YR6-AIMSFS-05XAIMS FAST SCAN RADAR SYSTEM (AIMSFS-05X)

DETAILED TECHNICAL USER MANUAL FOR: PC/104 plus smartModule855 MSM855/HLV/B/B2 Nordstrasse 11/F CH - 4542 Luterbach Tel.: ++41 (0)32 681 58 00 Fax: ++41 (0)32 681 58 01 Email: [email protected] Homepage: http://www.digitallogic.com DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 2 For internal use only: File: MSM855_Detailed_V1.0A Path: R:\HANDBUCH\MSM\cpu_boards\MSM855\MSM855_Detailed_V1.0A.doc COPYRIGHT    2008 BY DIGITAL-LOGIC AG This publication is protected by copyright and all rights are reserved. No part of this document may be reproduced, transmitted, transcribed or stored in a retrieval system, in any form or by any means, electronic, mechanical, optical, manual, or otherwise, without the prior written permission of DIGITAL-LOGIC AG. The software described herein, together with this document, are furnished under a license agreement and may be used or copied only in accordance with the terms of that agreement. About this Manual and How to Use It This manual is written for the original equipment manufacturer (OEM) who plans to build computer systems based on the single board MICROSPACE-PC. It is for integrators and programmers of systems based on the MICROSPACE-Computer family. This manual provides instructions for installing and configuring the board, and describes the system and setup requirements. This document contains information on hardware requirements, interconnections, and details of how to program the system. Please check the Product CD for further information and manuals. REVISION HISTORY: Document Version Date/Initials: Modification: Remarks, News, Attention: V1.0 02.2008 WAS Initial Version of Detailed Manual adapted from existing V1.4C Sections 1.12, 1.13 added / 2.11.1 & 2.11.2 updated V1.0A 07.2008 DAR Chapter 5.3.6 / 9.71 Attention! 1. All information in this manual, and the product, are subject to change without prior notice. 2. Read this manual prior to installation of the product. 3. Read the security information carefully prior to installation of the product. DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 3 Table of Contents 1. PREFACE.....................................................................................................................................................6 1.1. Trademarks ..................................................................................................................................... 6 1.2. Disclaimer ....................................................................................................................................... 6 1.3. Environmental Protection Statement ........................................................................................... 6 1.4. Who should use this Product ....................................................................................................... 6 1.5. Recycling Information.................................................................................................................... 7 1.6. Technical Support .......................................................................................................................... 7 1.7. Limited Two Year Warranty ........................................................................................................... 7 1.8. Explanation of Symbols................................................................................................................. 8 1.9. Applicable Documents and Standards ........................................................................................ 9 1.10. For Your Safety............................................................................................................................. 10 1.11. RoHS Commitment....................................................................................................................... 10 1.11.1. RoHS Compatible Product Design ........................................................................................ 11 1.11.2. RoHS Compliant Production Process ................................................................................... 11 1.11.3. WEEE Application.................................................................................................................. 11 1.12. Swiss Quality ................................................................................................................................ 12 1.13. The Swiss Association for Quality and Management Systems............................................... 12 2. OVERVIEW.................................................................................................................................................13 2.1. Standard Features........................................................................................................................ 13 2.2. Unique Features ........................................................................................................................... 13 2.3. Standards ...................................................................................................................................... 13 2.4. Block Diagrams ............................................................................................................................ 14 2.4.1. SM855 ................................................................................................................................... 14 2.4.2. MSM855 ................................................................................................................................ 14 2.4.3. MSM855B .............................................................................................................................. 15 2.4.4. MSM855B2 ............................................................................................................................ 15 2.5. Specifications .......................................................................................................................…

Text truncated - open the document above for the full version.

DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 62 5.6.3. ROM-BIOS Sockets An EPROM socket with 8bit wide data access normally contains the board's AT compatible ROM-BIOS. The socket takes an E82802AC8 EPROM (or equivalent) device. The board's wait-state control logic automatically inserts four memory wait-states in all CPU accesses to this socket. The ROM-BIOS sockets occupy the memory area from C0000H through FFFFFh; however, the board's ASIC logic reserves the entire area from C0000h through FFFFFh for onboard devices, so that this area is already usable for ROM-DOS and BIOS expansion modules. Consult the appropriate address map for the MICROSPACE MSM855 ROM- BIOS sockets. 5.7. CMOS RAM Map Systems based on the industry-standard specification include a battery backed Real Time Clock chip. This clock contains at least 64Bytes of non-volatile RAM. The system BIOS uses this area to store information including system configuration and initialization parameters, system diagnostics, and the time and date. This information remains intact even when the system is powered down. The BIOS supports 128Bytes of CMOS RAM. This information is accessible through I/O ports 70h and 71h. CMOS RAM can be divided into several segments:
Locations 00h - 0Fh contain real time clock (RTC) and status information
Locations 10h - 2Fh contain system configuration data
Locations 30h - 3Fh contain System BIOS-specific configuration data as well as chipset-specific information
Locations 40h - 7Fh contain chipset-specific information as well as power management configuration parameters The following table provides a summary of how these areas may be further divided. Beginning Ending Checksum Description 00h 0Fh No RTC and Checksum 10h 2Dh Yes System Configuration 2Eh 2Fh No Checksum Value of 10h - 2Dh 30h 33h No Standard CMOS 34h 3Fh No Standard CMOS - SystemSoft Reserved 40h 5Bh Yes Extended CMOS - Chipset Specific 5Ch 5Dh No Checksum Value of 40h - 5Bh 5Eh 6Eh No Extended CMOS - Chipset Specific 6Fh 7Dh Yes Extended CMOS - Power Management 7Eh 7Fh No Checksum Value of 6Fh - 7Dh DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 63 CMOS Map Location Description 00h Time of day (seconds) specified in BCD 01h Alarm (seconds) specified in BCD 02h Time of day (minutes) specified in BCD 03h Alarm (minutes) specified in BCD 04h Time of day (hours) specified in BCD 05h Alarm (hours) specified in BCD 06h Day of week specified in BCD 07h Day of month specified in BCD 08h Month specified in BCD 09h Year specified in BCD 0Ah Status Register A Bit 7 = Update in progress Bits 6-4 = Time based frequency divider Bits 3-0 = Rate selection bits that define the periodic interrupt rate and output frequency. 0Bh Status Register B Bit 7 = Run/Halt 0 Run 1 Halt Bit 6 = Periodic Timer 0 Disable 1 Enable Bit 5 = Alarm Interrupt 0 Disable 1 Enable Bit 4 = Update Ended Interrupt 0 Disable 1 Enable Bit 3 = Square Wave Interrupt 0 Disable 1 Enable Bit 2 = Calendar Format 0 BCD 1 Binary Bit 1 = Time Format 0 12-Hour 1 24-Hour Bit 0 = Daylight Savings Time 0 Disable 1 Enable 0Ch Status Register C Bit 7 = Interrupt Flag Bit 6 = Periodic Interrupt Flag Bit 5 = Alarm Interrupt Flag Bit 4 = Update Interrupt Flag Bits 3-0 = Reserved 0Dh Status Register D Bit 7 = Real Time Clock 0 Lost Power 1 Power 0Eh CMOS Location for Bad CMOS and Checksum Flags Bit 7 = Flag for CMOS Lost Power 0 = Power OK 1 = Lost Power Bit 6 = Flag for CMOS checksum bad 0 = Checksum is valid 1 = Checksum is bad DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 64 0Fh Shutdown Code 10h Diskette Drives Bits 7-4 = Diskette Drive A 0000 = Not installed 0001 = Drive A = 360 kB 0010 = Drive A = 1.2MB 0011 = Drive A = 720 kB 0100 = Drive A = 1.44MB 0101 = Drive A = 2.88MB Bits 3-0 = Diskette Drive B 0000 = Not installed 0001 = Drive B = 360 kB 0010 = Drive B = 1.2MB 0011 = Drive B = 720 kB 0100 = Drive B = 1.44MB 0101 = Drive B = 2.88MB 11h Reserved 12h Fixed (Hard) Drives Bits 7-4 = Hard Drive 0, AT Type 0000 = Not installed 0001-1110 = Types 1-14 1111 = Extended drive types 16-44. See location 19h. Bits 3-0 = Hard Drive 1, AT Type 0000 = Not installed 0001-1110 = Types 1-14 1111 = Extended drive types 16-44. See location 2Ah. 13h Reserved 14h Equipment Bits 7-6 = Number of Diskette Drives 00 = One diskette drive 01 = Two diskette drives 10, 11 = Reserved Bits 5-4 = Primary Display Type 00 = Adapter with option ROM 01 = CGA in 40 column mode 10 = CGA in 80 column mode 11 = Monochrome Bits 3-2 = Reserved Bit 1 = Math Coprocessor Presence 0 = Not installed 1 = Installed Bit 0 = Bootable Diskette Drive 0 = Not installed 1 = Installed 15h Base Memory Size (in kB) - Low Byte 16h Base Memory Size (in kB) - High Byte 17h Extended Memory Size (in kB) - Low Byte 18h Extended Memory Size (in kB) - High Byte 19h Extended Drive Type - Hard Drive 0 1Ah Extended Drive Type - Hard Drive 1 DIGITAL-LOGIC AG MSM855/HLV/B/B2 Detailed Manual V1.0A 65 1Bh Custom and Fixed (Hard) Drive Flags Bits 7-6 = Reserved Bit 5 = Internal Floppy Disk Controller 0 = Disabled 1 = Enabled Bit 4 = Internal IDE Controller 0 = Disabled 1 = Enabled Bit 3 = Hard Drive 0 Custom Flag 0 = Disabled 1 = Enabled Bit 2 = Hard Drive 0 IDE Flag 0 = Disabled 1 = Enabled Bit 1 = Hard Drive 1 Custom Flag 0 = Disabled 1 = Enabled Bit 0 = Hard Drive 1 IDE Flag 0 = Disabled 1 = Enabled 1Ch Reserved 1Dh EMS Memory Size Low Byte 1Eh EMS Memory Size High Byte 1Fh - 24h Custom Drive Table 0 These 6 Bytes (48 bits) contain the following data: Cylinders 10bits range 0-1023 Landing Zone 10bits range 0-1023 Write Precompensation 10bits range 0-1023 Heads 08bits range 0-15 Sectors/Track 08bits range 0-254 1Fh Byte 0 Bits 7-0 = Lower 8 bits of Cylinders 20h Byte 1 Bits 7-2 = Lower 6 bits of Landing Zone Bits 1-0 = Upper 2 bits of Cylinders 21h Byte 2 Bits 7-4 = Lower 4 bits of Write Precompensation Bits 3-0 = Upper 4 bits of Landing Zone 22h Byte 3 Bits 7-6 = Reserved Bits 5-0 = Upper 6 bits of Write Precompensation 23h Byte 4…

Text truncated - open the document above for the full version.

CB Series PC/104-Plus Multiport Serial Module User’s Manual www.moxa.com/product Fourth Edition, January 2008 © 2008 Moxa Inc., all rights reserved. Reproduction without permission is prohibited. CB Series PC/104-Plus Multiport Serial Module User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2008 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Trademarks MOXA is a registered trademark of Moxa Inc. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Moxa. Moxa provides this document “as is,” without warranty of any kind, either expressed or implied, including, but not limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the products and/or the programs described in this manual, at any time. Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for its use, or for any infringements on the rights of third parties that may result from its use. This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication. Technical Support Contact Information www.moxa.com/support Moxa Americas: Toll-free: 1-888-669-2872 Tel: +1-714-528-6777 Fax: +1-714-528-6778 Moxa China (Shanghai office) : Toll-free: 800-820-5036 Tel: +86-21-5258-9955 Fax: +86-10-6872-3958 Moxa Europe : Tel: +49-89-3 70 03 99-0 Fax: +49-89-3 70 03 99-99 Moxa Asia-Pacific : Tel: +886-2-8919-1230 Fax: +886-2-8919-1231 Table of Contents Chapter 1 Introduction...............................................................................................1-1 Overview.............................................................................................................................. 1-2 Package Checklist................................................................................................................. 1-2 Product Features................................................................................................................... 1-2 Product Specifications.......................................................................................................... 1-3 Chapter 2 Hardware Installation................................................................................2-1 Hardware Installation........................................................................................................... 2-2 Block Diagrams.................................................................................................................... 2-2 Rotary Switch............................................................................................................... 2-3 Termination Resistor.................................................................................................... 2-3 Serial Interface Selection...................................................................................................... 2-4 Chapter 3 Software Installation.................................................................................3-1 Windows NT......................................................................................................................... 3-2 Installing the Driver...................................................................................................... 3-2 Configuring the Ports.................................................................................................... 3-5 Removing the Board..................................................................................................... 3-7 Updating the Driver...................................................................................................... 3-7 Removing the Driver.................................................................................................... 3-8 Windows 95/98/ME.............................................................................................................. 3-9 Installing the Driver...................................................................................................... 3-9 Configuring the Ports.................................................................................................. 3-13 Updating the Driver.................................................................................................... 3-15 Removing the Driver.................................................................................................. 3-17 Windows Vista (32-bit and 64-bit)..................................................................................... 3-18 Installing the Driver.................................................................................................... 3-18 Using Device Manager to Verify Installation............................................................. 3-25 Port Configuration...................................................................................................... 3-26 Windows XP, 2003 (32-bit and 64-bit)............................................................................... 3-28 Installing the Driver.................................................................................................... 3-28 Using Device Manager to Verify Installation............................................................. 3-34 Port Configuration...................................................................................................... 3-35 Using PComm............................................................................................................. 3-37 Using Event Log....…

Text truncated - open the document above for the full version.

DMT, LLC • DMT-M200-311 • 08/2009 August 5, 2009 DMT LLC 45180 Business Court, Suite 500 Sterling, VA 20166 703-326-0004 703-326-0022 [email protected] DMT is a private company owned entirely by USA Citizens DMT radar systems are manufactured entirely in the USA AIMS Fast-Scan Radar v3.22 Installation and Configuration Manual Reference Number: DMT-M200-311 AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 08/2009 Change History Version Date Status Author Description 0.1 12/23/2008 DRAFT J Byrne 0.2 06/30/2011 RELEASE J Byrne FCC-related statements added AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 i Table of Contents 1 Introduction ....................................................................... Error! Bookmark not defined. 1.1 Radar Configurations ...................................................... Error! Bookmark not defined. 1.1.1 Transmit Power ........................................................ Error! Bookmark not defined. 1.1.2 Operating Frequency ................................................ Error! Bookmark not defined. 1.1.3 Physical Packaging .................................................. Error! Bookmark not defined. 1.2 Antennae.......................................................................... Error! Bookmark not defined. 1.3 AIMS Universal Communication Module ...................... Error! Bookmark not defined. 1.4 Other Value-Added Enhancements ................................. Error! Bookmark not defined. 2 Reference .......................................................................................................................... 1 2.1 Documents ........................................................................................................................ 1 2.2 Acronyms and Definitions ............................................................................................... 1 3 Installation ......................................................................................................................... 3 3.1 General Guidelines ........................................................................................................... 3 3.1.1 Cabling ...................................................................................................................... 3 3.1.2 Power Cabling ........................................................................................................... 4 3.1.3 Communications ....................................................................................................... 4 3.1.4 Selecting a Location .................................................................................................. 6 3.1.5 Installation on Towers, Buildings, or Poles .............................................................. 6 3.2 Preparation ....................................................................................................................... 9 3.2.1 Before You Begin ..................................................................................................... 9 3.2.2 Tools ......................................................................................................................... 9 3.2.3 Arrival of Equipment .............................................................................................. 10 3.3 Mounting the Radar ........................................................................................................ 12 3.3.1 Installation Procedures for AIMS Fast-Scan .......................................................... 12 3.4 Locating the UCM .......................................................................................................... 13 3.5 Camera Installation ........................................................................................................ 14 3.6 Connecting Power .......................................................................................................... 17 3.6.1 Radar ....................................................................................................................... 17 3.6.2 Cameras................................................................................................................... 17 AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 ii 3.6.3 Universal Communications Module and Utility Enclosures .................................. 17 3.7 Hardware Adjustments ................................................................................................... 18 3.7.1 Adjusting the Azimuth Home Pin ........................................................................... 19 3.7.2 Adjusting the Elevation Home Pin ......................................................................... 20 4 Server Software ..................................................................................................................... 21 4.1 Configurable Features .................................................................................................... 21 4.2 Server Interface Screens ................................................................................................. 22 4.2.1 Operation Tab ......................................................................................................... 24 4.2.1.1 Processing Parameters ..................................................................................... 24 4.2.1.2 GPS Parameters ............................................................................................... 25 4.2.1.3 Auto Scan Control ........................................................................................... 25 4.2.1.4 Camera Parameters .......................................................................................... 26 4.2.1.5 GPS/Compass Installed ................................................................................... 26 4.2.1.6 System Sta…

Text truncated - open the document above for the full version.

AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 17 3.6 Connecting Power 3.6.1 Radar AIMS Radar systems are all designed for 48 VDC input. Clients can optionally order 24 VDC versions as well, but these must have a 24 volt universal communications module version feeding it. AIMS radar systems are power conditioned, so they can be powered by four 12 volt car or RV batteries. A volt meter and cut-off switch should be installed if running on batteries to ensure the radar is not damaged from drooping voltage as the battery dies. The CPU will shutdown if voltage droops significantly. If this occurs, communications to the client software will discontinue and the radar will require cycling powering to restart the radar server software. AIMS Fast-Scan radar systems come in a variety of ranges. For 1.5 km systems, the power pull will be a consistent 2 AMP load, or 98 Watts when running. There is a rush pull of current (spike) at startup, which can be high as 2.5 AMPS. Power draw and current rush increases for further range systems. For 20 Watts, the power draw is about 150 watts (varies slightly with options) with a 200 Watt rush at startup. 3.6.2 Cameras Most thermal cameras use DC voltage. The range of voltage is 12 to 28 VDC for the most part. DMT has 24 VDC supply for the purpose of feeding thermal cameras. A 12 or 15 VDC supply is also included for powering onboard electronics. This can be routed to the wiring block for use by the camera (see wiring block diagram for Universal Communications Module – Figure 14). The power draw for many uncooled thermal cameras are less than 25 watts of power. Cooled thermal cameras or multi-sensor camera products can pull considerable current. Check that the power draw is less than 75% of the power rating on the 24 VDC power brick (printed on the brick). Many dome security companies use 24 VAC. Optionally, the Universal Communications Module can be fitted with a 24 VAC supply. This supply is rather large and should be able to power any dome camera on the market that uses 24 VAC. Check the camera literature before using this supply to ensure you have selected the right power. Some newer models of dome cameras have switched to DC voltage, so damage can occur if the wrong selection of DC or AC is made. 3.6.3 Universal Communications Module and Utility Enclosures The Universal Communications Module (UCM) and the base tower utility enclosures accept 120 to 240 VAC, 40-63 Hz (auto-ranging). Power conditioning is present on every enclosure provided by DMT, however, the power should be within 25% of the rated supply voltage. AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 18 Circuit breakers exist in all enclosures provided by DMT. These protect the radar, cameras and other equipment from faulty hookups or power problems. These are a safety measure supplied by DMT and are not a substitute for proper planning, preparation and care. 3.7 Hardware Adjustments The antenna is controlled by two motors, an azimuth motor for bearing and an elevation motor for elevation relative to the ground. Under normal circumstances, both of these should be properly adjusted and require no modification. When set to the home position (0º azimuth, 0º elevation) both of the home pin detection LEDs should be lit (see below). If not, these may require adjustment detailed in the following two subsections. AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 19 3.7.1 Adjusting the Azimuth Home Pin The adjustment of the azimuth home pin positions the top of the home pin close enough for the hall-effect sensor to detect it while far enough away to prevent accidental collision between the detector and the home pin during use or transport. The adjustment is fairly simply and only requires an adjustable open end wrench and hex key (see below). While adjusting the azimuth home pin, remember that the radar will always spin to the right (clockwise) when searching for the home pin. AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 06/2009 20 3.7.2 Adjusting the Elevation Home Pin The adjustment of the elevation home pin positions the home pin directly over the hall-effect sensor while the antenna is aimed parallel to the horizon. The adjustment is fairly simply and only requires a hex key (see below). When adjusting the elevation home pin, remember that the radar will always assume the antenna is resting in a downward position and will elevate the antenna to search for the home position. AIMS Fast-Scan Radar v3.22 Installation and Operations Manual DMT, LLC • DMT-M200-311 • 08/2009 21 4 Server Software Although most all of the software parameters may be modified through the server interface, it is recommended that the normal use and modification of the system parameters be performed from the client interface where more comprehensive error-checking and boundary conditioning is performed to prevent the user from configuring an abnormal operating condition. Nonetheless, in this section we will introduce the reader to the user screens available at the server interface and will advise which parameters must be setup from the server interface. 4.1 Configurable Features The table below provides a brief overview of the configurable parameters within the AIMS radar server. Additional features are available from the client interface. Waveform Generation Signal Processing Motion Display / Save Data Other BITE PRF Rate A/D Sample Rate Mode • Positional • Velocity Graphing GPS Check A/D Limits Pulse Width Range Bins • No of bins • Zero range Scripts Segment Trunc. Compass No. of Pulses Filters • Smoothing • Matched • Ramp Limits • Azimuth • Elevation Autosave Data Cameras • Track to Alarm • FOV • Comm. • Video Svr • Offsets Lobe Removal • Main Lobe • 2 nd Lobe • 3 rd Lobe Offsets Broadcast Interval Network • IP Addr • Port Tracker • AB Tracker •…

Text truncated - open the document above for the full version.
