YU8HTPCNB-01-HDMIHome Theater Personal Computer

【Directory】 【SAFETY PRECAUTIONS】 ............................................................................ 1 ELECTRONIC WARNINGS ..................................................................................... 1 OPERATIONAL NOTICE ......................................................................................... 1 NOTICE FOR THE USA FCC PART 15 ................................................................. 2 【IMPORTANT USAGE INFORMATION】 ..................................................... 3 【POSITION LAYOUT】 ..................................................................................... 4 【PRODUCT APPEARANCE INTRODUCTION】 ......................................... 5 FRONT PANEL ...................................................................................................... 5 【PRODUCT APPEARANCE INTRODUCTION】 ......................................... 6 BACK PANEL ........................................................................................................ 6 【PC PERIPHERALS CONNECTION】 ........................................................... 7 DISPLAY SETUP ................................................................................................... 7 INPUT PERIPHERALS SETUP ............................................................................... 7 LAN NETWORK CONNECTION ............................................................................. 8 POWER SWITCH ON ............................................................................................ 8 【SYSTEM CONFIGURATION】 ...................................................................... 9 WIRELESS NETWORK SETUP .............................................................................. 9 LAN SETUP ....................................................................................................... 10 SETTING FIXED IP ........................................................................................ 10 AUTOMATIC IP ADDRESS ............................................................................... 11 【SYSTEM RECOVERY】 ................................................................................ 13 【DRIVER INSTALLATION INSTRUCTIONS】 .......................................... 14 - 1 - 【Safety Precautions】 Electronic Warnings To avoid electronic shock or damage, please disconnect chargers from power source In case of power failure, please contact dealer or technical services for help and user must not try to fix the problem by self Operational notice Working temperature 35°C Please read user manual and all product information carefully before use Please make sure the power connect is correct before use. If significant product fault is found please do not hesitate to contact dealer. Please keep the device away from dust as dust, wet and violent vibration may cause damage or shorten use life Do not place the device at where unstable or vibrant For any technical issues in use, please contact qualified or experienced technician - 2 - Notice for the USA FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that my cause undesired operation. CAUTION: 1）To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device is comply with Class B limits. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may results in interference to radio or reception. 2）To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation disatance of 20 cm or more should be maintained between the antenna of this device and persons during operation. To ensure compliance, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter. MODIFICATION: Any changes or modifications not expressly approved by the grantee of this device could void the user‟s authority to operate the device. - 3 - 【Important Usage Information】 ·in order to avoid system damage or body hurt, Please read the instruction and notice carefully before use. ·Please check the device and all its accessories before first use, if any product fault is found please contact dealer for replacement as soon as possible. ·Please keep the device away from dust, heat and direct solar radiation ·Please keep the use environment dry. Water, moisture or mineral liquid may cause erodent damage. ·When using the device, please make sure the surroundings scatter heat radiation effectively. ·Please check though connection to every accessory is correct before power on. ·In order to avoid short circuit and fault connections, please keep the device and output connectors away from paper scrap, screw or any small object. ·In order to avoid short circuit and circuit damage, please DO NOT insert anything to the device…

Text truncated - open the document above for the full version.

External Photos of NB-01-HDMI

Internal Photos of NB-01-HDMI

Report Number: 68.760.10.208.01 Page 1 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 EMC TEST REPORT Report Number : 68.760.10.208.01 Date of Issue: 15 October 2010 Model : NB-01-HDMI Product Type : Home Theater Personal Computer Applicant : Smarty(HZ) Information Electronics Co., Ltd. Address : Yonghua Industrial District, Huishen Road, Zhenlong Town, Huizhou City, Guangdong, P. R. China 516227 Production Facility : Smarty(HZ) Information Electronics Co., Ltd. Address : Yonghua Industrial District, Huishen Road, Zhenlong Town, Huizhou City, Guangdong, P. R. China 516227 Test Result :  Positive  Negative Total pages including Appendices : 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. Jiangsu TÜV Product Service Ltd. – Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. Jiangsu TÜV Product Service Ltd. – Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from Jiangsu TÜV Product Service Ltd. – Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 68.760.10.208.01 Page 2 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 1 Table of Contents 1 Table of Contents............................................................................................ 2 2 Details about the Test Laboratory..................................................................... 3 3 Description of the Equipment Under Test........................................................... 4 4 Summary of Test Standards............................................................................ 5 5 Summary of Test Results................................................................................ 6 6 General Remarks.......................................................................................... 7 7 Technical Requirements.............................................................................. 8 7.1 Conducted Emission AC Power Port........................................................ 8 7.2 Radiated emissions............................................................................ 11 8 System Measurement Uncertainty................................................................... 18 Report Number: 68.760.10.208.01 Page 3 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 2 Details about the Test Laboratory Details about the Test Laboratory Company name: Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6th Floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District 518048, Shenzhen,P.R.C. Telephone: 86 755 8828 6998 Fax: 86 755 8828 5299 Company name: Audix Technology (shenzhen) Co.,Ltd Block Shenzhen, Science & Industry Park, Nantou, Shenzhen, Guangdong, China Telephone: 86 755 2663 9496 Fax: 86 755 2663 2877 Company name: SOLID Industrial (SHENZHEN) Co., Ltd. 333 Bulong Highway BUJI, Long Gang, Shenzhen, China Telephone: 86 755 8471 1789 Fax: 86 755 8471 1909 Report Number: 68.760.10.208.01 Page 4 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 3 Description of the Equipment Under Test Description of the Equipment Under Test Product: Home Theater Personal Computer Model no.: NB-01-HDMI Options and accessories: NIL Rating: DC 12V, 25W Test with adaptor: Input: AC 100-240V, 50/60Hz, 0.8A Output: DC 12V, 2.5A Description of the EUT: NIL Auxiliary Equipment and Cable Used during Test: DESCRIPTION MANUFACTURER MODEL NO.(SHIELD) S/N(LENGTH) LCD monitor Hisense HS-10023 36766-083-01 Keyboard Dell SK-115 CN-OJ4633 Mouse Dell OC8649 535000440 LCD monitor DELL 1907FPt 7735430660P0G WD-04 Keyboard DELL SK-8115 E145614 Mouse Lenovo MO32B0 4469064 Headphone AIWA HP-MO34 ---- SD card Kingston SD4/4GBFE ---- USB Flash drive Kingston USB/4G ---- USB Flash drive Kingston USB/2G ---- VGA cable Lenovo Unshield 100cm AC Power cable Lenovo Unshield 180cm Report Number: 68.760.10.208.01 Page 5 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 4 Summary of Test Standards Test Standards FCC Part 15 Subpart B PART 15 - RADIO FREQUENCY DEVICES Subpart B - Unintentional Radiators Report Number: 68.760.10.208.01 Page 6 of 18 Jiangsu TÜV Product Service Ltd. – Shenzhen Branch 6 floor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen 518048, P. R. China, Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 5 Summary of Test Results Technical Requirements …

Text truncated - open the document above for the full version.

Page 1 of 2 Test setup photos of NB-01-HDMI 1. Conducted Emission Test setup Front side Rear Side Page 2 of 2 2. Radiated Emission Test Below 1GHz Above 1GHz
