YVR-DC-W50Wireless Docking

DC-W50 Wireless Docking [Important] User Manual - English To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.Mylumens.com/support.php English - 1 Table of Contents Copyright Information ....................................................................................... 2 Chapter 1 Safety Instructions .......................................................................... 3  Precautions .................................................................................................. 4  FCC Statement ............................................................................................. 4  EN55022 (CE Radiation) Warning ............................................................... 5 Chapter 2 Package Contents ............................................................................ 6 Chapter 3 Product Overview ............................................................................ 7 3.1 DC-W50 .............................................................................................. 7 3.2 Lock USB Connector Holder .............................................................. 8 Chapter 4 Description of LED indicator .......................................................... 9 Chapter 5 Installation and Connections ....................................................... 10 5.1 Installation flow chart ........................................................................ 10 5.2 Installing Application Software .......................................................... 11 5.3 Install DC125 .................................................................................... 12 Chapter 6 Start Using ...................................................................................... 13 6.2 Start wireless connection .................................................................. 14 6.2.1 Manual connection ........................................................................... 15 6.2.2 WPS connection ............................................................................... 15 6.2.3 Change the SSID ............................................................................. 15 6.3 Change the setting of firewall ........................................................... 16 6.3.1 Windows XP ..................................................................................... 16 6.3.2 Windows 7 ........................................................................................ 16 6.3.3 Windows 8 ........................................................................................ 17 6.3.4 MAC OS X 10.7 / 10.8 / 10.9 ............................................................ 18 Chapter 7 Administration Menu ..................................................................... 20 7.1 Wireless ............................................................................................ 20 7.1.1 Basic ................................................................................................. 20 7.2 System .............................................................................................. 21 Chapter 8 Set DC-W50 for AP use ................................................................. 24 8.1 Connection diagram ......................................................................... 24 8.2 Equipment requirements .................................................................. 24 8.3 DC-W50 setup .................................................................................. 24 Chapter 9 Troubleshooting............................................................................. 27 English - 2 Copyright Information Copyrights © Lumens Digital Optics Inc. All rights reserved. Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. The information in this file is subject to change without prior notice. To fully explain or describe how this product should be used, this manual may refer to names of other products or companies without any intention of infringement. Disclaimer of warranties: Lumens Digital Optics Inc. is neither responsible for any possible technological, editorial errors or omissions, nor responsible for any incidental or related damages arising from providing this file, using, or operating this product. English - 3 Chapter 1 Safety Instructions Please use the product following the safety instructions below: 1. Operation 1.1 Please use the product in the recommended operating environment. 1.2 Do not place Light Engine in tilted position. 1.3 Do not place the product on an unstable trolley, stand or table. 1.4 Do not use this product near water or source of heat. 1.5 Use attachments only as recommended. 1.6 Use the type of power source indicated on this Product. If you are not sure of the type of power available, consult your dealer or local electricity company for advice. 1.7 Always take the following precautions when handling the plug. Failure to do so may result in sparks or fire.  Ensure the plug is free of dust before inserting it into a socket.  Ensure that the plug is inserted into the socket securely. 1.8 Do not overload wall sockets, extension cords or multi-way plug boards to avoid potential risks. 1.9 Do not block slots and openings in the case of this product as poor ventilation may lead to overheating of this product. 1.10 Except as specifically instructed in this User Manual, do not attempt to open or remove covers by yourself. It may expose you to electric shock or other hazards. Refer all servicing to licensed service personn…

Text truncated - open the document above for the full version.

Project No.: 1412005 Page 2 of 21 Project No.: 1412005 Page 3 of 21 Project No.: 1412005 Page 4 of 21 Project No.: 1412005 Page 5 of 21 Project No.: 1412005 Page 6 of 21

Project No.: 1412005 Page 7 of 21 Project No.: 1412005 Page 8 of 21 Project No.: 1412005 Page 9 of 21 Project No.: 1412005 Page 10 of 21 Project No.: 1412005 Page 11 of 21 Project No.: 1412005 Page 12 of 21 Project No.: 1412005 Page 13 of 21 Project No.: 1412005 Page 14 of 21 Project No.: 1412005 Page 15 of 21 Project No.: 1412005 Page 16 of 21 Project No.: 1412005 Page 17 of 21 Project No.: 1412005 Page 18 of 21 Project No.: 1412005 Page 19 of 21 Project No.: 1412005 Page 20 of 21 Project No.: 1412005 Page 21 of 21

FCC RF EXPOSURE REPORT FCC ID: YVR-DC-W50 Project No. : 1412005 Equipment : Wireless Docking Model : DC-W50 Applicant : Lumens Digital Optics Inc. Address : 5F,No.35,Sintai Rd.,Jhubei City,Hsinchu County 302,Taiwan According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULA TION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the a ntenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna 2.4G Ant. Brand Model Name Antenna TypeConnector Gain(dBi) Note 1 RainSun AN14-000024-W Internal N/A 5.00 TX/RX 5G Ant. Brand Model Name Antenna TypeConnector Gain(dBi) Note 2 RainSun AN14-000024-B Internal N/A 0 TX/RX TEST RESULTS 2.4G EUT： Wireless Docking Model Name : DC-W50 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5 3.1623 17.36 54.4503 0.034272861 Complies 5 3.1623 19.56 90.3649 0.056878791 Complies 5 3.1623 19.65 92.2571 0.058069811 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5 3.1623 21.41 138.3566 0.087086411 Complies 5 3.1623 21.44 139.3157 0.087690061 Complies 5 3.1623 21.48 140.6048 0.088501451 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5 3.1623 21.37 137.0882 0.086287991 Complies 5 3.1623 21.46 139.9587 0.088094821 Complies 5 3.1623 21.42 138.6756 0.087287161 Complies Band 1 EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX A MODE /CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 20.67 116.6810 0.023224711 Complies 0 1.0000 20.63 115.6112 0.023011791 Complies 0 1.0000 20.56 113.7627 0.022643861 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 20.77 119.3988 0.023765691 Complies 0 1.0000 20.75 118.8502 0.023656491 Complies 0 1.0000 20.62 115.3453 0.022958861 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE_Total /CH38, CH46 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 20.71 117.7606 0.023439611 Complies 0 1.0000 21.03 126.7652 0.025231921 Complies Band 4 EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX A MODE /CH149, CH157, CH165 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 21.02 126.4736 0.025173891 Complies 0 1.0000 20.83 121.0598 0.024096301 Complies 0 1.0000 20.7 117.4898 0.023385701 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH149, CH157, CH165 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 20.86 121.8990 0.024263331 Complies 0 1.0000 20.84 121.3389 0.024151851 Complies 0 1.0000 20.78 119.6741 0.023820471 Complies EUT： Wireless Docking Model Name : DC-W50 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH151, CH159 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 19.91 97.9490 0.019496221 Complies 0 1.0000 21.21 132.1296 0.026299671 Complies Note: the calculated distance is 20 cm.

Report No.: BTL-FCCP-2-1412005 Page 1 of 15 0 FCC Radio Test Report FCC ID: YVR-DC-W50 This report concerns (check one): Original Grant Class II Change Project No. : 1412005 Equipment : Wireless Docking Model Name : DC-W50 Applicant : Lumens Digital Optics Inc. Address : 5F,No.35,Sintai Rd.,Jhubei City,Hsinchu County 302,Taiwan Date of Receipt : Dec. 11, 2014 Date of Test : Dec. 11, 2014 ~Jan. 13, 2015 Issued Date : Jan. 14, 2015 Tested by : BTL Inc. Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) BTL INC. B1, No.37, Lane 365, Yang Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Report No.: BTL-FCCP-2-1412005 Page 2 of 150 Declaration BTLrepresents to the client that testing is done in accordance with standard proc edures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTLshall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTLissued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-2-1412005 Page 3 of 150 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9K TO 30MHz) 20 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz) 20 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 20 5 . 26dB SPECTRUM BANDWIDTH 21 5.1 APPLIED PROCEDURES / LIMIT 21 5.1.1 TEST PROCEDURE 21 5.1.2 DEVIATION FROM STANDARD 21 5.1.3 TEST SETUP 21 5.1.4 EUT OPERATION CONDITIONS 21 5.1.5 EUT TEST CONDITIONS 22 5.1.6 TEST RESULTS 22 6 . MAXIMUM CONDUCTED OUTPUT POWER 23 Report No.: BTL-FCCP-2-1412005 Page 4 of 150 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 23 6.1.1 TEST PROCEDURE 23 6.1.2 DEVIATION FROM STANDARD 24 6.1.3 TEST SETUP 24 6.1.4 EUT OPERATION CONDITIONS 24 6.1.5 EUT TEST CONDITIONS 24 6.1.6 TEST RESULTS 24 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 25 7.1 APPLIED PROCEDURES / LIMIT 25 7.1.1 TEST PROCEDURE 25 7.1.2 DEVIATION FROM STANDARD 25 7.1.3 TEST SETUP 25 7.1.4 EUT OPERATION CONDITIONS 25 7.1.5 EUT TEST CONDITIONS 25 7.1.6 TEST RESULTS 25 8 . POWER SPECTRAL DENSITY TEST 26 8.1 APPLIED PROCEDURES / LIMIT 26 8.1.1 TEST PROCEDURE 26 8.1.1 DEVIATION FROM STANDARD 27 8.1.2 TEST SETUP 27 8.1.3 EUT OPERATION CONDITIONS 27 8.1.4 EUT TEST CONDITIONS 27 8.1.5 TEST RESULTS 27 9 . FREQUENCY STABILITY MEASUREMENT 28 9.1 APPLIED PROCEDURES / LIMIT 28 9.1.1 TEST PROCEDURE 28 9.1.2 DEVIATION FROM STANDARD 28 9.1.3 TEST SETUP 29 9.1.4 EUT OPERATION CONDITIONS 29 9.1.5 EUT TEST CONDITIONS 29 9.1.6 TEST RESULTS 29 10 . MEASUREMENT INSTRUMENTS LIST 30 11 . EUT TEST PHOTOS 32 ATTACHMENT A - CONDUCTED EMISSION 36 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 39 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 41 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 44 ATTACHMENT E - BANDWIDTH 112 Report No.: BTL-FCCP-2-1412005 Page 5 of 150 Table of Contents Page ATTACHMENT F - MAXIMUM OUTPUT POWER 125 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 128 ATTACHMENT H - POWER SPECTRAL DENSITY 135 ATTACHMENT I - FREQUENCY STABILITY 148 Report No.: BTL-FCCP-2-1412005 Page 6 of 150 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-2- 1412005 Original Issue. Jan. 14, 2015 Report No.: BTL-FCCP-2-1412005 Page 7 of 150 1. CERTIFICATION Equipment : Wireless Docking Brand Name : Lumens Model Name : DC-W50 Applicant : Lumens Digital Optics Inc. Date of Test : Dec. 11, 2014 ~Jan. 13, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.4: 2009 FCC KDB 789033 D02 General UNII Test Procedures New Rules v01. The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-2- 1412005) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-2-1412005 Page 8 of 150 2. SUMMARY OF TEST RESULTS Test …

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1412005 Page 26 of 103 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1412005 Page 27 of 103 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1412005 Page 28 of 103 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-1-1412005 Page 29 of 103 Radiated Measurement Photos Above 1000MHz
