YYYKLEMA-675REMOTE CONTROL

REMOTE CONTROL (Default) Button Functions Conditions Press button 1 once a. Arm & lock doors b. Stop alarm trigger temporarily c. Lock/Unlock door a. ACC Off b. Sounding c. During driving/ Valet mode Press button 1 then 3 within 2 sec Arm bypassing shock sensor ACC Off Press button 1 then 2 within 2 sec Arm bypassing shock sensor and door trigger input ACC Off Press button 2 once a. Disarm & unlock doors b. Stop alarm trigger temporarily a. Armed b. Sounding Press and hold button 4 for 2 sec. Trunk release ACC Off Press and hold button 1 once for 3 sec. Car finder Armed Press and hold button 3 for 3 sec Remote panic ACC Off Press and hold button1and button 2 for 3 sec Enter anti carjacking ACC On Press button 3 then 1 within 2 sec Silent arming ACC Off Press button 3 then 2 within 2 sec Silent disarming Armed Press button 3+4 3rd Channel out put Anytime changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC ID: YYYKLEMA-675 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

KLEMA FLORIDA INTERNATIONAL L.L.C. ____________________________________________________ SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 KLEMA FLORIDA INTERNATIONAL L.L.C. ____________________________________________________ SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 (November 11, 2010) To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, KLEMA FLORIDA INTERNATIONAL L.L.C. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description, model name) FCC ID: YYYKLEMA-675 Product name: REMOTE CONTROL Model: KLEMA-675 We affirm that between SIEMIC and KLEMA FLORIDA INTERNATIONAL L.L.C., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature LUIS SIMON MARTINEZ / President Title: PRESIDENT Telephone: 1-305-626-9009 Email: [email protected] Date: November 11, 2010

To p Vi e w Bottom View Front View Left View Rear View Right View

FCC ID: YYYKLEMA-675

Label Location

Top View Bottom View ANTENNA

Circuit Description Transmitter(R219): When the button is pressing , SAW resonator (S1) resonates at 315MHz, while the encoder U1 will send out serial data include the address of the transmitter to modulate the 315MHz signal at Q1, the signal is send by the antenna. Product Specification Transmitter(R219): Frequency： 315MHz Modulation： ASK Antenna Impedance： 50Ω Antenna Gain： 0dBm TX Power： <6dBm Standby current： <1uA Operation current <10mA

1234 A B C D 4321 D C B A SHENZHEN CARSKY ELECTRONIC TECHNOLOY CO.,LTD Model Design Check Approval Rev Date Date Date Note： Q1 R25 C5 103 C4 1P C1 102 R1 100R' K3 K2 K1 K4 R2 68K R3 47K S1 315MHZ + B1 2016*3 R6 10K R4 4.7K R7 3.3M LED1 LED A0R219 315MHZ Q2 L6 C3 4P R10 3.3UH VCC 1 VSS 2 DOUT 3 D3 4 D2 5 D1 6 D0 7 OSC 8 U1 PT2240B PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

Shenzhen Certification Technologh Service Co., Ltd 3F, Bldg27,Area A, Tanglang Industrial Zone, Xili Town, Nanshan District, ShenZhen, Guang dong, P.R. China. FCCID: YYYKLEMA-675 Page 1 of 31 TEST REPORT FCC ID: YYYKLEMA-675 Applicant : KLEMA FLORIDA INTERNATIONAL L.L.C. Address : 4980 NW, 165th Street, Unit 17A, Miami, FL 33014, U.S.A. Equipment under Test (EUT): Name : REMOTE CONTROL Model : KLEMA-675 Standards : FCC PART 15, SUBPART C : 2008 (Section 15.231) Report No. : STE101105865 Date of Test : November 6-9, 2010 Date of Issue : November 10, 2010 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.:STE101105865 FCCID: YYYKLEMA-675 Page 2 of 31 TABLE OF CONTENT Description Page 1 General Information------------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility -----------------------------------------------------------------------4 2 EMC Equipment List --------------------------------------------------------------------------------- 4 3 Test Procedure ------------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------- 6 Occupied bandwidth -------------------------------------------------------------------------------------- 6 5 Radiation Emission----------------------------------------------------------------------------------- 7 5.1 Duty cycle------------------------------------------------------------------------------------------7 5.2 Radiation Emission Limits(15.209&231)------------------------------------------------- 13 5.3 Test Setup--------------------------------------------------------------------------------------- 13 5.4 Test Procedure--------------------------------------------------------------------------------- 15 5.5 Test Equipment Setting For emission test.est Result--------------------------------- 16 5.6 Test Condition---------------------------------------------------------------------------------- 16 5.7 Test Result-------------------------------------------------------------------------------------- 16 6 Occupied bandwidth -------------------------------------------------------------------------------- 20 6.1 Test limit------------------------------------------------------------------------------------------ 20 6.2 Method of measurement--------------------------------------------------------------------- 20 6.3 Test Setup--------------------------------------------------------------------------------------- 20 6.4 Test Results------------------------------------------------------------------------------------- 20 7 Transmission time ----------------------------------------------------------------------------------- 22 7.1 Test limit------------------------------------------------------------------------------------------ 22 7.2 Method of measurement--------------------------------------------------------------------- 22 7.3 Test Setup--------------------------------------------------------------------------------------- 22 7.4 Test Results------------------------------------------------------------------------------------- 22 8 Band Edge Check------------------------------------------------------------------------------------ 24 8.1 Test limit------------------------------------------------------------------------------------------ 24 Please refer section15.231 and section 15.205.----------------------------------------------- 24 8.2 Test Procedure--------------------------------------------------------------------------------- 24 8.3 Test Setup--------------------------------------------------------------------------------------- 24 8.4 Test Result-------------------------------------------------------------------------------------- 24 9 Antenna Requirement ------------------------------------------------------------------------------ 25 9.1 Standard Requirement----------------------------------------------------------------------- 25 9.2 Antenna Connected Construction---------------------------------------------------------- 25 9.3 Result--------------------------------------------------------------------------------------------- 25 10 Photographs of Test Setup ----------------------------------------------------------------------- 26 11 Photographs of EUT--------------------------------------------------------------------------------- 28 Report No.:STE101105865 FCCID: YYYKLEMA-675 Page 3 of 31 1 General Information 1.1 Description of Device (EUT) Trade Name : KLEMA EUT : REMOTE CONTROL Model No. : KLEMA-675 Type of Antenna : Integral Antenna Operation Frequency : 315 MHZ Channel number : 1 Modulation type : ASK Power Supply : DC 9V Supply by battery Rated PF output Power 78.52 dBuV (PK detector) Applicant : KLEMA FLORIDA INTERNATIONAL L.L.C. Address : 4980 NW, 165th Street, Unit 17A, Miami, FL 33014, U.S.A. Manufacturer : SHENZHEN CARSKY ELETRONIC TECHNOLOGY CO,LTD Address : C12 Fuyuan Industrial Zone Xixiang Baoan Shenzhen China Report No.:STE101105865 FCCID: YYYKLEMA-675 Page 4 of 31 1.2 Description of Test Facility Shenzhen Certification …

Text truncated - open the document above for the full version.

Report No.:STE101105865 FCCID: YYYKLEMA-675 Page 26 of 31 10 Photographs of Test Setup Photographs-Radiated Emission Test Setup in Chamber Below 1G test setup photo Report No.:STE101105865 FCCID: YYYKLEMA-675 Page 27 of 31 Above 1G test setup photo
