YWRSTT4-HDRDigital Video Broadcasting

Receiver/Digital Decoder DVB-C Set Top Box  Installation Manual & User Manual SAFETY PRECAUTION CAUTION: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of "dangerous voltage" and to prevent from risk of electric shock. Warning: To reduce the risk of electric shock, don’t open the cover or cabinet. Refer servicing to qualified personnel only. The exclamation point within an equilateral triangle is intended to alert the user to important operating and maintenance (servicing). Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.    For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help WARNING: The STB shall not be exposed to dripping or splashing of liquids. No objects filled with liquids, such as vases, shall be placed on the STB. WARNING: Do not put a candle or lamp on the housing, as this can cause a risk of fire. WARNING: The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the unit. If you are not sure of the type of power supply to your home, consult your local dealer or power company. WARNING: Do not open the housing on this unit, as this may expose you to dangerous voltages and radiation. WARNING: The unit should be connected to a power supply only of the type descry bed in the operating instructions or as marked on the unit. If you are not sure of the type of power supply to your home, consult your local dealer or local power company. WARNING: Do not open the housing or touch any parts in the inner mechanism. Consult your local dealer for technical service if the opening is required. WARNING: The mains plug is used as the disconnect device, the disconnect device shall remain readily operable. WARNING: The battery of remote control should not be exposed excessive heat such as sunshine, fire or the like. WARNING: Maintenance personnel must use the appropriate tools and replacement parts as specified by the manufacturer. Note: Do not open the housing to avoid the unit direct exposure to radiation. Unit Cleaning:After the unit power is turned off, you can clean the housing, panel and remote control with a soft cloth lightly moistened with a mild detergent solution. Attachments: Never add any attachments and/or equipment without the manufacturer consent; as such additions may result in the risk of fire, electric shock or other personal injury. Locating: Slots and openings in the housing are provided for ventilation to protect it from overheating. Do not block these openings or allow them to be blocked by placing the STB on a bed, sofa or other similar surface, nor should it be placed over a radiator or heat register. Power Cord Protection: Place the power supply cord out of the way, where it will not be walked on. Please take special attentions to cords at plugs, convenience receptacles and the point where they exit from the unit. Object and Liquid Entry: Never put objects of any kind into this STB through openings, as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill any liquid on the STB. Note: Moisture may be formed inside the unit in the following conditions: When the unit is suddenly moved from a cold environment or an air-condition room to a warm place. Immediately after a heater has been turned on. In a steamy or very humid room. If the moisture forms inside the unit, it may not operate properly. To correct this problem, turn on the power and wait about two hours for the moisture to evaporate. Parts Replacement: When parts need to be replaced, user should make sure the service technician use the replacement parts specified by the manufacturer or having the same characteristics as the original part. Unauthorized replacement may put the unit in the risk of fire, electric shock or other hazards. Safety Check: After all the maintenances and repairs are done, user is required to request the service technician to conduct the overall safety check to ensure the machine is in the proper operating condition. Contents 1 Contents 1. Remote Control & Panel Description....................................................................3 1.1 Front Panel Description ......................................................................................... 3 1.2 Rear Panel Description.......................................................................................... 4 1.3 Remote Control Description................................................................................... 5 2. Basic Operation .....................................................................…

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test Model No.: STT4-HDR

1 Photographs - EUT Constructional Details Test Model No.: STT4-HDR

SGS-CSTC Standards Technical Services Co., Ltd. No. 1 W orkshop, M-10, Middle Section, Science & Technology Park, Nanshan District Shenzhen, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM130400170701 Page: 1 of 29 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC Test Report Application No.: SZEM1304001707AV(GZEM1304001276AV) Applicant/ Manufacturer/Factory: Sandmartin (Zhong Shan) Electronic Co., Ltd. Address of Applicant/ Manufacturer/Factory: 3rd Industrial Area Tan Zhou, Zhong Shan, Guangdong, China Equipment Under Test (EUT): EUT Name: Digital Video Broadcasting Model No.: STT4-HDR FCC ID: YWRSTT4-HDR Standards: 47 CFR PART 15, Subpart B:2012 Date of Receipt: 2013-04-11 Date of Test: 2013-05-06 to 2013-05-30 Date of Issue: 2013-06-20 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Report No.: SZEM130400170701 Page: 2 of 29 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 2 Test Summary Test Test Requirement Test Method Class / Severity Result Radiated Emission (30MHz to 1GHz) 47 CFR PART 15, Subpart B:2012 ANSI C63.4:2009 Class B PASS Conducted Emission (150kHz to 30MHz) 47 CFR PART 15, Subpart B:2012 ANSI C63.4:2009 Class B PASS Radiated Emission above 1 GHz 47 CFR PART 15, Subpart B:2012 ANSI C63.4:2009 Class B PASS Antenna Power (30 MHz to 960 MHz) 47 CFR PART 15, Subpart B:2012 Section 15.111 Class B PASS Output and Spurious conducted level at RF output terminal 47 CFR PART 15, Subpart B:2012 Section 15.115 Class B PASS Demonstration on internal preventing circuitry 47 CFR PART 15, Subpart B:2012 Section 15.115 Class B PASS SGS-CSTC Standards Technical Services Co., Ltd. Report No.: SZEM130400170701 Page: 3 of 29 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup Test Model No.: STT4-HDR 1.1 Conducted Emission 1.2 Antenna Power test setup 1.3 Radiated Emission 1.4 Output and Spurious conducted level at RF output terminal 1.5 Demonstration on internal preventing circuitry
