YCS5900K01RF MODULE Remote Control

ARC Solid-State Lighting Corporation

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: May 25, 2010
Application Purpose: Original Equipment
Date of Application: May 25, 2010
Equipment Note: RF MODULE Remote Control
Frequency Range: 433.92000000 - 433.92000000
Company: ARC Solid-State Lighting Corporation
Country: Taiwan
