Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Copyright ⓒ 2020, Lab-T, Inc. User Manual GM-2.4G User Manual Maytel Co., Ltd CONTENTS 1. FEATURES ....................................................................................................................... 3 2. FUNCTION DESCRIPTION .............................................................................................. 4 2.1. VOLUME CONTROL .................................................................................................................. 4 2.2. GROUP SETTING ...................................................................................................................... 4 2.3. ID SETTING ............................................................................................................................. 5 2.4. SIDE TONE CONTROL .............................................................................................................. 5 2.5. MIC LEVEL CONTROL ............................................................................................................ 6 2.6. SECURITY CODE SETTING ....................................................................................................... 6 3. SPECIPICATIONS ............................................................................................................ 7 1. Features Item Description Power Button Power ON : Press and hold for 2 seconds or longer. Power OFF : Press and hold for 2 seconds or longer. Mode Button Group ID, Side Tone, Tx/Rx Mode, MIC level, Output level=Setting/Change Up Button Increase the setting value in each mode such as Volume, Channel, ID, etc. Down Button Lower the setting value in each mode such as Volume, Channel, ID, etc. Talk Button Group Version : Talk On/Off Team Version : Mic On/Off Function Button Multi function Key Headset Jack 3.5mm Headset Jack Antenna Antenna Jack USB Jack USB Jack, Formware upgrade Charger Contact Battery charge contact 2. Function Description 2-1. Volume Control GM-2.4G has volume control function that serves user to change volume level wanted. Volume level is displayed after power is turned on. Volume level can be set with Up/Down button in the range of 0~8. The default level is 3. 2-2. Group Setting GM-2.4G has group setting function that serves user to change group to communicate. Turn on the GM-2.4G. When press and hold the Mode button, the LCD window changed to Setting Mode. Setting the desired group by pressing the Up/Down button on the left side of device. The Group can be set from 0~39. Press and hold the Mode button to complete the setting. 2-3. ID Setting GM-2.4G has an ID setting function that allows users to change their ID. ID should be set not to overlap each other in the same group, and Master terminal of “ 00 “ must exist. Turn on the GM-2.4G. Press and hold Mode button to enter the setting mode. Press the Mode button briefly to enter the ID setting change window. Set up the desired ID by pressing Up/Down button. The ID can be set up to 00~99. - When ID is “00”, it is set as Master. - When ID is “01~99”, it is set as Slave. To complete the setting, press and hold the Mode button. 2-4. Side Tone Control GM-2.4G can turn side tone On/Off. Turn on the GM-2.4G. Press and hold Mode button to enter the setting mode. Press the Mode button twice in the setting mode to move to the side tone setting change window. Side tone can be turned On/Off by pressing the Up/Down button. To complete the setting, press and hold the Mode button. 2-5. MIC Level Control GM-2.4G can be used to adjust the MIC input level. Turn on the GM-2.4G. Press and hold Mode button to enter the setting mode. Press the Mode button 3 times in the setting mode to move to MIC gain setting change window. Press the Up/Down button to change the MIC gain setting. MIC gain can be adjusted from 1 to 5. To complete the setting, press and hold the Mode button. 2-6. Security Code Setting GM-2.4G can adjust the security code value. Turn on the GM-2.4G. Press and hold Mode button to enter the setting mode. In the setting mode, press Mode button 4 times to move to the security code setting change window. Security code can be changed by pressing Up/Down button. Security code has 4 digits and each digit can be set from 0 to 9, A, B, C, D, E, F. Security code can be set one by one. To move to another digit, simply press Mode button. To complete the setting, press and hold the Mode button. 3. SPECIFICATIONS ITEM SPECIFICATION Radio Frequency Type ISM 2407MHz ~ 2476MHz Radio Interface ISM 2.4GHz: GFSK Modulation with Frequency Hopping Voice Codec 16bit/8KHz Tx Max Output Power 100mW Rx Sensitivity -95dBm Voice Latency < 100ms Num. of Frequency Channel 139ch Channel Spacing 500 KHz Power Supply Li-ion Battery @3.7V/ 2000mA Antenna External Antenna (3.1dBi/4.0dBi) Distance Range(LOS) 500M @ Class 1 Frequency response 50 Hz ~ 4 kHz Maximum operation users 8person (include Master device) This product has been certified with the following antennas, and may only be used with the same or less antenna gain. Antenna Model Max. Gain Dipole Antenna HW-2450H-MSMA 3.1dBi Dipole Antenna LSDP-2402D(B) 4.0dBi This equipment complies with the essential requirements of EC Directive 2014/35/EU, 2014/30/EC and 2014/53/EU, as applicable. Declarations are available from your local representative. Replaceable battery If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an explosion (for example, with some lithium batteries), the following: - if the battery is placed in an OPERATOR ACCESS AREA, there shall be a marking close to the battery or a statement in both the operating and the servicing instructions; - if the battery is placed elsewhere in the equipment, there shall be a marking close to the battery or a statement in the servicing instructions. This marking or statement shall include the following or similar text: CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED …
Text truncated - open the document above for the full version.
Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Date : Feb, 26, 2020 Dear Sir/Madam, Re : Project and Product Certification Representative Authorization Letter We, Maytel Co., Ltd hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project : - Product Type : Grand Multicom 2.4G - Manufacturer : Maytel Co., Ltd - FCC ID : YJH-GM-24G We, the undersigned, hereby authorize SangHoon, Yu of Lab-T, Inc. to act on our behalf in all manners relating to application for equipment authorization for FCCID: YJH-GM-24G signing of all documents relating to these matters. Any and all acts carried out by SangHoon, Yu of Lab-T, Inc. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Maytel Co., Ltd , the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Su Won, Bae President
SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 , Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Date : Feb, 26, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: YJH-GM-24G Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Signature) Su Won, Bae / President +82-31-487-5508 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Date :Feb, 26, 2020 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: YJH-GM-24G To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of / / not to exceed 180 days from the Grant Date. See KDB 726920.. - User Manual - Internal Photos - External Photos - Test Setup photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, (Signature) Su Won, Bae / President +82-31-487-5508 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Date : Feb, 26, 2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Maytel Co., Ltd hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): - Product Type : Grand Multicom 2.4G - Manufacturer : Maytel Co., Ltd - FCC ID : YJH-GM-24G Sincerely, (Signature) Su Won, Bae / President +82-31-487-5508 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Date : Feb, 26, 2020 We, Maytel Co., Ltd hereby declare that the following products are Electrically Identical in Terms of RF parameters. - Product Type : Grand Multicom 2.4G - Model : GM-2.4G - Variant Model : MicroCom XR 2.4G, SWATCOM, XR-2.4G - Manufacturer : Maytel Co., Ltd - FCC ID : YJH-GM-24G Variant Model These models have the same circuit schematic, construction, PCB Layout and critical Components. The only difference is model number due to each other different Buyers. Sincerely, (Signature) Su Won, Bae / President +82-31-487-5508 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
Page: 1 / 5 Copyright ⓒ 2020, Lab-T, Inc. External Photos Page: 2 / 5 Copyright ⓒ 2020, Lab-T, Inc. External Photos Front Rear Page: 3 / 5 Copyright ⓒ 2020, Lab-T, Inc. External Photos Top Bottom Page: 4 / 5 Copyright ⓒ 2020, Lab-T, Inc. External Photos Left Right Page: 5 / 5 Copyright ⓒ 2020, Lab-T, Inc. External Photos Dipole Antenna(3.96 dBi) Dipole Antenna(3.14 dBi)
Copyright ⓒ 2020. Lab-T, Inc. Label Informaion Copyright ⓒ 2020. Lab-T, Inc. Label information Location
Page: 1 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos Page: 2 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos Main Board Front Main Board Rear Page: 3 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos inside
Ref. No.: LR500112002D Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 57 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com SAR TEST REPORT Equipment Under Test Model Name Variant Model Name Trade Mark Applicant Address of Applicant FCC ID IC ID Date of Receipt Date of Test(s) Date of Issue Max.SAR(1g) : Frequency Hopping Spread Spectrum systems (DSS) : GM-2.4G : MicroCom XR 2.4G, SWATCOM, XR-2.4G : Maytel Co., Ltd : Maytel Co., Ltd : #417 Doosan Venture Digm 126-1, Pyeongchon-dong,Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea : YJH-GM-24G : 9066A-GM24G : 2020-02-20 : 2020-02-24 : 2020-02-26 : 1.305 W/kg Standards: KDB Publication 447498 IEEE 1528, 2013 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distribute in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of LTA Co., Ltd. Or testing done by LTA Co.,Ltd. In connection with distribution or use of the product described in this report must be approved by LTA Co.,Ltd. In writing. Tested by ; : Eun-Hwan Jung 2020-02-26 Approved by : Ja-Beom Koo 2020-02-26 Ref. No.: LR500112002D Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 57 Contents 1. EXECUTIVE SUMMARY & EUT INFORMATION ................................................ 2. INTRODUCTION ................................................................................................... 3. SAR MEASUREMENT SETUP ............................................................................. 4. ANSI/IEEE C95.1-2005 RF EXPOSURE LIMIT .................................................... 5. SYSTEM AND LIQUID VALIDATION ................................................................... 6. TYPE A MEASUREMENT UNCERTAINTY ......................................................... 7. OUTPUT POWER VERIFICATION ....................................................................... 8. SAR TEST RESULTS ........................................................................................... ANNEX A. TEST INSTRUMENT ........................................................................... ANNEX B. SIMULATED TISSUE ELECTROSTATIC MEASUREMENT................. ANNEX C. EUT AND TEST SETUP PHOTOGRAPHS ............................................ ANNEX D. CALIBRATION REPORTS ..................................................................... 3 4 5 16 17 21 23 24 31 32 33 38 Ref. No.: LR500112002D Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 57 The purpose of this test programmed was to demonstrate compliance of the Intermec Technologies Corporation Model: 1005CP01 against the current Stipulated Standards. The Mobile Computer have demonstrated compliance with the C95.1 , IEEE 1528, KDB Publication 447498, RSS-102 Issue 5 and Safety Code 6. The test has demonstrated that this unit complies with stipulated standards. EUT information EUT Description Wireless Intercom Model Name GM-2.4G Serial No. Identical prototype Variant Model MicroCom XR 2.4G, SWATCOM, XR-2.4G Mode of Operations FHSS Body-Worn Accessory belt clip case TX Frequency Range 2,407 MHz ~ 2,476 MHz Conducted Max Power 20.21 dBm Battery Type DC 3.7 V Antenna Location Antenna 1TypeExternal Dipole Ant Gain3.1 dBi Usage distanceUsed with the rear of the product adhered to the body part. Antenna 2 (Antennas used for testing) TypeExternal Dipole Ant Gain4.0 dBi Usage distanceUsed with the rear of the product adhered to the body part. 1. Executive Summary & EUT Information Ref. No.: LR500112002D Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 57 Introduction This measurement report shows compliance of the EUT with KDB Publication 447498 & RSS 102 Issue 5.0. The test procedures, as described in ANSI C95.1 – 2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz [2], and ANSI C95.3 – 2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields [3], were employed. SAR Definition Specific Absorption Rate is defined as the time derivative (rate) of the incremental energy (dW) absorbed by (dissipated in) an incremental mass (dm) contained in a volume element (dV) of a given density (ρ). SAR is expressed in units of watts per kilogram (W/kg). SAR can be related to the electric field at a point by where: σ = conductivity of the tissue (S/m) ρ = mass density of the tissue (kg/m3) E = rms electric field strength (V/m) 2. Introduction Ref. No.: LR500112002D Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 57 Dosimetric Assessment System These measurements were performed with the automated near-field scanning system OPENSAR from SATIMO. The system is based on a high precision robot (working range: 850 mm), which positions the probes with a positional repeatability of better than ± 0.02 mm. Special E- and H-field probes have been developed for measurements close to material discontinuity, the sensors of which are directly loaded with a Schottky diode and connected via highly resistive lines to the data acquisition unit. The SAR measurements were conducted with dosimetric probe (manufactured by SATIMO), designed in the classical triangular configuration and optimized for dosimetric evaluation. The probe has been calibrated according to the procedure described in SAR standard with accuracy of better than ±10%. The spherical isotropy was evaluated with the procedure described in SAR starndard and found to be better than ±0.25 dB. The phantom used was …
Text truncated - open the document above for the full version.
REPORT No.:TRRFCC20-0004 Total 49 pages TRF-R-018(00) Page: 2 / 49 Copyright ⓒ 2020, Lab-T, Inc. CONTENTS 1. Applicant Information .............................................................................................................................. 3 2. Laboratory Information ............................................................................................................................ 3 3. Information About Test Equipment ......................................................................................................... 4 3.1 Equipment Information ............................................................................................................................. 4 3.2 Antenna Information ................................................................................................................................. 4 3.3 Test Frequency ......................................................................................................................................... 4 3.4 Tested Companion Device Information .................................................................................................... 4 4. Test Report ................................................................................................................................................ 7 4.1 Summary .................................................................................................................................................. 7 4.2 Measurement Uncertainty ........................................................................................................................ 8 4.3 Test Report Version .................................................................................................................................. 8 4.4 Transmitter Requirements ........................................................................................................................ 9 4.4.1 Antenna Requirement ........................................................................................................................ 9 4.4.2 20 dB Bandwidth and Occupied Bandwidth .................................................................................... 10 4.4.3 Number of Hopping Frequencies .................................................................................................... 15 4.4.4 Time of occupancy (Dwell Time) ..................................................................................................... 18 4.4.5 Carrier Frequencies Separation ...................................................................................................... 23 4.4.6 Peak Output Power ......................................................................................................................... 27 4.4.7 Spurious Emission, Band Edge, and Restricted bands ................................................................... 31 4.4.8 Conducted Emission ....................................................................................................................... 47 APPENDIX I .................................................................................................................................................... 48 REPORT No.:TRRFCC20-0004 Total 49 pages TRF-R-018(00) Page: 3 / 49 Copyright ⓒ 2020, Lab-T, Inc. 1. Applicant Information Applicant : Maytel Co., Ltd Address : #417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea Telephone No. : +82-32-487-5508 Person in charge : Su won Bae / [email protected] Manufacturer : Maytel Co., Ltd Address : #417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea 2. Laboratory Information Test Laboratory : Lab-T, Inc. Address : 2182-42 Baegok-daero, Mohyeon-myeon, Cheoin-gu, Yongin-si, Gyeonggi-do 17036, Korea Telephone No. : +82 31-322-6767 Facsimile No. : +82 31-322-6768 Certificate FCC Designation No. : KR0159 FCC Registration No. : 133186 IC Site Registration No. : 22000 REPORT No.:TRRFCC20-0004 Total 49 pages TRF-R-018(00) Page: 4 / 49 Copyright ⓒ 2020, Lab-T, Inc. 3. Information About Test Equipment 3.1 Equipment Information Equipment type Grand Multicom 2.4G Model name GM-2.4G Variant model name MicroCom XR 2.4G, SWATCOM, XR-2.4G Note2 Frequency range 2 407 ~ 2 476 MHz (Number of Channels : 139, Hopping Channels : 40) Note3 Modulation type (Symbol rate / Bit rate) GFSK (500 ksps / 500 kbps) Modulation technology FHSS Power supply DC 3.7 V H/W version V0.2 S/W version V0.2 Note1: The above EUT information was declared by the manufacturer. Note2 : Variant Model Names are used for each other different Buyers. Note3 : This device uses 40 random hopping channels among total 139 channels. 3.2 Antenna Information Antenna 1 Type Dipole Antenna Gain 3.1 dBi Antenna 2 Type Dipole Antenna Gain 4.0 dBi 3.3 Test Frequency Test mode Test frequency (MHz) Lowest frequency Middle frequency Highest frequency GFSK 2 407 2 441.5 2 476 3.4 Tested Companion Device Information Type Manufacturer Model Note - - - - REPORT No.:TRRFCC20-0004 Total 49 pages TRF-R-018(00) Page: 5 / 49 Copyright ⓒ 2020, Lab-T, Inc. 3.5 Operating conditions for the EUT Firmware state V0.2 Test software name(version) Used native test mode(-) Test power setting 20 dBm Serial number (Setup mode) EUT #1 N/A (Radiated Emission, Conducted Emission) EUT #2 - REPORT No.:TRRFCC20-0004 Total 49 pages TRF-R-018(00) Page: 6 / 49 Copyright ⓒ 2020, Lab-T, Inc. 3.6 Equipment Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2407 47 2430.5 94 2454 1 2407.5 48 2431 95 2454.5 2 2408 49 2431.5 96 2455 3 2408.5 50 2432 97 2455.5 4 2409 51 2432.5 98 2456 5 2409.5 52 2433 99 2456.5 6 2410 53 2433.5 100 2457 7 2410.5 54 2434 101 2457.5 8 2411 55 2434.5 102 2458 9 2411.5 56 2435 103 2458.5 10 2412 57 2435.5 104 2459 11 2412.5 58 2436 105 2459.5 12 2413 59 2436.5 106 2460 13 2413.5 60 2437 107 2460.5 14 2414 61 2…
Text truncated - open the document above for the full version.
Page: 1 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Page: 2 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Radiated Emission_9 kHz ~ 30 MHz Test distance : 3 m, height of table : 0.8 m Radiated Emission_30 MHz ~ 1 GHz Test distance : 3 m, height of table : 0.8 m Page: 3 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Radiated Emission_1 GHz ~ 18 GHz Test distance : 1 m, height of table : 1.5 m Radiated Emission_above 18 GHz Test distance : 1 m, height of table : 1.5 m
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.48 GHz | 105.00 mW |

Xepton NX 900M Stationary
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Grand Multicom
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Grand Multicom
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Multicom
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
