Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15C | 2.42 GHz - 2.45 GHz | 25.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval:
Power listed is conducted. Approval is limited to OEM installation only in devices that provide a stable power supply according to the requirements of DA 00-1407. This device is to be used only for fixed applications. The antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end-user has no manual instruction to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations.
When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz.
