YMICGW002The Action Back Remote control

User Manual The Action Back TM Remote CGW-002 Xiamen Pinrui Trade Co.,LTD. Baitou Hill, Ying Village, Houxi Town, Jimei Area,Xiamen City,Fujian Province,China FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

Xiamen Pinrui Trade Co.,LTD. Add: Baitou Hill, Ying Village, Houxi Town, Jimei Area, Xiamen City,Fujian Province,China To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Xiamen Pinrui Trade Co.,LTD hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description, model name) FCC ID: YMICGW002 Product name: The Action Back TM Remote Model: CGW-002 We affirm that between SIEMIC and Xiamen Pinrui Trade Co.,LTD , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Teddy Tang / Product enigneer Title: Product enigneer Telephone: 0596-6863171 Date: 2010-8-9 Xiamen Pinrui Trade Co.,LTD.

Xiamen Pinrui Trade Co.,LTD. Add: Baitou Hill, Ying Village, Houxi Town, Jimei Area, Xiamen City,Fujian Province,China 2010-8-9 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: YMICGW002 We hereby request confidential treatment of information accompanying this application as outlined below: • Schematics • Block diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Teddy Tang / Product enigneer Title: Product enigneer Telephone: 0596-6863171 Date: 2010-8-9 Xiamen Pinrui Trade Co.,LTD.

Page 2 of 4

W*L : 1.5CM * 2.5 CM FCC ID: YMICGW002 Model No.: CGW-002 Manufacturer: Egeer Electrical Co.,Ltd

Page 3 of 4 Page 4 of 4

Report No.: NTEK-2010NT0518001E Page 1 of 25 - FCC Radio TEST Report FCC ID: YMICGW002 This report concerns (check one) : Original Grant Class II Change Report No.： NTEK-2010NT0518001E Product： The Action Back TM Remote Model No.： CGW-002 Applicant： Xiamen Pinrui Trade Co.,LTD. Address： Baitou Hill, Ying Village, Houxi Town, Jimei Area,Xiamen City,Fujian Province,China Issued by： NTEK Testing Technology Co., Ltd Lab Location： 3/F,Block B, Hua feng Technology & Business Building, Xin｀an 6 Road, Bao an Center District, Shenzhen, China Tel： (86)-0755-29453021 Fax: (86)-0755-27667047 Date of Test: Aug. 02, 2010 ~ Aug. 11, 2010 Date of Issue： Aug. 11, 2010 Test Result：Pass Standards: FCC Part 15 subpart C(15.231) Testing Engineer : (Jake Wang) Technical Manager : (Ada Li) Authorized Signatory : (Can Liu) This device described above has been tested by Asia Institute Technology (Dongguan) Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. *This test report must not be used by the client to claim product endorsement by any agency of the U.S. government. Report No.: NTEK-2010NT0518001E Page 2 of 25 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 3 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST CONDITIONS 6 2.3 DESCRIPTION OF SUPPORT UNITS 7 2.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . TEST RESULT 9 3.1 ANTENNA REQUIREMENT 9 3.1.1 STANDARD REQUIREMENT 9 3.1.2 EUT ANTENNA 9 3.2 CONDUCTED EMISSION MEASUREMENT 10 3.2.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.2.2 TEST PROCEDURE 11 3.2.3 DEVIATION FROM TEST STANDARD 11 3.2.4 TEST SETUP 11 3.2.5 TEST RESULTS 12 3.3 RADIATED EMISSION MEASUREMENT 13 3.3.1 RADIATED EMISSION LIMITS 13 3.3.2 TEST PROCEDURE 14 3.3.3 DEVIATION FROM TEST STANDARD 14 3.3.4 TEST SETUP 15 3.3.5 TEST RESULTS (BETWEEN 30 – 1000 MHz) 18 3.3.6 TEST RESULTS (ABOVE 1000 MHz) 20 4 . BANDWIDTH TEST 22 4.1 LIMIT 22 4.2 TEST PROCEDURE 22 4.3 DEVIATION FROM STANDARD 22 4.4 TEST SETUP 22 4.5 TEST RESULTS 23 5 . TRANSMITTER TIMEOUT 24 5.1 REQUIREMENTS 24 6 . EUT TEST PHOTO 25 Radiated Measurement Photos 25 Report No.: NTEK-2010NT0518001E Page 3 of 25 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.231) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.231 Radiated Spurious Emission Pass 15.231 Occupied Bandwidth Pass 15.231 Transmitter Timeout Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. Report No.: NTEK-2010NT0518001E Page 4 of 25 1.1 TEST FACILITY Asia Institute Technology (Dongguan) Limited Add. : No.6 Binhe Road, Tianxin Village, Huangjiang, Dongguan, Guangdong, China. FCC Registered No.: 248337 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE C01 ANSI150 KHz ~ 30MHz 1.94 B. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE OS-01 ANSI30MHz ~ 200MHz V 2.93 30MHz ~ 200MHz H 2.86 200MHz ~ 1,000MHz V 3.86 200MHz ~ 1,000MHz H 3.94 Report No.: NTEK-2010NT0518001E Page 5 of 25 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment The Action Back TM Remote Brand Name N/A Model Name. CGW-002 OEM Brand/Model Name N/A Model Difference N/A Manufacturer Zhongshan City Guangdong Province Egeer Electrical Co.,Ltd Manufacturer Address Froor5,No.22,ChengguiRoad,WuguishanTown,ZhongShan City,Guangdong, China Product Description The EUT is a 433MHz Led driver control Product Type Remote Control Operation Frequency:433.92MHz Modulation Type: ASK Number Of Channel 1CH. Antenna Designation: Printed antenna Antenna Gain(Peak) 2.32 dBi Output Power: 75.16 dBuV/m (AV Max.) Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an Control Device. More details of EUT technical specification, please refer to the User's Manual. Channel List N/A Power Source DC Voltage supplied from 1*AA size Battery Power Rating DC 12V Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Report No.: NTEK-2010NT0518001E Page 6 of 25 2.2 DESCRIPTION OF TEST CONDITIONS (1) EUT was tested in normal configuration (Please See following Block diagram) 1. Block diagram of EUT configuration EUT (2) E.U.T. test conditions: 15.31(e) :For intentional radiators, measurements of the variation of the input power or the adiated signal level of the fundamental frequency component of the emission, as appropriate, shall be performed with the supply voltage varied between 85% and 115% ofthe nominal rated supply voltage. For battery operated equipment, theequipment tests shall be performed using a new battery. (3) Test frequencies: According to the 15.31(m) Measurements on intentional radiators or receivers, other than TV broadcast receivers, shall be performed and. if required. reported for each band in which the device can be operated with the device operating at the number of fequencies in each band specified in the following table: Frequency range over which device operates Number of frequencies Location in the range of operation 1 MHz or less 1 Middle 1 to 10 MHz 2 1 near top and 1 near bottom More than 10 MHz 3 1 near top, 1 near middle and 1 near bottom . (4) Frequency range of radiated measurements: According to the 15.33,The test range will be upto the tenth harmonic of the highest fundamental frequency Report No.: NTEK-2010NT0518001E Page 7 of 25 2.3 DESCRIPTION OF SUPPORT UNITS The EUT…

Text truncated - open the document above for the full version.

Report No.: NTEK-2010NT0518001E Page 25 of 25 6. EUT TEST PHOTO Radiated Measurement Photos
