YRV-ATY-FR01RWIRELESS CONTROL- RECEIVER

wireless control instructions MODEL:ATY-FR01 User manual shenzhen oread Electronics Co.,ltdTel：（86）0755-33168903 27546250Fax：（86）0755-27183277 Fourth Floor, A9 Building ,Yuansheng Logistics Park, Changsheng Road No.1, Changzhen Community, Gongming Street,Guangming New District. Shenzhen City. 1 wireless control instructions MODEL:ATY-FR01User manualTable of ContentsIntroduction .................................................................. 2Components .................................................................. 3Specification ......................................................... 4 Catalogue It is appreciated that you use our product ATY-FR01 fits many kinds of electrical machinery and apparatus related to wireless control controlling scenario Adapting isolated system and avoiding the wireless interference resulted in actuator working.More reliable Controlled by MCU,wireless date transmits more correctly.It mat ches the code automatically and it is easy to use,moreover, the products do not disturb each other when using. Important statements:This receiver is applied to the linear act uator controller The crystal connector does not fit connecting telephone line 2 Overview In order to use the Wireless EnergyMonitorproperly, please read this user manualcarefully to operate i t. And please take goodcare of it for future reference. We hope thatthis manual will enable you to understandand use our products well. If you haveencountered any problems, please contact us. LED Button1Button2 Transmitter Receiver Transmitter terminal Other announcements:1.This product should be protected from pressing2.Please change the battery when the battery leaking or expanding.3.Product can not be used in the place of moist or high temperature. Battery Holder 3 Specification 1 2 3 4 Transmitter ： Working Indicate:Press any button constantly,transmitter starts working,the indicator light blinksWhile stop pressing the button,the indicator extinguishes and the transmitter stops working Receiver: Power supply:10-30VDC(2 is negative pole,4 is positive pole,please see the drawing of transmitter terminal)Transmitter terminal:1.Output1. 2.Negative pole. 3.Output2 4.Positive pole Working Description 1 、 Transmitter connects with battery,receiver connects with power supply 2 、 Press any button of transmitter,receiver will matches the code itself after receiving the signal,then receiver matches the code successfully and starts 3 、 Press button 1 of transmitter,receiver terminal 1 pin outputs low voltage 4 、 Press the button2 of the transmitter,receiver terminal 3 pin outputs low voltage 5 、 Under uninterruptible power,the other same frequency can not matches the code when the receiver matches the code successfully 6 、 If need match the code again,the power supply should be stopped about 20 seconds and connects the power supply as the Step2

shen zhen oread Electronics Co.,ltd FCC ID: YRV-ATY-FR01R POWER OF ATTORNEY September 3, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Tian Hai Test Technology Co., Ltd (binglee) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen Tian Hai Test Technology Co., Ltd (binglee) on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act.We, shen zhen oread Electronics Co.,ltd are not subject to a denial of federal Benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuantto that section. Sincerely, shen zhen oread Electronics Co.,ltd Oswald qiu ( Engineer)

External Photographs EUT - Combination View EUT - Adapter View EUT - Connetor View EUT - Receiver View TOP view Rear View

FCC ID Location FCC ID Location

FCC ID Label Sample for FCC ID:YRV-ATY-FR01R F C C ID : Y RV-ATY-F R 01R Model: ATY-FR01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photographs EUT – Connector PCB View EUT – Receiver PCB View

Button1 Button2 TransmitterReceiver Frequency：433MHz Transmitter： Power supply:one 23A 12V battery No-load current：0A Transmitter terminal Working current:below 6mA Working Indicate:Press any button constantly,transmitter starts working,the in d While stop pressing the button,the indicator extinguishes and the transmitter sto Receiver: Power supply:10-30VDC(2 is negative pole,4 is positive pole,please see the dra Stanby current:below 5mA Working current:below 30mA Transmitter terminal:1.Output1. 2.Negative pole. 3.Output2 4.Positive pole Working Description 1、 Transmitter connects with battery,receiver connects with power supply 2、 Press any button of transmitter,receiver will matches the code itself after recei v Includes one pc of wireless transmitter paring with one pcs of wireless receiver. Ciruit Description 1 2 3 4 3、 Press button 1 of transmitter,receiver terminal 1 pin outputs low voltage 4、 Press the button2 of the transmitter,receiver terminal 3 pin outputs low voltage 5、 Under uninterruptible power,the other same frequency can not matches the co d 6、 If need matches the code again,the power supply should be stopped about 20 se Important statements:This receiver is applied to the linear actuator controller The crystal connector does not fit connecting telephone line Other announcements: 1.This product should be protected from pressing 2.Please change the battery when the battery leaking or expanding. 3.Product can not be used in the place of moist or high temperature.

1234 A B C D 4 321 D C B A Title NumberRevisionSize A4 Date:20-Jul-2010Sheet of File:G:\接收1.DDBDrawn By: 1 1 2 2 3 3 4 4 5 5 U3 C3 10UF C4 104 C5 100P C11 1UF C10 104 +5V VC25 3V SCK MISO MOSI 1 6 5 4 3 2 MOSI RESET SCK MISO VCC GND CN1 P6 SCK MISO MOSI Y1 13MHz C4 10uF 10V C3 120pF 50V L2 510 R3 1k C6 4.7uF 25V C8 100pF 50V L1 390nH C5 1uF 16V JP1 short JP3 open JP2 short ANT1 +3V C7 100P 16V 3V 3V 3V 12345678 CN2 P8 +5V MOSI 1 2 3 4 5 6 78 9 10 11 12 13 14 U1 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 U2 Vin 1 G N D 2 Vout 3 U4 VOLTREG Vin12-32Vdc Vout5Vdc/+5V C10 CAP K1 RELAY-SPDT K2 RELAY-SPDT Q3 PNP Q4 PNP Q1 NPN Q2 NPN D? DIODE D? DIODE R? RES2 R? RES2 R? RES2 R? RES2 R? RES2 R? RES2 R? RES2 +29V +29V NetLabel3 6 5 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

Test Report of FCC CFR 47 Part 15 Subpart B On Behalf of shen zhen oread Electronics Co.,ltd 4th Floor, A9 Building ,Yuansheng Logistics Park, Changsheng Road No.1, Changzhen, Gongming, Shenzhen,China Product description: wireless control instructions Receiver Model No.: ATY-FR01 FCC ID: YRV-ATY-FR01R Prepared for: shen zhen oread Electronics Co.,ltd 4th Floor, A9 Building ,Yuansheng Logistics Park, Changsheng Road No.1, Changzhen, Gongming, Shenzhen,China Prepared by: Shenzhen Tian Hai Test Technology Co., Ltd Unit A501, Shenzhen ChanXueYan Bldg., Wuhan University, Keyuan Nan Lu, Science Park south, Nanshan,Shenzhen, China Tel: 86- 0755-86615100 Fax:86-0755-86615105 Report No.: TH10IR-010E Issue Date: September 3, 2010 Test Date: September 1 ~ 3, 2010 Test by: Reviewed By: Sally Li (Engineer) Link wang(Manager) Report No.: TH10IR-010E Page 2 of 16 FCC ID: YRV-ATY-FR01R TABLE OF CONTENTS 1 - GENERAL INFORMATION ....................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................................ 3 1.2 TEST STANDARDS....................................................................................................................................................... 3 1.3 TEST SUMMARY.......................................................................................................................................................... 3 1.4 TEST METHODOLOGY.................................................................................................................................................. 4 1.5 TEST FACILITY............................................................................................................................................................ 4 2 - SYSTEM TEST CONFIGURATION ........................................................................................................... 5 2.1 EUT CONFIGURATION................................................................................................................................................. 5 2.2 EUT EXERCISE........................................................................................................................................................... 5 2.3 GENERAL TEST PROCEDURES...................................................................................................................................... 5 2.4 MEASUREMENT UNCERTAINTY...................................................................................................................................... 5 2.5 EUT EXERCISE SOFTWARE.......................................................................................................................................... 5 2.6 LIST OF MEASURING EQUIPMENTS USED....................................................................................................................... 6 3 - DISTURBANCE VOLTAGE AT THE MAINS TERMINALS ...................................................................... 8 3.1 MEASUREMENT UNCERTAINTY...................................................................................................................................... 8 3.2 LIMIT OF DISTURBANCE VOLTAGE AT THE MAINS TERMINALS........................................................................................... 8 3.3 EUT SETUP............................................................................................................................................................... 8 3.4 INSTRUMENT SETUP.................................................................................................................................................... 9 3.5 TEST PROCEDURE...................................................................................................................................................... 9 3.6 SUMMARY OF TEST RESULTS....................................................................................................................................... 9 3.7 DISTURBANCE VOLTAGE TEST DATA............................................................................................................................. 9 3.8 TEST RESULT............................................................................................................................................................. 9 4 - RADIATED DISTURBANCES ................................................................................................................. 12 4.1 MEASUREMENT UNCERTAINTY.................................................................................................................................... 12 4.2 LIMIT OF RADIATED DISTURBANCES............................................................................................................................ 12 4.3 EUT SETUP............................................................................................................................................................. 12 4.4 TEST RECEIVER SETUP............................................................................................................................................. 13 4.5 TEST PROCEDURE.................................................................................................................................................... 13 4.6 CORRECTED AMPLITUDE & MARGIN CALCULATION....................................................................................................... 13 4.7 RADIATED EMISSIONS TEST RESULT........................................................................................................................... 14 4.8 TEST RESULT........................................................................................................................................................... 14 Report No.: TH10IR-010E Page 3 of 16 FCC ID: YRV-ATY-FR01R 1 - G…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS Conducted Emission Radiated Emission
