PT4450 PRE1.0 - 1 - August, 2007 DESCRIPTION PT4450 is a high performance ASK/OOK transmitter for the Remote Keyless Entry (RKE) systems. It consists of a SAW oscillator, power amplifier, and one-shot circuit which control the SAW oscillator and power amplifier. FEATURES • Highly integrated ASK/OOK transmitter • High output power, 3V/+10dBm/18mA • Low supply voltage (2.2V to 3.6V operation range) • Low external component cost. • SAW-based oscillator, frequency range from 250MHz to 500MHz • On-chip one-shot circuit • 50dB RF on/off ratio • Available in 6 pins, SOT-23 package APPLICATIONS • Keyless entry systems • Remote control systems • Garage door openers • Alarm systems • Security systems • Wireless sensors manual PT4450 PRE1.0 - 2 - August, 2007 BLOCK DIAGRAM Regulator One Shot PA Output matching network OSCOUTVSSPAOUT DINVDDOSCIN PT4450 PRE1.0 - 3 - August, 2007 PIN CONFIGURATION PIN DESCRIPTION Pin Name I/O Description Pin No. OSCOUT O Oscillator output 1 VSS G Ground connection 2 PAOUT O Power amplifier output 3 DIN I Data input, it will also be used to enable the chip 4 VDD P Power supply 5 OSCIN I Oscillator input 6 DIE PAD DIAGRAM PT4450 PRE1.0 - 4 - August, 2007 ABSOLUTE MAXIMUM RATINGS (V SS =0V) Parameter SymbolRating Unit Supply voltage V DD V SS -0.3 to V SS +6.0 V Operating temperature Topr -40 to +85 °C Storage temperature Tstg -65 to +150 °C Soldering temperature T SLD 255 °C Soldering time t SLD 10 Sec. RECOMMEND OPERATING CONDITIONS (V SS =0V) Rating Parameter Symbol Min. Typ. Max. Unit Supply voltage range V DD 2.2 3.0 3.6 V Operating temperature T A -40 25 85 °C PT4450 PRE1.0 - 5 - August, 2007 ELECTRICAL CHARACTERISTICS (Unless otherwise specified, V DD =3.0V, V SS =0V, DIN=3.0V. Temp=27°C, f RF =434MHz) Rating Parameter SymbolCondition Min. Typ.Max. Unit DC Supply voltage V DD 2.2 3.0 3.6 V Operating current (Note) I DD DIN=High(CW mode); P OUT =10dBm 16 - 18 mA Standby current I standby DIN=Low; T DELAY >50ms- - 1 μA RF Frequency range f RF 250 - 500MHz Power amplifier output power (Note) P out - +10 - dBm RF power on/off ratio P EXT - 50 - dB Phase noise P NOISE 10KHz offset - -100- dBc/Hz Harmonics (see Note) P HARM 2x/3x f RF - -40 - dBc Data Input and One Shot Data rate D RATE 0.5 2 50 Kbps Start up time T ON - - 200 μs One shot delay time T DELAY 50 - - ms Note: Depend on power amplifier output matching. PT4450 PRE1.0 - 6 - August, 2007 TESTING CIRCUIT Values Component 315MHz Band 434MHz Band Unit S1 (see Note) 315 434 MHz R1 0 0 Ω R2 10K 10K Ω R3 470K 470K Ω L1 180n 180n H L2 27n 27n H C1 220p 220p F C2 12p 4.7p F C3 22p 12p F C4, C5 100n 100n F Note: S1 is a SAW resonator. PT4450 PRE1.0 - 7 - August, 2007 ORDER INFORMATION Valid Part Number Package Type Top Code PT4450 (L) 6 Pins, SOT-23 PT4450 Notes: 1. (L), (C) or (S) = Lead Free 2. The Lead Free mark is put in front of the date code PT4450 PRE1.0 - 8 - August, 2007 PACKAGE INFORMATION 6 PINS, SOT-23 PT4450 PRE1.0 - 9 - August, 2007 PT4450 PRE1.0 - 10 - August, 2007 Symbol Min. Typ. Max. A - - 1.45 A1 0 - 0.15 A2 0.90 1.15 1.30 b 0.30 - 0.50 b1 0.30 0.40 0.45 c 0.08 - 0.22 c1 0.08 0.13 0.20 D 2.90 BSC. E 2.80 BSC. E1 1.60 BSC. e 0.95 BSC. e1 1.90 BSC. L 0.30 0.45 0.60 L1 0.60 REF. L2 0.25 BSC. R 0.10 - - R1 0.10 - 0.25 θ 0° 4° 8° θ1 5° 10° 15° aaa 0.15 bbb 0.20 ccc 0.10 ddd 0.20 PT4450 PRE1.0 - 11 - August, 2007 Notes: 1. Dimension and tolerancing per ASME Y14.5M-1994. 2. Dimension in Millimeters. 3. Dimension D does not include mold flash, protrusion or gate burrs. Mold flash, protrusions or gate burrs shall not exceed 0.25mm per end. Dimension E1 does not include interlead flash or protrusion. Interlead flash or protrusion shall not exceed 0.25mm per side. D and E1 dimensions are determined at datum H. 4. The package top may be smaller than the package bottom. Dimensions D and E1 are determined at the outermost extremes of the plastic body exclusive of mold flash, tie bar burrs, gate burrs and interlead flash, but including any mismatch between the top and bottom of the plastic body. D and E1 dimensions are determined at datum H. 5. Datums A & B to be determined at datum H. 6. These dimensions apply to the flat section of the lead between 0.08mm and 0.15mm from the lead tip. 7. Dimension “b” does not include dambar protrusion. Allowable dambar protrusion shall be 0.08mm total in exceed of the “b” dimension at maximum material condition. The dambar cannot be located on the lower radius of the foot. Minimum space between protrusion and an adjacent lead shall not be less than 0.07mm. 8. Details of the pin 1 identifier are optional, but must be located within the zone indicated. 9. Refer to JEDEC MO-178 Variation AB JEDEC is the trademark of JEDEC SOLID STATE TECHNOLOGY ASSOCIATION FCC NOTE : THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation

433MHz

FCC ID LABEL FCC ID: YX325190701010 This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received,including interference that may cause undesired operation. Label Location on EUT EUT Bottom View/ FCC ID Label Location

Antenna

working principle FIGURE 1 As shown in Fig.1, via an emulating SPI communication interface CON , information from the mainframe is transmitted to the encoder circuit board “Encode” at a communication speed of 122Hz. When the MCU on the encoder board identifies the starting position of the data, it outputs Manchester code in an encode format of “header code + address code + condition + check code”. the following operating mode is used: the transmitting module transmits several sets of identical data in 0.6 second, then, after 20 seconds of pause, receives data again from the mainframe and repeats the above transmitting process. Table 1 is the main characteristic parameters of the transmitting module.。 Parameter Symbol Condition Value u nit mintyp max PowerSupply Modulation input Voltage Vcc 3.3 3 12 V Outout Power Pout +10 dBm Supply current Idd 18 mA Supply voltage Range Data Rate Ddate 10 Kbps Work Ffrequency Frf 433.92 MHz Modulate ASK Operating temperature -20°C～+60°C C O N

BOM TABLE component value unit U1PT4450Na Y1 M R1 0 Ω R2 10k Ω R3 Na Ω L1 180n H L2 47n H C1 C2 6p F C3 NaF C4,C5 100n F C6 NaF 433.92 F F 6p 6P F

OSCI N 6 VDD 5 DI N 4 OSCOUT 1 VSS 2 POUT 3 PA One Shot Regulator U1 PT4450 C5 C6 C2 C1 R3 GND GND GND 12 Y1 VCC L1 L2 C3 C4 GND R1VCC E1 An t e nn a GND R2 GND
