YHF125RCU125kHz Immobiliser

1 Foreword FOREWORD This handbook contains information on the Triumph Speed Triple motorcycle. Always store this owner's handbook with the motorcycle and refer to it for information whenever necessary. Warnings, Cautions and Notes Throughout this owner's handbook particularly important information is presented in the following form: Note: •This note symbol indicates points of particular interest for more efficient and convenient operation. cger Warning This warning symbol identifies special instructions or procedures, which, if not correctly followed, could result in personal injury, or loss of life. Caution This caution symbol identifies special instructions or procedures, which, if not strictly observed, could result in damage to, or destruction of, equipment. 2 Foreword Warning Labels At certain areas of the motorcycle, the symbol (left) can be seen. The symbol means 'CAUTION: REFER TO THE HANDBOOK' and will be followed by a pictorial representation of the subject concerned. Never attempt to ride the motorcycle or make any adjustments without reference to the relevant instructions contained in this handbook. See pages 10 and 11 for the location of all labels bearing this symbol. Where necessary, this symbol will also appear on the pages containing the relevant information. Maintenance To ensure a long, safe and trouble free life for your motorcycle, maintenance should only be carried out by an authorised Triumph dealer. Only an authorised Triumph dealer will have the necessary knowledge, equipment and skills to maintain your Triumph motorcycle correctly. To locate your nearest Triumph dealer, visit the Triumph web site at www.triumph.co.uk or telephone the authorised distributor in your country. Their address is given in the service record book that accompanies this handbook. Noise Control System Tampering with the Noise Control System is Prohibited. Owners are warned that the law may prohibit: •The removal or rendering inoperative by any person other than for purposes of maintenance, repair or replacement, of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use and, •the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person. Immobiliser and Tyre Pressure Monitoring System This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: •This device may not cause harmful interference; •This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to the device could void the user's authority to operate the equipment. 3 Foreword Owner's Handbook Thank you for choosing a Triumph motorcycle. This motorcycle is the product of Triumph's use of proven engineering, exhaustive testing, and continuous striving for superior reliability, safety and performance. Please read this owner's handbook before riding in order to become thoroughly familiar with the correct operation of your motorcycle's controls, its features, capabilities and limitations. This handbook includes safe riding tips, but does not contain all the techniques and skills necessary to ride a motorcycle safely. Triumph strongly recommends that all riders undertake a safety course approved by the Motorcycle Safety Foundation to ensure safe operation of this motorcycle. Information about the nearest Motorcycle Safety Foundation course to you can be obtained by calling the following nationwide toll free number: 800-447-4700, or by writing to the Motorcycle Safety Foundation at: 2, Jenner Street, Irvine, California 92718. This handbook is also available from your local dealers in: •French; •German; •Spanish; •Italian; •Dutch; •Japanese; •Swedish. Ta l k t o Tr i u m p h Our relationship with you does not end with the purchase of your Triumph. Your feedback on the buying and ownership experience is very important in helping us develop our products and services for you. Please help us by ensuring your dealership has your E-mail address and registers this with us. You will then receive an online customer satisfaction survey invitation to your E-mail address where you can give us this feedback. Yo u r Tr i u m p h Te a m . Warning This owner's handbook, and all other instructions that are supplied with your motorcycle, should be considered a permanent part of your motorcycle and should remain with it even if your motorcycle is subsequently sold. All riders must read this owner's handbook and all other instructions which are supplied with your motorcycle, before riding, in order to become thoroughly familiar with the correct operation of your motorcycle's controls, its features, capabilities and limitations. Do not lend your motorcycle to others as riding when not familiar with your motorcycle's controls, features, capabilities and limitations can lead to an accident. Foreword 4 Information The information contained in this publication is based on the latest information available at the time of printing. Triumph reserves the right to make changes at any time without prior notice, or obligation. Not to be reproduced wholly or in part without the written permission of Triumph Motorcycles Limited. © Copyright 05.2010 Triumph Motorcycles America Limited. Publication part number 3854464 issue 2. Table of Contents This handbook contains a number of different sections. The table of contents below will help you find the beginning of each section where, in the case of the major sections, a further table of contents will help you find the specific subject required. Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Warning Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Parts Ident…

Text truncated - open the document above for the full version.

FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 1 of 2 without the Permission of TUV Product Service Ltd Reference: 75909530 PHOTOGRAPHS OF EQUIPMENT View 1 View 2 FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 2 of 2 without the Permission of TUV Product Service Ltd Reference: 75909530 View 3

FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 1 of 3 without the Permission of TUV Product Service Ltd Reference: 75909530 PHOTOGRAPHS OF EQUIPMENT RCU PCB Underside B RCU PCB Topside B FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 2 of 3 without the Permission of TUV Product Service Ltd Reference: 75909530 RC PCB Topside Upper Right Quadrant RC PCB Topside Lower Right Quadrant FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 3 of 3 without the Permission of TUV Product Service Ltd Reference: 75909530 RC PCB Topside Upper Left Quadrant RC PCB Topside Lower Left Quadrant

Document 75909530 Report 01 Issue 2 November 2010 Report On FCC and Industry Canada Testing of the Triumph Designs Limited 125kHz Immobiliser COMMERCIAL-IN-CONFIDENCE FCC ID: YHF125RCU IC ID: 9053A-125RCU TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 1 of 21 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC and Industry Canada Testing of the Triumph Designs Limited 125kHz Immobiliser Document 75909530 Report 01 Issue 2 November 2010 PREPARED FOR Triumph Designs Limited Normandy Way, off Dodwells Road Hinckley Leicestershire LE10 3BZ PREPARED BY M Whiting Project Manager APPROVED BY C Lewis Authorised Signatory DATED 25 November 2010 This report has been up-issued to Issue 2 to correct specification references. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Part 15C and Industry Canada RSS-GEN. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineers; B Logan P Harrison COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 2 of 21 COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Declaration of Build Status ........................................................................................................... 6 1.4 Product Information ...................................................................................................................... 7 1.5 Test Conditions ............................................................................................................................. 8 1.6 Deviations From the Standard ...................................................................................................... 8 1.7 Modification Record ...................................................................................................................... 9 2 TEST DETAILS .......................................................................................................................... 10 2.1 Radiated Emissions (Enclosure Port) ......................................................................................... 11 2.2 Field Strength Peak Power ......................................................................................................... 14 3 TEST EQUIPMENT USED ......................................................................................................... 17 3.1 Test Equipment Used ................................................................................................................. 18 3.2 Measurement Uncertainty .......................................................................................................... 19 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 20 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 21 COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 3 of 21 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC and Industry Canada Testing of the Triumph Designs Limited 125kHz Immobiliser COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 4 of 21 COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Triumph Designs Limited, 125kHz Immobiliser to the requirements of FCC CFR 47 Part 15C and RSS-GEN. Objective To perform FCC and Industry Canada Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Triumph Designs Limited Part Number(s) 07057 Serial Number(s) 428B800F Software Version 4070571011 Hardware Version 308-057-1090-A Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 15C: 2009 RSS-GEN: Issue 2: 2007 Incoming Release Date Declaration of Build Status 07 September 2010 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date DES019962 25 February 2010 Start of Test 28 May 2010 Finish of Test 23 June 2010 Name of Engineer(s) B Logan P Harrison Related Document(s) ANSI C63.4: 2003 COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 5 of 21 COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results in accordance with FCC CFR 47 Part 15C and RSS-GEN is shown below. Configuration 1 - Stand Alone Section Spec Clause Test Description Mode Test Site Mod State Result Base Standard FCC IC 2.1 15.209 4.9, 4.10, 4.11 and 7.2.3 Radiated Emissions (Enclosure Port) 125kHz Tx Bearley 1 Pass ANSI C63.4 125kHz Rx Bearley 0 Pass 2.2 15.209 4.8 Field Strength Peak Power 125kHz Tx Octagon House 0 Pass ANSI C63.4 125kHz Rx Octagon House N/A N/A – Not Applicable COMMERCIAL-IN-CONFIDENCE Document 75909530 Report 01 Issue 2 Page 6 of 21 COMMERCIAL-IN-CONFIDENCE 1.3 DECLARATION OF BUILD STATUS Note: This document has been prepared to enable manufacturers with no mechanism for producing their own Declaration of Build Status, to declare the build state of the equipment submitted for test. No responsibility will be accepted by TÜV Product Service as to the accuracy of the information declared in this document by the manufacturer. COMMERCIAL-IN-CONFIDENCE Document…

Text truncated - open the document above for the full version.

FCC ID: YHF125RCU IC ID: 9053A-125RCU Triumph Designs Limited 125kHz Immobiliser 2010 Not to be reproduced, except in its entirety, Page 1 of 1 without the Permission of TUV Product Service Ltd Reference: 75909530 PHOTOGRAPHS OF TEST SET UP Radiated Emissions Radiated Emissions
