YW5-JH201011617VMID

Shenzhen Firstview Electronic Co. Ltd.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Nov 18, 2010
Application Purpose: Original Equipment
Date of Application: Nov 18, 2010
Equipment Note: MID
Company: Shenzhen Firstview Electronic Co. Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MID User Guide 1 Table of Contents Table of Contents............................................................................................................................1 1. Outlook Description....................................................................................................................3 2. Getting Started Guide.................................................................................................................4 2.1 Battery Charging .................................................................................................................4 2.2 How to use Memory Card ...................................................................................................4 2.3 How to use U disk ...............................................................................................................5 2.4 Remove and insert memory card and U disk ......................................................................6 2.5 Storage Space ......................................................................................................................6 2.6 Power On and Off ...............................................................................................................6 2.7 Vibrate .................................................................................................................................6 2.8 Interface rotation .................................................................................................................6 2.9 External Network Cable and U Disk...................................................................................6 2.10 Connecting to the Internet .................................................................................................7 2.11 USB connection ................................................................................................................7 3. Input Operation..........................................................................................................................8 3.1 Keyboard .............................................................................................................................8 3.2 Touch Screen .......................................................................................................................8 4. Desktop.........................................................................................................................................9 4.1 Status Bar ............................................................................................................................9 4.2 Shortcuts .............................................................................................................................9 4.3 Current Desktop Lamp ........................................................................................................9 4.4 Add To The Screen ..............................................................................................................9 5. Web Browsing........................................................................................................................... 11 6. Application Management.........................................................................................................12 6.1 Install and Uninstall ..........................................................................................................12 6.2 App Market .......................................................................................................................14 7. Typical Applications Introduced.............................................................................................16 7.1 Chat Tools .........................................................................................................................16 7.2 E-mail................................................................................................................................16 7.3 File Browser ......................................................................................................................17 7.4 My Photo...........................................................................................................................18 7.5 My Video...........................................................................................................................22 7.6 YouTube ............................................................................................................................23 7.7 Magic Album.....................................................................................................................23 7.8 My Music ..........................................................................................................................24 7.9 Camera ..............................................................................................................................26 7.10 Camcorder .......................................................................................................................27 8. Tips and Tricks.........................................................................................................................28 8.1 Some convenient mode of operation .................................................................................28 MID User Guide 2 8.2 Convenient Set ..................................................................................................................28 8.3 Battery Tips .......................................................................................................................30 9. Personalized settings.................................................................................................................31 9.1 Wireless controls ...............................................................................................................31 9.2 Ppoe settings .............................................................…

Text truncated - open the document above for the full version.

Block Diagram

CPU VT8505 LCD PANEL Main clock 27MHz RTC clock 32.768KHz EDS Close CS7146AEF USB HUB GL850G-HHG WI-FI Camera USB1 USB2 Ethernet PHY VT6113 NS0013LF Etherne (RJ45) G-Sensor MMA7660FC ITE6333-33 Shake ITE5121 NAND TF CARD DDR SPI FLASH EN25F40 AMP EUA2036 Codec WM8900 MIC SPAKERHead phone EN RTC clock 12MHz CPU VT-8505 Battery charger DC Switch 5V-VCCMEM1.8V 700mA ITE8160A-ADJ VIN-5VIN.1.5A ITE8410 5V-VDD 1.6V 700MA 5V-3.3V 700MA ITE8160A-ADJ 5V-1P5VSUS 10mA ITE6322-15 Battery LED AM 9V DC INPUT 1.5A Power DCandBattery Voltage Regulators VIN-VCCBAT 3.3V 10uA ITE6322-15 5V EN DC IN_DT CPU VT-8505 Battery charger DC Switch 5V-VCCMEM1.8V 700mA ITE8160A-ADJ VIN-5VIN.1.5A ITE8410 5V-VDD 1.6V 700MA 5V-3.3V 700MA ITE8160A-ADJ 5V-1P5VSUS 10mA ITE6322-15 Battery LED AM 9V DC INPUT 1.5A Power DCandBattery Voltage Regulators VIN-VCCBAT 3.3V 10uA ITE6322-15 5V EN DC IN_DT

Cover Letter(s)

2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Shenzhen Firstview Electronic Co. Ltd. 2010-11-04 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Firstview Electronic Co. Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description: MID Model name: PC617) We affirm that between SIEMIC and Shenzhen Firstview Electronic Co. Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Qu Yang / Manager Title: Manager Telephone: +086-755-29081735 Email: [email protected] Date: November 04, 2010 Name / title: Qu Yang / Manager

External Photos

ID Label/Location Info

FCC ID Label Sample for Model PC617 FCC ID: YW5-JH201011617V This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ID Label/Location Info

Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 22 of 22 7. FCC ID LABEL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed Label Location on EUT EUT Bottom View/proposed FCC Mark Location FCC ID: YW5-JH201011617V This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 16 of 22 Photo 5 Front View of PCB (Main Board) Photo 6 Back View of PCB (Main Board) Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 17 of 22 Photo 7 Front View of PCB (Camera) Photo 8 Back View of PCB (Camera) Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 18 of 22 Photo 9 Front View of PCB (External Interface Adapter) Photo 10 Back View of PCB (External Interface Adapter) Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 20 of 22 Photo 13 Front View of PCB (Adapter) Photo 14 Back View of PCB (Adapter)

Operational Description

WM8505 System Overview The wm8505Application processor is the SoC solution with superior networks and display capabilities that specially tailored for cost-effective embedded multimedia devices.The WM8505 supports display resolution up to 1024x600 and 10/100 Ethernet MAC.The WM8505 is a low power consumption SoC solution that demands 1.8V for DDR2 SDRAM,and 3.3V for other interfaces as operating power.the WM8505 integrates multimedia features and functionalities,e.g. decoding popular audio/video streams,2D graphics display,and peripheral I/Os that are aiming to meet upcoming market demands as well as reduce customer’s total BOM cost.the WM8505 is designed to deliver the state-of-the-art performance for applications such as Networked projector,Digital Signage,and Thin-Client Terminal. The WM8505 Application processor integrates all popular peripherals in an efficiently architected RISC (reduced instruction set computer)platform.Figure 1 illustrates the system block diagram of Wonder Media’s WM8505 Application processor. Figure 2 illustrates the software architecture of the WM8505 Application processor.The WM8505 supports Linux and windows CE for embedded systems.WonderMedia provides the software package that includes device drivers for multimedia ,peripheral ,and security-related devices as well as multimedia poayer with high audio,video,and image quality, The software architecture of WM8505 can easily collaborate with the 3 rd party software packages to provide versatile applications.

Schematics

55 44 33 22 11 D D C C B B A A close to WM8505_IOB Battery low detect circuit GPIO_0GPIO_1GPIO_2GPIO_3GPIO_4GPIO_5GPIO_6GPIO_7SPI0MOSISPI0SS-SPI0MISO DCIN_DTTOUCH_INTCharger_STATSensor_INTMuteGPIOMOTOR_SHAKEWifi_POWER_DN SPI0CLK CAMERA_POWER_DN PWRGD USB_ATTACH I2C0SDAI2C0SCL PWMOUT0 BAT_LOWMIIMDIOMIIRXD1MIIMDC UART0TXDUART0RXD MIITXCLK SPI0MISO MIIRXD3 SPI0CLK MIIRXD0 SDCLKSDDATA1SDCMDSDDATA2SDDATA3 SPI0MOSI I2S_LRCLKI2S_MCLKI2S_SDII2S_SCLKI2S_SDO SDWP PWRGD SDCDT VDOUT18 LCD_R2 VDOUT02 LCD_B2 SDDATA0 VDOUT21 LCD_R5 VDOUT12 LCD_G4 VDOUT13 LCD_G5 VDOUT14 LCD_G6 VDOUT15 LCD_G7 VDOUT22 LCD_R6 MIIRXERR VDOUT10 LCD_G2 VDOUT11 LCD_G3 VDOUT19 LCD_R3 VDOUT20 LCD_R4 SPI0SS- VDDEN MIITXD3MIITXD0PHY25MHZ VDCLK MIIRXDVMIITXD1KPAD_ROW2 VDOUT23 LCD_R7 USBH2- VDOUT06 LCD_B6 VDOUT07 LCD_B7 VDOUT04 LCD_B4 VDOUT05 LCD_B5 VDOUT03 LCD_B3 USBD0+USBD0-USBH1-MIIPHYPD-MIIPHYRST-USB_ATTACHUSBH1+MIIRXCLKMIICOLMIITXENUSBH2+MIIRXD2KPAD_ROW0 GPIO0GPIO1GPIO2 MIICRSKPAD_ROW1 GPIO6GPIO5 MIITXD2 USB_VBUS BAT_LOW GPIO7 GPIO3GPIO4 KPAD_COL1KPAD_COL0 SPI0MOSISPI0MISOSPI0SS-SPI0CLK 3P3V VDD VCCMEM 3P3V 1P5VSUS 3P3VSUS VCCBAT 3P3VSUS VPACK+ 3P3V KPAD_ROW0 11 KPAD_ROW1 11 LCD_BL_DIM 9 MIIMDIO 8 MIIRXD1 8 SPI0CLK 9 MIIMDC 8 UART0TXD 6 UART0RXD 6 DCIN_DT 3 MIITXCLK 8 SPI0MISO 9 MIIRXD3 8 MIIRXD0 8 SDCLK 5 SDDATA1 5 PWREN33 3,4,9,10 PWREN18 3,4 PWRBTN- 3 PWREN15 4 SDCMD 5 SDDATA2 5 SDDATA3 5 SPI0MOSI 9 I2S_MCLK 10 I2S_LRCLK 10 I2S_SDI 10 I2S_SCLK 10 I2S_SDO 10 SDWP 5 SDCDT 5 LCD_R2 9 LCD_B2 9 SDDATA0 5 Charger_STAT 3 LCD_R5 9 LCD_G2 9 LCD_G3 9 LCD_G4 9 LCD_G5 9 LCD_G6 9 LCD_G7 9 LCD_R6 9 MIIRXERR 8 LCD_R3 9 LCD_R4 9 VDDEN 9 MIITXD3 8 MIITXD0 8 PHY25MHZ 8 VDCLK 9 MIIRXDV 8 MIITXD1 8 LCD_R7 9 USBH2- 6 LCD_B6 9 LCD_B7 9 LCD_B4 9 LCD_B5 9 LCD_B3 9 USBD0- 6 USBD0+ 6 MIIPHYRST- 8 MIIPHYPD- 8 USBH1- 7 USBH1+ 7 MIIRXCLK 8 MIICOL 8 MIITXEN 8 Sensor_INT 11 TOUCH_INT 9 SPI0SS- 9 USBH2+ 6 MIIRXD2 8 I2C0SDA 10,11 MIICRS 8 I2C0SCL 10,11 MIITXD2 8 USB_VBUS 6 KPAD_ROW2 11 Wifi_POWER_DN 7 Charger_STAT 3 CAMERA_POWER_DN 7 MOTOR_SHAKE 11MuteGPIO 10 KPAD_COL1 11 KPAD_COL0 11 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc.WMS8105C1 1.0 CPU SOCKET Custom 212 Friday, October 22, 2010 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc.WMS8105C1 1.0 CPU SOCKET Custom 212 Friday, October 22, 2010 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc.WMS8105C1 1.0 CPU SOCKET Custom 212 Friday, October 22, 2010 U26BL8509-600DNRM/XU26BL8509-600DNRM/X VCC 3 GND 1 RESET 2 R4 10K R4 10K U22S-80860CNNB-B9LT2GU22S-80860CNNB-B9LT2G OUT 1 VDD 2 NC 3 VSS 4 R6 10K R6 10K R5 10K R5 10K C1314.7uFC1314.7uF R310KR310K R17230K_1%R17230K_1% R25.6KR25.6K C11uFC11uF C158 0.1uF C158 0.1uF R13 10K R13 10K R173330K_1%R173330K_1% R110KR110K U1 VT8505_IOB U1 VT8505_IOB UART0RXD 1 UART0TXD 2 I2C0SCL 3 I2C0SDA 4 AC97RST 5 AC97SYNC 6 AC97BCLK 7 AC97SDO 8 AC97SDI 9 GPIO3 10 GND 11 GPIO4 12 GPIO2 14 GPIO1 15 LCD_BL_DIM 16 PANEL_SCL 17 PANEL_SDA 18 PANEL_CSB 19 GND 20 PWRBTN- 21 GND 22 PWREN33 23 3P3V 24 3P3V 25 GND 26 PWREN15 27 VDD 28 VDD 29 GND 30 GND 31 PWREN18 32 VCCMEM 33 PWRGD 34 GND 35 USB_ATTACH 36 USBD0+ 37 USBD0- 38 GND 39 USBH2- 40 USBH2+ 41 GND 42 USBH1+ 43 USBH1- 44 GND 45 MIIRXD2 46 MIICRS 47 MIITXD2 48 MIIRXD1 49 PHY25MHZ 50 MIIRXERR 51 MIITXD3 52 MIIRXDV 53 MIIMDIO 54 MIIMDC 55 MIITXCLK 56 MIIRXD3 57 MIIRXD0 58 MIIRXCLK 59 MIITXD0 60 MIITXD1 61 MIICOL 62 MIITXEN 63 MIIPHYPD- 64 MIIPHYRST- 65 1P5VSUS 66 KBDT 67 MSDT 68 MSCK 69 KBCK 70 3P3VSUS 71 VCCBAT 72 LCD_R5 73 LCD_R4 74 LCD_R3 75 LCD_R2 76 LCD_R1 77 LCD_G0 78 LCD_G1 79 LCD_G2 80 LCD_G3 81 LCD_G4 82 LCD_G5 83 VDCLK 84 LCD_B5 85 LCD_B4 86 LCD_B3 87 LCD_B2 88 LCD_B1 89 VDDEN 90 SDDATA2 91 SDDATA3 92 SDCMD 93 SDDATA1 94 SDCLK 95 SDDATA0 96 SDCDT 97 SDWP 98 GPIO0 13 LCD_R0 99 LCD_B0 100 SPI0MISO 101 GPIO5 102 GPIO6 103 GPIO7 104 KPAD_ROW0 105 KPAD_ROW1 106 KPAD_ROW2 107 KPAD_COL0 108 KPAD_COL1 109 KPAD_COL2 110 WAKE_UP 111 C20.1uFC20.1uF R174100KR174100K 55 44 33 22 11 D D C C B B A A DC and Battery Battery charger 2-Cell 9V DC Input 1.5A Power button DC Switch Power Button 5V 3P3VSUS PWRBTN- R/C delay ~ 100ms RSMRST-PWRBTN-PWREN18 10 mil SATA2 SATA2 SATA1 DCIN_DT ISET1 SNS ISET1 VPACK+ SATA1 SNS VPACK+ VDCIN VDCIN VIN VDCIN 3P3V 3P3VSUS 3P3VSUS 3P3V VIN VDCIN VPACK+ VDCIN PWRBTN- 2 5V_EN 4 PWREN18 2,4 DCIN_DT 2 POWER_BT 11 Charger_STAT 2 SATA1 11 PWREN33 2,4,9,10 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc. WMS8105C1 1.0 DC and Battery Custom 312 Friday, October 22, 2010 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc. WMS8105C1 1.0 DC and Battery Custom 312 Friday, October 22, 2010 TitleSize Document Number Rev Date: Sheet of WonderMedia Technologies, Inc. WMS8105C1 1.0 DC and Battery Custom 312 Friday, October 22, 2010 R162 0.1_1% R162 0.1_1% R28100KR28100K C1550.1uFC1550.1uF R29 10K R29 10K C12 0.1uF C12 0.1uF U19 HB6298A_TSSOP20 U19 HB6298A_TSSOP20 VIN1 3 VIN2 4 NC 6 STAT1 2 OUT 19 VCC 5 SLEEP 7 ISET2 16 GND 10 BAT 11 SNS 12 TS 9 TTC 8 VTSB 14 VTRIM 15 ISET1 17 OUT 18 STAT2 1 CELL 20 NC 13 R21320R21320 Q3 RK7002B Q3 RK7002B G DS R18 4.7K R18 4.7K Q15MMBT3906Q15MMBT3906 B CE R15912KR15912K C1570.1uFC1570.1uF ESD1ESD1 1 2 C1560.1uFC1560.1uF PBT-PBT- 1 R7 1K R7 1K L9 12uH L9 12uH R167 10K R167 10K R23100K/XR23100K/X VINVIN 1 C8 10uF/16V C8 10uF/16V R910KR910K R8 51K R8 51K R5515KR5515K C9 10uF/16V C9 10uF/16V C61000pFC61000pF C1600.1uFC1600.1uF R165 18K R165 18K C181000pFC181000pF C101uFC101uF R10100KR10100K D5RB520S-30D5RB520S-30 A K R1610R1610 R160 100K R160 100K C50.1uFC50.1uF R11100KR11100K R207 100 R207 100 D2RB161M-20/XD2RB161M-20/X + A - K R22 5.6K R22 5.6K + BAT1150uF/X + BAT1150uF/X 12 C19730pFC19730pF C410uF/16VC410uF/16V C70.1uFC70.1uF R2610KR2610K R12100KR12100K C421000pFC421000pF R2084.7KR2084.7K J11 DS-0528-A J11 DS-0528-A 132 4 C153 4.7uFC153 4.7uF C13 0.1uF C13 0.1uF C1540.1uFC1540.1uF D4BAT54SD4BAT54S 2 3 1 Q1APM9435KC-TRLQ1APM9435KC-TRL S 1 S 2 S 3 G 4 D 5 D 6 D 7 D 8 R…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 22 FCC TEST REPORT For MID Model Number: PC617 FCC ID : YW5-JH201011617V Reference No. : CT10102426-S-F Applicant : Shenzhen Firstview Electronic Co. Ltd. Address : 3-4/F, Block B, Huafeng 1st Technology ZoneBaoan Main Road, Baoan District, Shenzhen, China Prepared By : Shenzhen CCE Test Electronic Co., Ltd. Address : 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Telephone : +86-755-33128901 Date of Test : November 01, 2010 Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 2 of 22 CONTENTS 1. TEST SUMMARY.................................................................................................................3 2. TEST LABORATORY AND FACILITY INFROMATION................................................4 2.1. Test Location................................................................................................................4 3. GENERAL INFORMATION................................................................................................5 3.1. EUT Description...........................................................................................................5 3.2. Block Diagram of EUT Configuration...........................................................................5 3.3. Test Conditions.............................................................................................................5 3.4. Standards Applicable for Testing...................................................................................5 4. TEST EQUIPMENT USED...................................................................................................6 5. CONDUCTED EMISSION TEST.........................................................................................7 5.1. Test Standard and Limit................................................................................................7 5.2. Test Procedure..............................................................................................................7 5.3. Test Setup.....................................................................................................................7 5.4. Test Data......................................................................................................................8 6. RADIATED EMISSION TEST...........................................................................................10 6.1. Test Standard and Limit..............................................................................................10 6.2. Test Procedure............................................................................................................10 6.3. Test Setup...................................................................................................................10 6.4. Measurement Uncertainty............................................................................................11 6.5. Spectrum Analyzer Setup............................................................................................11 6.6. Test Data....................................................................................................................12 APPENDIX: EUT PHOTOS AND TEST SETUP PHOTOS.........................................................14 7. FCC ID LABEL....................................................................................................................22 Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 3 of 22 1. TEST SUMMARY Test Items Test Requirement Test Method Test Results Conducted Emission (150KHz to 30MHz) FCC PART 15.107 ANSI C63.4: 2009 PASS Radiated Emission (30MHz to 1GHz) FCC PART 15.109 ANSI C63.4: 2009 PASS Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 4 of 22 2. TEST LABORATORY AND FACILITY INFROMATION The test facility is recognized, certified, or accredited by the following organizations: • FCC – Registration No.: 752051 Accurate Technology Co., Ltd. has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Registration 752051, June 02, 2008. 2.1. Test Location All Emissions tests were performed at:- Accurate Technology Co., Ltd. at F1, Bldg. A, Changyuan New Material Port, Keyuan Rd., Science & Industry Park, Nanshan, Shenzhen, 518057, China. Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.ccetest.com Page 5 of 22 3. GENERAL INFORMATION 3.1. EUT Description Product : MID Model No. : PC617 Technical Data: : Adapter Input: 100-240V AC, 0.5A,50/60Hz Adapter Output: 9V DC, 1500mA Applicant : Shenzhen Firstview Electronic Co. Ltd. Manufacturer : Shenzhen Firstview Electronic Co. Ltd. 3.2. Block Diagram of EUT Configuration 3.3. Test Conditions Temperature:23-26 °C Relative Humidity: 51-58% 3.4. Standards Applicable for Testing The customer requested FCC tests for a MID. The standards used were FCC Part 15 Subpart B. Adapter EUT External Interface USB Keyboard USB Mouse Earphone Power Supply Network Cable Shenzhen Firstview Electronic Co. Ltd. FCC ID: YW5-JH201011617V Shenzhen CCE Test Electronic Co., Ltd. 21F., COFCO Property Group Center, 3th Area of Baoan, Shenzhen, China Tel: +86-755-33128901 FAX: +86-755-86114052 Website:www.cc…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Qu Yang(manager)

[email protected]+86-755-29081735Fax: +86-755-29081715

Test Firm

Accurate Technology Co., Ltd.Sean Liu

[email protected]86-755-26503291Fax: 86-755-26503396

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15B	-	-
