YGM-M20BTHD Wireless Music System

Contents Safety Information .......................................................................................1 Important information - please read carefully ............................1 Correct disposal of this product .......................................................1 Service .......................................................................................................2 Important notice for UK users ...........................................................2 Notes .................................................................................................................2 FCC Statement (For US Customers) .................................................2 Industry Canada Statement (for Canadian Customers) ...........2 Introduction ...................................................................................................3 Package contents .........................................................................................3 Feature summary .........................................................................................4 Wired connectivity ................................................................................4 Wireless connectivity ...........................................................................4 Acoustic.....................................................................................................4 Remote batteries ..........................................................................................4 Key .....................................................................................................................5 Speaker rear connections and controls .........................................5 Speaker controls ....................................................................................6 Remote control .......................................................................................6 Operation ........................................................................................................7 Connecting between the speakers .................................................7 Speaker positioning and assembly .................................................7 Auto standby ...........................................................................................7 Playing audio using Bluetooth .........................................................8 Clearing the Bluetooth pairing list ..................................................8 Playing audio using optical digital ..................................................8 Playing audio using analogue ..........................................................8 Playing audio using USB .....................................................................8 LED states .................................................................................................9 Specification ...................................................................................................9 Amplifier performance ........................................................................9 Speakers ....................................................................................................9 Power .........................................................................................................9 Bluetooth® ................................................................................................9 Dimensions ..............................................................................................9 Weight .......................................................................................................9 Warranty ........................................................................................................10 Accessories ...................................................................................................10 Contact ...........................................................................................................10 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Armour Home Electronics Ltd. is under license. The aptX® mark and the aptX logo are trade marks of CSR plc or one of its group companies and may be registered in one or more jurisdictions. Other trademarks and trade names are those of their respective owners. EC DECLARATION OF CONFORMITY M20 conforms with the following EEC Directives, their supporting Statutory Instruments and relevant Standards, where applicable as follows: EC Council Directive on electromagnetic compatibility 2004/108/EC, Applicable standards with amendments: EN5013:2001 + A1:2003 + A2:2006 EN55020:2007 EN61000-3-2:2006 + A1:2009 + A2:2009 EN61000-3-3:2008 EC Low Voltage Directive 2006/95/EEC, Applicable standard with amendments: EN60065:2002 + A1:2006 + A11:2008 + A2:2012 Stage 1 of annex II of Commission regulation (ErP) EC no. 1275/2008 12 Safety Information Important information - please read carefully CAUTION! RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-REMOVEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED PERSONNEL This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit. Read and keep these instructions. Heed all warnings and follow all instructions. Do not use this apparatus near water. Clean only with a dry soft cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Protect the mains power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Use only attachments/accessories specified b…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021/3/18 Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name YGM-M20BTM20 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Mark Collingwood/Director of Product Development Company: Armour Home Electronics Limited Address: Woodside 2, Dunmow Road, Bishop ’ s Stortford, Hertfordshire, CM23 5RG, United Kingdom Phone: 00441483545623 Fax: 00441483545600 E-Mail: [email protected]

Armour Home Electronics Limited Woodside 2, Dunmow Road, Bishop’s Stortford, Hertfordshire, CM23 5RG, United Kingdom Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/3/18 To whom it may concern: We, Armour Home Electronics Limitedthe undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID:YGM-M20BTincluding the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Mark Collingwood/Director of Product Development Company: Armour Home Electronics Limited Address: Woodside 2, Dunmow Road, Bishop ’ s Stortford, Hertfordshire, CM23 5RG, United Kingdom Armour Home Electronics Limited Woodside 2, Dunmow Road, Bishop’s Stortford, Hertfordshire, CM23 5RG, United Kingdom Phone: 00441483545623 Fax: 00441483545600 E-Mail: [email protected]

FCC ID: YGM-M20BT FCC ID: YGM-M20BT FCC ID: YGM-M20BT FCC ID: YGM-M20BT

FCC ID: YGM-M20BT Label Location FCC ID: YGM-M20BT

FCCID:YGM-M20BT FCCID:YGM-M20BT FCCID:YGM-M20BT BTANT FCC ID: YGM-M20BT

RF Exposure evaluation Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v06 FCC Part 2 §2.1091 FCC ID: YGM-M20BT 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 6 3.0 – 30 1842/f 4.89/f (900/f 2 )* 6 30 – 300 61.4 0.163 1.0 6 300 – 1500 / / f/300 6 1500 – 100,000 / / 5 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 30 3.0 – 30 824/f 2.19/f (180/f 2 )* 30 30 – 300 27.5 0.073 0.2 30 300 – 1500 / / f/1500 30 1500 – 100,000 / / 1.0 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used BT antenna is 0 dBi, the RF power density can be obtained. Freq. (MHz) Output Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Output power to antenna (mW) Ant Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW/c m2) Result GFSK 2402 -4.655 -4±1.0 -3 0.501 0 0.00010 1 Pass 2440 -4.758 -4±1.0 -3 0.501 0 0.00010 1 Pass 2480 -4.954 -4±1.0 -3 0.501 0 0.00010 1 Pass Freq. (MHz) Output Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Output power to antenna (mW) Ant Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW/c m2) Result π/4DQPSK 2402 -4.517 -4±1.0 -3 0.501 0 0.00010 1 Pass 2440 -4.854 -4±1.0 -3 0.501 0 0.00010 1 Pass 2480 -4.618 -4±1.0 -3 0.501 0 0.00010 1 Pass Freq. (MHz) Output Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Output power to antenna (mW) Ant Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW/c m2) Result 8DPSK 2402 -4.758 -4±1.0 -3 0.501 0 0.00010 1 Pass 2440 -4.606 -4±1.0 -3 0.501 0 0.00010 1 Pass 2480 -4.766 -4±1.0 -3 0.501 0 0.00010 1 Pass Note: The estimation distance is 20cm 5. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device.

FCCID:YGM-M20BT RadiatedEmission(Below1G) RadiatedEmission(Above1G) FCCID:YGM-M20BT ConductedEmission
