-16.88825317-1.4650603361.445750185 0.0523598780.523598776330-5.042336154-5.878076623-12.610636122.52113182-0.289952731 0.1047197550.523598776630-2.844996634-4.282002233-8.346964305-3.0677223160.441659006 0.1570796330.523598776930-2.123204832-3.667244773-7.363633742-2.4110450571.019204711 0.209439510.5235987761230-2.69933287-4.121957649-8.238184879-1.7440118591.765951924 0.2617993880.5235987761530-3.441541833-5.331122209-7.966319427-0.93980…

Text truncated - open the document above for the full version.

Report No.: RF180803E05A-1 Page No. 1 / 74 Report Format Version:6.1.2 Reference No.: 181004E11 FCC Test Report (WLAN) Report No.: RF180803E05A-1 FCC ID: HD5-PVS6 Test Model: PVS6 Received Date: Sep. 04, 2018 Test Date: Oct. 20 to 30, 2018 Issued Date: Dec. 10, 2018 Applicant: SunPower Corporation Address: 1414 Harbour Way South Suite 1901, Richmond, CA 94804, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan R.O.C. Test Location : E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan R.O.C. FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF180803E05A-1 Page No. 2 / 74 Report Format Versio…

Text truncated - open the document above for the full version.
