YBE3090CeForce iCLASS Keyless Entry System

eForce ® Keyless Entry Owner’s Manual & Installation Instructions for Models 3090C & 3090P 80‐0180‐351 Rev. A Adams Rite Manufacturing Co. 260 Santa Fe Street Pomona, CA 91767 Phone: 800‐872‐3267 www.adamsrite.com General Information .................................................................... 1 Definitions ................................................................................. 1 FCC Statement ........................................................................... 2 IC Statement ............................................................................. 2 Operational Description................................................................ 3 Operational Specifications ............................................................ 4 Troubleshooting .......................................................................... 5 Installation Tools & Equipment...................................................... 6 Door Preparation......................................................................... 7 Spindle Preparation ..................................................................... 7 Configure for Lock....................................................................... 8 Handing................................................................................... 10 Mortise Cylinder Installation ....................................................... 11 Limited Warranty ...................................................................... 13 i 80‐0180‐327 Rev. A GENERAL INFORMATION The eForce ® Prox (3090P) and eForce ® iCLASS (3090C) lever operators have integrated contactless proximity readers that communicate with a Weigand protocol access control system. Utilizing HID 125kHz Prox or HID 13.56MHz iCLASS technology, the eForce ® offers reliable and secure access to your secured building or area. The eForce ® Prox or eForce ® iCLASS will mechanically interface with Adams Rite deadbolts, deadlatches, and exit devices. DEFINITIONS ● Prox – Class of contactless card credentials that operate on 125kHz. ● iCLASS – Class of contactless card credentials that operate on 13.56MHz. ● Secured – State of eForce ® when the clutch is not engaged, preventing lever rotation from retracting latch/deadbolt. ● Unsecured – State of eForce ® when clutch is engaged, allowing lever rotation to retract latch/deadbolt. ● Weigand – Communication protocol utilized between the eForce ® and access control system, which consists of two data lines, WG0, WG1. ● Access Control System – Third party system that manages contactless card credentials, and door opening states (secured/unsecured). 1 80‐0180‐327 Rev. A FCC STATEMENT This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment. IC STATEMENT This class [B] digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 80‐0180‐327 Rev. A OPERATIONAL DESCRIPTION Manual Operation – Key Cylinder 1. Insert key into lock cylinder. 2. Turn the key to the detent position. 3. Rotate the lever until latch or deadbolt clear the strike and open the door. 4. Return the key to a non-detent position that will allow the key to be removed. Credential Card Operation When the eForce ® is in a secured state, the LED in the front plastic faceplate will be red, and the lever will not operate the locking mechanism. To gain entry using the eForce ® Prox or eForce ® iCLASS: 1. Place Prox/iCLASS card in front of the eForce ® LED, at a distance no greater than one inch. 2. The access control system will receive the card credential information, and will send an unlock signal to the eForce ® if the credentials are valid. 3. The LED will change states from red to green, and a short audible tone will be heard to indicate a valid unlock status. 4. Rotate the lever to gain entry into the building. 5. The lock will return to a secured (locked state) after the access control system unlock period has expired. NOTE: the access control system will determine the unlock period. There are no adjustments in the eForce ® for unlock period. Adding Card Credentials Consult the access control system manual or the system administrator to manage your credential database. The eForce ® does not store card credentials; it simply extracts the information from the card and sends it to the access control system for verification. 3 80‐0180‐327 Rev. A OPERATIONAL SPECIFICATIONS Card Compatibility Prox: All HID (125kHz) Prox credentials iCLASS: All iCLASS (13.56MHz) creden…

Text truncated - open the document above for the full version.

Correspondence by Project Project Number: Correspondence NumberMemo YBE3090C-1 1) Please include additional internal photos of the EUT. A portion of some boards are not visible due to the camera flash. Also, please provide a photo of the entire EUT assembled and out of the door lock assembly. RESPONSE: New internal photos have been uploaded. 2) Please provide a modification letter stating the modifications made and that they will be implemented in the final manufacturing. RESPONSE: The modification letter has been uploaded. 3) The block diagram submitted is not sufficient. The data rates used in the device are not shown. As per section 2.1033(b)(5) of the FCC rules, the block diagram must show “the frequency of all oscillators used in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” RESPONSE: A revised block diagram has been uploaded. 4) Please correct either the operational description or the block diagram. The operational description lists multiple microcontrollers being used, however the block diagram submitted only shows one. RESPONSE: Please see revised block diagram and/or operational description. 5) For the operational description, please provide antenna information, a description of the ground system and the type of modulation used. RESPONSE: Please see revised block digram. 6) Please provide a diagram or photo showing the location of the FCC label and please provide a sample label with only one FCC ID, currently there are two label samples with different FCC ID’s. RESPONSE: A revised FCC label has been uploaded. The location of label exhibit will be uploaded. Correspondence NumberMemo YBE3090C-2 1) Please include the correct external photos of the EUT. The internal photos recently submitted have a board that is different from the board pictured in the external photos. RESPONSE: The incorrect board was photographed by mistake. The internal photos exhibit has been revised and uploaded.

NOT A PRODUCTION PART DO NOT BUILD TOOLING TO THIS DRAWING THIS DRAWING FOR COST AND PROTOTYPE DEVELOPMENT ONLY. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model: 3090P FCC ID: YBE3090P IC ID: 8890A-3090P 1.250 3.000 IC ID: 8890A-3090C FCC ID: YBE3090C Model: 3090C This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interence, and (2) this device must accept any interference received, including interference that may cause undesired operation. 20-0112-01 20-0112-02 REVDESCRIPTIONECNDATEREV. BYAPVD 1 2 3 4 5 6 7 8 D C B A D C B A 8 7 6 5 4 3 2 1 SHEET OF DO NOT SCALE DRAWING DWG. NO. SIZE SCALE INITIAL DRAWN BY DESIGN HISTORY DATE B 1:1 1 1 TOLERANCE UNLESS OTHERWISE SPECIFIED UNIT ENGLISH METRIC FRACTIONS .X .XX .XXX ANGLES 1/32 .1 .01 .005 1 .010 TIR .005 TIR ---- ---- .25 .12 1 .25 TIR .12 TIR APPLICATION NEXT ASSY PRODUCT PROJECT ENGINEER REV -.5 B. CHOW 00-0000 0000 B. CHOW 00-0000 0000 00-0000 0000 00-0000 0000 00-0000 0000 00-0000 0000 1-21-2010 FCC LABEL, 3090C & 3090P 20-0112 1-21-2010 THIS DRAWING REMAINS THE PROPERTY OF ADAMS RITE MFG. CO. IT MUST BE KEPT CONFIDENTIAL AND EMPLOYED ONLY FOR THE PURPOSE FOR WHICH IT WAS ISSUED. UNAUTHORIZED USE, REPRODUCTION, DISCLOSER OR RETENTION IS EXPRESSLY PROHIBITED. ALL PROPRIETARY AND MANUFACTURING RIGHTS RESERVED. 6. POST BAKE: 5. FINISH: PRINTED IN DENSE BLACK INK AND TEXT HAVE TO BE LEGIBLE. 4. HEAT TREAT: 3. MATERIAL: LAMINATED 2 MIL. WHITE VINYL WITH PERMAMENT ADHESIVE. 2. BREAK ALL SHARP EDGES. 1. ALL DIMENSIONS ARE FINISHED DIMENSIONS. NOTES: UNLESS OTHERWISE SPECIFIED. Adams Rite Manufacturing Co. 260 Santa Fe Street, Pomona, CA 91767 Phone: 909-632-2300 Fax: 909-632-2369 www.adamsrite.com 4/22/2010 20-0112.SLDDRW

NOT A PRODUCTION PART DO NOT BUILD TOOLING TO THIS DRAWING THIS DRAWING FOR COST AND PROTOTYPE DEVELOPMENT ONLY. 3.76±.50 REVDESCRIPTIONECNDATEREV. BYAPVD 1 2 3 4 5 6 7 8 D C B A D C B A 8 7 6 5 4 3 2 1 SHEET OF DO NOT SCALE DRAWING DWG. NO. SIZE SCALE INITIAL DRAWN BY DESIGN HISTORY DATE B 1:1 1 1 TOLERANCE UNLESS OTHERWISE SPECIFIED UNIT ENGLISH METRIC FRACTIONS .X .XX .XXX ANGLES 1/32 .1 .01 .005 1 .010 TIR .005 TIR ---- ---- .25 .12 1 .25 TIR .12 TIR APPLICATION NEXT ASSY PRODUCT PROJECT ENGINEER REV 00-0000 0000 00-0000 0000 00-0000 0000 00-0000 0000 00-0000 0000 00-0000 0000 THIS DRAWING REMAINS THE PROPERTY OF ADAMS RITE MFG. CO. IT MUST BE KEPT CONFIDENTIAL AND EMPLOYED ONLY FOR THE PURPOSE FOR WHICH IT WAS ISSUED. UNAUTHORIZED USE, REPRODUCTION, DISCLOSER OR RETENTION IS EXPRESSLY PROHIBITED. ALL PROPRIETARY AND MANUFACTURING RIGHTS RESERVED. 6. POST BAKE: 5. FINISH: 4. HEAT TREAT: 3. MATERIAL: 2. BREAK ALL SHARP EDGES. 1. ALL DIMENSIONS ARE FINISHED DIMENSIONS. NOTES: UNLESS OTHERWISE SPECIFIED. Adams Rite Manufacturing Co. 260 Santa Fe Street, Pomona, CA 91767 Phone: 909-632-2300 Fax: 909-632-2369 www.adamsrite.com 5/5/2010

Report Number: C91116H1 FCC Part 15 Subpart B and FCC Section 15.225 Test Report eForce ® iCLASS Keycard Entry System Model: 3090C Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 18 FCC PART 15, SUBPART B and C TEST REPORT for eForce ® iCLASS KEYCARD ENTRY SYSTEM Model: 3090C Prepared for ADAMS RITE MANUFACTURING CO. 260 SANTA FE STREET POMONA, CALIFORNIA 91767 Prepared by:_____________________ SCOTT McCUTCHAN Approved by:____________________ JOSH HANSEN COMPATIBLE ELECTRONICS INC. 19121 EL TORO ROAD SILVERADO, CALIFORNIA 92676 (949) 589-0700 DATE: APRIL 28, 2010 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 2 13 11 48 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: C91116H1 FCC Part 15 Subpart B and FCC Section 15.225 Test Report eForce ® iCLASS Keycard Entry System Model: 3090C Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. Description of Test Configuration 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 7. CHARACTERISTICS OF THE TRANSMITTER 14 7.1 Operating Frequency 14 7.2 Channel Number and Frequencies 14 8. Test Procedures 15 8.1 RF Emissions 15 8.1.1 Conducted Emissions Test 15 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 16 8.2 Frequency Tolerance of Carrier Signal 17 9. CONCLUSIONS 18 Report Number: C91116H1 FCC Part 15 Subpart B and FCC Section 15.225 Test Report eForce ® iCLASS Keycard Entry System Model: 3090C Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos  Test Setup Diagrams  Radiated and Conducted Emissions Photos  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Site – 3 Meters Report Number: C91116H1 FCC Part 15 Subpart B and FCC Section 15.225 Test Report eForce ® iCLASS Keycard Entry System Model: 3090C Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 18 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: eForce ® iCLASS Keycard Entry System Model: 3090C S/N: N/A Product Description: The product is a 13.56 MHz RFID System used for keyless doorway entry. Modifications: The EUT was modified during the testing. Please see list of modifications in Appendix B. Manufacturer: Adams Rite Manufacturing Co. 260 Santa Fe Street Santa Ana, California 91767 Test Dates: The tests were performed on November 11, 18 and 23, 2009. Test Specifications : EMI requirements CFR Title 47, Part 15, Subpart B, sections 15.31, 15.107, and 15.109; and Subpart C, sections 15.205, 15.207, 15.209, and 15.225 Test Procedure: ANSI C63.4: 2003 and ANSI C63.10: 2009 Test Deviations: The test procedure was not deviated from during the testing. Report Number: C91116H1 FCC Part 15 Subpart B and FCC Section 15.225 Test Report eForce ® iCLASS Keycard Entry System Model: 3090C Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 18 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207 2 Radiated RF Emissions, 10 kHz – 1 GHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B, sections 15.31(e), 15.107 and 15.109; and the limits of CFR Title 47, Part 15, Subpart C, section 15.209 and 15.225(a) through (d). 3 Frequency Tolerance, Temperature and Voltage Var…

Text truncated - open the document above for the full version.
