Block Diagram ANT Filter MCU U2 P211CS16 1MHz Oscillator 27.145 MHz Control key RF power amplifier EEPROM U3 400KHz 27.145MHz Regulator U1 78L05

13 th September, 2012 To whom it may concern, Letter of Agency I, an officer of China Industries Ltd. t/a Wow! Stuff do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Graeme Taylor Director

External Photos

Label Artwork and Location Label Size: 39.5 mm(W) x 29.0 mm(H)

Internal Photos

Technical description Description Function Component Antenna Transmit modulated RF signal ANT Filter Suppression of spurious emissions L1, C3, C8 RF power amplifier and modulation Modulate the carrier and amplify the modulated RF signal Q1 Oscillator Generate 27.145 MHz carrier TAL1, Q2 MCU Data process, generate code signal to modulator U2 EEPROM Data collect and process U3 Regulator Regulate Voltage U1 Type of antenna: Integral telescope antenna Type of modulation: Pulse modulation

27.145MHz Transmitter Circuit Diagram Hz 10UF /16V
