Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15C | 2.40 GHz - 2.48 GHz | 82.40 mW |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesPower listed is maximum combined conducted output power.
Approval is limited to OEM installation under the strict control of the Grantee. The OEM integrator is responsible for the compliance of the final end product according to it's categorization with special aspect of intermodulation of the module (no own antenna) and the host device. With the maximum permissible gain of 2.3 dBi in the 2.4 GHz band, and 5 dBi in the 5 GHz bands. Use of an antenna having a gain greater than the maximum gain specified, are strictly prohibited for use with this device and will void the user's authority to operate the equipment.
Device is 2X2 MIMO.
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures.
The device supports 20MHz and 40MHz bandwidth.
