YZ500000002WIRELESS N150 PCI-E ADAPTER

© 2010 Encore Electronics, Inc. All rights reserved.COVER © 2010 Encore Electronics, Inc. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders. 1 www.encore-usa.com TABLE OF CONTENTS CHAPTER 1: OVERVIEW ...................................................................... 3 1.1 PRODUCT OVERVIEW.......................................................... 3 1.2 LED INDICATOR.................................................................. 4 1.3 PACKAGE CONTENTS.......................................................... 4 1.4 SYSTEM REQUIREMENTS..................................................... 4 CHAPTER 2: INSTALLATION................................................................ 5 2.1 HARDWARE INSTALLATION................................................... 5 2.2 SOFTWARE INSTALLATION.................................................... 6 2.2.1 Windows ® 7 and Windows Vista ® ..................................... 6 2.2.2 Windows ® XP ................................................................... 9 2.3 REMOVING THE ENEWI-2XN4X OR ENEWI-1XN4X SOFTWARE ....................................................................... 12 2.4 UPGRADING THE ENEWI-2XN4X OR ENEWI-1XN4X SOFTWARE ....................................................................... 12 CHAPTER 3: CONNECTING TO WIRELESS NETWORKS IN WINDOWS 7 ® ................................................................. 13 CHAPTER 4: CONNECTING TO WIRELESS NETWORKS IN WINDOWS VISTA ® ........................................................ 15 CHAPTER 5: CONNECTING TO WIRELESS NETWORKS IN WINDOWS ® XP .............................................................. 17 CHAPTER 6: TECHNICAL SUPPORT ................................................ 20 CHAPTER 7: WARRANTY INFORMATION......................................... 20 APPENDIX A. WIRELESS SECURITY OVERVIEW ............................. 21 A1. WEP, WPA AND WPA2 COMPARISON................................ 21 www.encore-usa.com 2 A2. WEP / WPA / WPA2 802.1X ............................................ 21 A3. ENABLING 802.1X IN WINDOWS ® ....................................... 22 APPENDIX B. USING ENCORE WIRELESS MANAGER IN WINDOWS XP ® ................................................................................. 23 B1. STARTIN G ENCORE WIRELESS MANAGER........................... 23 B2. ENCORE WIRELESS MANAGER OVERVIEW......................... 24 B3. MANUAL CONNECTION...................................................... 26 B4. EASY CONNECTION WITH WPS ......................................... 27 B4.1. WPS — PBC (Push Button Configuration)..................... 28 B4.2. WPS — PIN (Personal Information Number) ................. 29 B5. USING 802.1X.................................................................. 32 APPENDIX C. CONNECTING TO WIRELESS NETWORKS WITH WIRELESS ZERO CONNECTION IN WINDOWS XP ® .33 APPENDIX D. SPECIFICATIONS.......................................................... 35 APPENDIX E. REGULATORY INFORMATION..................................... 37 E1. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT...................................................................... 37 E2. EUROPE – EU DECLARATION OF CONFORMITY................... 38 APPENDIX F. SOFTWARE END USER LICENSE AGREEMENT....... 40 APPENDIX G. USER’S NOTICE............................................................ 42 Product specifications, size, and shape are sub ject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective ho lders. © 2010 Encore Electronics, Inc. All rights reserved. 3 www.encore-usa.com Chapter 1: Overview Thank you for choosing Encore Electronics’ Wireless N300/N150 PCI-E Adapter. With just a fe w steps, you will be enjoying the convenience of wireless networking at the speed that is much faster than the prior Wireless G technology. Place the desktop computer at any place you want to avoid the hassle and unsightly view of wires. Moreover, ENEWI-2XN4x and ENEWI-1XN4x support Wi-Fi Protected Access (WPA/WPA2) data encryption to help protect your data and privacy. With Encore Electronics’ Wireless N300/N150 PCI-E Adapter, you can smoothly browse websites, play games, stream video, make phone calls and download files over the Internet. You also can easily share files with other users and access peripherals, such as network drives, printers and cameras, in your home or office networks. 1.1 Product Overview A. x1 PCI-E Connector B. Detachable, External Antennas* C. Antenna Connectors D. Activity LED (Green) Note: * N300 Ser ies come with two antennas and N150 Series come with one antenna. The antennas shown in the picture on the right are 5dBi antennas. Adapters with other type of antennas are also available. www.encore-usa.com 4 1.2 LED Indicator The Activity LED will be blinking when:  The adapter is scanning for available wireless networks.  The adapter is transferring and/or receiving data. 1.3 Package Contents N300 Series (ENEWI-2XN 4x)  Wireless N3 00 PCI-E Adapter x 1  Detachable, External Antennas* x 2  Quick Installation Guide x 1  Installation CD (User Manual on CD) x 1 N150 Series (ENEWI-1XN 4x)  Wireless N1 50 PCI-E Adapter x 1  Detachable, External Antennas* x 1  Quick Installation Guide x 1  Installation CD (User Manual on CD) x 1 Note: * The antennas shown on the front cover are 5dBi antennas. Other type of antennas, such as 2dBi and 3dBi antennas, are also available. 1.4 System Requirements  Available PCI-E slot  Operating System: Windows ® 7, Windows Vista ® or Windows ® XP  CD-ROM Drive 5 www.encore-usa.com Chapter 2: Installation 2.1 Hardware Installation 1. Shut down your computer and disconnect your computer’s power cord. 2. Open the case of your computer. 3. Locate an empt…

Text truncated - open the document above for the full version.

55 44 33 22 11 D D C C B B A A RTL8192CE (2T2R)RTL8188RE (1T1R) ANT1ANT2 XTAL 40MHz TX/RXmatchingcircuit 3.3V 1.5V 1.2V PCIEconnector TX/RXmatchingcircuit For 2T2R only Schematic of ENDB-ERL8192CE 0B BLOCK DIAGRAM A 2 3 Sunday, September 12, 2010 ENDB-ERL8192CE Model Size Document Number Rev Date: Sheet of Title Drawn By Encore Electronics Inc.

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EUT View 3 Short Antenna (Gain: 2dBi) ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 Long Antenna (Gain: 5dBi)

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: YZ500000002 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EXHIBIT 1- PRODUCT LABELING Proposed FCC ID Label Format FCC ID: YZ500000002 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Specifications : Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS Solder Board-Component View 1 Solder Board-Component View 2 ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 Antenna Connector View

Circuit Description XTAL1 the 40 MHz crystal oscillator provides the base clock source of U3 Wireless LAN network interface controller’s operating. U3 drives reference differential clock for modulator and demodulator of embedded RF transceiver. U3 combines a MAC and 1T1R capable baseband and includes a USB interface for host connection. Embedded RF transceiver consists of one receivers and one transmitters used to form a complete 2.4GHz ISM band Wireless LAN application. Antenna, Ground, and Power Source There is one external 2412MHz to 2462MHz band on-board antenna. Besides Print circuit board provides copper plane ground, host provides a reference grounding connecting by USB interface. Whole system power source is fed with DC 5Volt by USB interface.

1. MAXIMUM PERMISSIBLE EXPOSURE (MPE) 1.1 Standard Applicable According to §1.1307(b)(1), system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. (a) Limits for Occupational / Controlled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 / / F/300 6 1500-100000 / / 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-100000 / / 1 30 Note: f = frequency in MHz: * = Plane-wave equivalents power density 1.2 MPE Calculation Method S = (30*P*G) / (377*R 2 ) S = power density (in appropriate units, e.g., mw/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mw) G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor is normally numeric gain. R = distance to the center of radiation of the antenna (in appropriate units, e.g., cm) 1.3 MPE Calculation Result Maximum peak output power at antenna input terminal: 6.8(dBm) Maximum peak output power at antenna input terminal: 4.7863(mW) Prediction distance: >20 (cm) Prediction frequency: 2412 (MHz) Antenna gain (max.): 5 (dBi) Antenna gain (max.): 3.1623 (numeric) The worst case is power density at prediction frequency at 20cm: 0.0030112 (mw/cm 2 ) MPE limit for general population exposure at prediction frequency: 1 (mw/cm 2 ) 0.0030112 (mw/cm 2 ) < 1 (mw/cm 2 ) Result: Pass

55 44 33 22 11 D D C C B B A A C25,C21 closeto RTL8192CE RF PATH B RF PATH A Input Output Xtal Output WLANLED RF 50 ohms trace These components inside ofpink color line region areremoved for 1T1R option 1.2V Trace 1.5V Trace Choose X2 Crystal40MHz DIP , C44=27pF,C43=33pF B18 Top view A18 B1 Input in PC side A12 screw hole for breaket B11 A1 Output in PC side A11 B12 Opical point (for manufacture) Schematic of ENDB-ERL8192CE 0B BLOCK DIAGRAM C 3 3 Sunday, September 12, 2010 ENDB-ERL8192CE Model Size Document Number Rev Date: Sheet of Title Drawn By Encore Electronics Inc. HSOP_E VDD15D XI VDD15D XO_1 XI CLKREQ# LED_WLAN# DVDD3.3PCIE DVDD3.3 HSON_E WAKE# DVDD3.3 DVDD3.3R XI_1 XI_1 DVDD3.3A PAVCC0 PAVCC0 XO_1 VD15R1 CLK- LED_WLAN# DVDD3.3-1 CLK+ VD15R0 PAVCC1 DVDD3.3-1 DVDD3.3-1 HSIN HSOP_E PERSTB XO DVDD3.3R DVDD3.3PCIE HSOP_C DVDD3.3B PAVCC1 DVDD3.3B DVDD3.3A HSON_E XO HSIP HSON_C HSIPPRSNT HSOP_C WAKE#VCC33 VCC33HSON_CCLK+VCC33PRSNTPERSTB HSIN CLK- DVDD3.3-1 VCC33 VCC33 R230 R1 330 C411uF TP9 C4418pF R24 1nH C371nF TP1 L142.2nH C91.5pF H5SHIELD 1234 C520.1uF C141.5pF X2 40MHz DIP Crystal C6822pF C48 0.1uF C510uF(0805) R160 C601uF 12 H2 2 3 4 5 6 7 8 9 1 L22 0(0603) 1 2 R36 0 C621uF R21 0 C15 NC R4 Bead(0402) C6322pF C4610pF C2622pF L122.7nH C59NC C49NC R43 10K C122pF C131.2pF C3810pF C71.2pF C421uF C221nF R29 0 C241uF TP2 L8NC C640.6pF R39 1nH C6610pF C77NC L1610nH L9 0 R32 0 TP3 C2822pF L23 0(0603) 1 2 R44NC C74NC 12 TP4 LED1 LED/GREEN 1 2 C390.1uF C19NC C181uF H1 2 3 4 5 6 7 8 9 1 C21 0.1uF R55 NC R30 0 C5422pF C4318pF C47 0.6pF L42.7nH R25NC L72.7nH C75NC 12 L1710nH C1722pF R220 C6 1uF C51 10uF(0805) GFB1 PCI_1X 123456789 101112131415161718 12V_312V_4RSVD1GNDSMCLKSMDATGND3.3VTRST#33VAXWAKE#RSVD2GNDTp0Tn0GNDPRSNT2#GND C321.5pF L24 0(0603) 1 2 C361.5pF TP8 C23NC C111.5pF C12 NC R70 L10NC L138.2nH R1724K C351.2pF TP7 C81nF C222uF(X5R) C76NC C5522pF L152.7nH C271uF L310nH GFA1 PCI_1X 123456789101112131415161718 PRSNT1# 12V_112V_2 GND TCK TDI TDO TMS 3.3V3.3V PERST# GND REFCLK+ REFCLK- GND Rp0Rn0 GND TP6 C29 0.1uF R27NC R35 0 C331.5pF C7322pF L58.2nH L62.2nH C401uF ANT1 SMA CONNECTOR 1 2 3 4 5 C101uF R54 NC TP5 C500.1uF C16 NC C2022pF R37 10K R28NC C31uF C410pF C30NC C311.2pF C34NC R40 10K X1NC/40MHz SMD 14 32 XTALPGND XTALP GND R4210K RTL8192CE U1 173130292322202119182632 33 34 36 35 37 38 39 40 41 42 43 44 57 1 47 48 544950515356555263615859606264 45 46 2 4 5 6 7 3 8 16 9 10 11 12 13 14 15 65 27282425 PAPE[0]TX2G_PAON[1]TX2G_PAOP[1]RX2G_IP[1]RX2G_IP[0]VD15R[0]TX2G_PAON[0]TX2G_PAOP[0]VD33PA[0]TRSWP[0]VD15R[1]VD33PA[1] TRSWP[1] TRSWN[1] LED1 / ANT_SEL_N LED0 / ANT_SWL_P VD33A RETX VD15A VD12A_LDO XI XO CK_BT_40M NC REFCLK_N V33PCIe BT_STATE BT_PRI VD15D PDn WAKEn CLKREQn VD12D_LDO HSOP HSON PERSTn HSDP GNDS REFCLK_P HSIN HSIP VD12S_LDO HSDM WL_ACT WL_RX / B15V_VLD ANT_SEL_P / LED2 TRSWN[0] / LED2 VD33IO VDSPS33 LX_SPS0 ANT_SEL_N GND_SPS0 TSSI_0 VD12D_LDO BT_Suspend GPIO[5] EEDO EEDI EESK EECS GND VD33RRX2G_IN[1]RX2G_IN[0]PAPE[1] C25 0.1uF C4510uF(0805) L210nH C7122pF ANT2 SMA CONNECTOR 1 2 3 4 5 R5Bead(0402) C6122pF C580.1uF L16.8uH

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I PAGE 1 OF 79 FCC PART 15.247 FCC Part 15C Measurement and Test Report For ENCORE ELECTRONICS INC. 16483 Old Valley Blvd., La Puente, CA 91744, USA FCC ID: YZ500000002 Report Concerns: Original Report Equipment Type: Wireless N150 PCI-E Adapter Model: ENEWI-1XN45 Report No.: STR11018113I Test Date: 2011-01-15 to 2011-02-28 Issue Date: 2011-03-08 Tested By: Galy He / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so/PSQ Manager Prepared By: SEM.Test Compliance Service Co., Ltd 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by SEM.Test Compliance Service Co., Ltd . ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I PAGE 2 OF 79 FCC PART 15.247 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)...............................................................................3 1.2 TEST STANDARDS...................................................................................................................................................3 1.3 TEST METHODOLOGY.............................................................................................................................................4 1.4 TEST FACILITY.......................................................................................................................................................4 1.5 EUT EXERCISE SOFTWARE....................................................................................................................................4 1.6 ACCESSORIES EQUIPMENT LIST AND DETAILS.......................................................................................................4 1.7 EUT CABLE LIST AND DETAILS.............................................................................................................................4 2. SUMMARY OF TEST RESULTS ...........................................................................................................................5 3. CONDUCTED EMISSIONS ....................................................................................................................................6 3.1 MEASUREMENT UNCERTAINTY..............................................................................................................................6 3.2 TEST EQUIPMENT LIST AND DETAILS.....................................................................................................................6 3.3 TEST PROCEDURE...................................................................................................................................................6 3.4 BASIC TEST SETUP BLOCK DIAGRAM.....................................................................................................................6 3.5 ENVIRONMENTAL CONDITIONS..............................................................................................................................7 3.6 SUMMARY OF TEST RESULTS/PLOTS......................................................................................................................7 3.7 CONDUCTED EMISSIONS TEST DATA......................................................................................................................7 4. §15.203 - ANTENNA REQUIREMENT................................................................................................................10 4.1 STANDARD APPLICABLE.......................................................................................................................................10 4.2 TEST RESULT........................................................................................................................................................10 5. POWER SPECTRAL DENSITY ...........................................................................................................................11 5.1 STANDARD APPLICABLE.......................................................................................................................................11 5.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................11 5.3 TEST PROCEDURE.................................................................................................................................................11 5.4 ENVIRONMENTAL CONDITIONS............................................................................................................................11 5.5 SUMMARY OF TEST RESULTS/PLOTS....................................................................................................................12 6. 6-DB BANDWIDTH ................................................................................................................................................19 6.1 STANDARD APPLICABLE.......................................................................................................................................19 6.2 TEST EQUIPMENT LIST AND DETAILS...................................................................................................................19 6.3 TEST PROCEDURE.................................................................................................................................................19 6.4 ENVIRONMENTAL CONDITIONS............................................................................................................................19 6.5 SUMMARY OF TEST RESULTS/PLOTS.....................................................…

Text truncated - open the document above for the full version.

ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (30MHz to 1GHz) ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 Radiation Emission Test Setup (Above 1GHz) Test Setup View Rear ENCORE ELECTRONICS INC. Model: ENEWI-1XN45 REPORT NO.: STR11018113I FCC PART 15.247 Test Setup View Inside
